CALMPER BM600 User manual

CALMPER
T H E D R E A M B U I L D E R
Model: BM600
User Manual
Baby Monitor

Please don't hesitate to contact us for any
issues or concerns you may have, we are
happy to help.
https://www.calmper.net/register
SCAN NOW!
Register Warranty
and Contact Us.
Customer Support:
[email protected]
[email protected]
Warranty Register:

SAFETY INSTRUCTIONS
1
COMPONENTS
3
WHAT'S IN THE BOX
2
QUICK SETUP
4
SETTINGS & OPERATIONS
5
TROUBLESHOOTING
12
SPECIFICATIONS
11
WARRANTY & CUSTOMER SERVICE
13
TABLE
OF CONTENTS

WARNING:
Adult assemble required. Keep small parts away from children when assembling.
STRANGULATION HAZARD - Keep cord out of baby's reach.
- NEVER place camera or cords within 1m of cot or playpen.
- NEVER mount the camera directly above cot or playpen to
avoid the risk of injury
WARNING:
Caution:
NOT toys. Do not allow children to play with the product.
This product is NOT intended to replace the proper supervision
of children. You MUST check your child's safety regularly.
This product is not intended for use as a medical camera and its
use should not replace adult supervision.
For indoor use only.
Safety Instructions
Please only use the provided chargers.
Never use the product near water, including, but not limited to,
bathtub, sink, swimming pool, etc.
Do not install near any heat sources such as radiators, heat
registers, stoves, or other devices that produce heat.
Only use child safe attachments and accessories.
Disconnect both monitor and camera if unused for long periods
of time.
For your and your baby's safety:
1

Unplug the product during lightning storms.
Please check the product condition and safety at initial
installation, and on a regular basis.
Please check the reception regularly, especially after relocation
the camera.
Please only use dry microfiber cleaning cloth on the camera
lens.
Allow 10cm of air space around the product for ventilation.
Please keep the monitor 1 meter (3 feet) apart from the camera
to avoid feedback sound, you won't want to disturb a sleeping
baby.
User
Manual
Display Unit
1 Display Unit Charger
User Manual
Camera
1 Camera Unit Charger
2
What's In The Box

Components
Display Unit
Microphone
Reset Key
Talk Button
Menu Button
Power Charging Indicator
OK Button
Volume Buttons(Left&Right) /
Brightness Buttons(Up&Down) /
Menu Navigation Buttons
Signal Antenna
Back Stand
Power On/Off Button
USB-C Charging Port
3
Speaker

IR Light Sensor
Camera Lens
Indicator Light
Microphone
Infrared Light
microSD Card Slot
USB-C Power Input Port
Speaker
Pairing Button
Thermometer
Camera
Quick Setup
Connect the camera to the power point using the provided
charger. Wait about 2 seconds or until the Power Indicator
turns on, the camera will start to work.
Make sure the display unit is fully charged before use for the first
time.
Long Press the Power Button to turn on the display unit.
Confirm the connection is established by checking the signal
bars, the picture will show on the display unit.
1.
2.
3.
4.
4

Signal Levels (5 Levels)
No Signal
Camera 1
Camera 2
Camera Switch Mode
Zoom In (x10)
Lullaby
Volume Levels (6 Levels)
Night Vision Mode
VOX Mode (High, Medium and Low)
Camera Unit Room Temperature
System Time
Keyboard Click Sound Switch
Battery Levels
Intercom Mode
microSD Card Recognised
x
x
Settings & Operations
Top Status Dock
5
x10 VOX
VOX
x10

Volume Settings
Feeding Reminder
Play Lullaby
System Time Setting
Temperature Unit Setting
Temperature Alarm On/Off
Camera Selection
VOX Mode On/Off
Sound Sensitivity Setting
Camera Zoon In/Out
x10
Display Unit Menu Icons
6

Warranty
@ CALMPER All rights reserved.
www.calmper.net
Register: calmper
Contact Us
www.calmper
.net/register
E-mail: support@calmper
.net/contact-us
.net
CALMPER
T H E D R E A M B U I L D E R
Policy: calmper .net/warranty

Turn On VOX Mode: Press the Menu button -> Select ______
from the menu -> select "HIGH" / "MED" / "LOW" ->Press OK
Button to confirm. When enabled, the icon appears in the
Top Status Dock. The video and audio will be turned off in 30 sec.
Then, be both turns back on by a detected sound that's louder
than the configured threshold.
M
Turn Off VOX Mode: Press the Menu button -> select ______
from the menu -> select "OFF" ->Press OK to turn it off.
Press the Power button to turn off the display.
Double check the sound by putting your ear close to the
speaker at the back of the display unit.
1.
2.
3.
To make a selection, use Buttons to navigate up / down / left
/right in the menu, and click on OK button to confirm.
Long press the Power Button at the right edge side, to turn on
or turn off the display unit.
Press the Menu Button to show the menu at the bottom row
on the display. Press it again to hide the menu.
M
Volume: Press Right or Left Arrow button to turn the
volume up or down.
Brightness: Press Up or Down Arrow button to brighten or
dim the display.
Enable Auto Screen-On Sleep Mode
7
Operations
Turn off Display & Allow Audio Only
Turn Display Unit On and Off
Adjust Volume and Brightness
Show / Hide Menu Settings

Press and hold the Microphone button to talk to your baby,
release it to exit the intercom mode.
Please note: You will not hear any sound until the release of
Microphone button.
Press Menu Button -> select -> press OK button to zoom
in. The icon will appear in the top status bar to confirm the
zoom in is active.
M
x10
Press Menu Button -> select -> pick the desired song ->
press OK Button to play. The icon will appear in the Top
Status Dock to confirm playing.
M
Press Menu Button -> select -> select "OFF" or your
desired timer durations -> press OK Button to confirm. When the
timer is on, the icon will appear in the Top Status Dock.
M
Select -> press OK Button to turn off temperature
alarm.
Select -> press OK Button to turn on temperature
alarm. Alarm goes off if room temperature is above or below
of the range 20°C ~ 30°C.
Select °C / °F -> press OK Button to set temperature unit.
Press Menu Button -> select
M
8
Adjust View Angle
This can be done by manually adjusting the camera's position.
Talk To Your Baby
Zoom In & Out
Play Lullaby
Feeding Reminder
Temperature Settings

The signal alert is enabled by default, and can not be turned off. It
goes off, when signal lost for 5 seconds, making beep sound for 5
times. Meanwhile, the signal lost icon will be
displayed on the screen and keeps flashing after the 5 beeping
sound.
The Battery alert is also enabled by default, and can not be
turned off. In the Top Status Dock, the battery icon
indicates the current battery level.
The alert goes off , when the battery level is low and need
recharge. The icon appears and prompt "LOW BATTERY"
message on the screen. Meanwhile, it makes 5 alerting beep
sounds.
Insert MicroSD Card: Put a compatible card into the card slot
on camera. The icon appears in the Top Status Dock, that
indicates the card is ready for recording.
Start Recording: On the display unit, long press OK Button for
2 seconds until the icon flashes on the screen.
Stop Recording: Long press OK Button for another 2 seconds,
to exit recording mode.
Play Recorded Videos: Take out the microSD card from the
camera and play on a computer with a card reader.
Signal Alert
9
Battery Alert
Note: To avoid interference from other electronic devices, place
your baby monitor at least 1 meter(3 feet) away from devices such
as wireless routers, microwaves, cell phones, computers or other
baby monitors.
Video Recording
Recording Now.
Please quit

Press Menu Button -> select -> select -> select
available camera slot -> press OK Button to confirm -> a
message will display on the screen . The
display unit paring mode times out in 30 seconds.
Connect the new camera to power and keep it within 1 meter
from the display unit. Press and hold the pairing key for 3
seconds until the indicator light flash quickly. The camera is
now in pairing mode. Once it's connected with the display unit,
the indicator light will stay on. The camera's pairing mode
times out in 60 seconds.
1.
2.
M
Keep pressing the button of the
camera for three seconds to pair
2
Press Menu Button -> select -> select -> select
active camera slot -> press OK Button -> select to
confirm deletion, or to cancel the action. The red square is
gone once confirmed deletion .
M
2
2
2
Long press the Menu Button for 5 seconds, until the icon
is displayed in the Top Status Dock. Long press for another 5
seconds, to turn it off.
M
Note: The red square next to a camera slot, means that slot is
already token by a connected camera.
Add A Camera
*
*
Available slot
Unavailable slot
Delete A Camera
Turn On Buttons Click Sound
Press the Menu Button -> select -> select -> select
the desired option: is to view camera 1, is to view
camera 2, is to automatically switch between camera 1 and 2.
Switch Between 2 Cameras
M
2
10

Camera
Camera Pixel
720p ( 1280 * 720p )
Image Sensor
1/4 CMOS Sensor
Transmission Method
2.4GHz FHSS
Transmission Distance
300 Meters (Open Space)
View Angle
60° Degree
Pan-n-Tilt
Manual Rotation: 360° Horizontal / 120°
Vertical
Power Consumption
1.5W
Working Temperature
-20°C ~ 65°C / -4°F ~ 149°F
Size / Weight
66 * 109 mm / 60 grams
Specifications
11
Monitor
Monitor Screen
3.5-inch IPS Colour Display (480 * 320p)
Battery
1500 mAh
Power Consumption
1.6W
Working Temperature
-20°C ~ 65°C / -4°F ~ 149°F
Size / Weight
133 * 76 * 20 mm / 110 grams
Features
VOX, Infrared Night Vision, Lullaby Player, Feeding Reminder,
High/Low Temperature Alert, Poor Signal Alert, Low Battery Alert
and more.

The display unit
doesn't turn on
Refer to "Turn Display Unit On and Off" on
page 7
Weak or no signal
Restart the display unit, and pull out the
antenna.
Test the signal in another location.
Keep it away from other 2.4GHz products,
like WIFI Routers, Microwave ovens and
other baby monitors, which may interfere
with the connection.
Re-pairing, follow the Operations guide to
Delete the camera and add it back on
page 10.
No sound?
Check the volume settings on the monitor,
making sure it is not on mute.
Image is in black
and white?
Night Vision makes picture appears as black
and white, when the light sensor detects
enough light, it will switch back to full colour.
Can't connect to
the WIFI?
This model doesn't connect to WIFI. The
image only runs on the display unit.
The product
doesn't charge or
takes too long?
Confirm the power point in working order.
Make sure to use the provided charger.
There's no video
on the display
unit?
Confirm the camera has been connected
to power, and the power indicator is on.
Follow the troubleshooting guide to re-
pair the camera with the display unit.
Questions & Answers
12

Under the warranty policy, CALMPER warrants that the product is
free from defects in material and workmanship for a period of 12
months from the date of purchase. Within the warranty, it is at the
discretion of CALMPER to decide whether products under warranty
are repaired or replaced. The warranty does not cover any damage
caused by incorrect mounting, negligent operation, dropping,
impact, misuse, liquid ingress, extreme temperatures or any other
physical damage caused by anything other than normal use etc., or
normal wear and tear.
The protection under this Warranty is provided to the original
purchaser only and is not transferable to any subsequent owner
who acquires the product.
Background noise
from the speaker
A bit of noise that comes from the speaker,
is normal for all baby monitors.
Temperature is
inaccurate
After you relocated the camera, please give
it up to 30min, before read the
temperature.
13
Please don't hesitate to contact us if you need more help.
Please register your product for warranty support:
https://calmper.net/register
https://calmper.com.au/register
Warranty & Customer Service
Find more details about warranty, our products and contact us at
https://www.calmper.net/warranty
https://www.calmper.net/contact-us
[email protected]
[email protected]

Purchase Date:
Order Number:
