Calphalon TSCLTRDG1-AF User manual

1
INSTRUCTION MANUAL
PERFORMANCE AIR FRY
COUNTERTOP OVEN
MODEL: TSCLTRDG1-AF & TSCLTRDG2-AF PN 202688
TSCLTRDG1-AF_TSCLTRDG2-AF_20EM1.indd 1TSCLTRDG1-AF_TSCLTRDG2-AF_20EM1.indd 1 4/8/20 10:024/8/20 10:02

TABLE OF CONTENTS
IMPORTANT SAFEGUARDS 3
POLARIZED PLUG 4
PRODUCT DIAGRAM 5
LCD DISPLAY 5
USAGE INSTRUCTIONS
PREPARING YOUR COUNTERTOP OVEN 6
OVEN FUNCTIONS OVERVIEW 6
HOW TO USE YOUR COUNTERTOP OVEN 7
COOKING FUNCTIONS DETAILS 8
CLEANING & MAINTENANCE 14
TROUBLESHOOTING 15
WARRANTY 16
TSCLTRDG1-AF_TSCLTRDG2-AF_20EM1.indd 2TSCLTRDG1-AF_TSCLTRDG2-AF_20EM1.indd 2 4/8/20 10:024/8/20 10:02

3
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed, including the following:
1. Read all instructions, product labels and warnings before using Performance Air Fry countertop oven.
2. This appliance generates heat during use. Do not touch hot surfaces. Use handles or knobs. Always
protect your hands with non-slip oven mitts or similar.
3. To protect against electric shock, do not place or immerse cord, plugs, or appliance in water or other liquid.
4. This appliance is not to be used by children or by persons with reduced physical, sensory or mental
capabilities.
5. Close supervision is necessary when any appliance is used near children. Children should not play with
the appliance.
6. Unplug from outlet when not in use, before putting on or taking o parts and before cleaning. Allow to
cool before putting on or taking o parts, and before cleaning. To disconnect, turn any control to OFF,
then unplug power cord from outlet. Do not disconnect by pulling on cord. Always grasp the plug and
pull to disconnect.
7. Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions, or has
been damaged in any manner. Do not attempt to replace or splice a damaged cord. Return appliance to
the manufacturer (see warranty) for examination, repair or adjustment.
8. The use of accessory attachments not recommended by the appliance manufacturer may cause injuries.
9. Do not use outdoors or for commercial purposes.
10. Do not let cord hang over edge of table or counter, or touch hot surfaces.
11. Do not place on or near wet surfaces, or heat sources such as a hot gas or electric burner, or in a heated
oven.
12. Extreme caution must be used when moving an appliance or removing a pan, containing hot oil or other
hot liquids. Always protect your hands with non-slip oven mitts or similar.
13. Do not use appliance for other than intended use. Misuse can cause injuries. Intended for household
countertop use only. Keep 6 inches (152 mm) clear from the wall and on all sides. Always use appliance
on a dry, stable, level surface.
14. Oversize foods or metal utensils must not be inserted in the countertop oven as they may create a fire
or risk of electric shock.
15. A fire may occur if the countertop oven is covered, touching or near flammable materials, including
curtains, draperies, towels, walls, and the like, when in operation. Do not store any item on top of the
appliance when in operation.
16. Do not clean with metal scouring pads. Pieces can break o the pad and touch electrical parts, creating
a risk of electric shock.
17. Extreme caution should be exercised when using containers constructed of materials other than metal
or glass.
18. Do not store any materials, other than manufacturers recommended accessories, in this oven when not
in use.
19. Do not place any of the following materials in the oven: paper, cardboard, plastic, or any materials that
may catch fire or melt.
TSCLTRDG1-AF_TSCLTRDG2-AF_20EM1.indd 3TSCLTRDG1-AF_TSCLTRDG2-AF_20EM1.indd 3 4/8/20 10:024/8/20 10:02

4
POWER CORD INSTRUCTIONS
A short power-supply cord or detachable power-supply cord is provided to reduce risks resulting from
becoming entangled in or tripping over a longer cord. Longer detachable power-supply cords or extension
cords are available and may be used if care is exercised in their use. If a long detachable power-supply
cord or extension cord is used:
• The marked electrical rating of the cord set or extension cord should be at least as great as the
electrical rating of the appliance;
• The cord should be arranged so that it will not drape over the countertop or tabletop where it can be
pulled on by children or tripped over unintentionally; and
• If the appliance is of the grounded type, the cord set or extension cord should be a grounding-type
3-wire cord. Do not pull, twist or otherwise abuse the power cord.
NOTICES
• Some countertop and table surfaces are not designed to withstand the prolonged heat generated by
certain appliances. Do not set the heated unit on a finished wood table. We recommend placing a hot
pad or trivet under your countertop oven to prevent possible damage to the surface.
• During initial use of this appliance, some slight smoke and/or odor may be detected. This is normal
with many heating appliances and will not recur after a few uses.
POLARIZED PLUG
This appliance has a polarized plug, (one blade is wider than the
other). As a safety feature to reduce the risk of electrical shock, this
plug is intended to fit in a polarized outlet only one way. If the plug
does not fit fully in the outlet, reverse the plug. If it still does not fit,
contact a qualified electrician. Do not attempt to defeat this safety feature or modify the plug
in any way. If the plug fits loosely into the AC outlet or if the AC outlet feels warm do not use
that outlet.
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY
20. Do not cover crumb tray or any part of the oven with metal foil. This will cause overheating of the oven.
21. Empty the crumb tray after each use.
22. The glass door is made of tempered glass. Always inspect the glass door for chips, cracks or any other
damage. Do not use the countertop oven if the glass door is damaged, as the glass may shatter during use.
23. If your toaster oven is equipped with a STAY-ON feature, toaster oven will stay ON if knob is turned
counter-clockwise past zero. Exercise caution when using this feature and do not operate unattended
for long periods.
24. Do not use with a programmer, timer, wireless plug adapter or outlet that allows control remotely, or
connect to a circuit that is regularly switched on and o by the utility.
TSCLTRDG1-AF_TSCLTRDG2-AF_20EM1.indd 4TSCLTRDG1-AF_TSCLTRDG2-AF_20EM1.indd 4 4/8/20 10:024/8/20 10:02

5
TOAST
BAGEL
BAKE
AIRFRY
ROAST
PIZZA
BROIL
REHEAT
KEEP WARM
DEFROST
DEHYDRATE
SET SHADE
PREHEATING
SET TEMP
SET TIME
HR:MIN:SEC
PRODUCT DIAGRAM
1. LCD Screen Display
2. Light, Start and Cancel/OFF Buttons
3. Function Selector Dial
4. Turbo Convection Selector Button
5. Time/ Temperature Selector Button
6. Time/ Temperature Control Dial
7. Two Rack Positions
8. *Air Fry Basket / Dehydrate Rack
9. *Baking Pan
10. *Removable Wire Rack
11. *Removable Crumb Tray
12. Interior Light (not shown in image)
*These parts can be replaced on Calphalon.com or
at 1-800-809-7267
LCD DISPLAY
a. Function Options
b. Function Indicator
c. Shade Setting or Temperature Setting
d. Timer
e. Air Fry and Turbo Convection Icon
1
2
3
4
5
7
8
a
d
e
c
b
911
10
6
TSCLTRDG1-AF_TSCLTRDG2-AF_20EM1.indd 5TSCLTRDG1-AF_TSCLTRDG2-AF_20EM1.indd 5 4/8/20 10:024/8/20 10:02

6
PREPARING YOUR COUNTERTOP OVEN
• Remove all packaging before using the Calphalon® Performance Air Fry Oven.
• Wipe Countertop Oven with a damp cloth. DO NOT IMMERSE IN WATER. Make sure to only use mild,
soapy water. Abrasive cleaners, scrubbing brushes and chemical cleaners will damage the coating
on this unit. Dry the unit thoroughly before using.
NOTE: Do not immerse the cord, plug or body of the unit in water.
• Clean accessories. Remove them from packaging and immerse in warm, soapy water and wipe with
soft cloth or sponge. These accessories may also be washed in the top rack of the dishwasher. Dry
thoroughly.
• Select a location for the countertop oven. The location should be in an open area, on a dry, stable,
level surface where the plug will reach an outlet.
• Plug the Countertop Oven into the electrical outlet.
OVEN FUNCTIONS OVERVIEW
Function Rack Position Preheat Range
Toast Upper No Shade 1-7
1:35 mins. – 12:30 mins.
Air Fry Upper No 250°F - 450 °F
Up to 1 hour
Bagel Upper No Shade 1-7
1:35 mins. - 11:00 mins.
Bake Lower Yes 150°F -450°F
Up to 1 hour
Roast Lower Yes 150°F -450°F
Up to 2 hours
Broil Upper No 350°F -450°F
Up to 2 hours
Pizza Upper Yes 150°F -450°F
Up to 1 hour
Reheat Upper/Lower No 150°F -200°F
Up to 1 hour
Keep Warm Upper/Lower No 150°F -450°F
Up to 1 hour
Defrost Upper/Lower Yes 150°F -450°F
Up to 1 hour
Dehydrate Upper Yes 150°F -200°F
Up to 4 hours
TSCLTRDG1-AF_TSCLTRDG2-AF_20EM1.indd 6TSCLTRDG1-AF_TSCLTRDG2-AF_20EM1.indd 6 4/8/20 10:024/8/20 10:02

7
HOW TO USE YOUR COUNTERTOP OVEN
• Once the Calphalon® Performance Air Fry Countertop Oven is plugged in, the LCD screen will
illuminate and the START Button LED light will flash.
• The Function Options will be displayed on the LCD Screen with the Function Indicator on the default
preset TOAST function.
• Turn the Function Selector Dial to select one of the following 11 options: Toast, Bagel, Bake, Air Fry,
Roast, Broil, Pizza, Reheat, Keep Warm, Defrost, and Dehydrate. The Function Indicator will scroll as
the Function Selector Dial is turned.
• Once the desired function has been selected, use the Time/Temperature Control Dial to select the
desired cooking temperature or shade (for TOAST and BAGEL functions). Turn clockwise to increase
and counter-clockwise to decrease.
• Press the START button to begin preheating. PREHEATING will display on the LCD screen. Ensure the
Oven door is closed for preheating. Oven does not preheat for BAGEL and TOAST functions. For these
functions, food items may be placed inside the Oven immediately after pressing the START button.
• Once the Countertop Oven is preheated, it will beep and PREHEATING will disappear from the LCD
screen.
• You may set the timer before the oven begins preheating, during preheating, or once preheating is
complete. Press the Time/ Temperature Selector Button to change the Time/ Temperature Selector
Dial to time selection. Turn dial clockwise to increase cooking time and counter-clockwise to
decrease cooking time. The maximum time setting is 4 hours.
NOTE: TOAST and BAGEL functions automatically select time based on shade setting.
• Once preheating is complete and timer is set, put food into the Countertop Oven, using the Wire
Rack, Baking Pan or Air Fry Basket / Dehydrate Rack. When using the Baking Pan, always place on
top of the Wire Rack.
NOTE: Never place food or accessories directly on the Quartz Heating elements.
• Once food is inside, close the door and press the START button again. The Timer will begin counting
down.
NOTE: When dehydrating or broiling, leave the door open approximately 3 inches from the closed
position (See Figure 1).
• Press the Turbo Convect Button for better air circulation and crispier food
if needed.
• Once the allotted time has expired, the Countertop Oven will beep, and it
will stop heating, but the display will remain lit for a period of time and
then it will time out. You may press Cancel/OFF to turn o the display
before it times out.
• Use pot holders to carefully remove food from the Countertop Oven.
• The LCD screen light will turn o after 90 seconds of inactivity. Press any button to wake up the
appliance.
• Press the Cancel/OFF Button to turn o the Countertop Oven.
Figure 1
TSCLTRDG1-AF_TSCLTRDG2-AF_20EM1.indd 7TSCLTRDG1-AF_TSCLTRDG2-AF_20EM1.indd 7 4/8/20 10:024/8/20 10:02

8
NOTE: For further details on product features and usage instructions, please visit www.calphalon.com.
COOKING FUNCTIONS DETAILS
Toast
For best TOAST results, place wire rack in the upper rack position. This function is ideal for toasting
sliced bread, English muns and frozen waes.
NOTE: For darker toast results, use a higher shade setting.
1. Insert the wire rack into the upper rack position.
2. Place food in the center of the wire rack for more even toasting.
3. Close the countertop oven door.
4. Turn the Function Selector Dial to select the TOAST function. Once the function has been selected,
use the Time/Temperature Control Dial to select the desired shade. Turn the Time/Temperature
Control Dial clockwise to increase shade selection and counter-clockwise to decrease.
5. Press the START button to begin toasting.
6. When toasting cycle is complete, an audible alert will sound.
7. Open countertop oven door fully and remove food carefully with oven mitt.
WARNING: Cooked food can be very hot. Handle with care. Do not leave countertop oven unattended.
Bagel
For optimal results, place wire rack in the upper rack position.
1. Insert the wire rack into the upper rack position.
2. Place food in the center of the wire rack for more even cooking.
3. Close the countertop oven door.
4. Turn the Function Selector Dial to select the BAGEL function. Once the function has been selected,
use the Time/Temperature Control Dial to select the desired shade. Turn the Time/Temperature
Control Dial clockwise to increase shade selection and counter-clockwise to decrease.
5. Press the START button to begin the bagel cycle.
6. When bagel cycle is complete, an audible alert will sound.
7. Open countertop oven door fully and remove food carefully. We recommend using oven mitts or pot
holders when removing food from the countertop oven.
WARNING: Cooked food can be very hot. Handle with care. Do not leave countertop oven unattended.
Bake
For optimal results, place wire rack in the lower rack position.
1. Insert the wire rack into the lower rack position. Note that certain baked goods call for upper rack
placement.
2. Ensure the countertop oven door is closed for preheating.
TSCLTRDG1-AF_TSCLTRDG2-AF_20EM1.indd 8TSCLTRDG1-AF_TSCLTRDG2-AF_20EM1.indd 8 4/8/20 10:024/8/20 10:02

9
3. Turn the Function Selector Dial to select the BAKE function. Once the function has been selected,
use the Time/Temperature Control Dial to select the desired cooking temperature and time. Turn the
Time/Temperature Control Dial clockwise to increase temperature and time and counter-clockwise
to decrease.
4. Press the TURBO CONVECT button for better air circulation and crispier food if needed. The turbo
convection fan will appear on the LCD screen to indicate that Turbo Convection is on. To cancel
convection setting, press the TURBO CONVECT button once more.
5. Press the START button to begin preheating. PREHEATING will appear on the LCD screen.
6. Once preheating is complete, an audible alert will sound. The START button will flash.
7. Carefully place food in the center of the wire rack for more even cooking.
8. Close the countertop oven door.
9. Press the START button to begin the baking cycle.
Note: The timer will not begin until the START button is pressed.
10. When baking cycle is complete, an audible alert will sound.
11. Open countertop oven door fully and remove food carefully. We recommend using oven mitts or pot
holders when removing food from the countertop oven.
WARNING: Cooked food can be very hot. Handle with care. Do not leave countertop oven unattended.
Air Fry
For optimal results, slide the Air Fry Basket into the upper rack position. For foods with high amounts
of fat or grease, it is recommended to place the baking pan below the Air Fry Basket during the cooking
cycle.
1. Place food evenly on the Air Fry Basket in a single layer and leave space between the pieces.
2. Carefully slide the Air Fry Basket into in the upper rack position.
3. Close the Countertop Oven door.
4. Turn the Function Selector Dial to select the Air Fry function. Once the function has been selected,
use the Time/Temperature Control Dial to select the desired cooking temperature and time. Turn the
Time/Temperature Control Dial clockwise to increase temperature and time and counter-clockwise
to decrease.
5. Press the START button to begin the Air Fry cycle.
6. When Air Fry cycle is complete, an audible alert will sound.
7. Open the Countertop Oven door fully and remove food carefully. We recommend using oven mitts or
pot holders when removing food from the Countertop Oven.
WARNING: Cooked food can be very hot. Handle with care. Do not leave the Countertop Oven
unattended.
TSCLTRDG1-AF_TSCLTRDG2-AF_20EM1.indd 9TSCLTRDG1-AF_TSCLTRDG2-AF_20EM1.indd 9 4/8/20 10:024/8/20 10:02

10
Roast
For optimal results, place wire rack in the lower rack position.
1. Insert the wire rack into the lower rack position.
2. Ensure the countertop oven door is closed for preheating.
3. Turn the Function Selector Dial to select the ROAST function. Once the function has been selected,
use the Time/Temperature Control Dial to select the desired cooking temperature and time. Turn the
Time/Temperature Control Dial clockwise to increase temperature and time and counter-clockwise
to decrease.
4. Press the TURBO CONVECT button for better air circulation and crispier food if needed. The turbo
convection fan will appear on the LCD screen to indicate that Turbo Convection is on. To cancel
convection setting, press the TURBO CONVECT button once more.
5. Press the START button to begin preheating. PREHEATING will appear on the LCD screen.
6. Once preheating is complete, an audible alert will sound. The START button will flash.
7. Carefully place food in the center of the wire rack for more even roasting.
8. Close the countertop oven door.
9. Press the START button to begin the roasting cycle.
Note: The timer will not begin until the START button is pressed.
10. When roasting cycle is complete, an audible alert will sound.
11. Open countertop oven door fully and remove food carefully. We recommend using oven mitts or pot
holders when removing food from the countertop oven.
WARNING: Cooked food can be very hot. Handle with care. Do not leave countertop oven unattended.
Broil
For optimal results, place wire rack in the lower rack position.
1. Insert the wire rack into the lower rack position.
2. Ensure the countertop oven door is closed for preheating.
3. Turn the Function Selector Dial to select the BROIL function. Once the function has been selected,
use the Time/Temperature Control Dial to select the desired cooking temperature and time. Turn the
Time/Temperature Control Dial clockwise to increase temperature and time and counter-clockwise
to decrease.
4. Press the TURBO CONVECT button for better air circulation and crispier food if needed. The turbo
convection fan will appear on the LCD screen to indicate that Turbo Convection is on. To cancel
convection setting, press the TURBO CONVECT button once more.
5. Press the START button to begin preheating. PREHEATING will appear on the LCD screen.
6. Once preheating is complete, an audible alert will sound. The START button will flash.
7. Carefully place food in the center of the wire rack for more even roasting.
8. Leave the door open approximately 3 inches from the closed position.
9. Press the START button to begin the broiling cycle.
TSCLTRDG1-AF_TSCLTRDG2-AF_20EM1.indd 10TSCLTRDG1-AF_TSCLTRDG2-AF_20EM1.indd 10 4/8/20 10:024/8/20 10:02

11
Note: The timer will not begin until the START button is pressed.
10. When BROILING cycle is complete, an audible alert will sound.
11. Open countertop oven door fully and remove food carefully. We recommend using oven mitts or pot
holders when removing food from the countertop oven.
WARNING: Cooked food can be very hot. Handle with care. Do not leave countertop oven unattended.
Pizza
For optimal results, place wire rack in the lower rack position.
1. Insert the wire rack into the lower rack position.
2. Ensure the countertop oven door is closed for preheating.
3. Turn the Function Selector Dial to select the PIZZA function. Once the function has been selected,
use the Time/Temperature Control Dial to select the desired cooking temperature and time. Turn the
Time/Temperature Control Dial clockwise to increase temperature and time and counter-clockwise
to decrease.
4. Press the TURBO CONVECT button for better air circulation and crispier food if needed. The turbo
convection fan will appear on the LCD screen to indicate that Turbo Convection is on. To cancel
convection setting, press the TURBO CONVECT button once more.
5. Press the START button to begin preheating. PREHEATING will appear on the LCD screen.
6. Once preheating is complete, an audible alert will sound. The START button will flash.
7. Carefully place pizza on the center of the wire rack for more even cooking.
8. Close the countertop oven door.
9. Press the START button to begin the pizza cycle.
Note: The timer will not begin until the START button is pressed.
10. When pizza cycle is complete, an audible alert will sound.
11. Open countertop oven door fully and remove food carefully. We recommend using oven mitts or pot
holders when removing food from the countertop oven.
WARNING: Cooked food can be very hot. Handle with care. Do not leave countertop oven unattended.
Reheat
For optimal results, place wire rack in the desired rack position.
1. Insert the wire rack in desired rack position.
2. Place food on an oven-safe accessory. Then, carefully place accessory in the center of the wire rack
for even heating.
3. Close countertop oven door.
4. Turn the Function Selector Dial to select the REHEAT function. Once the function has been selected,
use the Time/Temperature Control Dial to select the desired cooking temperature and time. Turn the
Time/Temperature Control Dial clockwise to increase temperature and time and counter-clockwise
to decrease.
TSCLTRDG1-AF_TSCLTRDG2-AF_20EM1.indd 11TSCLTRDG1-AF_TSCLTRDG2-AF_20EM1.indd 11 4/8/20 10:024/8/20 10:02

12
5. Press the TURBO CONVECT button for better air circulation and crispier food if needed. The turbo
convection fan will appear on the LCD screen to indicate that Turbo Convection is on. To cancel
convection setting, press the TURBO CONVECT button once more.
6. Press the START button to begin the reheat cycle.
Note: The timer will not begin until the START button is pressed.
7. When reheat cycle is complete, an audible alert will sound.
8. Open countertop oven door fully and remove food carefully. We recommend using oven mitts or pot
holders when removing food from the countertop oven.
WARNING: Cooked food can be very hot. Handle with care. Do not leave countertop oven unattended.
Keep Warm
For optimal results, place wire rack in desired rack position.
1. Insert the wire rack in desired rack position.
2. Close the countertop oven door.
3. Carefully place food on an oven-safe accessory. Then, carefully place accessory in the center of the
wire rack for even heating.
4. Turn the Function Selector Dial to select the KEEP WARM function. Once the function has been
selected, use the Time/Temperature Control Dial to select the desired cooking temperature and
time. Turn the Time/Temperature Control Dial clockwise to increase temperature and time and
counter-clockwise to decrease.
5. Press the TURBO CONVECT button for better air circulation and crispier food if needed. The turbo
convection fan will appear on the LCD screen to indicate that Turbo Convection is on. To cancel
convection setting, press the TURBO CONVECT button once more.
6. Press the START button to begin the warming cycle.
Note: The timer will not begin until the START button is pressed.
7. When warming cycle is complete, an audible alert will sound.
8. Open countertop oven door fully and remove food carefully. We recommend using oven mitts or pot
holders when removing food from the countertop oven.
WARNING: Cooked food can be very hot. Handle with care. Do not leave countertop oven unattended.
Defrost
For optimal results, place wire rack in the upper rack position.
1. Insert the wire rack into the upper rack position.
2. Ensure the countertop oven door is closed for preheating.
3. Turn the Function Selector Dial to select the DEFROST function. Once the function has been
selected, use the Time/Temperature Control Dial to select the desired cooking temperature and
time. Turn the Time/Temperature Control Dial clockwise to increase temperature and time and
counter-clockwise to decrease.
TSCLTRDG1-AF_TSCLTRDG2-AF_20EM1.indd 12TSCLTRDG1-AF_TSCLTRDG2-AF_20EM1.indd 12 4/8/20 10:024/8/20 10:02

13
4. Press the START button to begin preheating. PREHEATING will appear on the LCD screen.
5. Once preheating is complete, an audible alert will sound. The START button will flash.
6. Carefully place food in the center of the wire rack.
7. Close the countertop oven door.
8. Press the START button to begin the defrost cycle.
Note: The timer will not begin until the START button is pressed.
9. When defrost cycle is complete, an audible alert will sound.
10. Open countertop oven door fully and remove food carefully. If food requires more time to defrost,
place it back inside the countertop oven and repeat steps 3, 4, 7 & 8. If food is suciently
defrosted, place it back into the oven and choose the appropriate Cooking Function and Cooking
Time to complete food preparation.
WARNING: Cooked food can be very hot. Handle with care. Do not leave countertop oven unattended.
Dehydrate
For optimal results, slide DEHYDRATE RACK in the upper rack position.
1. Place food evenly on the DEHYDRATE RACK in a single layer and leave space between the pieces.
2. Insert the DEHYDRATE RACK directly into the upper rack position.
3. Ensure the countertop oven door is closed for preheating.
4. Turn the Function Selector Dial to select the DEHYRATE function. Once the function has been
selected, use the Time/Temperature Control Dial to select the desired cooking temperature and
time. Turn the Time/Temperature Control Dial clockwise to increase temperature and time and
counter-clockwise to decrease.
5. Press the TURBO CONVECT button for better air circulation and crispier food if needed. The turbo
convection fan will appear on the LCD screen to indicate that Turbo Convection is on. To cancel
Turbo Convection option, press the TURBO CONVECT button once more.
6. Press the START button to begin preheating. PREHEATING will appear on the LCD screen.
7. Once preheating is complete, an audible alert will sound. The START button will flash.
8. Leave the door open approximately 3 inches from the closed position.
9. Press the START button to begin the dehydrate cycle.
Note: The timer will not begin until the START button is pressed.
10. When dehydrate cycle is complete, an audible alert will sound.
11. Open countertop oven door fully and remove food carefully. We recommend using oven mitts or pot
holders when removing food from the countertop oven.
WARNING: Cooked food can be very hot. Handle with care. Do not leave countertop oven unattended.
During initial use of this appliance, some slight smoke and/or odor may be detected. This is normal
with many heating appliances and will not recur after a few hours.
TSCLTRDG1-AF_TSCLTRDG2-AF_20EM1.indd 13TSCLTRDG1-AF_TSCLTRDG2-AF_20EM1.indd 13 4/8/20 10:024/8/20 10:02

14
CLEANING & MAINTENANCE
• Clean oven and any accessory after each use.
• Before cleaning your Calphalon® Performance Air Fry Countertop Oven, press the CANCEL/OFF
button to turn OFF the countertop oven. Unplug the cord and allow it to cool before cleaning.
• To clean exterior of oven, wipe with a damp cloth. DO NOT IMMERSE IN WATER. Make sure to only
use mild, soapy water. Abrasive cleaners, scrubbing brushes and chemical cleaners will damage
the coating on this unit.
• To clean the Wire Rack, Baking Pan, or Air Fry Basket/ Dehydrate Rack remove from the Oven and
immerse in warm, soapy water and wipe with soft cloth or sponge. These accessories may also be
washed in the top rack of the dishwasher. Dry thoroughly.
• Remove the Removable Crumb Tray and shake o crumbs. Wash with soapy water, and dry
thoroughly. Cleaning the Crumb Tray often will avoid any accumulations.
TSCLTRDG1-AF_TSCLTRDG2-AF_20EM1.indd 14TSCLTRDG1-AF_TSCLTRDG2-AF_20EM1.indd 14 4/8/20 10:024/8/20 10:02

15
TROUBLESHOOTING
Possible Problem Easy Solution
Oven does not turn ON • Plug the Countertop into the electrical outlet.
• Check that the power plug is securely inserted into the outlet.
• Insert the power plug into a dierent outlet.
• Press the START button.
Smoke odor • During initial use of this appliance, some slight smoke and/or odor
may be detected. This is normal with many heating appliances and
will not recur after a few uses.
Oven light does not
turn ON
• Press the LIGHT button.
Heating elements do not
stay ON
• Be certain that function is as desired. Heating elements will cycle ON
and OFF to maintain proper heat.
Overcooked/
undercooked foods
• You may have to adjust the time and temperature to desired taste.
• Because your countertop oven is smaller than your regular oven, it
will heat up faster and generally cook in shorter periods of time.
• Rack may need to be adjusted to accommodate food type.
Burnt smell • Refer to “Cleaning & Maintenance.” Food build-up inside the
countertop oven, on heating elements, in crumb tray can sometimes
cause burnt smell.
LCD display turns OFF • Press any button to wake up the appliance. The LCD screen light turns
o after 90 seconds of inactivity.
Steam is escaping from
the unit
• This may happen when cooking foods with high water content. To
prevent condensate forming, move unit away from walls or other
kitchen appliances.
TSCLTRDG1-AF_TSCLTRDG2-AF_20EM1.indd 15TSCLTRDG1-AF_TSCLTRDG2-AF_20EM1.indd 15 4/8/20 10:024/8/20 10:02

16
WARRANTY
3 YEAR LIMITED WARRANTY
Sunbeam Products, Inc. (“Calphalon”) warrants that for a period of three year from the date of
purchase, this product will be free from defects in material and workmanship. Calphalon, at its option,
will repair or replace this product or any component of the product found to be defective during the
guarantee period. Replacement will be made with a new or remanufactured product or component.
If the product is no longer available, replacement may be made with a similar product of equal or
greater value. This is your exclusive guarantee. Do NOT attempt to repair or adjust any electrical or
mechanical functions on this product. Doing so will void this guarantee. This guarantee is valid for
the original retail purchaser from the date of initial retail purchase and is not transferable. Keep the
original sales receipt. Proof of purchase is required to obtain satisfaction guarantee performance.
Calphalon dealers, service centers, or retail stores selling Calphalon, do not have the right to alter,
modify or any way change the terms and conditions of this guarantee. This guarantee does not cover
damage resulting from any of the following: negligent use or misuse of the product, use on improper
voltage or current, use contrary to the operating instructions, disassembly, repair or alteration by
anyone other than Calphalon or an authorized Calphalon service center. Further, the guarantee does
not cover: Acts of God, such as fire, flood, hurricanes and tornadoes.
What are the limits on Calphalon’s Liability?
Calphalon shall not be liable for any incidental or consequential damages caused by the breach of
any express, implied or statutory guarantee or condition. Except to the extent prohibited by applicable
law, any implied guarantee or condition of merchantability or fitness for a particular purpose is
limited in duration to the duration of the above guarantee. Calphalon disclaims all other guarantees,
conditions or representations, express, implied, statutory or otherwise. Calphalon shall not be liable
for any damages of any kind resulting from the purchase, use or misuse of, or inability to use the
product including incidental, special, consequential or similar damages or loss of profits, or for
any breach of contract, fundamental or otherwise, or for any claim brought against purchaser by
any other party. Some provinces, states or jurisdictions do not allow the exclusion or limitation of
incidental or consequential damages or limitations on how long an implied guarantee lasts, so the
above limitations or exclusion may not apply to you. This guarantee gives you specific legal rights,
and you may also have other rights that vary from province to province, state to state or jurisdiction to
jurisdiction.
WWW.CALPHALON.COM 1-800-809-7267
TSCLTRDG1-AF_TSCLTRDG2-AF_20EM1 GCDS-CAL1115155-JC P.N. 202688
TSCLTRDG1-AF_TSCLTRDG2-AF_20EM1.indd 16TSCLTRDG1-AF_TSCLTRDG2-AF_20EM1.indd 16 4/8/20 10:024/8/20 10:02
