Calumet 7000 Series User manual

©CALUMET PHOTOGRAPHIC, INC. 2006 0806
www.calumetphoto.com
U.S.A. 630.860.7447 x2258
United Kingdom 08000 964396
Germany 040 4231600
Belgium [phone]
Netherlands 020-697-7171
CALUMET THREE-WAYHEAD
THREE-YEAR WARRANTY
Three Year Parts-and-Labor Warranty
IMPORTANT: In order totake full advantage of our three-year warranty, please register your product
today buy logging on to our website at www.calumetphoto.com/warranty/. Be sure to have your
receipt in hand when registering to easily locate your order number when prompted. Registering
online will also give you the option to receive other great offers from Calumet.
Calumet warrants these tripods to be free from defects in material and workmanship for
three years from date of purchase. If this product is found to be defective in material or workmanship,
Calumet Photographic will, at its option, repair or replace it without charge, subject to the following
limitations and exclusions:
•Warranty extends to the original purchaser only and is not transferable or assignable.
•Returned product must be accompanied with proof of purchase if online registration is not
available.
•Warranty shall not apply to any product that has, in Calumet’s judgment, been subject to misuse,
abuse, negligence, accident or unauthorized repair.
Calumet’s obligation is limited to repair or replacement of head only, and no one is authorized to
assume any obligation not in accordance with the above. Should service be necessary under this
warranty, please contact us to receive the required Return Merchandise Authorization Number
(RMA#) and return the product with the freight prepaid to the address provided at that time.
Collect shipments will not be accepted. Product will be repaired or replaced and returned to you
prepaid. For technical assistance or to place an order, please call.
Tripod Safety Tips
•Do not exceed maximum weight load.
•Always engage safety locks when using tripod.
•Remove camera before transporting tripod.
•Do not leave tripod unattended when working in
public places.
•Tripod does not require regular lubrication, but if
required, use a standard lubricant, oil or grease.
•Clean with mild detergent and a soft cloth.
Remove dust and sand from locking threads and
sliding segments.
•If tripod is found to be or becomes defective from
normal use, please contact your nearest Calumet
service and repair center.

calumet 7000 series tripods
7016 three-way quick-release head
www.calumetphoto.com
Features include:
•Quick-release plate with
safety lock
•Individual forward and
side tilt locks and pan
locking knob
•Built-in spirit level
Specifications
Height 5.5" (140mm)
NET Weight: 2.4 lbs. (1.1kg)
THIS THREE-AXIS HEAD IS IDEAL FOR USE
WITH ANY DIGITAL, 35MM OR MEDIUM
FORMAT SLR CAMERAS.
CK7061

OPERATING INSTRUCTIONS
A
J
K
G
H
I
C
J
E
F
B
www.calumetphoto.com

Mounting Camera to
Head
With camera facing
forward, insert the
quick-release plate
under the front lip on top
of the head (G) and push
down on the camera
until the locking lever clicks into locking position, holding
plate in place. Make sure the plate is securely locked in place
by rotating the safety lock (D) into its locked position.
Attaching Camera to
Quick-Release Plate
Mount the camera to the
QR plate by screwing the
threaded screw into the
camera’s base mount
using the pop-up handle
(F) on the under side of
plate. Before fully tightening, be sure that camera is parallel
tothe platewith the lens side of the camera over the small
hole in the QR plate. When fully tightened, replace pop-up
handle flat against plate.
Remove the Quick-Release Plate
from the Head
To remove the QR plate (C) from the head, open the safety
lock (D) by rotating it counterclockwise until it clicks. Then
rotate the locking lever (E) counterclockwise until the QR
plate pops up.
Attaching the Locking Handles to the Head
There are three locking handles that need to be attached to
the head. The longest handle locks the forward and
backward tilting movement. The next-shortest handle locks
the side-to-side tilting movement. The shortest handle locks
the panning movement.
Removing Camera from Head
First release the safety lock and, while holding the camera
securely in one hand, rotate the locking lever (E) counter-
clockwise until plate pops up and is released from head.
Assembling Head to
Tripod
Mount the head on a tripod
using the 3⁄8"female thread
on the bottom of the head
(A).The top plateof the
Calumet tripods feature
three set screws (B) which
tighten against the base of
the head to ensure secure
positioning.
Using the 3-Way Head
Each movement of the head — side-to-side tilt, forward-to-
back tilt and pan — has its own locking handle. The bottom
locking handle(H) controls 360° panning movement. The
short locking handle (I) controls side-to-side tilting
movement. The long locking handle (J) controls forward and
backwardtilting movement. A spirit level is built into the top
of the head (K),in front of the mounting plate for convenient
leveling of the camera.
calumet 7016
three-way quick-release head
