CAMDEN CX-ED1079 Series User manual

Page 1 of 3
CX-ED1079 Series
‘Universal’ Electric Strike
INSTALLATION INSTRUCTIONS
Electrified Locks, Relays and Timers
1- 4 PIN power connector (12V)
1- 4 PIN power connector (24V)
1- 3 PIN door status connector
(with ‘L’ Models)
1- ESP1B, ESP3B and ESP4B faceplates
4- Wire nuts
2- #10 x 1 1/4” wood screws
4- #12-24 x 1/2” screws
2- Mounting brackets
2- Spacers
1- Varistor
THIS PACKAGE INCLUDES:
1. DESCRIPTION
Camden CX-ED1079 Series Grade 1 ANSI strikes for cylindrical
locksets offer the very best strike quality and performance, with
three stainless steel faceplates provided. The ‘Universal’ strike
design delivers unparalleled application exibility, with eld
selectable voltage, fail safe/fail secure operation and mechanical
adjustment of the strike body.
2. SPECIFICATIONS
Voltage 12/24V AC/DC
Current Draw 260mA@12V DC
150mA@24V DC
Static Strength 1,500 Lbs.
Dynamic Strength 70 Ft-Lbs.
Endurance 1,000,000 Cycles (Factory Tested)
250,000 Cycles (UL Veried)
Mode Field Selectable
Fail Safe/Fail Secure
Mech. Adjustment Strike Body/Faceplate
Operation AC-Buzz, DC-Silent
Duty Continuous
Latch Bolt Monitor SPDT, 100mA @ 24V DC
Dimensions (Body) CX-ED1079L:
3 3/8” H x 1 3/4” W x 1 7/32” D
(86mm x 44mm x 31mm)
CX-ED1079DL:
3 3/8” H x 1 3/4” W x 1 3/8” D
(86mm x 44mm x 35mm)
3. DIMENSIONS
UL 1034
UL 294
UL 294 Performance Levels
- Line Security = Level I
- Attack Level = Level I
- Endurance Level = Level IV
- Standby Power = Level I
(32mm)
(16mm)
1 1/4”
(42mm)
1 5/8”
(19mm)
3/4”
5/8”
(104mm)
4 1/8”
(123mm)
4 7/8”
(44mm)
1 3/4”
(32mm)
1 1/4”
(3mm)
1/8”
(12mm)
(86mm)
3 3/8”
1/2”
(31mm)
1 7/32”
(31mm)
1 7/32”
(35mm)
1 3/8”
(3mm)
1/8”
(86mm)
3 3/8”
(35mm)
1 3/8”
CX-ED1079L
CX-ED1079L
CX-ED1079DL
CX-ED1079DL

Page 2 of 3
CX-ED1079 Series ‘Universal’ Electric Strike
INSTALLATION INSTRUCTIONS
4. INSTALLATION
1. Prepare the door jamb as per the appropriate drawing.
2. Install mounting brackets to jamb using 12-24 x 1/2” screws
and pressed metal nuts. Do not tighten.
3. Spacers are used to assure ush nal assembly of faceplate
into jamb. Add one or more spacers between jamb and
mounting bracket when face plate extends beyond the jamb.
When the faceplate sits inside the jamb, spacers must be
added between the mounting bracket & the lip bracket.
Make sure the clearance hole in the spacer aligns with the hole
in mounting bracket.
4. Connect wires coming from the low voltage side of the
transformer to wires (black) from strike.
5. Install electric strike jamb by attaching with # 12-24 screws
and lockwashers.
6. Tighten secure 12-24 x 1/2” screws holding mounting
brackets to jamb.
(86mm)
3 3/8”
(187mm)
7 3/8”
(35mm)
1 3/8”
(200mm)
7 7/8”
(86mm)
3 3/8”
(86mm)
3 3/8”
(168mm)
6 3/8”
(31mm)
1 7/32”
(105mm)
4 1/8”
(124mm)
4 7/8”
(89mm)
3 1/2”
(155mm)
6 1/8”
L:
(35mm)
1 3/8”
DL:
(31mm)
1 7/32”
L:
(35mm)
1 3/8”
DL:
(31mm)
1 7/32”
L:
(35mm)
1 3/8”
DL:
(173mm)
6 7/8”
(144mm)
5 11/16”
ESP4B
ESP3B
ESP1B + ESP2B
Mounting Bracket
Spacer
12-24 x 1/2”
Flat-Head Screw (2pcs)
12-24 x 1/2”
Spacer
Spacer (Option)
JAMP
Loosen screw to
adjust strike body
VERTICAL CENTERLINE
Note: The products are intended to be installed in accordance with
the installation wiring diagram, mechanical assembly drawings
provided with each product, the local authority having jurisdiction
(AHJ) and the National Electric Code,
NFPA 70. When installed in fail secure mode, the local authority shall
be consulted with regard to the use of possible panic hardware to
allow emergency exit from the secure area.
The electric door strike shall be installed in such a way and in such a
location so as to not impair the operation of an emergency exit device
or panic hardware mounted on the door.

Call: 1.877.226.3369 / 905.366.3377
Visit: www.camdencontrols.com
Opening New Doors to
Innovation, Quality and Support!
Page 3 of 3
CX-ED1079 Series ‘Universal’ Electric Strike
INSTALLATION INSTRUCTIONS
5. CONNECTIONS
6. OPERATION
6. FACEPLATES
Black
Red
Blue
Green
Black
Red
Blue
Green
(+12V)
( - )
(+24V)
( - )
12V
24V
Varistor
Varistor
White
Orange
Grey
Or
FOR CUT WIRES
2
4
V
1
2
V
POWER
12V AC/DC
Red/Black: +12V
Blue/Green: Ground
A varistor is provided to protect/prevent strike from spikes.
Connect varistor between input wires.
How to modify fail-safe to fail-secure or vice versa.
(1). Loosen the screw as per the product diagram below.
(2). Rotate the set plate 180° and slide the plate until it is
properly seated.
(3). Tighten the screw.
Note: For UL 294 / UL 1034 compliance the door strikes are to be
powered via a UL 294/ UL 603 class 2 power limited output from
a control panel and or power supply. Furthermore, when powered
by AC/DC the units shall use a UL regulated UL 294/ UL 603 power
limited class 2 output rated 12/24V with AC on indicator.
24V AC/DC
Red: +24V
Black/Blue: -
Green: Ground
Door Status Sensor
(Closed position)
With ‘L’ Models
White = N/O
Grey = N/C
Orange = COM
FAIL SAFE CHANGING FAIL SECURE
(32mm)
(16mm)
1 ¼”
⁄”
(32mm)
1 ¼”
(104mm)
4 ⁄”
(123mm)
4 ⁄”
(16mm)
⁄”
(104mm)
4 ⁄”
(123mm)
4 ⁄”
(154mm)
6 ⁄”
(173mm)
6 ⁄”
(189mm)
7 ½”
(200mm)
7 ⁄”
(85mm)
3 ⁄”
(19mm)
¾”
(85mm)
3 ⁄”
(19mm)
¾”
(85mm)
3 ⁄”
(85mm)
3 ⁄”
(32mm)
1 ¼”
(44mm)
1 ¾”
(57mm)
2 ¼”
(16mm)
⁄”
(36mm)
1 ⁄”
(16mm)
⁄”
INCLUDED IN PACKAGE ADDITIONAL FACEPL ATE
ESP1B - ANSI SQUARE ESP3B - HOLLOW METAL DOOR ESP4B - WOOD DOOR ESP2B - ANSI ROUND
File: CX-ED1079 Series Manual Eng
.indd R6
Revision: 15/07/2019
Part No.: 40-82B192
