Cameo Zenit B200 User manual

USER´S MANUAL
BEDIENUNGSANLEITUNG
MANUEL D`UTILISATION
MANUAL DE USUARIO
INSTRUKCJA OBSŁUGI
MANUALE D‘ USO
ZENIT®B200
LED BATTERY OUTDOOR WASHLIGHT
CLZB200
FIRMWARE VERSION 1.90 AND HIGHER

CONTENTS / INHALTSVERZEICHNIS / CONTENU / CONTENIDO / TREŚĆ /
CONTENUTO
ENGLISH
INFORMATION ON THIS USER MANUAL 6
INTENDED USE 6
DEFINITIONS AND SYMBOL EXPLANATIONS 6
SAFETY INSTRUCTIONS 7
CHARGING, OPERATING AND STORING BATTERIES 14
NOTES ON PORTABLE OUTDOOR DEVICES 14
SCOPE OF DELIVERY 15
INTRODUCTION 15
CONNECTIONS, OPERATING AND DISPLAY ELEMENTS 16
OPERATION 17
IR REMOTE CONTROL 28
SETUP AND INSTALLATION 29
CARE, MAINTENANCE AND REPAIR 29
OPTIONAL ACCESSORIES 31
DMX TECHNOLOGY 32
TECHNICAL DATA 34
EXPLANATION OF IP PROTECTION CLASS 36
MINIMUM DISTANCE TO ILLUMINATED SURFACE 36
MINIMUM DISTANCE TO NORMALLY FLAMMABLE MATERIALS 36
DISPOSAL 37
MANUFACTURER’S DECLARATIONS 38
DEUTSCH
INFORMATIONEN ZU DIESER BEDIENUNGSANLEITUNG 39
BESTIMMUNGSGEMÄSSER GEBRAUCH 39
BEGRIFFS- UND SYMBOLERKLÄRUNGEN 39
SICHERHEITSHINWEISE 40
HINWEISE FÜR ORTSVERÄNDERLICHE OUTDOOR-GERÄTE 47
LIEFERUMFANG 48
EINFÜHRUNG 48
ANSCHLÜSSE, BEDIEN- UND ANZEIGEELEMENTE 49
BEDIENUNG 50
AUFSTELLUNG UND MONTAGE 63
PFLEGE, WARTUNG UND REPARATUR 63
OPTIONALES ZUBEHÖR 65
DMX TECHNIK 66

TECHNISCHE DATEN 68
IP-SCHUTZART 70
MINDESTABSTAND ZUR BELEUCHTETEN FLÄCHE 70
MINDESTABSTAND ZU NORMAL ENTFLAMMBAREN MATERIALIEN 70
ENTSORGUNG 71
HERSTELLERERKLÄRUNGEN 72
FRANCAIS
INFORMATIONS CONCERNANT CE MANUEL D’UTILISATION 73
UTILISATION CONFORME 73
EXPLICATIONS DES TERMES ET DES SYMBOLES 73
CONSIGNES DE SÉCURITÉ 74
CHARGER, UTILISER ET STOCKER LES ACCUMULATEURS 82
REMARQUES CONCERNANT LES APPAREILS D’EXTÉRIEUR MOBILES 83
CONTENU DE LA LIVRAISON 83
INTRODUCTION 83
ANSCHLÜSSE, BEDIEN- UND ANZEIGEELEMENTE 84
MODE D’EMPLOI 86
TÉLÉCOMMANDE INFRAROUGE 98
INSTALLATION ET MONTAGE 99
ENTRETIEN, MAINTENANCE ET RÉPARATION 100
ACCESSOIRES DISPONIBLES EN OPTION 102
TECHNIQUE DMX 103
CARACTÉRISTIQUES TECHNIQUES 105
EXPLICATIONS RELATIVES À L’INDICE DE PROTECTIONIP 107
DISTANCE MINIMALE PAR RAPPORT À LA SURFACE ÉCLAIRÉE 107
DISTANCE MINIMALE PAR RAPPORT AUX MATÉRIAUX NORMALEMENT INFLAMMABLES 107
ÉLIMINATION 108
DÉCLARATIONS DU FABRICANT 109
ESPAÑOL
INFORMACIÓN SOBRE ESTE MANUAL DE INSTRUCCIONES 110
USO PREVISTO 110
TÉRMINOS Y SÍMBOLOS 110
INSTRUCCIONES DE SEGURIDAD 111
CARGA, FUNCIONAMIENTO Y ALMACENAMIENTO DE LAS BATERÍAS 118
INDICACIONES PARA EQUIPOS PORTÁTILES DE EXTERIOR 119

VOLUMEN DE SUMINISTRO 119
INTRODUCCIÓN 119
CONEXIONES, ELEMENTOS DE MANEJO Y ELEMENTOS DE VISUALIZACIÓN 120
FUNCIONAMIENTO 122
MANDO A DISTANCIA POR INFRARROJOS 134
INSTALACIÓN Y MONTAJE 135
CUIDADO, MANTENIMIENTO Y REPARACIÓN 135
ACCESORIOS OPCIONALES 137
TECNOLOGÍA DMX 138
DATOS TÉCNICOS 140
EXPLICACIÓN SOBRE LA CLASE DE PROTECCIÓN IP 142
DISTANCIA MÍNIMA CON RESPECTO A LA SUPERFICIE ILUMINADA 142
DISTANCIA MÍNIMA CON RESPECTO A MATERIALES NORMALMENTE INFLAMABLES 142
ELIMINACIÓN 143
DECLARACIONES DEL FABRICANTE 144
POLSKI
INFORMACJE DOTYCZĄCE NINIEJSZEJ INSTRUKCJI OBSŁUGI 145
UŻYTKOWANIE ZGODNE Z PRZEZNACZENIEM 145
OBJAŚNIENIA TERMINÓW I SYMBOLI 145
ZASADY BEZPIECZEŃSTWA 146
ŁADOWANIE, OBSŁUGA I PRZECHOWYWANIE AKUMULATORÓW 153
UWAGI DOTYCZĄCE PRZENOŚNEGO SPRZĘTU ZEWNĘTRZNEGO 154
ZAKRES DOSTAWY 154
WPROWADZENIE 154
GNIAZDA, ELEMENTY OBSŁUGI I WSKAŹNIKI 155
OBSŁUGA 157
PILOT NA PODCZERWIEŃ 168
USTAWIANIE I MONTAŻ 169
CZYSZCZENIE, KONSERWACJA I NAPRAWY 169
OPCJONALNE AKCESORIA 171
TECHNIKA DMX 172
DANE TECHNICZNE 174
OBJAŚNIENIA DOTYCZĄCE STOPNIA OCHRONY IP 176
MINIMALNA ODLEGŁOŚĆ OD POWIERZCHNI OŚWIETLONEJ 176
MINIMALNA ODLEGŁOŚĆ OD NORMALNIE ŁATWOPALNYCH MATERIAŁÓW 176
UTYLIZACJA 177
OŚWIADCZENIA PRODUCENTA 178

ITALIANO
INFORMAZIONI SUL PRESENTE MANUALE D’USO 179
UTILIZZO CONFORME 179
SPIEGAZIONE DI CONCETTI E SIMBOLI 179
INDICAZIONI SULLA SICUREZZA 180
AVVERTENZE PER DISPOSITIVI PORTATILI PER ESTERNI 188
VOLUME DI CONSEGNA 188
INTRODUZIONE 188
CONNETTORI, ELEMENTI DI COMANDO E VISUALIZZAZIONE 189
UTILIZZO 191
TELECOMANDO A INFRAROSSI 202
INSTALLAZIONE E MONTAGGIO 203
PULIZIA, MANUTENZIONE E RIPARAZIONE 203
OPTIONALES ZUBEHÖR 205
TECNOLOGIA DMX 206
DATI TECNICI 208
SPIEGAZIONI SULLA PROTEZIONE IP 210
DISTANZA MINIMA DALLA SUPERFICIE ILLUMINATA 210
DISTANZA MINIMA DAI MATERIALI NORMALMENTE INFIAMMABILI 210
SMALTIMENTO 211
DICHIARAZIONI DEL PRODUTTORE 212
DMX
DMX CONTROL / DMX STEUERUNG / PILOTAGE DMX / CONTROL DMX /
STEROWANIE DMX / CONTROLLO DMX 213

6
DMX
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
DEUTSCHENGLISH
ENGLISH
YOU‘VE MADE THE RIGHT CHOICE!
We have designed this product to operate reliably over many years. Please read this User‘s Ma-
nual carefully, so that you can begin making optimum use of your Cameo Light product quickly.
Learn more about Cameo Light on our website CAMEOLIGHT.COM.
INFORMATION ON THIS USER MANUAL
• Carefully read the safety instructions and the entire manual before operating the device.
• Observe the warnings on the device and in the user manual.
• Always keep the user manual within reach.
• If you sell or pass on the device, it is important that you also include this user manual, as it is an
integral part of the product.
INTENDED USE
The product is a device for event technology!
This product has been developed for professional use in the field of event technology and is not
suitable for use as domestic lighting!
Furthermore, this product is only intended for qualified users with specialist knowledge of event
technology!
Use of the product outside the specified technical data and operating conditions is considered
inappropriate!
Liability for damage and third-party damage to persons and property due to inappropriate use is
excluded!
The product is not suitable for:
• Use by persons (including children) with limited physical, sensory or mental abilities or lack of
experience and knowledge.
• children (children must be instructed not to play with the device).
DEFINITIONS AND SYMBOL EXPLANATIONS
1. HAZARD: The word HAZARD, possibly in combination with a symbol, indicates situations in
which there is an immediate danger or risk of potentially fatal injury.
2. WARNING: The word WARNING, possibly in combination with a symbol, indicates situations in
which there is an immediate danger or risk of potentially fatal injury.
3. CAUTION: The word CAUTION, possibly in combination with a symbol, indicates situations or
conditions that could result in injury.
4. ATTENTION: The word ATTENTION, possibly in combination with a symbol, indicates situations
or conditions that could result in damage to property and/or the environment.

7
DMX DEUTSCHFRANCAIS
ESPAÑOL ENGLISH
ITALIANO POLSKI
This symbol identifies hazards that can cause electric shock.
This symbol identifies hazardous areas or hazardous situations.
This symbol indicates hazards caused by hot surfaces.
This symbol indicates hazards caused by intense light sources.
This symbol indicates a device in which there are no user-replaceable parts.
This symbol indicates additional information on the operation of the product.
SAFETY INSTRUCTIONS
HAZARD:
1. Do not open the device and do not perform any modifications.
2. If your device no longer functions properly, if liquids or objects get inside it or if it
has been damaged in any other way, switch it off immediately and unplug it from
the power source. The device may be repaired only by authorised repair techni-
cians.
3. For devices of protection class 1, the protective conductor must be connected
correctly. Never disconnect the protective conductor. Devices of protection class 2
do not have a protective conductor.
4. Ensure that live cables are not kinked or otherwise mechanically damaged.
5. Never bypass the device fuse.
WARNING:
1. The device may not be operated if it shows obvious signs of damage.
2. The device may only be installed in a voltage-free state.
3. If the device's power cable is damaged, the device may not be used.
4. Permanently connected power cables may only be replaced by a qualified person.

8
DMX
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
DEUTSCHENGLISH
ATTENTION:
1. Do not switch on the device if it has been exposed to extreme temperature fluctu-
ations (for example, following transport). Moisture and condensation can damage
the device. Switch on the device only when it has reached room temperature.
2. Ensure that the voltage and frequency of the mains supply match the values spec-
ified on the device. If the device has a voltage selector switch, do not connect the
device until it has been set correctly. Use only suitable power cables.
3. To disconnect the device from the mains on all poles, it is not sufficient to press the
on/off switch on the device.
4. Make sure that the fuse used corresponds to the type printed on the device.
5. Ensure that suitable measures have been taken against overvoltage (e.g. lightning
strikes).
6. Observe the specified maximum output current on devices with a Power Out con-
nection. Ensure that the total current consumption of all connected devices does
not exceed the specified value.
7. Replace plug-in power cables with original cables only.
HAZARD:
1. Choking hazard! Plastic bags and small parts must be kept out of reach of persons
(including children) with reduced physical, sensory or mental capabilities.
2. Risk of falling! Make sure that the device is securely installed and will not fall
down. Only use suitable stands or mounts (particularly for fixed installations).
Ensure that accessories are properly installed and secured. Ensure that applicable
safety regulations are observed.
WARNING:
1. Use the device in the prescribed manner only.
2. Operate the device using only accessories of the type recommended and supplied
by the manufacturer.
3. Observe safety regulations applicable in your country during installation.
4. After connecting the device, ensure that all cables are routed so as to avoid dam-
age or accidents, such as from tripping.
5. Always observe the specified minimum distance to normally flammable materials!
Unless explicitly stated, the minimum distance is 0.3 m.
6. Always observe the minimum distance to the illuminated surface, which can be
read on the device!

9
DMX DEUTSCHFRANCAIS
ESPAÑOL ENGLISH
ITALIANO POLSKI
CAUTION:
1. Moving components such as mounting brackets may become jammed.
2. In the case of devices with motor-driven components, there is a risk of injury due
to the movement of the device. Sudden movement of the device can cause shock
reactions.
3. The housing surface of the device can become very hot during regular operation.
Ensure that accidental touching of the housing is not possible. Always allow the
device to cool sufficiently before removal, maintenance work and charging etc.
ATTENTION:
1. Do not install or use the device in the vicinity of radiators, accumulators, stoves, or
other heat sources. Ensure that the device is always installed in such a way that it
is sufficiently cooled and cannot overheat.
2. Do not place any ignition sources, such as burning candles, near the device.
3. Ventilation openings must not be covered and fans must not be blocked.
4. For transport, use the original packaging or packaging provided by the manufactur-
er.
5. Avoid any impacts to or shaking of the device.
6. Observe the IP rating and the ambient conditions such as temperature and humidi-
ty according to the specifications.
7. Devices can be continuously further developed. In the event of deviating informa-
tion on operating conditions, performance or other device properties between the
user manual and the device labelling, the information on the device always has
priority.
8. The device is not suitable for tropical climate zones or for operation over 2,000 m
above sea level.
9. Unless explicitly stated, the device is not suitable for operation under marine
conditions.
NOTE:
In the case of conversion or retrofit sets or accessories provided by the manufacturer,
be sure to observe the enclosed instructions.
CAUTION! IMPORTANT INFORMATION REGARDING LIGHTING PRODUCTS!
1. Never look directly into the beam of light, not even for a short period of time.
2. Never look into the beam of light using optical devices such as a magnifying glass.
3. Stroboscopic effects may cause epileptic seizures in susceptible individuals!

10
DMX
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
DEUTSCHENGLISH
4. These luminaires contain permanently installed light sources which cannot be
replaced by the user. The light source contained in this luminaire may only be
replaced by the manufacturer or its service partner or a similarly qualified person.
SIGNAL TRANSMISSION AND CONTROL BY RADIO
(E.g. W-DMX or audio radio systems, Bluetooth):
The quality and performance of wireless signal transmissions generally depends on
the ambient conditions.
The following factors can impact range and signal stability, for example:
• Shielding (e.g. masonry, metal structures, water)
• High volume of radio traffic (e.g. powerful wireless LAN networks)
• Interference
• Electromagnetic radiation (e.g. LED video screens, dimmers)
All range specifications refer to free-field application with visual contact and without
interference!
The operation of transmission systems is subject to official regulations. These may
vary from region to region and must be checked by the operator before use (e.g. radio
frequency and transmission power).
WARNING: Devices with wireless signal transmission are not suitable for use in sen-
sitive areas in which radio operation can lead to potential detrimental effects. These
include:
• Hospitals, health centres or other healthcare facilities that provide patient treatment
with skilled personnel and equipment.
• Hazardous areas Class I, II and III
• Restricted areas
• Military facilities
• Aircraft or vehicles
• Areas where the use of mobile phones is prohibited

11
DMX DEUTSCHFRANCAIS
ESPAÑOL ENGLISH
ITALIANO POLSKI
TRANSMISSION VIA W-DMX
WARNING: In general, wireless DMX transmission must not be used for applications
involving safety-related factors that might result in personal injury or property dam-
age in the event of a failure.
This applies in particular to moving scene or traverse structures, DMX-controlled
motors/lifts or lifting devices for operating DMX-operated platform lifts, hydraulic
systems or comparable moving components.
Furthermore, wireless DMX transmission must not be used to trigger flame or pyro-
technic devices, explosion-driven effects, or to control gas or liquid effects. These
include CO2cannons, confetti shooters, water effects or similar.

12
DMX
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
DEUTSCHENGLISH
DEVICES WITH BATTERY, BATTERIES AND CHARGERS
DANGER:
1. Keep the device with battery away from heat sources and do not expose it to di-
rect sunlight. Do not place it on or in heating devices such as microwaves, ovens
or radiators. Batteries can explode if overheated. Be sure to observe the per-
missible ambient and operating conditions! These can be found in the technical
specifications.
2. Do not open the unit! Do not make any changes to the battery and do not attempt
to replace battery cells!
3. Battery cells or battery packs must not be damaged. Protective foils and stickers
must not be removed. No foreign objects may be inserted into the battery. No
liquids may get into the battery. There is a risk of fire and explosion as well as
other dangerous situations (e.g. outgassing).
4. In case of deformation of the unit or overheating, put the unit out of operation im-
mediately! If you continue to operate the unit, there is a risk of fire and explosion,
as well as other dangerous situations (e.g. outgassing).
5. Do not throw the appliance into a fire! Danger of explosion!
6. Avoid strong mechanical impacts on the unit! Damage due to falling, smashing or
piercing as well as high pressure leads to fire and explosion hazards as well as
the risk of further dangerous situations (e.g. outgassing).
7. Only charge the device or the battery in the intended manner. Only use the
original charger. Note that a compatible plug connection does not indicate the
suitability of the charger.
8. Please note that the charging function is not deactivated by the main unit switch
on all units.
9. In the case of charging devices integrated in transport cases, the charging pro-
cess may only be carried out with the lid open.
10. Spilled liquid is corrosive and may be toxic. It can cause skin and eye irritation
and is dangerous if swallowed. Avoid any contact with spilled liquid. In case of
contact with spilled liquid, wash the affected area immediately with plenty of
water and contact a doctor.

13
DMX DEUTSCHFRANCAIS
ESPAÑOL ENGLISH
ITALIANO POLSKI
DEVICES WITH BATTERY OR ACCUMULATOR REPLACEMENT PROVIDED BY THE
USER (e.g. remote control)
DANGER:
Be sure to observe the manufacturer's data sheet for the batteries or
rechargeable batteries used!
1. Batteries and rechargeable batteries must be kept out of reach of persons (inclu-
ding children) with reduced physical, sensory or mental capabilities. Danger of
suffocation!
2. Avoid strong mechanical impacts on batteries and accumulators! Damage due to
falling, smashing or puncturing as well as high pressure leads to fire and explosion
hazards as well as the risk of further dangerous situations (e.g. outgassing).
3. Leaking battery fluid is corrosive and can be toxic. It can cause skin and eye irrita-
tion and is dangerous if swallowed. Avoid any contact with leaked fluid. In case of
contact with leaked liquid, wash the affected area immediately with plenty of water
and contact a doctor.
4. Never attempt to charge non-rechargeable batteries. Danger of explosion!
5. Do not throw batteries and rechargeable batteries into a fire! Danger of explosion!
6. Do not short-circuit batteries and rechargeable batteries! Avoid contact of the
battery terminals with electrically conductive objects (e.g. key ring or coins).
ATTENTION:
1. When inserting batteries and rechargeable batteries, ensure that the polarity is
correct (see illustrations in the battery compartment or on the housing).
2. Do not use different cell types and battery brands in the same unit at the same
time.
3. Only use batteries and rechargeable batteries with the same discharge status.
4. Check batteries and rechargeable batteries for damage and do not use damaged
batteries and rechargeable batteries!

14
DMX
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
DEUTSCHENGLISH
CHARGING, OPERATING AND STORING BATTERIES
1. To charge permanently installed batteries, connect the unit to the power supply
provided. Please note that the charging function is not deactivated by the main
unit switch on all units.
2. Please refer to the technical data for the charging time required to fully charge
the battery. For information on displaying the battery charge status, see the
OPERATION chapter.
3. Units with lithium batteries are equipped with the usual protective devices.
4. Do not charge the battery outside the ambient conditions specified in the techni-
cal data. Unless otherwise stated, these are between +5° and +35° Celsius in a
dry environment.
5. The permissible ambient conditions for operation can be found in the technical
data. Unless otherwise specified, the temperature must not fall below +5°C and
must not exceed +35°C in a dry environment.
6. The permissible ambient temperature for storage can be found in the technical
data. Unless otherwise stated, do not go below +5°C and do not exceed +35°C in
a dry environment.
7. After discharging the battery, fully charge it again as soon as possible.
8. Only store the unit with a fully charged battery. Batteries that are not fully charged
may lose capacity and life prematurely.
9. If the unit is not used for a long period of time, perform a complete discharge and
recharge cycle at least every 3 months.
10. The main switch of the unit must be switched off during storage.
11. Battery runtimes stated always refer to a new battery and normal operating
conditions.
12. When operating in a cold environment, the battery life may be shorter than speci-
fied.
13. If the device runtime in battery mode deviates significantly from the specifica-
tions, contact your sales partner.
NOTES ON PORTABLE OUTDOOR DEVICES
1. Temporary operation! Event equipment is generally only designed for temporary
operation.
2. Continuous operation or permanent structural installation – particularly outdoors –
can impair the function, surfaces and seals and accelerate material fatigue.
3. Damage to the surface coating can impair the device's corrosion protection.
Damaged surface coating (e.g. scratches) must be promptly repaired by suitable
measures.

15
DMX DEUTSCHFRANCAIS
ESPAÑOL ENGLISH
ITALIANO POLSKI
SCOPE OF DELIVERY
Remove the product from the packaging and remove all packaging material.
Please check the completeness and integrity of the delivery and notify your distribution partner
immediately after purchase if the delivery is not complete or if it is damaged.
Product includes:
• Headlight
• Mains cable
• 1x Omega bracket
• IR remote control
• Operating instructions
INTRODUCTION
LED BATTERY OUTDOOR WASHLIGHT WITH W-DMX™
CLZB200
CONTROL FUNCTIONS:
2-channel CCT, 3-channel color macros, 3-channel RGB 8-bit, 4-channel RGBW 8-bit, 6-channel
RGB 16-bit, 8-channel RGBW 8 Bit, 8-channel RGBW 16-bit, 10-channel full-access 8-bit, and
15-channel full-access 16-bit DMX controll
Master/Slave operation
Standalone functions
IR remote control
W-DMX™
FEATURES:
DMX-512. 21 x 15 W High Power CREE RGBW LEDs. W-DMX™. Battery operation with up to 24
hours running time. IR remote control included. Strobe. 16-bit dimmer. 4 dimmer curves. Colour
temperature correction. Adjustable LED PWM frequency. Fast Access Feature. IP65-rated. IP65 5-pin
DMX ports. Plastic feet. Omega mounting bracket included. Operating voltage 100–240 V AC. Power
consumption 180W. 25°, 45°, 60° x 10°, 100° diffusers and barn-door available as an option.
The spotlight features the RDM standard (Remote Device Management). This remote device man-
agement system makes it possible to carry out status checks and configure RDM devices with an
RDM-enabled controller.

16
DMX
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
DEUTSCHENGLISH
CONNECTIONS, OPERATING AND DISPLAY ELEMENTS
1
3
4 5
6
7 7
2
1POWER IN
IP65 power input socket with rubber sealing cap. Operating voltage 100 - 240 V AC / 50 - 60Hz.
Connection via supplied power cable (when not in use, always close with rubber sealing cap).
2POWER OUT
IP65 power output socket with rubber sealing cap. Facilitates power supply to other CAMEO lights.
Ensure that the total current consumption of all connected devices does not exceed the value specified
on the device in amperes (A) (when not in use, always close with the rubber sealing cap).
3ON / OFF
Ensure that the battery is charged sufficiently or connect the lights correctly to the power supply.
Move the switch to the down position to make the floodlight ready for operation. During the start-
up process, “Welcome to Cameo”, the model name and the software version will be shown con-
secutively on the display. When the switch is not in the down position, the floodlight is in standby
mode. In both operating states, the battery is constantly being charged, as long as the floodlight is
connected to the power supply correctly.
4DMX IN
Male IP65 5-pin XLR socket for connecting a DMX control device (e.g. DMX console. When not in
use, always close with the rubber sealing cap).
5DMX OUT
Female IP65 5-pin XLR socket for sending DMX control signal (when not in use, always close with
the rubber sealing cap).
6OLED-DISPLAY
Shows current operating mode, charging status of the battery and the menu items in the edit
menu.

17
DMX DEUTSCHFRANCAIS
ESPAÑOL ENGLISH
ITALIANO POLSKI
7TOUCH-SENSITIVE CONTROLS
MODE – Press mode to access the selection menu for system settings. Press repeatedly to go
back to the main display.
ENTER – Press ENTER to access the menu levels to make value changes, and to access the
sub-menus. Confirm value changes by pressing ENTER.
UP and DOWN – Select individual menu items in the selection menu (DMX address, operating mode
etc.) and in the sub-menus. Allow changes to the value of a menu item, such as the DMX address as
required.
PRESSURE EQUALISATION ELEMENT
The pressure compensation element to prevent condensation forming inside the housing is locat-
ed in the base of the device behind the cable feed to the LED unit. In order to ensure its proper
function, the element must be protected from contamination.
PLEASE NOTE: In order to provide protection from spraying water, in accordance with protection
class IP65, special IP65-rated XLR connectors must be used correctly with the DMX input and
output sockets, or they must be closed using the rubber sealing caps. When connected correctly,
or when sealed correctly with the rubber sealing caps, the POWER IN and POWER OUT sockets are
protected from spraying water according to IP65.
OPERATION
PLEASE NOTE
• When the lamp is correctly connected to the mains supply and the standby switch is in the
down position, “Welcome to Cameo”, the model name and the software version are shown on
the display consecutively during start-up. After this process, the lamp is ready for operation and
starts in the previously enabled mode.
• If one of the DMX operating modes is activated and there is no DMX signal to the DMX input, the
currently programmed DMX address is displayed and the characters on the display will begin to
flash. The flashing stops when a DMX signal is present.
• Following approximately one minute of no input, the display automatically returns to the main
display and the currently active mode is displayed.
• Fast Access Feature: In order to simplify the menu guide, the device has an intelligent menu
structure that allows direct access to previously selected menu items and sub-menu items.
1. Press MODE and ENTER simultaneously for direct access to the last-edited sub-menu item,
where you can make changes instantly as required (DMX starting address and all modes).
2. Press MODE for direct access to the last-selected and last-edited menu item. Press ENTER
repeatedly to access the sub-menu items in order to change individual settings (DMX starting
address and all modes).

18
DMX
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
DEUTSCHENGLISH
• Before changing device settings, ensure that the control panel is dry and dust free, in order not
to impair its functionality.
• The display can be rotated through 180° by pressing UP when the main display is visible.
MAIN DISPLAY
After the power-up process, the lamp is ready for operation and starts in the previously activated
mode. The main display appears with the following information: current mode (e.g. DMX mode),
W-DMX™ status, battery charge status and mains operation.
DMX Address
001
W-DMX™status Battery charge status
Mains operation
Current operating mode
BATTERY CHARGE STATUS IN STANDBY MODE
To recharge the internal battery, connect the lamp to the mains with the supplied power cable. The
battery charge status is indicated by the battery symbol on the display.
W-DMX™
1. To pair with W-DMX™ compatible transmitters, enable W-DMX™ in the device settings (Set-
tings -> Wireless Setting -> W-DMX On Off -> On) and reset the W-DMX™ module (Receive Re-
set -> Yes). Start the pairing process as described in the operating instructions of the W-DMX™
transmitter. Pairing is then completed automatically.
2. Connect a group of W-DMX™ devices to create a DMX universe. Disconnect all devices that
are supposed to form the group (Settings -> Wireless Setting -> Receive Reset). Now activate
a CLZB200 with a DMX controller via DMX cable and in the settings, select „Transmit“ (Send)
(Settings -> Wireless Setting -> Operating Mode -> Transmit). In the settings of the W-DMX™
devices to be controlled via W-DMX™, select „Receive“ (Settings -> Wireless Setting -> Opera-
ting Mode -> Receive), pair them and confirm by selecting „Link“ (Settings -> Wireless Setting ->
Link -> Link) in the settings of the CLZB200 controlled via DMX cable. Pairing is then completed
automatically.

19
DMX DEUTSCHFRANCAIS
ESPAÑOL ENGLISH
ITALIANO POLSKI
3. It is also possible to create a networked group of W-DMX™ devices via W-DMX™ and to
operate them in master/slave mode to use. Disconnect all devices that are supposed to form the
group (Settings -> Wireless Setting -> Receive Reset). Now, in the settings (Settings -> Wireless
Setting -> Operating Mode) of the master unit select „Transmit“ (send) and in the settings of the
selected slave units, select „Receive“. In the master unit, select the entry „Link“ (Settings ->
Wireless Setting -> Link -> Link) and confirm by pressing ENTER. Pairing of the devices is then
completed automatically. In the master unit, select one of the standalone modes (Auto, Colour
Macro, Static, Tunable White, User Colour) and control the slave units with it.
W-DMX™ STATUS
G3 G4S
W-DMX™
deactivated
W-DMX™
as receiver
activated,
not coupled
W-DMX™
as receiver
activated and
device coupled,
Transmitter off,
or out of range
W-DMX
activated and
coupled device,
no DMX signal
W-DMX™
as reveicer
activated and
coupled device,
DMX signal is
present
W-DMX™
and transmissi-
on mode G3
Arrow up = send
operation
Down arrow =
Receive mode
Arrow flashing =
Coupling
Flashing stops =
Coupled
W-DMX™
and transmissi-
on mode G4S
Arrow up = send
operation
Down arrow =
Receive mode
Arrow flashing =
Coupling
Flashing stops =
coupled
SETTING DMX START ADDRESS (DMX Address)
Press MODE to access the selection menu. Using the UP and DOWN controls, select the menu
item “DMX address” (observe arrow) and confirm with ENTER. The display will show a three-di-
git number field and you can use the UP and DOWN controls to configure the desired DMX start
address. Confirm the entry with ENTER and press MODE to return to the main display (in the
example, “DMX address 001”).
---------------- Menu ----------------
DMX Address
DMX mode
Stand Alone
Slave
Settings
System Info
DMX Address
001
001
5xx
–

20
DMX
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
DEUTSCHENGLISH
CONFIGURING DMX MODE (DMX Mode)
Press MODE to access the selection menu. Using the UP and DOWN controls, select the menu
item “DMX Mode” (observe arrow) and confirm with ENTER. In the sub-menu, you can now select
between 9 different DMX operating modes with the UP and DOWN buttons. Confirm your selection
with ENTER. Tables with the channel assignments can be found in these instructions under DMX
CONTROL.
---------------- Menu ----------------
DMX Address
DMX Mode
Stand Alone
Slave
Settings
System Info
------------ DMX MODE ------------
15CH Full Access
10CH Full Access
8CH (Bit
8CH User-Calibrated
6CH Factory-Calibrated
4CH User-Calibrated
3CH Factory-Calibrated
3CH Color Macro
2CH CCT Factory-Calib
SETTING STANDALONE MODE
Press MODE to access the selection menu. Use UP and DOWN to select the menu item “Stand
Alone” (observe arrow) and confirm with ENTER. In the sub-menu you can now select from the
standalone modes “Auto”, “Colour Macro”, “Static”, “Tunable White” and “User Colour” as well as
the timer function “Timer” using UP and DOWN. Confirm your selection with ENTER.
---------------- Menu ----------------
DMX Address
DMX mode
Stand Alone
Slave
Settings
System Info
------------ Stand Alone -----------
Auto
Color Macro
Static
Tunable White
User Color
Timer
AUTO MODE (programme 1 - programme 6)
The 6 different auto-programmes each comprise non-editable colour-change sequences. Brightness
and speed are independently adjustable. Select auto mode as per the procedure previously descri-
bed in SETTING STAND ALONE MODE and confirm with ENTER. Using the UP and DOWN controls,
now select one of the 6 auto-programmes (observe arrow) and confirm with ENTER. To adjust
brightness, use the UP and DOWN controls to select the menu item “Dim”, and confirm with ENTER,
then use the UP and DOWN controls to select the desired value between 000 and 255. Confirm with
ENTER.To adjust the run speed, select the menu item “Speed”, confirm with ENTER, and then
select the desired value between 001 and 100. Confirm with ENTER. Press MODE four times to
return to the main display (Mode Auto).
000
255
–
Dim
001
100
–
Speed
----------- Stand Alone -----------
Auto
Colour Macro
Static
Tunable White
User Colour
Timer
Mode
Auto
---------------- Auto ----------------
Program 1
Program 2
Program 3
Program 4
Program 5
Program 6
---------- Programme x ----------
Dim <255>
Speed <100>
001
100
–
