Cameo ZENIT Z120 G2 User manual

USER´S MANUAL
BEDIENUNGSANLEITUNG
MANUEL D´UTILISATION
MANUAL DE USUARIO
INSTRUKCJA OBSŁUGI
MANUALE D´USO
ZENIT®Z120 G2
ZENIT Z120 G2 PROFESSIONAL ZOOM PAR IP65
CLZZ120G2

CONTENTS / INHALTSVERZEICHNIS / CONTENU / CONTENIDO / TREŚĆ / CONTENUTO
ENGLISH
PREVENTIVE MEASURES 3-4
INTRODUCTION 4
CONNECTIONS, OPERATING AND DISPLAY ELEMENTS 5-6
OPERATION 6-11
INSTALLATION AND MOUNTING 12
DMX TECHNOLOGY 14
TECHNICAL DATA 14
MANUFACTURER’S DECLARATIONS 14-15
DMX CONTROL 82-87
DEUTSCH
SICHERHEITSHINWEISE 16-17
EINFÜHRUNG 17-18
ANSCHLÜSSE, BEDIEN- UND ANZEIGEELEMENTE 18-19
BEDIENUNG 19-25
AUFSTELLUNG UND MONTAGE 25
DMX TECHNIK 26
TECHNISCHE DATEN 27
HERSTELLERERKLÄRUNGEN 27-28
DMX STEUERUNG 82-87
FRANCAIS
MESURES PRÉVENTIVES 29-30
INTRODUCTION 30
RACCORDEMENTS, ÉLÉMENTS DE COMMANDE
ET D’AFFICHAGE 31-32
UTILISATION 32-38
INSTALLATION ET MONTAGE 39
TECHNOLOGIE DMX 40
CARACTÉRISTIQUES TECHNIQUES 41
DÉCLARATIONS DU FABRICANT 41-42
PILOTAGE EN MODE DMX 82-87
ESPAÑOL
MEDIDAS DE SEGURIDAD 43-44
INTRODUCCIÓN 44
CONEXIONES, ELEMENTOS DE MANEJO Y ELEMENTOS
DE VISUALIZACIÓN 45-46
MANEJO 46-52
INSTALACIÓN Y MONTAJE 52
TECNOLOGÍA DMX 53
DATOS TÉCNICOS 54
DECLARACIONES DEL FABRICANTE 55
CONTROL DMX 82-87
POLSKI
ŚRODKI OSTROŻNOŚCI 56-57
WPROWADZENIE 57-58
GNIAZDA, ELEMENTY OBSŁUGI I WSKAŹNIKI 58-59
OBSŁUGA 59
USTAWIANIE I MONTAŻ 65
TECHNIKA DMX 66
DANE TECHNICZNE 67
OŚWIADCZENIA PRODUCENTA 68
STEROWANIE DMX 82-87
ITALIANO
MISURE PRECAUZIONALI 69-70
INTRODUZIONE 70-71
CONNESSIONI, ELEMENTI DI COMANDO E VISUALIZZAZIONE 71-72
UTILIZZO 72-78
INSTALLAZIONE E MONTAGGIO 78
TECNOLOGIA DMX 79
DATI TECNICI 80
DICHIARAZIONI DEL PRODUTTORE 80-81
CONTROLLO DMX 82-87

3
DMX DEUTSCHFRANCAIS
ESPAÑOL ENGLISH
ITALIANO POLSKI
ENGLISH
YOU‘VE MADE THE RIGHT CHOICE!
We have designed this product to operate reliably over many years. Please read this User‘s Manual carefully, so that you can begin making
optimum use of your Cameo Light product quickly. Learn more about Cameo Light on our website WWW.CAMEOLIGHT.COM.
PREVENTIVE MEASURES
1. Please read these instructions carefully.
2. Keep all information and instructions in a safe place.
3. Follow the instructions.
4. Observe all safety warnings. Never remove safety warnings or other information from the equipment.
5. Use the equipment only in the intended manner and for the intended purpose.
6. Use only sufficiently stable and compatible stands and/or mounts (for fixed installations). Make certain that wall mounts are properly
installed and secured. Make certain that the equipment is installed securely and cannot fall down.
7. During installation, observ e the applicable safety regulations for your country.
8. Never install and operate the equipment near radiators, heat registers, ovens or other sources of heat. Make certain that the equipment is
always installed so that is cooled sufficiently and cannot overheat.
9. Never place sources of ignition, e.g., burning candles, on the equipment.
10. Ventilation slits must not be blocked.
11. This appliance is designed exclusively for indoor use, do not use this equipment in the immediate vicinity of water (does not apply
to special outdoor equipment - in this case, observe the special instructions noted below). Do not expose this equipment to flammable
materials, fluids or gases.
12. Make certain that dripping or splashed water cannot enter the equipment. Do not place containers filled with liquids, such as vases or
drinking vessels, on the equipment.
13. Make certain that objects cannot fall into the device.
14. Use this equipment only with the accessories recommended and intended by the manufacturer.
15. Do not open or modify this equipment.
16. After connecting the equipment, check all cables in order to prevent damage or accidents, e.g., due to tripping hazards.
17. During transport, make certain that the equipment cannot fall down and possibly cause property damage and personal injuries.
18. If your equipment is no longer functioning properly, if fluids or objects have gotten inside the equipment or if it has been damaged in
anot her way, switch it off immediately and unplug it from the mains outlet (if it is a powered device). This equipment may only be repaired
by authorized, qualified personnel.
19. Clean the equipment using a dry cloth.
20. Comply with all applicable disposal laws in your country. During disposal of packaging, please separate plastic and paper/cardboard.
21. Plastic bags must be kept out of reach of children.
FOR EQUIPMENT THAT CONNECTS TO THE POWER MAINS:
22. CAUTION: If the power cord of the device is equipped with an earthing contact, then it must be connected to an outlet with a protective
ground. Never deactivate the protective ground of a power cord.
23. If the equipment has been exposed to strong fluctuations in temperature (for example, after transport), do not switch it on immediately.
Moisture and condensation could damage the equipment. Do not switch on the equipment until it has reached room temperature.
24. Before connecting the equipment to the power outlet, first verify that the mains voltage and frequency match the values specified on the
equipment. If the equipment has a voltage selection switch, connect the equipment to the power outlet only if the equipment values and the
mains power values match. If the included power cord or power adapter does not fit in your wall outlet, contact your electrician.
25. Do not step on the power cord. Make certain that the power cable does not become kinked, especially at the mains outlet and/or power
adapter and the equipment connector.
26. When connecting the equipment, make certain that the power cord or power adapter is always freely accessible. Always disconnect the
equipment from the power supply if the equipment is not in use or if you want to clean the equipment. Always unplug the power cord and
power adapter from the power outlet at the plug or adapter and not by pulling on the cord. Never touch the power cord and power adapter
with wet hands.
27. Whenever possible, avoid switching the equipment on and off in quick succession because otherwise this can shorten the useful life of
the equipment.
28. IMPORTANT INFORMATION: Replace fuses only with fuses of the same type and rating. If a fuse blows repeatedly, please contact an
authorised service centre.
29. To disconnect the equipment from the power mains completely, unplug the power cord or power adapter from the power outlet.
30. If your device is equipped with a Volex power connector, the mating Volex equipment connector must be unlocked before it can be re-
moved. However, this also means that the equipment can slide and fall down if the power cable is pulled, which can lead to personal injuries
and/or other damage. For this reason, always be careful when laying cables.
31. Unplug the power cord and power adapter from the power outlet if there is a risk of a lightning strike or before extended periods of disuse.
32. The device must only be installed in a voltage-free condition (disconnect the mains plug from the mains).
33. Dust and other debris inside the unit may cause damage. The unit should be regularly serviced or cleaned (no guarantee) depending on
ambient conditions (dust etc., nicotine, fog) by qualified personnel to prevent overheating and malfunction.
34. Please keep a distance of at least 0.5 m to any combustible materials.
35. Power cables to power multiple devices must have a cross-section of at least 1.5 mm². Within the EU, the cables must correspond to
H05VV-F, or similar. Suitable cables are offered by Adam Hall. With these cables, you can connect multiple devices via the power OUT
connection to the power IN connection of an additional device. Make sure that the total current consumption of all connected devices does not
exceed the specified value on all connected devices (label on the device). Make sure to keep power cable connections as short as possible.

4
DMX
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
DEUTSCHENGLISH
CAUTION:
To reduce the risk of electric shock, do not remove cover (or back).There are no user serviceable
parts inside. Maintenance and repairs should be exclusively carried out by qualified service
personnel.
The warning triangle with lightning symbol indicates dangerous uninsulated voltage inside the unit, which may cause an
electrical shock.
The warning triangle with exclamation mark indicates important operating and maintenance instructions.
Warning! This symbol indicates a hot surface. Certain parts of the housing can become hot during operation. After use, wait for
a cool-down period of at least 10 minutes before handling or transporting the device.
Warning! This device is designed for use below 2000 metres in altitude.
Warning! This product is not intended for use in tropical climates.
Caution! Intense LED light source! Risk of eye damage. Do not look into the light source.
CAUTION! IMPORTANT INFORMATION ABOUT LIGHTING PRODUCTS!
1. The product has been developed for professional use in the field of event technology and is not suitable as household lighting.
2. Do not stare, even temporarily, directly into the light beam.
3. Do not look at the beam directly with optical instruments such as magnifiers.
4. Stroboscope effects may cause epileptic seizures in sensitive people! People with epilepsy should definitely avoid places where
strobes are used.
INTRODUCTION
OUTDOOR ZENIT ZOOM 120 G2
CLZZ120G2
CONTROL FUNCTIONS
3-channel, 4-channel, 5-channel 9-channel, 10-channel, 11-channel and 17-channel DMX functions
Master/Slave operation
Stand-alone functions
FEATURES
Outdoor spotlight with zoom function and a 120 W COB LED (RGBW). 7 DMX modes. DMX-512 control. Master/Slave operation. Stand-alone
functions. Stand or mounting bracket and 16 mm TV spigot included. Omega bracket included. Operating voltage 100–240 V AC/50–60 Hz.
Power consumption 180 W. IP65 protection rating.
The spotlights feature the RDM standard (remote device management). Remote device management allows the user to view status and
configuration of RDM terminals via an RDM-capable controller.

5
DMX DEUTSCHFRANCAIS
ESPAÑOL ENGLISH
ITALIANO POLSKI
5
6
1 2 3 4
7
8
CONNECTIONS, OPERATING AND DISPLAY ELEMENTS
1POWER IN
IP65 Power Twist mains input socket with rubber sealing cap. Operating voltage 100–240 V AC/50–60 Hz. Connection via supplied power
cable (when not in use, always close with rubber sealing cap).
2POWER OUT
IP65 Power Twist mains output socket with rubber sealing cap. Facilitates power supply to other CAMEO lights. Ensure that the total current
consumption of all connected devices does not exceed the value specified on the device in amperes (A) (when not in use, always close with
the rubber sealing cap).
3DMX IN
Male IP65 5-pin XLR socket for connecting a DMX control device (e.g. DMX console. When not in use, always close with the rubber sealing cap).
4DMX OUT
Female IP65 5-pin XLR socket for sending DMX control signal (when not in use, always close with the rubber sealing cap).
5OLED DISPLAY
Displays the current operating mode and other system settings.
