Cameo CLPST64RGBWAU12W User manual

STUDIO PAR 64 LED CAN
12 X 12W 6-IN-1 LED RGBWA+UV PAR CAN
CLPST64RGBWAU12W
USER´S MANUAL
BEDIENUNGSANLEITUNG
MANUEL D´UTILISATION
MANUAL DE USUARIO
INSTRUKCJA OBSŁUGI
MANUALE D‘USO

2
3
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
Thank you for choosing Cameo Lights!
We have designed this product to give you reliable operation over many years.
Please, take a few moments to read these instructions carefully, as we want you to enjoy your new Cameo Lights
products quickly and to the fullest.
Further information about Cameo Lights check our website WWW.CAMEOLIGHT.COM

STUDIO PAR 64 LED CAN
12 X 12 W 6-IN-1 LED RGBWA+UV PAR PROJECTOR
CLPST64RGBWAU10WBS/PS
2
3
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
FRANCAIS FRANCAIS FRANCAIS FRANCAIS
DEUTSCH
ENGLISH

4
5
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
PREVENTIVE MEASURES:
1. Please read these instructions carefully.
2. Keep all information and instructions in a safe place.
3. Follow the instructions.
4. Observe all safety warnings. Never remove safety warnings or other information from the equipment.
5. Use the equipment only in the intended manner and for the intended purpose.
6. Use only sufficiently stable and compatible stands and/or mounts (for fixed installations). Make certain that wall
mounts are properly installed and secured. Make certain that the equipment is installed securely and cannot fall down.
7. During installation, observ e the applicable safety regulations for your country.
8. Never install and operate the equipment near radiators, heat registers, ovens or other sources of heat. Make
certain that the equipment is always installed so that is cooled sufficiently and cannot overheat.
9. Never place sources of ignition, e.g., burning candles, on the equipment.
10. Ventilation slits must not be blocked.
11. Do not use this equipment in the immediate vicinity of water (does not apply to special outdoor equipment -
in this case, observe the special instructions noted below. Do not expose this equipment to flammable materials,
fluids or gases.
12. Make certain that dripping or splashed water cannot enter the equipment. Do not place containers filled with
liquids, such as vases or drinking vessels, on the equipment.
13. Make certain that objects cannot fall into the device.
14. Use this equipment only with the accessories recommended and intended by the manufacturer.
15. Do not open or modify this equipment.
16. After connecting the equipment, check all cables in order to prevent damage or accidents, e.g., due to
tripping hazards.
17. During transport, make certain that the equipment cannot fall down and possibly cause property damage and
personal injuries.
18. If your equipment is no longer functioning properly, if fluids or objects have gotten inside the equipment or
if it has been damaged in anot her way, switch it off immediately and unplug it from the mains outlet (if it is a
powered device). This equipment may only be repaired by authorized, qualified personnel.
19. Clean the equipment using a dry cloth.
20. Comply with all applicable disposal laws in your country. During disposal of packaging, please separate
plastic and paper/cardboard.
21. Plastic bags must be kept out of reach of children.
FOR EQUIPMENT THAT CONNECTS TO THE POWER MAINS:
22. CAUTION: If the power cord of the device is equipped with an earthing contact, then it must be connected to
an outlet with a protective ground. Never deactivate the protective ground of a power cord.
23. If the equipment has been exposed to strong fluctuations in temperature (for example, after transport), do
not switch it on immediately. Moisture and condensation could damage the equipment. Do not switch on the
equipment until it has reached room temperature.
24. Before connecting the equipment to the power outlet, first verify that the mains voltage and frequency match
the values specified on the equipment. If the equipment has a voltage selection switch, connect the equipment to
the power outlet only if the equipment values and the mains power values match. If the included power cord or
power adapter does not fit in your wall outlet, contact your electrician.
25. Do not step on the power cord. Make certain that the power cable does not become kinked, especially at the
mains outlet and/or power adapter and the equipment connector.
26. When connecting the equipment, make certain that the power cord or power adapter is always freely
accessible. Always disconnect the equipment from the power supply if the equipment is not in use or if you want

4
5
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
FRANCAIS FRANCAIS FRANCAIS FRANCAIS
DEUTSCH
ENGLISH
SAFETY:
to clean the equipment. Always unplug the power cord and power adapter from the power outlet at the plug or
adapter and not by pulling on the cord. Never touch the power cord and power adapter with wet hands.
27. Whenever possible, avoid switching the equipment on and off in quick succession because otherwise this
can shorten the useful life of the equipment.
28. IMPORTANT INFORMATION: Replace fuses only with fuses of the same type and rating. If a fuse blows repea-
tedly, please contact an authorised service centre.
29. To disconnect the equipment from the power mains completely, unplug the power cord or power adapter
from the power outlet.
30. If your device is equipped with a Volex power connector, the mating Volex equipment connector must be
unlocked before it can be removed. However, this also means that the equipment can slide and fall down if
the power cable is pulled, which can lead to personal injuries and/or other damage. For this reason, always be
careful when laying cables.
31. Unplug the power cord and power adapter from the power outlet if there is a risk of a lightning strike or
before extended periods of disuse.
CAUTION
RISK OF ELECTRIC S HOCK
DO NOT OPEN
CAUTION:
Never remove the cover, because otherwise there may be a risk of electric shock. There are no user serviceable
parts inside. Have repairs carried out only by qualified service personnel.
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user
to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electrical shock.
The exclamation mark within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance instructions.
CAUTION! IMPORTANT INFORMATION ABOUT LIGHTING PRODUCTS
1. Do not look into the beam from a distance of less than 40 cm.
2. Do not stare into the beam for extended periods at short-to-medium distances.
3. Do not view the beam directly with optical instruments such as magnifiers.
4. Under some circumstances, stroboscopic effects may trigger epileptic seizures in sensitive individuals! For this
reason, persons who suffer from epilepsy should always avoid places where strobe lights are used.
The product has been developed for professional use in the field of event technology and is not suitable as
household lighting.

INTRODUCTION:
12 x 12 W 6-in-1 LED RGBWA+UV STUDIO PAR PROJECTOR
CLPST64RGBWAU12W
CONTROL FUNCTIONS:
• 2-channel, 3-channel 1, 3-channel 2, 6-channel and 9-channel DMX control
• red, green, blue, white, amber and UV separately controllable
FEATURES:
• 12 X 12 W 6-in-1 LEDs
• RGB colour spectrum + white + amber + UV
• 25° beam angle
• Refresh rate 3000 Hz
• Power consumption 55 W
• Operating voltage 100V - 240 V AC
• Lit multifunctional LC display
• Adjustable double bracket
• Music control via built-in microphone
• Master/slave mode
• Colour change rate and stroboscope effect controllable via control panel and DMX
OPERATION:
The Cameo CLPST64RGBWAU12W is a DMX-512 controllable LED lighting system with RGBWAU colour mixing
that excels due to highly efficient, extra bright LEDs. The intensity of the six colour groups (red, green, blue,
white, amber, UV) can be controlled independently of one another, thus permitting an unlimited number of
different colours. The Cameo LED light can can be used both individually and in master/slave mode, with music
control, and via DMX-512 protocol.
CONTROLS AND INDICATORS:
1DMX IN
3-pin XLR socket for connection of a DMX controller (e.g., DMX mixer).
2DMX OUT
3-pin XLR socket for looping through the DMX control signal.
3POWER IN
Neutrik powerCON power input socket. Operating voltage 100 - 240 V AC / 50 - 60 Hz. Connection via the
supplied powerCON power cord.
6
7
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO

CONTROLS AND DISPLAY:
4POWER OUT
Neutrik powerCON power output socket. Used
to supply power to additional CAMEO projectors.
Make sure that the total current consumption in
amperes (A) of all connected devices does not
exceed the specified value on the device.
5FUSE HOLDER
IMPORTANT INFORMATION: Replace the fuse only
with a fuse of the same type and rating. If the fuse
blows repeatedly, please contact an authorised
service centre.
6MODE
Selection of the standalone functions, DMX
modes, and DMX address.
7ENTER
Makes it possible to change a value and confirm
changes.
8UP AND DOWN BUTTONS
Press the UP and DOWN buttons, for example, to
change the microphone sensitivity, stroboscope
speed or DMX address.
9LIT LC DISPLAY
Displays the operating mode and values of
individual functions. The illumination of the LC
display switches off automatically after approx.
70 seconds of inactivity. Pressing any one of the 4
control buttons will turn the illumination of the LC
display on again.
10 EYELET FOR SAFETY CABLE
Overhead installation may only be carried out by
trained personnel. The spotlight must be secured
with an appropriate safety cable to prevent falling.
6
7
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
FRANCAIS FRANCAIS FRANCAIS FRANCAIS
DEUTSCH
ENGLISH
1 2
3 4
5
6 7 8 8
9 10

OPERATION:
NOTE:
When the projector is properly connected to the mains, the following
information appears successively in the display during the startup process:
"Software Update, Please Wait..." (for service purposes only), the software
version "Software V1.xx" and "WELCOME TO cameo". After this operation,
the projector is ready for use and changes to the mode that was previously
selected.
STATIC COLOUR
This mode offers the ability to separately adjust the intensity for each of
the 6 LED groups and to generate an unlimited number of different colours
(colour mixing).
Press the MODE button until "STATIC" appears in the upper line of the
display. By repeatedly pressing the ENTER button, select the LED group for
which you want to change the brightness level (please note the cursor in
the display, Rxx = red, Gxx = green, Bxx = blue, Wxx = white, Axx = amber,
UVxx = UV / black light). Now you can set the intensity of the selected light
from 00 to 99 using the UP and DOWN buttons (example: R00 = red at 0%,
i.e. out. R99 = red at 100%, i.e. maximum brightness).
Adjust the flash frequency of the strobe effect by pressing ENTER repeatedly
until the cursor shows "Fxx". Now you can activate the strobe effect using
the UP and DOWN buttons and set the flash frequency from 00 to 99 (F00 =
strobe effect deactivated, F01 = approx. 1 Hz, F99 = approx. 20 Hz). Confirm
with ENTER.
RED
Intensity R00 - R99
GREEN
Intensity G00 - G99
BLUE
Intensity B00 - B99
WHITE
Intensity W00 - W99
AMBER
Intensity A00 - A99
UV / BLACK LIGHT
Intensity UV00 - UV99
STROBOSCOPE
Speed F00 - F99
8
9
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO

OPERATION:
COLOUR MACROS
In this mode, one of the 6 basic colours of the projector or one of the 9
different mixed colours can be selected as a preset.
Press the MODE button until "MACRO" appears in the upper line of the
display. Now press ENTER and then select one of the 15 colour presets
using the UP and DOWN buttons. Confirm with ENTER.
MACRO 01 = red MACRO 09 = lavender
MACRO 02 = green MACRO 10 = light green
MACRO 03 = blue MACRO 11 = magenta
MACRO 04 = white MACRO 12 = turquoise
MACRO 05 = amber MACRO 13 = orange
MACRO 06 = UV / black light MACRO 14 = cool white
MACRO 07 = yellow MACRO 15 = warm white
MACRO 08 = cyan
COLOUR CHANGE
In the colour change mode (Jumping Mode), 12 different colours alternate
in rapid succession (red, green, blue, white, amber, yellow, cyan, lavender,
pink, light green, magenta, turquoise, orange). The speed of the program is
adjustable separately and a stroboscope effect can also be activated.
Press the MODE button until "JUMPING" appears in the upper line of the
display. Now, press ENTER until the cursor appears in the lower line of the
display, and then select the rate (SPEED) using the UP and DOWN buttons,
with the colours alternating from 00 to 99.
Confirm with ENTER. The indicator in the bottom line of the display changes
to "FLASH:xx". At the same time, the cursor will appear in the bottom
line and you can activate the stroboscope effect using the UP and DOWN
buttons and adjust the flash frequency from 00 to 99 (FLASH:00 = strobe
deactivated, FLASH: 01 = approx. 1 Hz, FLASH: 99 = approx. 20 Hz).
Confirm with ENTER.
COLOUR CHANGE
Rate SPEED:00 - SPEED:99
STROBOSCOPE
Flash frequency FLASH:00 - FLASH:99
8
9
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
FRANCAIS FRANCAIS FRANCAIS FRANCAIS
DEUTSCH
ENGLISH

OPERATION:
COLOUR BLENDING
In the colour fade mode (fading mode) different colours are blended into one
another in succession. The speed of the program is adjustable separately and
a stroboscope effect can also be activated.
Press the MODE button until "FADING" appears in the upper line of the
display. Now, press ENTER until the cursor appears in the lower line of the
display, and then select the rate (SPEED) using the UP and DOWN buttons,
with the colours alternating from 00 to 99.
Confirm with ENTER. The indicator in the bottom line of the display changes
to "FLASH:xx". At the same time, the cursor will appear in the bottom
line and you can activate the stroboscope effect using the UP and DOWN
buttons and adjust the flash frequency from 00 to 99 (FLASH:00 = strobe
deactivated, FLASH: 01 = approx. 1 Hz, FLASH: 99 = approx. 20 Hz).
Confirm with ENTER.
COLOUR BLENDING
Rate SPEED:00 - SPEED:99
STROBOSCOPE
Flash frequency FLASH:00 - FLASH:99
AUTO MODE
Press the MODE button repeatedly until "AUTO MODE" appears on the
display. In this operating mode, the light switches automatically between
colour change and colour blending mode. The colour change and/or colour
blending rate is determined by the settings of the respective mode. A
stroboscopic effect cannot be activated.
SLAVE MODE
Press the MODE button repeatedly until "SLAVE MODE" appears on the
display. Connect the slave and the master unit (same model) with a DMX
cable. Now the slave unit follows the master unit.
10
11
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO

OPERATION:
MUSIC CONTROL
Press the MODE button until "SOUND" appears in the upper line of the
display. Now the projector is controlled by the built-in microphone and
follows the beat of the music. To adjust the microphone sensitivity, press
ENTER, and the cursor appears in the lower line of the display (SENS:xx)
and use the UP and DOWN buttons to set the desired value from 00 to 31
(SENS:00 = minimum sensitivity, SENS:31 = maximum sensitivity). Confirm
with ENTER.
SELECTING DMX MODE
Press the MODE button repeatedly until "DMX MODE" appears in the upper
line of the display. Press ENTER, and the cursor appears in the lower line
of the display and then use the UP and DOWN buttons to select one of the
five DMX modes (02CH, 03CH1, 03CH2, 06CH, 09CH). Confirm with ENTER.
You will find tables with the channels of the different DMX modes on the
following pages of this manual.
DMX START ADDRESS
Press the MODE button repeatedly until "DMX ADDR" appears in the upper
line of the display. Press ENTER, and the cursor appears in the lower line
of the display and then use the UP and DOWN buttons to select the desired
DMX start address between 001 and 512. Confirm with ENTER.
NOTE: The illumination of the LC display switches off automatically after
approx. 70 seconds of inactivity. Pressing any one of the 4 control buttons
will turn the illumination of the LC display on again.
10
11
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
FRANCAIS FRANCAIS FRANCAIS FRANCAIS
DEUTSCH
ENGLISH

DMXCONTROL:
2-CHANNEL MODE
CHANNEL VALUE FUNCTION
CH1 000 - 255 Master Dimmer (0 - 100%)
CH2
000 - 255 Colour Macros:
000 - 016 Red
017 - 033 Green
034 - 050 Blue
051 - 067 White
068 - 084 Amber
085 - 101 UV
102 - 118 Yellow
119 - 135 Cyan
136 - 152 Lavender
153 - 169 Light Green
170 - 186 Magenta
187 - 203 Turquoise
204 - 220 Orange
221 - 237 Cool White
238 - 255 Warm White
12
13
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO

DMXCONTROL:
3-CHANNEL MODE 1
CHANNEL VALUE FUNCTION
CH1 000 - 255 Master dimmer (0 - 100%)
CH2 000 - 255 Stroboscope (rate 0 - 100%)
CH3
000 - 080 Colour Macros:
000 - 004 Blackout
005 - 010 Red
011 - 015 Green
016 - 020 Blue
021 - 025 White
026 - 030 Amber
031 - 035 UV
036 - 040 Yellow
041 - 045 Cyan
046 - 050 Lavender
051 - 055 Light Green
056 - 060 Magenta
061 - 065 Turquoise
066 - 070 Orange
071 - 075 Cool White
076 - 080 Warm White
081 - 150 Colour Change (rate)
151 - 220 Colour Blending (rate)
221 - 255 Music Control (microphone sensitivity)
12
13
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
FRANCAIS FRANCAIS FRANCAIS FRANCAIS
DEUTSCH
ENGLISH

DMXCONTROL:
3-CHANNEL MODE 2
CHANNEL VALUE FUNCTION
CH1 000 - 255 Red (0 - 100%)
CH2 000 - 255 Green (0 - 100%)
CH3 000 - 255 Blue (0 - 100%)
6-CHANNEL MODE
CHANNEL VALUE FUNCTION
CH1 000 - 255 Red (0 - 100%)
CH2 000 - 255 Green (0 - 100%)
CH3 000 - 255 Blue (0 - 100%)
CH4 000 - 255 White (0 - 100%)
CH5 000 - 255 Amber (0 - 100%)
CH6 000 - 255 UV (0 - 100%)
14
15
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO

DMXCONTROL:
9-CHANNEL MODE
CHANNEL VALUE FUNCTION
CH1 000 - 255 Master Dimmer (0 - 100%)
CH2 000 - 255 Stroboscope (rate 0 - 100%)
CH3 000 - 255 Red (0 - 100%)
CH4 000 - 255 Green (0 - 100%)
CH5 000 - 255 Blue (0 - 100%)
CH6 000 - 255 White (0 - 100%)
CH7 000 - 255 Amber (0 - 100%)
CH8 000 - 255 UV (0 - 100%)
CH9
000 - 080 Colour Macros:
000 - 004 Blackout / Colour Mixing CH3 - CH8
005 - 010 Red
011 - 015 Green
016 - 020 Blue
021 - 025 White
026 - 030 Amber
031 - 035 UV
036 - 040 Yellow
041 - 045 Cyan
046 - 050 Lavender
051 - 055 Light Green
056 - 060 Magenta
061 - 065 Turquoise
066 - 070 Orange
071 - 075 Cool White
076 - 080 Warm White
081 - 150 Colour Change (rate)
151 - 220 Colour Blending (rate)
221 - 255 Music Control (microphone sensitivity)
14
15
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
FRANCAIS FRANCAIS FRANCAIS FRANCAIS
DEUTSCH
ENGLISH

16
17
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
DMX CONNECTION:
DMX-512
DMX (Digital Multiplex) is the name of a universal transmission protocol for communication between
corresponding devices and controllers. A DMX controller sends DMX data to the connected DMX device(s).
The DMX data is always transmitted as a serial data stream that is forwarded from one connected device to
the next via the "DMX IN" and "DMX OUT" connectors (XLR plug-type connectors) that are found on every
DMX-capable device. (Most controllers only have a DMX output.)
DMX CONNECTION:
DMX is the common "language" via which a very wide range of types and models of equipment from
various manufacturers can be connected with one another and controlled via a central controller, provided
that all of the devices and the controller are DMX-compatible. For optimum data transmission, it is
necessary to keep the connecting cables between the individual devices as short as possible. The order in
which the devices are integrated in the DMX network has no influence on addressing. Thus the device with
the DMX address 1 can be located at any position in the (serial) DMX chain: at the beginning, at the end
or somewhere in the middle. If the DMX address 1 is assigned to a device, the controller "knows" that it
should send all data allocated to address 1 to this device regardless of its position in the DMX network.
The Adam Hall 3 STAR, 4 STAR, and 5 STAR product ranges include an extensive selection of suitable
cables.
SERIAL CONNECTION OF MULTIPLE LIGHTS
1.) Connect the male 3-pole XLR connector of the DMX cable to the DMX output (female 3-pole socket) of
the first light or other DMX device.
2.) Connect the female 3-pole connector of the DMX cable connected to the first light to the DMX input
(male 3-pole socket) of the next DMX device. In like manner, connect the DMX output of this device to the
DMX input of the next device and repeat until all devices have been connected.
Please note that as a rule, DMX devices are connected in series and connections cannot be shared without
active splitters.

16
17
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
FRANCAIS FRANCAIS FRANCAIS FRANCAIS
DEUTSCH
ENGLISH
DMX CABLE:
NOTE:
• When fabricating your own cables, always observe the illustrations on this page. Never connect the shielding
of the cable to the ground contact of the plug, and always make certain that the shielding does not come into
contact with the housing of the XLR plug. If the shielding is connected to ground, this can lead to short-circuiting
and system malfunctions.
PLEASE NOTE: TERMINATION:
• With extended cable runs, the last device in the chain may require a terminating resistor in order to prevent
system malfunctions.
This is achieved by using a cable terminator module (Product No. K3DMXT3).
• Some manufacturers use 5-pole versions for data transmission instead of 3-pole XLR plugs. However, devices
with 5-pole XLR connectors can also be integrated in a DMX network with 3-pole XLR connectors. In this case,
a suitable cable adapter is required. The following illustration shows the correct pin-out of the corresponding
plugs.
Use of a terminating resistor (termination)
reduces interference and other problems during
signal transmission. It is always advisable to
connect a DMX termination module (resistance
120 ohms, 1/4 W) between pole 2 (DMX-) and
pole 3 (DMX+) of the last device in the chain.
Usual connection
DMX-512 output
3-pole XLR
DMX-512 input
3-pole XLR
5-pole XLR(socket)
Pole 1: Ground
(shielding)
Pole 2: Signal (-)
Pole 3: Signal (+)
Pole 4: unused
Pole 5: unused
5-pole XLR(socket)
Pole 1: Ground
(shielding)
Pole 2: Signal (-)
Pole 3: Signal (+)
Pole 4: unused
Pole 5: unused
3-pole XLR(socket)
Pole 1: Ground
(shielding)
Pole 2: Signal (-)
Pole 3: Signal (+)
3-pole XLR(socket)
Pole 1: Ground
(shielding)
Pole 2: Signal (-)
Pole 3: Signal (+)

SPECIFICATIONS:
Model Name: CLPST64RGBWAU12W
Product Type: LED PAR can
Type: PAR 64 Can
Colour Spectrum: RGBWA+UV
Number of LEDs: 12
LED Type: 12 W 6-in-1
Refresh Rate: 3000 Hz
Dispersion Angle: 25°
DMX Input: 3-pin XLR male
DMX Output: 3-pin XLR female
DMX Mode: 2-channel, 3-channel 1, 3-channel 2, 6-channel,
9-channel
DMX Functions: colour change, colour blending, music control,
stroboscope, RGBWAU
Standalone Functions: colour change, colour blending, music control,
stroboscope, static colours, colour macros, master/
slave operation
Controls: Mode, Enter, Up, Down
Indicators: lit LC Display
Operating Voltage: 100 - 240 V AC / 50 - 60 Hz
Power Consumption: 55 W
Power Connector: Neutrik powerCON input and output
Fuse: F2AL / 250 V
Housing Material: cast metal
Housing Colour: black
Housing Cooling: fan
Dimensions (W x H x D, excluding bracket): 230 x 220 x 255 mm
Weight: 4.5 kg
Other Features: 1m power cable with Neutrik PowerCon and Schuko
plug included, double bracket included
18
19
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO

18
19
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
FRANCAIS FRANCAIS FRANCAIS FRANCAIS
DEUTSCH
ENGLISH
MANUFACTURER´S DECLARATIONS:
MANUFACTURER‘S WARRANTY
This warranty extends to the CAMEO branded product you purchased from Adam Hall.The statutory warranty rights
against the vendor shall not be affected by this warranty. Rather, this warranty gives you additional independent
claims against Adam Hall.
With this warranty, Adam Hall ensures that products you have purchased from Adam Hall or Adam Hall partners,
under normal use, are free of defects in material or workmanship for a period of 2 years from the date of purchase.
The warranty period begins on the date of purchase. In order to assert a claim for warranty service, the proof of
date of purchase is provided by the receipt bearing the date of purchase or the date of purchase on the delivery
note. You are entitled to warranty service under the conditions and provisions set out in this document, if a repair
within the warranty period is required.
This warranty applies only to the original purchaser of the products supplied by Adam Hall and is not transferable
to any person to whom the property is transferred by the original purchaser.
Within the warranty period, the defective parts or the product from Adam Hall will be repaired or replaced. Under
the terms of this warranty, all the replaced or removed components become the property of Adam Hall.
In the unlikely event that a product acquired from Adam Hall, repeatedly exhibits a defect, Adam Hall may decide,
at its discretion, to replace this product with a comparable product of at least the same performance.
Adam Hall does not guarantee that the operation of this product will be uninterrupted or error-free. Adam Hall
accepts no responsibility for any damage due to incorrect compliance with the instructions received in the delivery.
This warranty does not extend to:
- wearing parts (eg battery, tubes).
- devices that have had their serial number removed or damaged, or failed as a result of an accident
- inappropriate or abusive use or other external causes
- devices that were not used in accordance with the operating parameters defined in the user documentation
shipped with the product
- devices that have been repaired using parts not made or distributed by Adam Hall
- devices that have been serviced, modified or repaired by someone other than Adam Hall or an authorised service partner.
These terms and conditions constitute the complete and exclusive warranty agreement between you and Adam
Hall regarding the Adam Hall branded product you have purchased.
This warranty is valid only within Europe. Outside of Europe please contact our official distributors.

20
21
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
MANUFACTURER´S DECLARATIONS:
LIMITATION OF LIABILITY
If your Adam Hall branded hardware product fails to work as warranted above, your sole and exclusive remedy
shall be repair or replacement. Adam Halls’ maximum liability under this limited warranty is expressly limited to
the lesser of the price you have paid for the product or the cost of repair or replacement of any components that
malfunction under conditions of normal use.
Adam Hall is not liable for any damages caused by the product or the failure of the product, including any lost
profits or savings or special, incidental, or consequential damages. Adam Hall is not liable for any claim made by
a third party or made by you for a third party.
This limitation of liability applies whether damages are sought, or claims are made, under this Limited Warranty
or as a tort claim (including negligence and strict product liability), a contract claim, or any other claim, and
cannot be rescinded or changed by anyone. This limitation of liability will be effective even if you have advised
Adam Hall or an authorized representative of Adam Hall of the possibility of any such damages, but not, however,
in the event of claims for damages in connection with personal injuries.
This manufacturer‘s warranty grants you specific rights; depending on jurisdiction (nation or state), you may be
be entitled to additional claims. You are advised to consult applicable state or national laws for a full determina-
tion of your rights.
REQUESTING WARRANTY SERVICE
To request warranty service for the product, contact Adam Hall or the Adam Hall authorized reseller from which
you purchased the product.
EC DECLARATION OF CONFORMITY
The equipment marketed by Adam Hall complies (where applicable) with the essential requirements and other
relevant specifications of Directives 1999/5/EC (R&TTE), 2004/108/EC (EMC) und 2006/95/EC (LVD). Additional
information can be found at www.adamhall.com.
