Camlab Lovibond MD 610 User manual

Photometer
1
Instruction manual
GB
Lovibond®Water Testing
Tintometer®Group
www.lovibond.com
Distributed By:
Camlab Limited
Camlab House, Norman Way Industrial Estate, Over, Cambridge CB24 5WE, UK
E: [email protected]
T: [phone]

Important stepsbefore usingthe photometer
Pleasecarryout the following stepsasdescribedin the
Instruction manual. Becomefamiliar with your new pho-
tometer before starting with the rst tests:
• Unpacking and inspection of deliverycontents,
seepage 358.
• Installthe batteries, seepage302 and following.
Performthe following settingsin the Mode-Menu;
Instructionmanualfrom page315 and following:
• MODE10: selectlanguage
• MODE12: setdate and time
• MODE 34: perform “Delete data“
• MODE 69: perform “Userm. init” to initialisethe
user polynomial system
If required setother functions.
