Camoga C 420 User manual

D U P L I C A T E
Leather
Splitting
Machine
Model C 420
Instruction Manual
Serial No. .......................
20161 Milano  Via Oroboni, 27
Tel. [phone]  Fax [phone]
site www.camoga.com e-mail [email protected]
S.p.A.

D U P L I C A T E
0
Important
Warnings
Important Warnings  0-1
The machine is provided with guards and safety devices to prevent accidents.
In any case, due to the presence of moving components and of a very sharp knife, pay
utmost attention while using and servicing the machine.
 KEEP TO THE INSTRUCTIONS FOR INSTALLATION AND
USE.
 DO NOT REMOVE OR VIOLATE THE GUARDS.
 THE MAINTENANCE MUST BE CARRIED OUT BY
SPECIALISTS WITH MAXIMUM CAUTION.
 DO NOT CLEAN OR LUBRICATE MOVING COMPONENTS
WITH THE MACHINE ON.
 KEEP TO THE SAFETY REGULATIONS WHEN CHECKING
AND/OR REPAIRING ELECTRICAL PARTS.
 CARRY OUT SETTING, SERVICING AND REPAIR WORK
WITH SWITCH QS1 IN OFF POSITION.
 FOR SERVICING AND SETTING DISABLE THE SAFETY
MICROSWITCHES BY MEANS OF KEY SWITCH SA1 AND
START THE MACHINE TO HAVE THE KNIFE,THE GRIND-
ING STONES AND THE EMERY DUST EXHAUSTOR.
OPERATING. DURING THIS OPERATION, TO BE CARRIED
OUT BY AN AUTHORI ED SPECIALIST, RED LAMP HL1
(FIG. 1 AND 2) LIGHTS.
 USE SUITABLE TOOLS.
 USE THE INDIVIDUAL PROTECTION MEANS EXACTED BY
THE ACCIDENT PREVENTION REGULATIONS.
Basic Rules

D U P L I C A T E
Safety Rules
or a safe and suitable use of the machine it is necessary to always keep to the
accident prevention regulations.
- Periodically check for the perfect working order of all safety devices (protections,
safety interlocks, emergency).
THE SA ETY DEVICES MUST NEVER BE VIOLATED OR REMOVED.
- Make sure that the staff assigned to work on the machine is adequately trained.
- Make sure that the staff assigned to service the machine is adequately trained.
- The work place must be kept clean and efficient, do not lean any tool on the ma-
chine.
- or cleaning and servicing operations always consult this instrucions manual; in
case of doubts or to get explanations contact the Camoga assistance service.
If You Have Problems
You do not manage to solve with the help of this instruction manual apply to our
authorized dealer or directly to Camoga S.p.A., phone [phone], fax 0039-
26454007, e-mail [email protected].
To avail yourself of Camoga's after sales service fill in and mail the Warranty in-
cluded in this manual.
Important Warnings  0-2

D U P L I C A T E
Scope of the Manual
This manual permits both to new and to expert users to save time, to improve their
experience and to take maximum advantage of the machine features.
The manual is conceived for a rapid retrieval of the required information.
The manual contains
 Lists with an initial point containing information without specific sequence
 Lists with progressive numbers containing the instructions for a given procedure.
Important Warnings 0-3
Advices
Attentively read at least the fundamental chapters of the instruction manual. Even if
you are expert in the use of splitting machines, you will thus know all the features of
the C 420 splitter and achieve its best performance.
 Make sure that the service personnel is perfectly trained on model C 420.
 Program in time the persons and material for routine and emergency maintenance.
You will avoid loss of time and delays.
 Use only original Camoga spare parts.
 Very often a non-ideal performance is due to inadequate or poor quality material.
Warranty
To benefit from the warranty and from the after sales service fill in and mail the
Warranty included in the instruction manual.

D U P L I C A T E
Contents
Contents S1
0 : Important Warnin s 0-1
Basic Rules 0-1
Safety Rules 0-2
If You Have Problems 0-2
Scope of the Manual 0-3
Advices 0-3
Warranty 0-3
1 : Description 1-1
Welcome to C 420 1-1
Specification 1-2
Machine Dimensions 1-2
Noise Level 1-3
Machine Version 1-4
Accessories 1-5
Attachments 1-5
Outfit 1-5
2 : Machine Purpose 2-1
Machine Purpose 2-1
3 : Handlin and Transportation 3-1
Transportation 3-1
Warnings 3-1
4 : Installation 4-1
Machine Installation 4-1
Preliminary Checks for Electrical Connection 4-2
Connecting to the Mains 4-2
5 : Preparation for Start-up 5-1
Preliminary Operations and Cleaning 5-1
6 : Operation 6-1
Preliminary Checks 6-1
Push-button unctions 6-2
Alarm and Message Display C 420 R 6-3
Alarm and Message Display C 420 L-X 6-4
Starting 6-5
Sharpening with Corundum Stones 6-6
Dressing 6-6
Bevel Symmetry 6-6
Sharpening with Diamond Stones 6-7
Dressing 6-7
Bevel Symmetry 6-7

D U P L I C A T E
Setting the Splitting Thickness 6-8
Setting the Bottom eed Roll 6-8
Bottom Roll Position Adjustment 6-8
Setting the Bottom eed Roll Pressure 6-8
Top eed Roll 6-9
Steady Guide Bar 6-9
Interchanging Top eed Roll/Steady Guide Bar 6-9
Knurled Bottom eed Roll 6-9
Rubber-coated Bottom eed Roll 6-9
Automatic Incision Device 6-9
Cleaning 6-10
7 : Maintenance and Repair 7-1
Basic Rules 7-2
Replacing the Knife 7-3
Replacing the Grinding Stones 7-4
Replacing the Knife Guide Gibs 7-4
Replacing the Upper Knife Back Guide 7-4
Replacing the Lower Knife Back Guide 7-4
Tensioning the Belts 7-5
Setting the Thickness Readout 7-5
Interchanging the Botto Knurled Feed Roll/Rubber-coated Feed Roll 7-5
Scrap Exhaustor 7-5
Emery Dust Exhaustor 7-6
Routine Maintenance 7-6
Troubles: Causes and Remedies 7-7
Trouble Shooting 7-7
Electrical Troubles C 420 R 7-8
Electrical Troubles C 420 L / C 420 X 7-9
Electrical Troubles C 420 L / C 420 X 7-10
8 : Glossary 8-1
9 : Parts List 9-1
When ordering spare parts 9-1
Spare parts list 1 - 2 - 3 - 5 - 6 - 7 - 9 9-2
Spare parts list 10 - 11 - 12 - 13 - 14 - 15 9-3
Accessories - Options 9-4
C 420 Instruction Manual
This manual is of Camoga's exclusive property. No part of the manual may be repro-
duced without prior written permission by Camoga S.p.A.
Camoga S.p.A. reserve the right of modifying the contents of the manual at any time
without notice.
Copyright © Camoga S.p.A. 2007. All rights reserved.
Contents S2
A
?

D U P L I C A T E
Before using the C 420 splitter attentively read this chapter.
It specifies the contents of the supply, describes the use of the machine and gives
many other useful information.
 Welcome to C 420
Congratulations! You have purchased the Camoga C 420 splitter, a technologically
advanced machine that permits an easy, accurate and economic ork.
If this is your first splitter, you have made an excellent choice.
The machine is very simple in use and does not need complex servicing and mainte-
nance.
To an experienced user the technical features of the machine assure an optimum and
multipurpose use and a ne quality standard.
The C 420 splitter is provided ith an endless band knife running on t o heels, a
grinding unit (par. 6-5) hich continuously sharpens the knife, a scrap exhaustor (par.
7-5), a scrap dust filter (par. 7-5), an emery dust filter (par. 7-6) and a stock feed roll
(par. 6-8).
THE C 420 SPLITTER CONFORMS TO THE DIRECTIVES:
98/37/EEC
73/23/EEC
89/336/EEC
Description 1-1
1
Description
Welcome

D U P L I C A T E
Description 1-2
Specification
Working idth 420 mm
Working height 1010 mm
Knife dimensions 0.7x50x3500 mm
Splitting thickness ith driven top roll from 0.6 to 8.0 mm
Splitting thickness ith steady guide bar from 0.2 to 8.0 mm
Minimum thickness increments 0.10 mm
Po er installed 3.5 kW max
Weight 680 kg
Dimensions
1100
1230
1600
1080 450

D U P L I C A T E
Acousting Features C 420
Standards
The acoustic tests have been carried out in conformity ith DLgs 277 and ISO 230-5
to measure the data required by the EEC directive 89/392 CEE.
Operative Conditions
For lack of specifications covering the machine operative conditions the tests have
been carried out according to the average values of normally applied standards.
Noise level dB(A) measured hile the machine is on ork and its dosimetry on
operator are lo er of 73 dB(A).
Description 1-3
Noise Level
OPERATOR

D U P L I C A T E
C 420 R
 Electric version ith alarms display
 Automatic knife shifting and positioning
 4 electric-mechanical feed speeds (2-2) 6, 10, 15, 22 m/min.
 Digital splitting thickness readout
 Driven top feed roll (accessory)
 Bottom steel feed roll
 Steady guide bar
 Bottom feed roll pressure mechanical setting
C 420 L
 Electronic version by microprocessor ith Touch Screen alfanumencal display
sho ing machine status (anomalies messages, alarms, instructions for proper
maintenance)
 Automatic knife shifting and positioning
 Feed rate infinitely variable from 5 to 24 m/min.
 Digital displays for splitting thickness, feed speed and toe-split timing
 Driven top feed roll (accessory)
 Automatic incision device
 Bottom steel feed roll
 Steady guide bar
 Bottom feed roll pressure mechanical setting
C 420 X
 Electronic version by microprocessor ith Touch Screen alfanumencal display
sho ing machine status (anomalies messages, alarms, instructions for proper
maintenance)
 Automatic knife shifting and positioning
 Feed rate infinitely variable from 5 to 24 m/min.
 Digital displays for splitting thickness, feed speed, toe-split timing and orking
pressure
 Driven top feed roll (accessory)
 Automatic incision device
 Bottom steel feed roll
 Steady guide bar
 Bottom feed roll pressure mechanical setting
 Bottom roll controlled positioning
Description 1-4
Versions

D U P L I C A T E
Accessories
 Top feed roll
 Special top feed roll
 Rubber-coated bottom feed roll
 Mechanical thickness gauge
 External electronic thickness gauge Thick-O-Mat
Attachments
 Tooling for equalizing and skiving belts
 Special feed table
 Split-piece remover
Outfit
The supply includes
 Splitter Camoga version C 420 R or C 420 L or C 420 X
 Set of service renches
#1 Allen rench 3
#1 Allen rench 4
#1 Allen rench 5
#1 Allen rench 6
#1 Allen rench 8
#1 Open-end rench 8-9
#1 Open-end rench 10-11
#1 Open-end rench 13-17
#1 Open-end rench 17-19
#1 Scre driver 4x80
#1 Phillips scre driver 4x80
#1 Oiler
#1 Vaseline oil container
 Set of accessories
#1 Cartene machine cover
#1 Steady guide bar
#1 Knife tension adjusting hand heel
 Set of spare parts
#1 Dresser stick for diamond heels
#2 Upper knife back guide
#1 Lo er knife back guide
#2 Knife felts (sets)
#3 Main fuse 16A
 1 Instruction manual ith electrical and/or electronic diagrams
 1 Test certificate
 1 Warranty
 1 EEC conformity declaration
Description 1-5
Outfit
Accessories
and
Attachments

D U P L I C A T E
The C 420 splitter has been designed for the purpose of equalizing and reducing the
thickness of leather and similar materials (fo example false leather, salpa, regener-
ated materials). The stock maximum hardness must be < / = 90 SHORE-A.
The machine is mainly used in shoe factories, leathergoods industries and belt
production.
It can split stock up to a maximum idth of 410 mm and a maximum thickness of 8
mm at the origin, do n to a minimum thickness of 0.2 mm.
It can split and skive on pattern or be equipped ith tools to skive and equalize belts
or square pieces (parts of allets, bags and so on).
The use of splitter can be considered adequate only hen you keep to the instructions
contained in this manual and hen the cleaning and servicing operations are follo ed.
The use of different materials ( ith hardness higher than 90 SHORE-A), and of
cutting additives, can be cause of damages and of non compliance ith safety rules.
Machine Purpose 2-1
2
Machine
Purpose

D U P L I C A T E
3
Machine
Handling and
Transportation
Machine Handling and Transportation 3-1
Transportation
Packing features
Palletized case
a) waterproof walls
b) machine co er made of cartene
c) antioxidati e VCI paper
d) metal parts coated with rust pre enter CASTROL RUSTILO DW
Palletized crate
 same as palletized case except item a) and c).
Pallet
 same as palletized case except item a) and c).
Unpacking
 do not throw away the cartene co er (to be used during shutdown periods).
 remo e the fixing bolts.
 to remo e the pallet hoist the machine in front by a fork lift.
The machine weights about 700 kgs.
Warnings
 Do not lea e the machine outdoors.
 Handle with caution.
 To hoist the machine use a fork lift in front.
The machine weights about 700 kgs.
 Remo e the protecti e paper and packing only at the moment of installation.

D U P L I C A T E
Installation 4-1
4
Installation
Machine Installation
 Keep to the safety regulations.
 Do not remo e or tamper the guards and safety de ices.
-Finger guard PPD on feed table PEM (fig. 1)
-Upper co er plate C1 (fig. 1)
-Co er plate C2 C3 C4 C5 (fig. 1)
-Safety switches SQ1-SQ2-SQ3 (fig. 2)
-Grinding stone belt guard PCM (fig. 1)
-Grinding stone guard PM (fig. 1)
-LH lower knife guard PLM1 (fig. 1)
-Central lower knife guard PM-PCM-PLM2 (fig. 1)
-RH upper knife guard PLM3 (fig. 1)
-Rear co er plate PPC (fig. 1)
ATTENTION: DO NOT TAMPER THE MACHINE
 Make sure that the floor is le el. Pro ide for correct earthing by means of terminal
PE.
 Make sure that scrap dust filter bag SPS (fig. 1) and emery dust filter bag SPA (fig.
1) are mounted.
 Make sure that scrap pan CS (fig. 1) is fitted.

D U P L I C A T E
Installation 4-2
Electrical
Connection
ATTENTION
Execute the hereafter listed operations before connecting the machine to the power
supply.
Preliminary Checks.
Make sure that the mains oltage copes with the oltage quoted on the data plate
located near the cable entry in the back of the machine.
The permissible tolerance on rating is +/- 5%.
Out of this tolerance the proper operation of the functions is no longer guaranteed.
Make sure that there is no moisture in the switch cabinet.
Connecting to the Mains
 Connect the machine by means of its own power supply cable (4 x 2.5 mm2) with
plug to the EEC prescription.
 For the protection of the connection use a circuit breaker, min. breaking capacity
15 kA with min. current 25A for 200 - 254 V ac, 20A for 380 - 440 V ac.
IN CASE OF DAMAGE TO OR REPLACEMENT OF THE
POWER SUPPLY CABLE OR ANY OTHER ELECTRICAL
COMPONENT ANY GUARANTEE AND LAW
RESPONSABILITY IS INVALIDATED.

D U P L I C A T E
5
Preparation for
Start-up
Preliminary Operations and Cleaning
 Remo e the protecti e paper.
 Make sure that the transportation has not caused any damage to the machine.
 Release upper counterweights DS (fig. 1) and check nylon cord FL (fig. 1) for
correct winding on the pulley.
 Remo e central co er plate C3 (fig. 1) and fasten lower counterweight D; check
the nylon cord for correct winding on the idler (fig. beside).
 Make sure that scrap pan CS (fig. 1) is correctly fitted.
 Cleaning
1 Remo e guide plate guard (fig. 1)
2 Remo e the ball pins AG (fig. beside)
3 Remo e upper guide plate PAS (fig. 1)
4 Clean upper guide plate PAS (fig. 1) and all the machine surfaces coated with
grease
5 To remount the plate proceed in re erse order
6 Release upper knife back guide wedges CUS by remo ing knob P4 (fig. 1)
7 Fasten counterweights DS (fig. 1) and check nylon cord FL for correct winding on
the pulleys
8 Release lower counterweight D by loosening knob P6 (fig. beside)
Carefully clean the knife surfaces and the knife wheel contact surface; remo e the
protecti e lubricant.
Mount feed table PEM (fig. 1) and fasten with knobs P3.
Preparation for Start-up 5-1
P6
D
AG

D U P L I C A T E
Operation 6-1
6
Operation
Preliminary
Checks
Emergency switch SB1 (fig. 1 and 2), is pro ided with mechanical lock.
Release by pulling the red push-button outwards.
Make sure that no damage has been caused to the machine and the electrical system
by transportation.
Make sure that main switch QS1 (fig. 2), is in OFF position.
After the checks and connections described in par. 4-2 connect the plug and close
main switch QS1 (fig. 2).
Digitals readouts shall light on on control panel.
The alphanumeric display PH1 shall light and display "Camoga".
Depress white push-button SB3 (par. 6-2) and check the knife for correct direction
of rotation (clockwise). If wrong interchange the leads in the plug.

D U P L I C A T E
Operarion 6-2
Push-Button
Functions
PH1 Alarm display
PN1 Digital thickness readout
SA1 Key switch. Disables safety microswitches for maintenance
SB2 Stop
SB3 Start. Low feed rate
SB4 Start. High feed rate
PH1 Alarm display
PN1 Digital thickness readout
PN2 Digital feed speed readout
PN3 Digital incision readout
RP1 Feed rate ariation
RP3 Incision length ariation
SA1 Key switch disables safety microswitches for maintenance
SB2 Stop
SB3 Start
SB4 Automatic incision, toe split
PH1 Alarm display
PN1 Digital thickness
PN1 Digital thickness readout
PN2 Digital feed speed readout
PN3 Digital incision readout
RP1 Feed rate ariation
RP3 Incision length ariation
SA1 Key switch disables safety microswitches for maintenance
SB2 Stop
SB3 Start
SB4 Automatic incision, toe split
PN1
C 420 R
PN1
RP1 RP3
5.5
5.5
SB2 SB3 SB4 SA1
SB2
SB3 SB4
5.5 5.5
SA1PN2
CAMOGA
C 420 L
PN3
PH1
CAMOGA
PH1
OIII
O
I
CAMOGA
C 420 X
PH1
PN1
RP1 RP3
5.5
SB2
SB3 SB4
5.5 5.5
SA1PN2 PN3
O
I

D U P L I C A T E
Alarm and
Message
Display
C 420 R
Operation 6-3
C 420 R
Alarm and Message Display
The machine stops immediately in the case of emergency or opening of co er plate
during operation or o erheating of a motor or scrap wrapped on the feed roll.
The machine does not stop if knife used up, scrap pan full, scrap pan filter clogged
is signalled.
On the other hand while machine signalling knife used up, scrap pan full, scrap pan
filter clogged, it continues working and will not stop.
When a danger or alarm occurs, the following messages are displayed:
-Emergency pedal
-Safety barriers
-Scrap on feed roll
-Electronic thermal cut-out FT1
-Electronic thermal cut-out FT2
-Electronic thermal cut-out FT3
-Electronic thermal cut-out FT4
-Electronic thermal cut-out FT5
-Knife used up
While alarm or warnings are displayed it is possible by means of OK push button, to
get further messages useful for locating and sol ing.
The number disappears as soon as the cause of alarm is eliminated.
When the machine operation is OK, the alphanumeric display (par. 6-2) shows the
word "Camoga".
You can act on the below buttons to display further infos
Serial No.
Manufacture date
R code for spare parts
Knife
Grinding wheels
Guide gib
Guide roll
These alarms
cause the
machine to
stop.
When this
message
appears
machine does
not stop.

D U P L I C A T E
Alarm and
Message
Display
C 420 - X
Operation 6-4
C 420 L -X
Alarm and Message Display
The machine stops immediately in the case of emergency or opening of co er plate
during operation or o erheating of a motor or scrap wrapped on the feed roll. The
machine does not stop if knife used up, scrap pan full, scrap pan filter clogged is
signalled.
On the other hand while machine signalling knife used up, scrap pan full, scrap pan
filter clogged, it continues working and will not stop.
When a danger or alarm occurs, the following messages are displayed:
-Emergency pedal
-Safety barriers
-Scrap on feed roll
-Electronic thermal cut-out FT1
-Electronic thermal cut-out FT2
-Electronic thermal cut-out FT3
-Electronic thermal cut-out FT4
-In erter inhibited
-Scrap pan full
-Scrap pan filter clogged
-Knife used up
While alarm or warnings are displayed it is possible by means of OK push button, to
get further messages useful for locating and sol ing.
The number disappears as soon as the cause of alarm is eliminated.
When the machine operation is OK, the touch screen alphanumeric display (par. 6-2)
shows the word "Camoga" and machine model.
You can act on the below buttons to display further infos
LH side display Serial No.
Manufacture date
Software ersion
RH side display Working hours
These alarms
cause machine
stop.
When these
messages
appear the
machine does
not stop.
