Air Line Accessories
Air Tool Accessories
• Thread size: 1/4” Female NPT
• Dual foot air chuck for use in hard-to-reach areas
• 10-120 PSI gauge, calibrated in 2 PSI increments
• Built-in relief valve to reduce pressure in
over inflated tires and to zero gauge
• Includes 12” flexible hose
• Compact design to fit in confined spaces
• Hang-up hook for easy storage
• Includes: safety nozzle, extension nozzle,
rubber tip, inflation adapter, tapered
inflation nozzle, and
inflation needle
• Inflation gun, chuck, and gauge are all combined
in one easy to use unit
• Clip on design enables hands-free chuck use
• Built-in relief valve for reducing pressure in over-
inflated tires
• Includes flexible hose for easier use
• 10-140 PSI gauge
• Use to connect a variety of thread
sizes and shapes
• Thread size: 1/4” Male NPT
• Trigger controls airflow to gun tip
• Narrow 3” extended nozzle easily fits
into confined spaces
• Comfortable, lightweight design
* More sizes available
Lever Safety Blowgun Kit MP5141
Pistol Grip Blowgun MP5143
Ball Foot Chuck MP3233
Air Line Inflator Gauge MP5142
Tire Inflator with Gauge MP6000
Male Coupling MP2118

35
Air Line Accessories
Or call CH Air Tools at: 1- 800-543-6400
Air Tool Accessories
• 360˚ swivel action reduces hose kinking
• 1/4” NPT(M) x 1/4” NPT(F)
• Supplies 2 air tools from 1 source
• Corrosion resistant brass construction
• 1/4” NPT (M) x two 1/4” NPT (F)
• Supplies 3 air tools to 1 source
• Sturdy aluminum construction
• 3/8” NPT (M) x three 1/4” NPT (F)
• Covered quarter-turn handle quickly turns air on or off
• Brass body with steel ball and Teflon® seals for long life
• High capacity airflow design reduces pressure drop to
tools for better performance
• Includes adapters to install on air compressors with
3/4” NPTF ports
• Reduces down to 3/8” NPTF
• Use to adapt a variety of thread sizes and shapes
• Thread size: 1/4” Male NPTx 3/8” Male NPT
• Threaded end connects to tools, fittings, couplers, or plugs
• Corrosion resistant brass construction
• Hose barb repairs or assembles damaged or bulk hose
• Secure fittings with properly crimped ferrules
or hose clamps
• 1/4” x 1/4” Female
* More ball valves available
* More sizes available
* More sizes available
Campbell Hausfeld offers a complete line of quality
accessories to properly install and maintain an air system.
In addition, many air tool acessories are offered to get the
most out of every tool. The following is a brief overview
of CH accessories. For a complete listing, please
visit www.chpower.com.
Compressor Shut-Off Kits PA1170
Swivel Connector MP1038
Tee Fitting PA1040
3-in-1 Air Manifold MP3230
Adapter PA1111
Barbed and Swivel Hose Ends MP3209
Why Accessories?

Visit us online: www.chpower.com
36
Air Line Accessories
Air Tool Accessories
• Repairs damaged air hose
• Includes: (1) hose splicer, (1) hose end, (3)
hose clamps for 3/8” hose
Hose Repair Kits MP3314
• Use on all male threaded connections to prevent
air leaks
• Thicker and denser for better sealing and easier use
• 275” x 1/2”
PTFE Tape MP5136
• 50’ Hose easily expands to full length and
retracts for storage
• 35˚ to 250˚ F working temperature
• 200 PSI maximum working pressure
• 1 Year Limited Warranty
Nylon Recoil Air Hose MP2874
• Includes 50’ x 3/8” air hose
• Mounting plate attaches to any flat surface
• Beveled flanges makes it easier to wind hose
without kinking
Hose Reel PA1194
• Heavy-duty reinforcement
• 0˚ to 130˚ F working temperature
• 300 PSI maximum working pressure
• 1 Year Limited Warranty
PVC Air Hose PA1178
• Removes unwanted dirt particles and condensed water
to extend tool life
• 5 micron element provides maximum filtration
• Metal bowl-guard protects against impacts
• Quick-release bowl and quarter turn drain for easier use
• 57 scfm flow capacity at 90 PSI
• 3/8” NPT(F) ports
Standard Air Filters PA2121
* Also available in 1/4” (MP3214)
* Also available in 25’
* More sizes available

37
Air Line Accessories
MP5148
Or call CH Air Tools at: 1- 800-543-6400
Air Tool Accessories
• Removes unwanted dirt particles and condensed water
to extend tool life
• 5 micron element provides maximum filtration
• Screw-on bowl with manual drain
• 21 scfm flow capacity at 90 PSI
• 1/4” NPT(F) ports
Mini Air Filters MP5138
Dessicant Dryer
• Removes water vapor at the point of use
• Desiccant changes color when it needs to be changed
or recharged
• Outlet screen keeps desiccant particles out of tools
• Oil-removal filter removes 99.9% of all oil aerosols
• Clear bowl with metal guards for easy viewing fluid
level and impact protection
• Quick-release bowl, and quarter turn drain for
easy maintenance
Clean Air System PA2085
Standard Series
• Provides regulated output pressure of 0 to 150 PSI for
proper tool operation
• Self-relieving design vents downstream air flow for
easier adjustment
• Locking pressure knob prevents accidental
pressure changes
• Includes 0 to 160 PSI pressure gauge
• 120 scfm flow capacity @ 90 PSI
• 3/8” NPT(F) ports
Pressure Regulators PA2123
Mini Series
• Provides regulated output pressure of 0 to 125 PSI
for proper tool operation
• Self-relieving design vents downstream air flow for
easier adjustment
• Locking pressure knob prevents accidental
pressure changes
• Includes 0 to 160 PSI pressure gauge
• 15 scfm flow capacity @ 90 PSI
• 1/4” NPT(F) ports
Standard Series
• Provides automatic line lubrication to extend air tool life
• Oil-fog design allows bowl to be filled without
depressurizing system for easier convenience
• 3.5 oz. quick-release bowl and quarter turn drain
provide easier use
• 28 scfm flow capacity @ 90 PSI
• 3/8” NPT(F) ports
Air Lubricators PA2081
• Oil can be used in both air tools and nailers
Pneumatic Tool Lubricant ST1270
* Compressor oil also available

Visit us online: www.chpower.com
38
Air Line Accessories
Air Tool Accessories
Standard Series
• Combines filter and regulator into one unit to save space
• Large capacity metal bowl for use with higher pressure
air compressors
• 52 scfm flow capacity @ 90 PSI
• 3/8” NPT(F) ports
• 250 PSI maximum inlet pressure
• Combines standard series filter (PA2121) and standard series
regulator (PA2123)
Standard Series
• Combines standard series filter, regulator and lubricator
into one unit to save space
• Complete unit comes pre-assembled with modular mounting
bracket for extra convenience
• 3.5 oz. quick-release bowl and quarter turn drain allows
easy maintenance
• 28 SCFM flow capacity @ 90 PSI
• 3/8” NPT(F) ports
Easy-Connect Coupler
• Easy-connect design - simply push plug
into coupler to connect
Easy-Connect Coupler
• Easy-connect design - simply push
plug into coupler to connect
Easy-Connect Coupler
• Easy-connect design - simply push plug
into coupler to connect
Easy-Connect Coupler
• Easy-connect design - simply push
plug into coupler to connect
• Easy-connect design - simply push
plug into coupler to connect
* More sizes available for couplers & plugs
* More sizes available for couplers & plugs
* More sizes available for couplers & plugs
* More sizes available for couplers & plugs
Filter / Regulators PA2125
Filter / Regulators / Lubricators PA2078
1/4” Series Industrial Style MP2883
1/4” Series Aro MP5190
1/4” Series Automotive MP3236
1/4” Series Lincoln BC4084
3/8” Series Automotive PA1013

39
Air Line Accessories
Or call CH Air Tools at: 1- 800-543-6400
Air Tool Accessories
• Set Includes:
(1) Coupler 1/4” NPT(F), (4)
Plugs 1/4” NPT(M)
Universal Design Couplers and Plugs:
• Eliminate coupler confusion
• Fits most popular plug styles including automotive,
industrial and aro
• Easy-connect design - simply push plug into
coupler to connect
• Includes accidental disconnect protection which also
protects the coupler sleeve.
•Accepts 1/4” industrial, automotive
and aro style plugs
•Tubular valve design provides higher
flow rates over conventional blade
style valves
•Heat treated locking balls provide
long life of wear parts
• Easy connect design - simply push plug into coupler to connect
•Brass construction resists corrosion and prevents sparks
• Set Includes:
(1) Coupler 1/4” NPT(F), (2)
Plugs 1/4” NPT(M),
(1) Coupling 1/4” NPT(M),
(1) Coupling 1/4” NPT(F)
• Accepts 1/2” automotive plugs
produced by Campbell Hausfeld
and other manufacturers
• Set Includes:
• Blowgun
• Safety Nozzle
• (2)Tapered Inflation Nozzle
• (2) Inflation Needles
• PTFE Tape
• Rubber Blow Gun Tip
• Female Tire Chuck
• Dual Foot Air Chuck
• Tire Gauge
• Coupler
• (6) Male Plugs
• (2) Male Couplings
• (2) Female Couplings
• (2) Female Plugs
* More coupler sizes available
Industrial Coupler and Plug Set MP2920
1/4” Series Universal MP3335
Automotive Coupler and Plug Set PA1014
1/2” Series 2-in-1 Style BC4107
25 Piece Air Line Accessory Kit MP5200
