Campbell UT30 User manual

UT30 WEATHER STATION
INSTALLATION MANUAL
REVISED: 4/98
COPYRIGHT (c) 1993-1998 CAMPBELL SCIENTIFIC, INC.

WARRANTY AND ASSISTANCE
The UT30 is warranted by CAMPBELL SCIENTIFIC, INC. to be free from defects in materials and
workmanship under normal use and service for twelve (12) months from date of shipment unless specified
otherwise. Batteries have no warranty. CAMPBELL SCIENTIFIC, INC.'s obligation under this warranty is
limited to repairing or replacing (at CAMPBELL SCIENTIFIC, INC.'s option) defective products. The
customer shall assume all costs of removing, reinstalling, and shipping defective products to CAMPBELL
SCIENTIFIC, INC. CAMPBELL SCIENTIFIC, INC. will return such products by surface carrier prepaid.
This warranty shall not apply to any CAMPBELL SCIENTIFIC, INC. products which have been subjected
to modification, misuse, neglect, accidents of nature, or shipping damage. This warranty is in lieu of all
other warranties, expressed or implied, including warranties of merchantability or fitness for a particular
purpose. CAMPBELL SCIENTIFIC, INC. is not liable for special, indirect, incidental, or consequential
damages.
Products may not be returned without prior authorization. To obtain a Returned Materials Authorization
(RMA), contact CAMPBELL SCIENTIFIC, INC., phone [phone]. After an applications engineer
determines the nature of the problem, an RMA number will be issued. Please write this number clearly on
the outside of the shipping container. CAMPBELL SCIENTIFIC's shipping address is:
CAMPBELL SCIENTIFIC, INC.
RMA#_____
815 West 1800 North
Logan, Utah 84321-1784
CAMPBELL SCIENTIFIC, INC. does not accept collect calls.
Non-warranty products returned for repair should be accompanied by a purchase order to cover the repair.
815 W. 1800 N.
Logan, UT 84321-1784
USA
Phone [phone]
FAX [phone]
www.campbellsci.com
Campbell Scientific Canada Corp.
11564 -149th Street
Edmonton, Alberta T5M 1W7
CANADA
Phone [phone]
FAX [phone]
Campbell Scientific Ltd.
Campbell Park
80 Hathern Road
Shepshed, Leics. LE12 9RP
ENGLAND
Phone [phone]
FAX [phone]

I
TABLE OF CONTENTS
PAGE
1. PREPARATION AND SITING.............................................................................................1-1
1.1 Installation Tasks....................................................................................................................1-1
1.2 Tools Required.......................................................................................................................1-1
1.3 Siting and Exposure ...............................................................................................................1-3
1.4 Determining True North for Wind Vane Orientation...............................................................1-5
2. TOWER/TRIPOD INSTALLATION ...................................................................................2-1
2.1 Tower/Tripod Installation
2.2 Sensor Mounting Brackets
3. INSTRUMENTATION INSTALLATION ...........................................................................3-1
3.1 Enclosure, Datalogger, and Power Supply
3.2 Sensor Connection
3.3 Communication and Data Storage Peripherals
3.4 Sealing and Desiccating the Enclosure
4. SENSOR INSTALLATION...................................................................................................4-1
4.1 034A Met One Windset..........................................................................................................4-1
4.2 014A Met One Wind Speed Sensor.......................................................................................4-1
4.3 024A Met One Wind Direction Sensor ...................................................................................4-2
4.4 05103 and 05305 RM Young Wind Monitors .........................................................................4-2
4.5 03001 RM Young Wind Sentry Wind Set...............................................................................4-3
4.6 03101 RM Young Wind Sentry Anemometer.........................................................................4-3
4.7 LI200S Li-Cor Silicon Pyranometer/LI190SB Quantum Sensor.............................................4-4
4.8 107/108 Temperature Probe..................................................................................................4-4
4.9 107B Soil Temperature Probe................................................................................................4-5
4.10 CS500 Vaisala Temperature and RH Probe..........................................................................4-5
4.11 HMP35C Vaisala Temperature and RH Probe.......................................................................4-6
4.12 CS105 Vaisala Barometric Pressure Sensor .........................................................................4-6
4.13 TE525 Texas Electronics Tipping Bucket Rain Gage ............................................................4-7
4.14 CS700-L Rain Gage...............................................................................................................4-7
4.15 SR50 Sonic Ranging Sensor..................................................................................................4-8
4.16 CS615-L Water Content Reflectometer .................................................................................4-8
4.17 237 Leaf Wetness Sensor......................................................................................................4-9
4.18 257 Soil Moisture Sensor .......................................................................................................4-9
4.19 Wind Direction Sensor Orientation.......................................................................................4-10
5. SOFTWARE INSTALLATION.............................................................................................5-1
6. MAINTENANCE AND TROUBLESHOOTING ..............................................................6-1
6.1 Maintenance...........................................................................................................................6-1
6.2 Troubleshooting......................................................................................................................6-2

TABLE OF CONTENTS
II
LIST OF TABLES
3.3-1 Station ID Numbers and Corresponding Switch Settings**..................................................3-12
3.3-2 Station ID Numbers and Corresponding Switch Settings.....................................................3-14
LIST OF FIGURES
2.1-1 UT30 Tower-Based Weather Station .....................................................................................2-1
2.1-2 Top View of Base and Guy Anchor Layout.............................................................................2-1
2.1-3 Foundation for B18 Base........................................................................................................2-2
2.1-4 B18 Concrete Mounting Base.................................................................................................2-3
2.1-5 RFM18 Flat Roof Mounting Base...........................................................................................2-3
2.1-6 UTEYE Eyebolt Guy Anchor...................................................................................................2-3
2.1-7 UTDUK Duckbill Guy Anchor..................................................................................................2-4
2.1-8 Guy Wire Attached to Tower ..................................................................................................2-4
2.1-9 Guy Wire/Turnbuckle Attached to UTEYE Anchor.................................................................2-5
2.1-10 Ground Rod and Clamp..........................................................................................................2-5
2.1-11 Tower Grounding Clamp ........................................................................................................2-5
2.2-1 Top View of Tower..................................................................................................................2-6
2.2-2 019ALU Crossarm and Lightning Rod....................................................................................2-6
2.2-3 UT12VA Gill Radiation Shield and UT018 Crossarm.............................................................2-7
2.2-4 UTLI Leveling Fixture/Crossarm Mount and UT018...............................................................2-7
2.2-5 025 Pyranometer Crossarm Stand.........................................................................................2-7
3.1-1 ENC 12/14 Enclosure on CM6/CM10.....................................................................................3-1
3.1-2 ENC 12/14 Enclosure on UT10..............................................................................................3-1
3.1-3 ENC 16/18 Enclosure on UT30..............................................................................................3-1
3.1-4 21X Mounted Inside of the ENC 12/14 Enclosure..................................................................3-2
3.1-5 21X Alkaline Batteries ............................................................................................................3-2
3.1-6 21XL Rechargeable Batteries.................................................................................................3-3
3.1-7 BPALK 12 Volt Power Supply.................................................................................................3-3
3.1-8 PS12LA 12 Volt Power Supply ............................................................................................... 3-4
3.1-9 MSX10 Solar Panel ................................................................................................................3-4
3.2-1 Routing and Wiring Sensor Leads to the Datalogger.............................................................3-5
3.3-1 SM192/SM716 Storage Module..............................................................................................3-6
3.3-2 DC112 Modem with 6362 Surge Protector.............................................................................3-7
3.3-3 COM100 Cellular Transceiver................................................................................................3-7
3.3-4 SRM-5A and SC932 at Datalogger ........................................................................................3-9
3.3-5 SRM-5A Wiring.....................................................................................................................3-10
3.3-6 RF95 RF Modem and RF100/RF200 Transceiver ...............................................................3-11
3.3-7 RF232 Base Station Installation ...........................................................................................3-13
3.3-8 MD9 Multidrop Interface.......................................................................................................3-13
3.3-9 MD9 Multidrop Interface at the Computer ............................................................................3-15
3.4-1 Enclosure Supply Kit.............................................................................................................3-16
4.1-1 Met One 034A Wind Speed and Direction Sensor.................................................................4-1
4.2-1 Met One 014A Wind Speed Sensor.......................................................................................4-1
4.3-1 Met One 024A Wind Direction Sensor ...................................................................................4-2
4.4-1 05103 RM Young Wind Monitor .............................................................................................4-2
4.5-1 03001 Mounted to the Mast....................................................................................................4-3
4.5-2 03001 Mounted to 019ALU Crossarm....................................................................................4-3
4.6-1 03101 RM Young Wind Sentry Anemometer.........................................................................4-3
4.7-1 LI200S/LI190SB and LI2003S Leveling Fixture......................................................................4-4
4.8-1 107 Temperature Probe .........................................................................................................4-4
4.10-1 CS500 Temperature and RH Probe.......................................................................................4-5
4.11-1 HMP35C Vaisala Temperature and RH Probe.......................................................................4-6
4.12-1 CS105 Vaisala Barometric Pressure Sensor in a Custom Weather Station Enclosure.........4-6
4.12-2 CS105MD Vaisala Barometric Pressure Sensor in a MetData1 Enclosure ...........................4-6
4.13-1 TE525 Texas Electronics Rain Gage.....................................................................................4-7
4.14-1 CS700-L Rain Gage and CM100 Mounting Bracket...............................................................4-7

TABLE OF CONTENTS
III
4.15-1 SR50 Sonic Ranging Sensor..................................................................................................4-8
4.16-1 CS615 Water Content Reflectometer with CS615G Probe Insertion Guide ..........................4-8
4.17-1 237 Leaf Wetness Sensor......................................................................................................4-9
4.18-1 257 Soil Moisture Sensor .......................................................................................................4-9
4.19-1 Magnetic Declination for the Contiguous United States.......................................................4-10
4.19-2 Declination Angles East of True North Are Subtracted From 0 to Get True North...............4-11
4.19-3 Declination Angles West of True North Are Added to 0 to Get True North..........................4-11

1-1
SECTION 1. PREPARATION AND SITING
These guidelines apply to several different Campbell Scientific weather stations.
1.1 INSTALLATION TASKS
1.1.1 INDOORS
• Immediately upon receipt of your
shipment…
⇒ Open shipping cartons.
⇒ Check contents against invoice.
Contact CSI immediately about any
shortages.
• Several days prior to the planned
installation date…
⇒ Collect tools and site information
(Section 1)
⇒ Assemble datalogger, communications
device, and power supply in enclosure
(Section 3)
⇒ Install datalogger support software on
PC (Section 5)
⇒ Establish communications between the
datalogger and the PC (Section 5)
⇒ Program datalogger, test sensors, and
retrieve data (Section 5)
⇒ Trial run the tower / tripod installation,
assembling as much as possible
(Section 2)
⇒ Repackage equipment for transport to
the field site
1.1.2 OUTDOORS
• Locate suitable site (Section 1)
• Prepare tower or tripod base (Section 2)
• Tripod and UT10 (3 meter tower) tower
stations:
⇒ Raise tripod or tower (Section 2)
⇒ Install instrumentation enclosure
(Section 3)
⇒ Install sensors (Section 4)
• UT30 (10 meter tower) tower stations:
⇒ Install 3 to 10 meter level sensors
(Section 4)
⇒ Raise tower (Section 2)
⇒ Install instrumentation enclosure
(Section 3)
⇒ Install 0 to 3 meter level sensors
(Section 4)
• ET101 / ET106 ET Stations:
⇒ Place instrumentation enclosure low on
the ET Tower (Section 3)
⇒ Install sensor option (Section 4)
⇒ Slide enclosure to top of tower and
secure with correct orientation (Section 3)
1.2 TOOLS REQUIRED
Tools required to install and maintain a weather
station are listed below.
1.2.1 TOOLS FOR TOWER INSTALLATION
All Towers
Shovel
Rake
Open end wrenches: 3/8", 7/16", ½",
(2) 9/16"
Magnetic compass
6' Step ladder
CM6/CM10
Tape measure (12')
Level (12" to 24")
Small sledge hammer
Teflon tape or pipe dope
Allen hex wrench (5/64)

SECTION 1. PREPARATION AND SITING
1-2
UT10
Tape measure (12' to 20')
Level (24" to 36")
Pick or digging bar
Claw Hammer
Materials for concrete form:
Hand saw
(4) 12" wood stakes
(1) 2"x 4"x 8' piece of lumber
(8) 8p double-head nails
(8) 16p double-head nails
Concrete trowels
(2) 1 to 1.5" thick x 24" boards
to support base above
forms (optional)
Concrete (0.4 cubic yards)
ET Tower
Tape measure (12’ to 20’)
Claw hammer
Level (24” to 36”)
Hand saw
Materials for concrete form:
(4) 1" x 2" x 12" stakes
(2) 2" x 4" x 96" lumber
(12) 8p double-head nails
(8) 16p double-head nails
20 ft form wire
½ Yard concrete
Concrete trowel, edger
Electrical Fish tape or 20 feet of
small diameter rope
Wheelbarrow
UT30
Tape measure (12' and 20')
Nut driver (3/8")
Level (36" to 48")
Small sledge hammer
Pliers
Tie wire
Climbing harness
Hard hat
Haul rope (50')
Non-stretch line (20')
Wire rope cutters
Materials for B18 Base and UTEYE Anchors:
(4) Wood stakes 12"
Pick or digging bar
Concrete form materials (2"x 4"
lumber, stakes, saw,
hammer, nails, etc.)
Concrete trowel and edger
Materials for UTDUK Duckbill Anchors
Sledgehammer
Highlift jack
Chain (to attach jack to anchor
loops)
Materials for RFM18 Base:
(3) anchors appropriate for
mounting surface
(3) bolts and washers to secure
base to anchors
1.2.2 TOOLS FOR INSTRUMENTATION AND
MAINTENANCE
All Towers
Lock and key for enclosure
Magnetic declination angle (Section 4)
Magnetic compass
Straight bit screwdrivers (small,
medium, large)
Phillips-head screwdrivers (small,
medium)
Small diagonal side-cuts
Needle-nose pliers
Wire strippers
Pocket knife
Calculator
Volt / Ohm Meter
Electrical Tape
Step ladder (6')
Datalogger prompt sheet (Section 6)
Station manuals
Station log and pen
Open end wrenches: 3/8", 7/16", ½", (2)
9/16"
Socket wrench and 7/16" deep well
socket
Adjustable wrench
Pliers
Conduit and associated tools (as
required)
Felt-tipped marking pen
Claw hammer
Pipe wrench (12")
CM6/CM10
Tape measure (12')
Level (12" to 24")
Teflon tape or pipe dope
UT10
Tape measure (12' to 20')
3/8" nut driver
Level (24" to 36")
Teflon tape or pipe dope
(12) ¼" washers (for the 015 Crossarm
stand only)
Allen wrench set

SECTION 1. PREPARATION AND SITING
1-3
UT30
Tape measure (12' to 20')
3/8" nut driver
Level (36" to 48")
Pliers
Climbing harness
Hard hats
50' haul rope
Crescent wrench
Channel-lock pliers
¼" washers (spacers for U-bolts)
5/64" Allen hex wrench
1.2.3 SUPPLIES FOR POWER AND
COMMUNICATIONS OPTIONS
AC Power
Wire, conduit, and junction boxes as
needed
Phone Modem
Hayes compatible calling modem for PC
Phone line to weather station or
junction box
Short-Haul Modem
4 Conductor communications cable
from PC to weather station or
junction box
6' copper ground rod and clamp for PC
surge protection (optional)
1.3 SITING AND EXPOSURE
CAUTION: If any part of the weather
station comes in contact with power lines,
you could be killed. Contact local utilities
for the location of buried utility lines before
digging or driving ground rods.
Selecting an appropriate site for the weather
station is critical in order to obtain accurate
meteorological data. In general, the site should
be representative of the general area of interest,
and away from the influence of obstructions
such as buildings and trees.
The weather station should not be located
where sprinkler irrigation water will strike
sensors or instrument enclosure.
Some general guidelines for site selection are
listed below, which were condensed from EPA
(1988)1, WMO (1983)2, and AASC (1985)3
publications.
1.3.1 WIND SPEED AND DIRECTION
Wind sensors should be located over open level
terrain, and at a distance of at least ten times
(EPA) the height of any nearby building, tree or
other obstruction, as illustrated in Figure 1.3-1.
Standard measurement heights:
3.0 m ± 0.1 m recommended (AASC)
2.0 m ± 0.1 m, 10.0 m ± 0.5 m optional (AASC)
10.0 m (WMO and EPA)
1.3.2 TEMPERATURE AND RELATIVE
HUMIDITY
Sensors should be located over an open level
area at least 9 m (EPA) in diameter. The
surface should be covered by short grass, or
where grass does not grow, the natural earth
surface. Sensors should be located at a
distance of at least four times the height of any
nearby obstruction and at least 30 m (EPA)
from large paved areas. Sensors should be
protected from thermal radiation, and
adequately ventilated.
Situations to avoid include:
• large industrial heat sources
• rooftops
• steep slopes
• sheltered hollows
• high vegetation
• shaded areas
• swamps
• areas where snow drifts occur
• low places holding standing water after
rains
Standard measurement heights:
1.5 m ± 1.0 m (AASC)
1.25 - 2.0 m (WMO)
2.0 m temperature (EPA)
2.0 m and 10.0 m for temperature difference
(EPA)
1.3.3 PRECIPITATION
A rain gage should be sited on level ground that
is covered with short grass or gravel. In open
areas, the distance to obstructions should be
two to four times (EPA, AASC) the height of the
obstruction.
The height of the opening should be as low as
possible, but should be high enough to avoid
splashing from the ground. Wind shields, such
as those used by the National Weather Service,
are recommended for open areas.

SECTION 1. PREPARATION AND SITING
1-4
Collectors should be heated, if necessary, to
properly measure frozen precipitation. The
gage must be mounted above the average level
of snow accumulation in areas that experience
significant snowfall.
Standard measurement heights:
1.0 m ± 1.0 cm (AASC)
30.0 cm minimum (WMO, EPA)
1.3.4 SOLAR RADIATION
Pyranometers should be located to avoid
shadows on the sensor at any time. Mounting it
on the southern most (northern hemisphere)
portion of the weather station will minimize the
chance of shading from other weather station
structures. Reflective surfaces and sources of
artificial radiation should be avoided. The height
at which the sensor is mounted is not critical.
1.3.5 SOIL TEMPERATURE
The measurement site for soil temperature should
be at least 1 m2and typical of the surface of
interest. The ground surface should be level with
respect to the immediate area (10 m radius).
Standard measurement depths:
10.0 cm ± 1.0 cm (AASC)
5.0 cm, 10.0 cm, 50.0 cm, 100.0 cm (WMO)
REGCOMENDED
FeedSENSORS
PortlandOrUSA
Serial27115
REGCOMENDED
FeedSENSORS
PortlandOrUSA
Serial27115
REGCOMENDED
FeedSENSORS
PortlandOrUSA
Serial2711527115
H
10H
10T
Height of tree (T)
FIGURE 1.3-1. Effect of Structure on Wind Flow

SECTION 1. PREPARATION AND SITING
1-5
1.4 DETERMINING TRUE NORTH FOR
WIND VANE ORIENTATION
Magnetic declination, or other methods to find True
North, should be determined prior to installing the
weather station. True North is usually found by
reading a magnetic compass and applying the
correction for magnetic declination*; where
magnetic declination is the number of degrees
between True North and Magnetic North. Magnetic
declination for a specific site can be obtained from a
USFA map, local airport, or through an internet
service called NSSDC CGM (Section 1.4.1). A
general map showing magnetic declination for the
contiguous United States is shown in Figure 1.4-1.
Declination angles east of True North are
considered negative, and are subtracted from 0
degrees to get True North as shown Figure 1.4-2.
Declination angles west of True North are con-
sidered positive, and are added to 0 degrees to get
True North as shown in Figure 1.4-3. For
example, the declination for Logan, Utah is 14.5°
East. True North is 360°- 14.5°, or 345.5°as read
on a compass.
* Other methods employ observations using
the North Star or the sun, and are
discussed in the Quality Assurance
Handbook for Air Pollution Measurement
Systems, Volume IV - Meteorological
Measurements4.
Subtract declination from 360°Add declination to 0°
22 E
18 E
16 E
14 E
12 E
10 E 8 E 6 E 4 E 2 E 02 W
4 W
6 W
8 W
10 W
14 W
12 W
16 W
18 W
20 W
20 E
FIGURE 1.4-1. Magnetic Declination for the Contiguous United States

SECTION 1. PREPARATION AND SITING
1-6
1.4.1 NSSDC CGM SERVICE
The NSSDC CGM (Corrected Geomagnetic)
Service provides an easy way of determining
magnetic declination of a specific site. Since
magnetic declination fluctuates with time, it
should be determined each time the wind vane
orientation is adjusted. It can be accessed on
the world wide web at
http://nssdc.gsfc.nasa.gov/space/cgm/cgm.html
If you know the latitude and longitude of your
site, fill out Form 1as shown below for an
accurate magnetic declination. If you do not
know the latitude and longitude of your site, fill
out Form 2 for estimate of magnetic declination.
Note that longitude is expressed in 0 to 360
degrees east of the Greenwich prime meridian,
and that north latitudes are positive.
Query Form 1: Latitude/Longitude
Latitude/Longitude below specified in:
Geographic
Year (from 1945 to 2000): 1998
Altitude above Earth's surface (km) [from 0.
to 40000.]: 0
Latitude (degrees) [from -90.00 to 90.00]:
42.03
Longitude (degrees) [from 0.00 to 360.00]:
248.15
Query Form 2: Image Map
Year (from 1945 to 2000): 1998
Altitude above Earth's surface (km)
[0. - 40000.]: 0
Click on map to specify location and submit:
(select area on map provided)
A table containing similar information to the
following will be returned after submitting Forms
1 or 2.
Geographic Alt. CGM IGRF Magnetic Field Dipole
Lat. Long. (km) Lat. Long. H(nT) D(deg) Z(nt) Lat. Long.
42.03 248.15 0. 49.80 311.06 20608. 14.417 50505. 49.68 312.14

SECTION 1. PREPARATION AND SITING
1-7
Magnetic declination is bold in this example to
show its location in the table. A positive
declination is east, while a negative declination
is west. The declination in this example is
14.417 degrees. As shown in Figure 1.4-1, the
declination for Logan, UT is east, so True North
for this site is 360 - 14.417, or 345.5 degrees.
FIGURE 1.4-2. Declination Angles East of
True North Are Subtracted From 0 to Get
True North
FIGURE 1.4-3. Declination Angles West of True
North Are Added to 0 to Get
True North
References
1EPA, (1987). On-Site Meteorological Program
Guidance for Regulatory Modeling Applications,
EPA-450/4-87-013. Office of Air Quality
Planning and Standards, Research Triangle
Park, North Carolina 27711.
2WMO, (1983). Guide to Meteorological
Instruments and Methods of Observation.
World Meteorological Organization No. 8, 5th
edition, Geneva, Switzerland.
3The State Climatologist, (1985) Publication of
the American Association of State
Climatologists: Height and Exposure Standards
for Sensors on Automated Weather Stations,
v. 9, No. 4 October, 1985.
4EPA, (1989). Quality Assurance Handbook for
Air Pollution Measurement Systems, EPA Office
of Research and Development, Research
Triangle Park, North Carolina 27711.

2-1
SECTION 2. UT30 TOWER INSTALLATION
2.1 UT30 TOWER INSTALLATION
The UT30 10 meter tower provides a support
structure for mounting the weather station
components. Figure 2.1-1 shows a typical
UT30 equipped with instrumentation enclosure,
meteorological sensors, and solar panel.
2.1.1 TOWER INSTALLATION SAFETY
CONCERNS
WARNING: Tower installation near power
lines is dangerous. The minimum safe
recommended distance from overhead
power lines is 2 times the height of the
tower and mast combined.
When installing the tower, remember:
• DO NOT use a metal ladder
• DO NOT work on a wet or windy day
• DO dress properly−shoes with rubber soles
and heels, rubber gloves, and long sleeves.
2.1.2 BASE AND GUY ANCHOR LAYOUT
1. A guyed UT30 tower requires an area
approximately 17 feet in diameter. Brush and
tall weeds should be removed, otherwise the
natural vegetation and ground surface should
be disturbed as little as possible.
2. Drive a stake where the base of the tower
will be located. Attach a line to the stake
and scribe a circle with a 17 foot radius.
Drive a stake on the scribed line opposite
the direction the tower will hinge for the first
guy anchor location (Figure 2.1-2).
On level ground, lay out the remaining two
anchor locations by measuring 29.5 feet
from the first anchor to the scribed line on
either side of the base stake (Figure 2.1-2).
On unlevel ground, use a compass at the
base stake to lay out the remaining two
anchor locations 120 degrees from the first.
Vary the distance between the tower and
each anchor so that the angle between the
tower and the guy wire will be approximately
30 degrees.
2.1.3 TOWER BASE INSTALLATION
There are two base options: the B18 base is
poured in concrete; the RFM18 roof mount base
is anchored to a flat surface.
2.1.3.1 B18 Base installation
1. Dig a hole 36" square and 48" deep where
the tower base will be located (Figure 2.1-3).
2. Optionalconstruct a concrete form out of
2" x 4" lumber 36" square (inside
dimensions). Center the form over the hole
and drive two stakes along the outside edge
of each side. Level the form by driving nails
through the stakes and into the form while
holding the form level.
3. Attach the bottom section of the tower to
the B18 base using one bolt per leg, making
sure that the hinge direction is common for
all legs.
4. Center the bottom tower section with the
base attached in the hole. Orient the
tower/base for the proper hinge direction.
Make sure that the top of the legs will be at
least 1/2" above the finished height of the
concrete (Figure 2.1-4).
5. Fill the hole with concrete. Getting the
bottom tower section plumb is very
important. As concrete is poured into the
hole, periodically check the tower for plumb
using a carpenter's level and make
adjustments as necessary. Allow three to
four days for the concrete to cure.
REGCOMENDED
FeedSENSORS
PortlandOrUSA
Serial27115
REGCOMENDED
FeedSENSORS
PortlandOrUSA
Serial27115
REGCOMENDED
FeedSENSORS
PortlandOrUSA
Serial2711527115
FIGURE 2.1-1. UT30 Tower-Based
Weather Station

SECTION 2. TOWER INSTALLATION
2-2
120
29.5 '
17 ' RADIUS
TILT DIRECTION
(NORTH)
CENTER POINT
ANCHOR LOCATIONS
(3) PLCS
29.5 '
FIGURE 2.1-2. Top View of Base and Guy Anchor Layout
SIDE VIEW
TOP VIEW
ANCHOR BOLT
CEMENT
FOUNDATION
48"
36"
36"
North
FIGURE 2.1-3. Foundation for B18 Base
B18 Base
(3) places
Cement
Foundation

SECTION 2. TOWER INSTALLATION
2-3
2.1.3.2 RFM18 Base Installation
1. Position the RFM18 on the surface where it will
be installed. Make sure the hinge direction is
correct and mark the locations of the three
mounting holes. Install an appropriate anchor
(user-supplied) for each hole.
Attach the bottom section of the tower to
the RFM18 base using one bolt per leg
(Figure 2.1-5). Position the base over the
anchor holes. Secure the base to the
anchors with appropriate hardware (user-
supplied). Check the tower for plumb and
shim the RFM18 if necessary before fully
tightening the bolts.
2.1.4 GUY ANCHOR INSTALLATION
There are two types of anchors for the tower
guy wires: the UTEYE eye bolts are poured in
concrete; the UTDUK duckbill anchors are
driven into the soil.
2.1.4.1 UTEYE Eyebolt Guy Anchor
1. Dig a hole 24" square by 24" deep at each
anchor location (Section 2.1.2).
2. Optionalconstruct a concrete form out of
2" x 4" lumber 24" square (inside
dimensions) for each hole. Center the
forms over the holes and level them using a
carpenter's level and stakes.
3. Fill the holes with concrete and install the
eyebolts as shown in Figure 2.1-6.
2.1.4.2 UTDUK Duckbill Guy Anchor
1. Locate the three anchor locations (Section
2.1.2). It is important that the anchors be
driven at the same angle as the guy wires
(Figure 2.1-7). Insert the steel drive bar into
the anchor body and drive the anchor into
the ground using a fence post driver or
sledgehammer until only the top half of the
loop remains above the ground.
2. Attach a high-lift jack to the loop and jack
the anchor up about 6 inches to rotate the
anchor into the load-lock position.
WARNING: Failure to install and lock the
anchor at the correct angle will result in the
anchor cable cutting through the soil until
the angles equalize, causing slack in the
guy wires.
UT3B#B
(tripods)
FIGURE 2.1-4. B18 Concrete Mounting Base
RFM18
(tripods)
FIGURE 2.1-5. RFM18 Flat Roof
Mounting Base
60
Eyebolt
Cement foundation
24 "
24 "
SIDE VIEW
FIGURE 2.1-6. UTEYE Eyebolt Guy Anchor
B18
(3) places
RFM18
Eyebolt
Cement
Foundation
Tower →
Mounting Hole
(3) places

SECTION 2. TOWER INSTALLATION
2-4
2.1.5 UT30 10 M TOWER ASSEMBLY
1. Having previously installed the base and
bottom tower section (Section 2.1.4), remove
the bolt from the rear tower leg, and loosen
the bolt in the side legs so the bottom tower
section is free to hinge. Tilt the tower section
to the ground and assemble the remaining
sections and mast using the hardware
provided with the tower.
2. Install the guy wires to the top of the tower
(Figure 2.1-8). Cut the 120' piece of guy wire
into three pieces; lengths will vary with slope.
Attach the guy wires to the tower using two U-
bolts for each guy wire.
3. Mounting brackets and sensors that attach to
upper tower sections are most easily attached
while the tower is lying on the ground.
4. "Walk" the tower to its upright position and
install the remaining bolts in the tower base.
5. Attach the guy wires to the anchors (Figure
2.1-9). Unscrew the jaw and eye bolts until 1
inch of thread extends through the turnbuckle
body. Attach the jaw end of the turnbuckles to
the anchors. While holding the tower plumb,
attach the guy wires to the eye end of the
turnbuckles using a thimble and two U-bolts
for each guy wire. Tighten the turnbuckles
until the guy wires are snug and the tower is
plumb. Do not overtighten the turnbuckles.
2.1.6 UTGND TOWER GROUNDING KIT
1. Drive the ground rod close to the tower
(Figure 2.2-1) using a fence post driver or
sledgehammer. Drive the rod at an angle if
an impenetrable hardpan layer exists. In hard
clay soils, a gallon milk jug of water can be
used to "prime" the soil and hole to make
driving the rod easier.
2. Loosen the bolt that attaches the clamp to
the ground rod. Insert one end of the 4
AWG wire between the rod and the clamp
and tighten the bolt (Figure 2.1-10).
3. Attach the tower grounding clamp to a
tower leg (Figure 2.1-11). Route the 4
AWG wire attached to the ground rod up
the tower leg to the grounding clamp.
Loosen the set screw and insert the 4 AWG
wire and the 24 AWG enclosure ground
wire into the hole behind the set screw and
tighten the set screw. Route the green wire
to where the enclosure will be installed.
60
o
FIGURE 2.1-7. UTDUK Duckbill Guy Anchor
FIGURE 2.1-8. Guy Wire Attached to Tower
Drive Bar
Duckbill Anchor
U-bolts
(2) places
Tower →

SECTION 2. TOWER INSTALLATION
2-5
FIGURE 2.1-9. Guy Wire/Turnbuckle
Attached to UTEYE Anchor
FIGURE 2.1-10. Ground Rod and Clamp
FIGURE 2.1-11. Tower Grounding Clamp
Clamp
Ground Rod
Wire to
Ground Rod
Turnbuckle
Thimble
U-bolt
(2) places
Wire to
Enclosure
Clamp

SECTION 2. TOWER INSTALLATION
2-6
2.2 SENSOR MOUNTING BRACKETS
Sensor mounting brackets provide a means of
mounting the sensors to the tower. General
orientation of the mounting brackets is shown in
Figure 2.2-1.
2.2.1 019ALU CROSSARM SENSOR MOUNT
1. Loosen the two bolts that secure the mast
to the top tower section. Extend the mast
16" (swaged end up) above the top of the
tower and tighten the bolts.
2. Attach the 019ALU crossarm to the mast as
shown in Figure 2.2-2. Position the middle
NU-RAIL at the base of the swaged mast
section. Orient the 019ALU in a north/south
direction, with the 3/4" NU-RAIL facing
south (northern hemisphere) and tighten the
set screws.
3. Install the lightning rod to the mast as
shown in Figure 2.2-2. Loosen the two
screws on the lightning rod mounting
bracket. Position the mounting bracket 2"
down from the top of the mast and tighten
both screws evenly. Make sure the
lightning rod set screw is tight.
2.2.2 GILL RADIATION SHIELDS
1. Attach the Gill Radiation Shield (UT12VA,
UT12P, or UT6P) to the UT018 crossarm
with the bolt and nut provided (Figure 2.2-3).
2. Attach the UT018 to the tower leg facing the
prevailing wind direction (Figure 2.2-3). The
top of the crossarm mounting bracket should
be 74" from the bottom of the tower. Tighten
the four nuts on the compression bracket to
secure the crossarm.
2.2.3 UTLI LEVELING FIXTURE AND
CROSSARM MOUNT
1. Attach the UTLI leveling fixture to the UT018
crossarm with the nut and bolt provided
(Figure 2.2-4).
2. Attach the UT018 to a tower leg so that the
crossarm faces south (northern hemisphere).
The top of the crossarm mounting bracket
should be 98 inches from the bottom of the
tower. Tighten the four nuts on the
compression bracket to secure the crossarm.
FIGURE 2.2-1. Top View of Tower
FIGURE 2.2-2. 019ALU Crossarm and
Lightning Rod
1" NU-RAIL
Enclosure
UT018 Crossarm
Lightning Rod
Ground Rod
UT30
RFM18
019ALU Crossarm
3/4" NU-RAIL
NORTH
Lightning Rod
019ALU

SECTION 2. TOWER INSTALLATION
2-7
2.2.4 025 PYRANOMETER CROSSARM STAND
1. Attach the LI2003S Leveling Fixture to the
025 Pyranometer Crossarm Stand using the
three screws provided (see Figure 2.2-5).
2. Position the 025 mounting plate 5" above
the 3/4" x 3/4" NU-RAIL and tighten the set
screws.
NOTE: The 025 mounts to the 3/4" x 3/4"
NU-RAIL (PN 1017) on the 019ALU
Crossarm, which may not be available
depending on the wind sensor
configuration.
FIGURE 2.2-3. UT12VA Gill Radiation Shield
and UT018 Crossarm
UTLI-B1
FIGURE 2.2-4. UTLI Leveling
Fixture/Crossarm Mount and UT018
FIGURE 2.2-5. 025 Pyranometer
Crossarm Stand
UT018
UT12VA
025
019ALU
UT018
UT018
UTLI

3-1
SECTION 3. INSTRUMENTATION INSTALLATION
3.1 ENCLOSURE, DATALOGGER,
POWER SUPPLY
3.1.1 ENCLOSURE
All instrumentation (datalogger, power supply,
and communication peripherals) are mounted in
the enclosure. A PVC bulkhead port is installed
in the enclosure for routing the sensor and
communication cables to the instrumentation.
Mount the enclosure to the mast as shown in
Figure 3.1-1.
1. Position the enclosure on the north side of the
mast or tower (northern hemisphere) as shown
in Figure 3.1-1, 3.1-2, or 3.1-3. Attach the
enclosure with the U-bolts provided.
2. Route the 14 AWG wire from the brass
tripod grounding clamp (Section 2) to the
enclosure grounding lug. Strip one inch of
insulation from each end of the wire and
insert the end of the wire into the grounding
lugs and tighten the set screws.
FIGURE 3.1-1. ENC 12/14 Enclosure on
CM6/CM10
FIGURE 3.1-2. ENC 12/14 Enclosure on
UT10
FIGURE 3.1-3. ENC 16/18 Enclosure on
UT30
Upper
Mounting
Bracket
and U-Bolt
13” (CM6), 47.5” (CM10)
To Top Of Bell Reducer
Mounting
Bracket
ENC 12/14
59”
To Base
59”
To Base
