Campomatic WBC12SZ User manual

WBC12SZ
WINE COOLER
!
Caution:"Read"and"follow"all"safety"and"operating"instruction"before"first"use"of"this"product."
!
!
Campomatic!S.R.L.!Via!Configliachi!5/B!.!35031,!Abano!Terme!(Padova),!ITALIA!
www.campomatic.com!
!
INSTRUCTION)MANUAL) )
!

1!
Contents:!
1.!Your!Wine!Cooler!
2.!Technical!Data!
3.!Important!Safety!Instructions!
4.!Installation!Instructions!
5.!Electrical!Connection!
6.!Operation!
7.!Care!and!Maintenance!
8.!Troubleshooting!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!

2!
Your)Wine)Cooler)
!
!
1.HINGE!! ! ! 2.!LIGHT!!!!!!!!!!!!!!3.!FAN!MASK! ! ! 4.!SHELF!
5.FOOT! ! ! ! 6.!TEMPERATURE!CONTROL!PANEL! ! 7.LIGHT!SWITCH! ! 8.MAGNETIC!SEAL! ! !
9.GLASS!!!!!!!! ! 10.!DOOR!HANDLE! ! ! ! ! ! !!!11.!DOOR!HANDLE!
!
!
!
!
Technical)Data)
Model!no.!
WBC12SZ!
Capacity! !
33L(1.17!cuff)!
Voltage!
220V! !
Current!
0.5A(25°C/77°F)!
Protection!class!
Ⅰ!
Climate!class!
SN;N!
Input!power!
70W(25°C/77°F)!
Power!Consumption(KW.h/24h)!
1.0(15°C/!59°F)!
Max!Temperature!Difference!
﹥13°C(56°F)!
Temperature!Control!Range!
10`18°C(50`66°F)!
Net!weight!
12KG!
Gross!weight!
13.6KG!
Shape!size(W×H×D)!
340!x!468!x!510!mm!
Packing!size(W×H×D)!
430!x!555!x!600!mm!
!
!
!

3!
!
Important)Safety)Instructions)
!
!Read!all!instructions!before!using!the!wine!cooler!
!Never!allow!children!to!operate!or!play!with!the!cooler!
!Never!clean!appliance!parts!with!flammable!fluids.!The!fumes!can!create!a!fire!hazard!or!explosion.!
!Do! not! store! or! use! gasoline! or! any! other! flammable! vapors! and! liquids!in! the! vicinity! of! this! or! any! other!
appliance.!The!fumes!can!create!a!fire!hazard!or!explosion.!
!
!!!Save)these)instructions)
Installation)Instructions)
Before!using!your!wine!cooler!
!Remove!the!exterior!and!interior!packing! !
!Check!to!be!sure!the!following!parts!are!included:!
"3!Slide!out!shelves!
"1!Instruction!manual!
!Before! connecting! the! appliance! to! the! power! source,! let!it! stand! upright! for! approximately! 2! hours.! This! will!
reduce!the!possibility!of!a!malfunction!in!the!cooling!system!from!handling!during!transportation.!
!Clean!the!interior!surface!with!lukewarm!water!using!a!soft!cloth.!
!
!Place!your!appliance!on!a!floor!that!is!strong!enough!to!support!the!appliance!when!it!is!fully!loaded.! !
To!level!your!appliance,!adjust!the!front!legs!at!the!bottom!of!the!appliance.!
!The)handle)installing) )
The! wine! cooler! comes! with! 1! metal!stainless! steel! handle.! To! install! simply! screw!them! to! the! door! with! the!
supplied!screws!
!
!Installation!should!be!done!away!from!direct!sunlight!and!sources!of!heat!(stove,!heater,!radiator,!etc.).Direct!
sunlight!may!affect!the!acrylic!coating!and!heat!sources!may!increase!electrical!consumption.!Extreme!cold!or!
hot!ambient!temperatures!may!also!cause!the!appliances!not!to!perform!properly.!
!Designed!for!indoor!use!only!
!
)
)
)
To!reduce!the!risk!of!fire,!electrical!shock,!or!injury!when!using!your!
appliance,!follows!these!basic!precautions;!

4!
)
Electrical)Connection)
!
!
!
!
!
This!unit!should!be!properly!grounded!for!your!safety.!The!power!cord!of!this!unit!is!equipped!with!a!2`pin!plug!which!
matches!with!2`pin!wall!outlets!to!minimize!the!possibility!of!electrical!shock.!Do!not!under!any!circumstances!cut!or!
remove!the!ground!wire!from!the!power!cord!supplied.!
Use!of!extension!cords!is!not!recommended.!
This!unit!requires!a!standard!220V`50HZ!electrical!outlet!with!2`pin!plug.!
The!cord!should!be!secured!behind!the!wine!refrigerator!and!not!let!exposed!or!dangling!to!prevent!accidental!injury.!
!
Operation)
It!is!recommended!that!you!install!the!wine!cooler!in!a!place!where!the!ambient!temperature!is!between!10`26°C!(50°
F! `80°F).!!If! the! ambient! temperature!is! above! or! below! recommended! temperatures,!the! performance! of! the! unit!
may!be!affected.! !
The!temperature!may!fluctuate!depending!on!whether!or!not!the!interior!light!is!on!or!off!or!whether!the!bottles!are!
located!on!the!upper,!middle!or!lower!section.!
!
How)to)use)the)pressFbuttons)on)the)Display)Panel:)
You!can!set!the!temperature!as!your!desire!by!pressing!the!button.!There!are!three!press`buttons!on!the!panel!“ ”!and!
“ ”!to!adjust!the!temperature!by!1°C!among!10`18°C.!
You!can!turn!the!interior!light!on!or!off!by!pressing!the!“Light”!button.!
!
Care)and)Maintenance)
Cleaning)your)wine)cooler)
!Unplug!the!wine!cooler!and!remove!the!bottles.!
!Wash!the!inside!with!a!warm!water!and!baking!soda!solution.!The!solution!should!be!about!2!tablespoons!of!baking!
soda!to!a!quart!of!water.!
!The!outside!of!wine!refrigerator!should!be!cleaned!with!mild!detergent!and!warm!water.!
!Draw!out!the!water!box!at!the!bottom,!and!wash.!
Moving)your)wine)cooler)
!Remove!all!the!bottles.!
!Securely!tape!down!all!loose!items!inside!your!wine!refrigerator.!
!Turn!the!leveling!legs!up!to!the!base!to!avoid!damage.!
!Tape!the!door.!
!Be!sure!the!wine!refrigerator!stays!in!the!upright!position!during!transportation.!
!
Warning)
Improper! use! of! the! grounded! plug! can! result! in! the! risk! of! electrical! shock.! If! the!
power!cord!is!damaged,!have!it!replaced!by!an!authorized!Products!service!center.!

5!
Troubleshooting)
You! can! solve! many! common! wine! cooler!problems! easily,! saving! you! the! cost! of! a! possible! service! call.! Try! the!
suggestion!below!to!see!if!you!can!solve!the!problem!before!calling!the!service!center.!
!
PROBLEM)
POSSIBLE)CAUSE)
Wine!cooler!does!not!operate!
Not! plugged! in! using! different! voltage.! The!circuit!
breaker!tripped!or!a!blown!fuse.!
Wine!cooler!is!not!cold!enough!
Check!the!temperature!control!setting.!
External!environment!may!require!a!higher!setting.!
The!door!is!open!too!often.!
The!door!is!not!closed!completely.!
The!door!seal!does!not!seal!properly.!
The!wine!cooler!does!not!have!the!correct!clearance.!
The!light!does!not!work!
Check!the!service!center.!
Vibrations!
Check!to!assure!that!the!wine!cooler!is!level.!
Too!noisy!
Check!to!assure!that!the!wine!cooler!is!level.!
Check!the!fan.!
The!door!will!not!close!properly!
Check!to!assure!that!the!wine!cooler!is!level.!
The!doors!were!reversed!and!not!properly!installed.!
The!seal!is!weak.!
LED!does!not!display!
Main!control!board!does!not!work.!
PCB!Problem.!
There!is!some!problem!with!the!plug.!
