CAN CU3002 User manual

INSTRUCTION
BOOKLET
CU3002
BUILT IN GAS COOKER
INSTALLATION
USE
MAINTENANCE

2
CAN Srl –CU 3002 –ENGLISH –Rev 1/2018
CAN S.r.l.
Via Nazionale 65, 25080
Puegnago del Garda –(BS)
ITALY
www.cansrl.com
[e-mail]
tel. [phone]
fax. [phone]

3
CAN Srl –CU 3002 –ENGLISH –Rev 1/2018
Thank you for purchasing a cooking appliance by CAN s.r.l.
It is a quality appliance, made in Italy, capable of accompanying your pleasure
and free-time in a reliable and safe manner, always guaranteeing the highest level
performance.
Installation and use of the appliance is simple and immediate.
We invite you to read this manual carefully: this will enable correct installation and
use which will ensure your appliance is always perfect and efficient over the years.
The instructions in this booklet are only valid for the country of intended use. Gas
supply systems must comply with national legislation in force.
To facilitate reading of this manual, the following symbols are used:
RESTRICTIONS EXPRESSED
Non-compliance with this restriction exposes people and property to
serious damage.
IMPORTANT PROVISIONS FOR SAFETY OF THE INSTALLATION
TECHNICIANS’ AND END USERS’ OF THE APPLIANCE:
Non-compliance with this note can cause material damage and
compromise product operation.
GENERAL INFORMATION
additional information for installation technicians and users
Fig. X ()
These data refer to an element in a figure
CAN S.r.l., as the manufacturer, reserves the right to make changes to its products
and to this manual which it deems necessary without being obliged to provide
advance notification.
The drawings, installation diagrams and tables contained in this manual are
considered approximate and for the purpose of information only.
This product was designed, manufactured and tested in compliance with the
harmonised standards EN 30-1-1:2008+A3:2013, EN 30-2-1:2015; EN
437:2003+A1:2009, therefore the appliance complies with EEC directives in force for
the sector and in particular the essential requirements contained in regulation UE
2016/426. CAN S.r.l. forbids the copying and partial or total reproduction of the
content of this manual and its distribution to third parties without the manufacturer’s
permission.

4
CAN Srl –CU 3002 –ENGLISH –Rev 1/2018
CONTENT
EQUIPMENT AND CONTENT OF PACKAGING............................................................................... 5
LABELLING - CE MARKING.............................................................................................................6
TECHNICAL DATA SHEET - PRODUCT DATA .................................................................................. 7
..........................................................................................................................................................8
....................................................................................................................................................... 8
INSTALLATION ................................................................................................................................ 9
SAFETY WARNINGS - GENERAL PRECAUTIONS............................................................................9
CONTROL AND MAINTENANCE ....................................................................................................9
DISPOSAL OF PACKAGING .........................................................................................................10
CHOICE OF INSTALLATION LOCATION.......................................................................................10
SWITCH ON AND ELECTRICAL CONNECTION ...........................................................................12
GAS CONNECTION ......................................................................................................................14
APPLIANCE FITTING.......................................................................................................................17
USE ............................................................................................................................................... 18
SAFETY WARNINGS FOR CORRECT AND SAFE USE OF THE PRODUCT....................................18
SPECIFIC WARNINGS FOR COOKING ........................................................................................20
BEFORE STARTING .........................................................................................................................21
USE OF APPLIANCE.......................................................................................................................26
DESCRIPTION OF THE HOB BURNERS...........................................................................................26
DESCRIPTION AND USE OF THE OVEN AND GRILL ....................................................................30
ACCESSORIES................................................................................................................................33
MAINTENANCE ............................................................................................................................ 34
SAFETY WARNINGS .......................................................................................................................34
ROUTINE MAINTENANCE..............................................................................................................34
CLEANING .....................................................................................................................................35
LONG PERIODS OF INACTIVITY ...................................................................................................36
DISPOSAL ON DECOMMISSIONING............................................................................................36
AFTER SALES SUPPORT ..................................................................................................................36
PROCEDURE IN THE EVENT OF A MALFUNCTION ......................................................................37
SPARE PARTS ................................................................................................................................ 38
SPARE PARTS..................................................................................................................................38
NOTES........................................................................................................................................... 39

5
CAN Srl –CU 3002 –ENGLISH –Rev 1/2018
EQUIPMENT AND CONTENT OF
PACKAGING
The product reaches the client in a cardboard box (Fig. 1), protected by shaped
polystyrene shells (Fig. 2) to avoid damage to the appliance during transport and
storage.
Inside the packaging, there is the installation, use and maintenance manual (Fig. 3)
and a mounting kit (Fig. 4) including the screws and any accessories for installation
of the product on kitchen furniture.
Fig. 1
Fig. 2
Fig. 3
Fig. 4

6
CAN Srl –CU 3002 –ENGLISH –Rev 1/2018
LABELLING - CE MARKING
Each product leaves the production plant following an accurate control and testing
cycle. The right-hand panel of each device has a label (Fig. 5), to identify the
product, reporting the details of the serial number, typology/functionality
characteristics of the part and its certification details.
The CE MARKING certifies the product meets the requirements of the directive EU
2009/142/EC on gas appliances.
No.
FIELD - DESCRIPTION
1
MANUFACTURER'S LOGO/BRAND
2
PRODUCTION SITE LOCATION
3
PRODUCT NAME
4
PRODUCT RANGE
5
MODEL
6
CE CERTIFICATION SERIAL NO.
7
DESCRIPTION OF THE WORKING PRESSURE - CERTIFICATION PARAMETERS - COUNTRIES
8
POWER AND TOTAL CONSUMPTION
9
BARCODE - PRODUCTION SERIAL NO.
10
DATE OF MANUFACTURE
11
CE MARK
Fig. 5

7
CAN Srl –CU 3002 –ENGLISH –Rev 1/2018
TECHNICAL DATA SHEET - PRODUCT DATA
CHARACTERISTIC
VALUE
DIMENSIONS:
▪Width
▪Depth
▪Max. height
457 (mm)
562 (mm)
472 (mm)
PRODUCT WEIGHT
26 kg
PACKAGE WEIGHT
30 kg
IGNITION:
▪IGN
Button and generator 12 V / DC
ONLY VERY LOW VOLTAGE CONNECTION
POWER SUPPLY:
▪BUTANE (I3+)
▪PROPANE(I3+)
▪BUTANE-PROPANE (I3B/P)
G30 (28-30 mbar)
G31 (37 mbar)
G30-G31 (30 mbar)
Fig. 6

8
CAN Srl –CU 3002 –ENGLISH –Rev 1/2018
BURNER
NOMINAL
POWER
REDUCED
POWER
Ø
INJECTOR
Ø
BY-PASS
CONSUMPTI
ON
AUXILIARY
1.00 kW
0.50 kW
0.50 mm
0.36 mm
72.50 g/h
SEMI RAPID
1.75 kW
0.55 kW
0.65 mm
0.36 mm
127.50 g/h
OVEN
2.10 kW
0.90 kW
0.80 mm
0.52 mm
152.00 g/h
GRILL
1.70 kW
0.90 kW
0.69 mm
0.52 mm
125.50 g/h
Fig. 7

9
CAN Srl –CU 3002 –ENGLISH –Rev 1/2018
INSTALLATION
SAFETY WARNINGS - GENERAL PRECAUTIONS
ATTENTION - READ THIS INSTRUCTIONS BOOKLET CAREFULLY BEFORE
INSTALLATION AND/OR USING THE APPLIANCE
Keep this documentation in a place accessible to all users for future
consultation; if the appliance is transferred or sold, ensure the new user
also receives the booklet to ensure he or she is aware of installation, use
and the safety provisions.
ATTENTION - INSTALLATION AND ALL INTERVENTIONS ON THE APPLIANCE
DESCRIBED IN THIS CHAPTER (e.g. extraordinary maintenance,
replacement of the nozzles, etc.…) SHOULD ONLY BE CARRIED OUT BY
QUALIFIED STAFF AS SPECIFIED IN THIS BOOKLET.
ATTENTION - The gas connection systems and the installation premises
must be suitable and comply with safety standards in force in the
country of use.
ATTENTION - This appliance is not connected to an exhaust device for
combustion products. The user will be responsible for using the
appliance while guaranteeing a high rate of ventilation in the
environment where it is installed.
THE MANUFACTURER CANNOT BE HELD LIABLE IN THE EVENT OF NON-COMPLIANCE
WITH THE AFOREMENTIONED. Incorrect, improper or irresponsible use can seriously
prejudice the health and safety of people, property and animals.
ATTENTION - During installation, maintenance and repair operations,
always close the gas supply taps.
ATTENTION - The appliance was not designed to work outdoors.
ATTENTION - The appliances could have particularly sharp edges,
handle carefully and using appropriate personal protective equipment
(safety shoes, gloves, etc.)
CONTROL AND MAINTENANCE
After opening the packaging, remove the appliance and having removed all the
packaging and possible protective film, check there are no obvious anomalies: if

10
CAN Srl –CU 3002 –ENGLISH –Rev 1/2018
so, do not proceed to installation and contact the dealer within 8 days,
communicating the data outlined on the identification label of the product,
positioned on the side of the appliance and any problems encountered.
ATTENTION - Do not leave the material used for packaging unguarded
(plastic bags, polystyrene, film, etc.…) because it is potentially
dangerous for children and animals (danger of suffocation).
Transport the appliance to the installation location equipped with personal
protective equipment and using all the precautions necessary to avoid damaging
the appliance, people, animals and property.
DISPOSAL OF PACKAGING
ATTENTION - Dispose of packaging in compliance with legislation in
force in the country of installation.
Composition of packaging:
- box
- polyethylene / polypropylene: outer film of packaging, bag with instructions
- expanded polystyrene: impact-proof guards.
CHOICE OF INSTALLATION LOCATION
Characteristics of installation premises
The appliances covered in this manual are not suitable for installation
outdoors, exposed to atmospheric agents or bad weather. These
appliances must therefore be positioned indoors, in premises suitable
for the purpose; they must meet the safety standards in force in the
country of use.
The appliances can only be assembled on furniture whose material is resistant to
heat. The work counter must be fitted in a perfectly horizontal position and
perpendicular to all the surrounding vertical panelling. The appliances must be kept
a certain distance from the walls (Fig. 3).

11
CAN Srl –CU 3002 –ENGLISH –Rev 1/2018
ATTENTION - The installation premises must have continuous air
exchange or however such to guarantee normal and correct gas
DISTANCE
MINIMUM VALUE
A
50 mm
B
37 mm
C
20 mm
D
524 mm
X
650 mm (minimum distance between the work counter/installation
of the kitchen and the press above)
A
B
C
D

12
CAN Srl –CU 3002 –ENGLISH –Rev 1/2018
combustion, as outlined in the standards in force in the country of
installation (UNI –7131)
FUME EXTRACTOR
The appliance is not equipped with a fume and combustion products
exhaust/extractor system Always check the presence in the premises of appropriate
air vents.
If a hood is installed over the hob, consult the assembly instructions of
the hood, which reports the correct distance to maintain.
IGNITION AND ELECTRICAL CONNECTION
The cooker is equipped with an electronic ignition device, composed of a low
voltage generator (12V - DC) which triggers the flame on each of the burners on
the product (hob, gas and grill). The generator must be correctly connected to the
local electrical distribution mains in DIRECT CURRENT (DC) and VERY LOW VOLTAGE
(12 V).
The generator is located to the rear of the cooker; two connection cables exit the
generator (conductor with positive polarity and conductor with negative polarity).
The free end of the conductor marked with the sign ”+“(positive polarity) should be
connected to the positive pole of the terminal board of the very low voltage mains
or connected to the positive pole of a conductor, while the free end of the other
conductor, marked with the sign “-“ (negative polarity) should be connected to the
counterpart negative pole.
Fig. 8

13
CAN Srl –CU 3002 –ENGLISH –Rev 1/2018
FORBIDDEN - NEVER CONNECT THE APPLIANCE TO MAINS WITH VOLTAGE
OVER 12V AND IN ALTERNATING CURRENT. A similar connection would
cause irreversible damage to the appliance and pose a significant
danger to the user's life.

14
CAN Srl –CU 3002 –ENGLISH –Rev 1/2018
GAS CONNECTION
ATTENTION - Before connecting, ensure the gas system and the
installation premises comply with the provisions of standards in force in
the country of use (UNI-CIG 7129 and 7131) or the specific sector
standards.
•Ensure the power line is free of obstructions and of adequate capacity to
ensure correct operation of the appliance.
•Ensure that immediately downstream of the cylinder or the gas container
used to power the system that there is an adequate pressure
regulator/reducer which complies with the categories of gas usable on the
appliance.
•Ensure that on the power supply line, downstream of the regulator, in an easily
accessible and inspectionable place, there is a shut-off tap for the gas or
valve to section the system: this valve should always be closed during
installation and maintenance operations on the appliance.
ATTENTION - Check the type of gas used to power the appliance is
among those listed in this instructions booklet.
The appliance was designed for correct operation only with the types and working
pressures of the categories of gas below:
GAS CATEGORY AND
COUNTRY OF INTENDED USE
NAME OF GAS
WORKING
PRESSURE
I3B/P (30)
AT-BE-DE-DK-FI-GB-NL-NO-PT-
SE-SI
Butane (G30)
Propane (G30)
30 mbar
30 mbar
I3+ (28-30/37)
BE-CH-ES-FR-GB-IE-IT-PT-SI
Butane (G30)
Propane (G31)
28-30 mbar
37 mbar
ATTENTION –connection of the appliance to the gas piping must be
carried out using a suitable connection tube and compression fittings,
certified and the most suitable for the application. All installation and
connection operations must be performed only by qualified technical
staff.

15
CAN Srl –CU 3002 –ENGLISH –Rev 1/2018
It is possible to use flexible connection tubes, however they must guarantee
compliance with the following requirements:
▪Tubes always inspectionable
▪Tubes protected from contact with hot parts (e.g. burner bowls)
▪Avoid all mechanical stress on flexible tubing during installation and
during use (protection against traction, torsion, crushing, etc...)
▪Tubes protected against mobile parts of fitting (drawings, doors, etc...)
▪Permitted lengths: from 40 cm to 200 cm
▪Maintenance and periodic replacement of the flexible tube as outlined
on the sheath and however not beyond the natural expiry or before
expiry if visible torn.
Proceed to connection:
The main ramp of the gas supply has an 8 mm outer diameter tube with
a free, smooth end, to allow maximum connection flexibility and to
connect a wide range of compression fittings for connection to the gas
distribution mains.
ATTENTION - During the installation and connection operations, the gas
conductor tube of the appliance must not be subject to torsion, traction
or other mechanical stresses which can compromise its seal and
resistance. The portion of the system subject to connection to the
appliance must not be overfull with gas. The outflow of gaseous fuel
should be blocked upstream of the connection zone using an adequate
sectioning valve on the system.
With installation complete, check correct seal of all the joints using a solution of
water and soap. The operation should be carried out by a professional.
FORBIDDEN -NEVER USE OPEN FLAMES BEFORE PASSING THE INSPECTION
TEST!
IF THE OUTCOME OF THE TEST IS SATISFACTORY, you can proceed to
switch on all the burners (consult page 24) to check the flame is stable
and regular.

16
CAN Srl –CU 3002 –ENGLISH –Rev 1/2018
To conclude the installation, the qualified technician is asked to provide all
clarifications and instructions to the end user on correct use of the appliance.
If the appliance is not working correctly after all the controls made, contact the
authorised local dealer.
PROBLEMS
POSSIBLE SOLUTIONS
The flow of gas
appears irregular
•Check the gas tap is completely open
•Check the power supply mains of the fuel has
an adequate flow rate.
•Check the gas rings and the relevant caps
are positioned correctly and are free of
obstructions.
•Check the nozzles are suitable for the type of
gas used.
•Check compatibility and correct calibration
of the pressure regulator if present.
•Check the gas supply tube (tube obstructed,
tube bent/crushed, tube excessively long,
unsuitable tube, etc...).

17
CAN Srl –CU 3002 –ENGLISH –Rev 1/2018
APPLIANCE FITTING
Before proceeding with appliance fitting, ensure the perfect status and stability of
the furniture on which the product will be positioned (Standard DIN 68930). You are
advised to prepare a suitable fitting hole, with the measures indicated in Figure 9.
Arrange the appliance over the fitting hole by pushing it against the top. Block the
appliance with the fastening kit screws supplied with the product.
For non-standard manufactures, the fastening system is customised.
Fig. 9

18
CAN Srl –CU 3002 –ENGLISH –Rev 1/2018
USE
SAFETY WARNINGS FOR CORRECT AND SAFE USE OF THE
PRODUCT
ATTENTION - This appliance was designed and manufactured
exclusively for cooking food.
ATTENTION - Use of the gas cooking appliance produces heat and
humidity in the environment/premises in which it is installed. Always
guarantee good ventilation of the premises by keeping the
openings/air intakes or windows fully open. If this is not necessary, install
a mechanical ventilation/extraction device for the combustion
products (e.g. extractor hood).
ATTENTION - The appliance is equipped with a glass cover to protect
and decorate the hob. The glass covers can break if heated with a
direct flame or if placed in immediate contact with very high sources of
heat. You are advised to always open the cover before switching on
any burner and take care to switch off the burners leaving them to cool
for a few minutes before closing the glass cover at the end of each use
cycle.
Different use to that described here is considered improper and therefore
potentially dangerous for people, animals and property. Furthermore, improper
use and use not complying with the specifications in this manual could irreversibly
damage the appliance: in this case, the manufacturer cannot be held
responsible and does not recognise the right to warranty.
ATTENTION - Always disconnect the electrical power supply (if present)
and close the gas supply taps before each cleaning operation or if a
long period of inactivity is forecast. Ensure all the knobs are always in
the “off” position at the end of use.
If you should note any anomaly, do not use the appliance and contact an
authorised Support Centre by communicating the data on the identification
label outlining the serial number of the product.

19
CAN Srl –CU 3002 –ENGLISH –Rev 1/2018
This appliance is not suitable for use by children and people with physical, sensory
or mental difficulties or with lack of experience and know-how, unless a person
responsible for their safety supervises them or gives them adequate instructions
on use of the appliance.
Children must be supervised to ensure they do not play with the appliance or
with parts of it.
Do not use spray products near this appliance while it is on.
FORBIDDEN - Do not modify or tamper with this appliance in any way.
ATTENTION - Do not use the appliance as a support surface.
DANGER OF FIRE - Never position heat-sensitive or inflammable objects
(pot holders, curtains, bottles of alcohol, etc...) near the appliance.
The area near the appliance can be very hot, pay attention to positioning of
electricity sockets, other electrical appliances, electrical cables, tubing and any
other heat-sensitive or inflammable material in this space.

20
CAN Srl –CU 3002 –ENGLISH –Rev 1/2018
SPECIFIC WARNINGS FOR COOKING
ATTENTION - Danger of scalding! During operation and for a few minutes
after use, some parts of the appliance reach very high temperatures!
Do not come in contact with these parts without adequate personal
protective equipment.
Before use, check the gas rings, the caps and the grate are correctly positioned. In
particular, check the grate is resting correctly on the appliance without wobbling.
FORBIDDEN - Danger of fire! Never cook food in direct contact with the
flame.
FORBIDDEN - Danger of fire! In the event of a fire caused by cooking
grease or hot oil, never extinguish the flames with water but suffocate
them with a damp dishcloth or similar and promptly call the fire brigade.
FORBIDDEN - Danger of fire! Never cover the appliance or parts of it with
aluminium sheets or similar.
FORBIDDEN - Danger of explosion! Never heat tins or hermetically
sealed containers on the appliance, the excess pressure would
generate heat and could cause them to explode, causing serious
personal damage.
Always supervise the appliance during the entire duration it is on.
If the flame is accidentally extinguished on the burner, turn the knob “off” and do
not re-attempt to switch back on for a minute.
Intensive and prolonged use of the appliance can require additional
ventilation (for example opening a window) or a more efficient
ventilation/extraction system (installing or increasing the mechanical
extraction power, if present)
ATTENTION - Ensure the cooking containers rest correctly on the grate
without wobbling. The containers must have an adequate diameter for
the burner chosen and must not protrude from the grate. The
manufacturer cannot be held responsible and does not acknowledge
the right to warranty if this standard is not applied.
