C&C TECHNIC Smart View IC-714-IA User manual

KVM
SWITCH
(IC-712-IA)
(IC-714-IA)
USERMANUAL V1.0
IC-712-IA
IC-714-IA
Package Contents –
1 Smart View IC-712-IAor IC-714-IAKVM Switch
1 User Manual
1 DC 9V 300mApower adapter
2 Rack rails, 8 screws for IC-714-IAonly
Cables: 3L-1512C, 3L-1518C, 2L-1212C and
2L-1218C each 1 pcs for IC-712-IA, each 2 pcs for
IC-714-IA
Please contact your vendor if anything is missed.
Features
Controls PCs with one PS/2 keyboard, PS/2 mouse and monitor
respectively
Supports speaker & microphone
Supports the standard PS/2 mouse, Microsoft IntelliMouse (PS/2
compatible/Optical/Explorer 3.0), WheelMouse Optical, Trackball
(Optical 1.0/Explorer 1.0) & Logitech TrackMan (Marble/Marble FX/
Marble+), Cordless MouseMan (Wheel/Optical), Cordless TrackMan
(FX/Live) mouse, Cordless Optical TrackMan, MX300 Optical
mouse
Fully supports the Microsoft IntelliPoint 5.0 mouse driver & Logitech
Mouse Ware driver
Supports the Windows 95/98/98SE/Me/NT4.0/2000/XP, DOS, Linux,
Novell Netware, FreeBSD
Superior video quality - Up to 1920 x 1440, DDC, DDC2, DDC2B,
DDC2AB, 200MHz
Supports selecting PC by mouse clicking
Real mouse identification function
3 ways for PC selection -- Push-button switch, hot key or mouse
clicking
Easy to install--No software required
Hot Pluggable
Integral keyboard and mouse emulation for PC booting error free
Auto scan function to monitor PCs
Auto skips over the power-off PC
Beep sound and multi selection ways on/off option for port selection
Specifications
Function IC-712-IA IC-714-IA
PC Connectors 2 4
Port Selection Push-button Switch / Hot Key
/ Mouse Clicking
On Line 2 4
LEDs Selected 2 4
Keyboard PS/2
Emulation Mouse PS/2
Console Port 1x6 pin mini-DIN Female (PS/2)
Connector
-Keyboard CPU Port 2x6 pin mini-DIN
Female (PS/2) 4x6 pin mini-DIN Female (PS/2)
Console Port 1x6 pin mini-DIN Female (PS/2)
Connector
-Mouse CPU Port 2x6 pin mini-DIN
Female (PS/2) 4x6 pin mini-DIN Female (PS/2)
Console Port 1x HD-15 Female (Std. VGA/SVGA)
Connector
-Monitor CPU Port 2x HD-15 Male
(Std. VGA/SVGA) 4x HD-15 Male (Std. VGA/SVGA)
Console Port 1 x Audio, MicrophoneConnector
-Audio,Mic.
(Jack) CPU Port 2 x Audio, Mic. 4 x Audio, Mic.
VGA Resolution 1920x1440 (Max.), DDC, DDC2,
DDC2B, DDC2AB, 200MHz
Power Adapter DC 9V 300mA (Min.) spare
Scan Interval 5 sec ~ 30 sec
Housing Metal
Weight 475 g 1085 g
Dimensions (LxWxH) 128x75x45 mm 269x104x45 mm
Cable Requirement 3L-1512C (1.2m), 3L-1518C (1.8m) &
2L-1212C (1.2m), 2L-1218C (1.8m)
-1-
Hardware Requirements
Required specifications
Console
One highest resolution VGA, SVGA or Multisync monitor
One PS/2 mouse
One PS/2 keyboard
One pair of speakers.
One microphone.
PC
One VGA, SVGA or Multisync card
One 6-pin mini-DIN (PS/2) mouse port
One 6-pin mini-DIN (PS/2) keyboard port
One audio jack port.
One microphone port.
Cable Smart View custom cables or equivalent
Appearance
Front View
1.Push-button Switches (Manual type)
2.Port LEDs
3.Console Keyboard, Mouse, Speaker and
Microphone Ports
Rear View
1.Console Monitor Connector
2.CPU Port Connectors
-2-

Installation
Before the installation, make sure the peripherals of all PCs are
grounded properly and turned off.
1. Connect the monitor, keyboard and mouse with the Console
Port Connectors.
2. Use the recommended extension cables to connect the
PCs with the CPU Ports of KVM Switch.
3. Turn on the PCs.
Operation
1.The function of LED display:
LED DISPLAY DESCRIPTION
Light off PC power off
Green light on PC power on and connected
Green light on & Red light
flashing PC power on, connected and selected
Note: It occurs occasionally that the green light of LED display is
on and the red light of LED display keeps flashing after
shutting down the PC because of the PC default. The
condition will not affect the regular operation of KVM
switch.
2. 3 ways for PC selection – Push-button switch, hot key or
mouse clicking
2-1 Push-button switch (Manual Type)
Press the button on front panel to switch the CPU ports.
The red light of LED indicates which PC is selected.
2-2 Mouse clicking
Item Operation Function
IC-712-IA [Middle button] + [Left Button] or
[Middle button] + [Right Button] Access between
two PCs.
IC-714-IA [Middle button] + [Left Button] Switch to the
previous PC.
IC-714-IA [Middle button] + [Right Button] Switch to the next
PC.
Note: 2-Key Mouse is NOT applicable.
2-3 Hot Key option
Hot Key Navigation allows you to select PC from the
keyboard directly.
Options for Hot Key Navigation:
Select PC by Hot Key
Command mode
Auto scan mode
Beep sound on/off option: Press [Right Shift] key
twice to turn on or off the beep sound when needed.
Select PC by Hot Key:
Press either left or right [Ctrl] key twice.
Item Hot Key Operation Function
IC-712-IA [L Ctrl] + [LCtrl] or
[R Ctrl] + [R Ctrl] Access between two PCs.
IC-714-IA [L Ctrl] + [LCtrl] Switch to the previous PC.
IC-714-IA [R Ctrl] + [R Ctrl] Switch to the next PC.
-3-
Command Mode:
Press [Num Lock] key twice, and the 3 keys [Num Lock],
[Caps Lock] and [Scroll Lock] will flash to access the
Command Mode.
a). Directly press the function key [F1] ~ [F2] for IC-712-IA or
[F1] ~ [F4] for IC-714-IA to select PC.
b). Press [Left Ctrl] key to disable [Ctrl] and [Shift] hot key
function.
c). Press [Right Ctrl] key to enable [Ctrl] and [Shift] hot key
function.
d). Press [Left Shift] key to turn off the beep sound.
e). Press [Right Shift] key to turn on the beep sound.
f). Press [Left Win] key or mouse [Middle button] + [Left
Button] to disable Mouse clicking function.
g). Press [Right Win] key or mouse [Middle button] + [Right
Button] to enable Mouse clicking function.
h). Press [Left Alt] key to disable Auto skip function.
i). Press [Right Alt] key to enable Auto skip function.
j). Press [Esc] or [Enter] key to quit the mode.
Note: [Ctrl] Hot Key function – Selecting PC ports.
[Shift] Hot Key function – Beep sound on/off.
Auto Scan Mode:
Press [Scroll Lock] key twice to activate the Auto Scan Mode.
The time scale of Auto Scan ranges from 5 to 30 seconds,
and it can be recognized by the lights of the 3 keys [Num
Lock], [Caps Lock] and [Scroll Lock] as the timetable below.
a). Press the right number key [+] to increase time scale.
b). Press the right number key [-] to decrease time scale.
c). Press [Esc] key to quit the mode.
Note: Light(s) corresponding timetable
Seconds Num Lock Caps Lock Scroll Lock
5 seconds Off Off On
10 seconds On Off Off
15 seconds On Off On
20 seconds Off On Off
25 seconds Off On On
30 seconds On On Off
3.The boot-up default of Smart View KVM Switch is
connected to your first activated PC.
4.When the PC is shut down under the function of “Auto
skips over the power-off PC”, it cannot be turned on again
by keyboard.
Troubleshooting
Make sure the cables are qualified and positioned.
Q1 : The keyboard does not respond accurately.
A1a:
Re-install the keyboard. Unplug the keyboard from the
Console Port and plug it back again.
-4-
A1b:
Re-install the Smart View KVM Switch. Shut down the
PCs, unplug the cables from the Smart View KVM
Switch and wait for five seconds. Then plug the cables
back and activate the PCs.
A1c: When under Auto Scan Mode, please press [Esc] key
to escape.
A1d: PCs can’t supply the power to Smart View KVM
Switch. Please attach a power adapter of DC9V
300mA with positive central polarity.
A1e: Try another keyboard.
Q2 : The mouse does not respond accurately.
A2a: Re-install the mouse. Unplug the mouse from the
Console Port and plug it back again.
A2b: Re-install the Smart View KVM Switch. Shut down
the PCs, unplug the cables from the Smart View
KVM Switch, and wait for five seconds. Then plug
the cables back and activate the PCs.
A2c: Make sure the mouse is set on PS/2 mode.
A2d:
PCs can’t supply the power to Smart View KVM
Switch. Please attach a power adapter of DC9V
300mA with positive central polarity.
A2e: Try another mouse.
Note: If you are using a particular mouse, we suggest
installing the mouse driver from original manufacturer
to reveal the functionality of Smart View KVM Switch.
Q3: The mouse is out of control.
A3: The characteristic of the mouse is inefficient. Try
another superior mouse and plug it back again. Start
the operation after hearing the beep sound.
Q4: There is the video problem.
A4a: The setting of resolution or bandwidth is over high.
Smart View KVM Switch supports the VGA, SVGA,
Multisync and XGA (interlaced) with the resolution up
to 1920 x 1440 Hz. The maximum bandwidth is 200
MHz.
A4b: The cable is unqualified. Please use the superior
cables of Smart View cables series.
Q5:
A5:
Why the green light of LED display is on and red
light keeps flashing after shutting down the PC?
The condition is normal and caused from the PC
default. The condition will not affect the regular
operation of Smart View KVM switch.
