Candy CIC60 User manual

CIC60
Reverse Action
User Instructions
GB
05651181 25/6/01 8:32 pm Page 1

2
Safety reminders
User’s manual. This machine should only
be used for its intended purpose as
described in this manual. Ensure that it is
fully understood before operating.
Installation. This machine should not be
installed in a bathroom or shower room.
Never install the dryer against curtains
and be sure to prevent items from falling
behind or collecting beneath the dryer. If
the floor is carpeted stand the machine on
a piece of hardboard.
Ventilation. Check regularly that the air
flowing through the dryer is not restricted:
Check the fluff filter after use, and clean,
if necessary.
The inlets and outlets should be kept free
from obstructions.
If the dryer is used frequently the period
between checks should be reduced
accordingly.
Water container. Empty the container
after every drying cycle. Use both hands
when carrying a full water container.
Dryness. Clothes should be spin dried or
thoroughly wrung before they are put into
the tumble dryer. Clothes that are dripping
wet should NOT be put into the dryer.
Lighters and matches must not be left in
pockets and NEVER use flammable
liquids near the machine.
Foam plastic, foam rubber and rubber-
like material are not suitable for tumble
drying. Articles made from these
materials MUST NOT be placed in the
dryer.
Glass fibre curtains should never be put
in this machine. Skin irritation may occur
if other garments are contaminated with
the glass fibres.
Garments treated with flammable
cleaning sprays or liquids such as petrol,
must not be put in this machine.
Lint or fluff must not be allowed to
collect on the floor around the outside or
beneath the machine.
Cool down period. The drum inside may
be very hot. Always allow the dryer to
complete the cool down period before
removing the laundry.
Faults. Do not continue to use this
machine if it appears to be faulty.
After use. Remove the plug from the
electricity supply. Always remove the
plug before cleaning the appliance.
Supply cord. If the supply cord on this
appliance is damaged, it must be replaced
by a special cord which is only available
from GIAS Service or an authorised
Dealer.
GIAS Service. To ensure the continued
safe and efficient operation of this
appliance we recommend that any
servicing or repairs are only carried out
by an authorised GIAS service engineer.
05651181 25/6/01 8:33 pm Page 2

Installation
3
Before using the tumble dryer for the
first time:
●please read this instruction book
thoroughly.
●remove all items packed inside drum.
●wipe the inside of the drum and door
with a damp cloth to remove any dust
which may have settled in transit.
IMPORTANT: This dryer must only be
used for drying household textiles and
garments where a water solution has
been used for the cleaning process.
DO NOT tumble dry fabrics treated
with dry cleaning fluids.
Electrical requirements
This appliance is fitted with a moulded-on
non-rewireable plug (in the UK fitted with
a 13 Amp fuse).
The plug should be accessible for
disconnection after the appliance has been
installed.
WARNING!
ELECTRICITY CAN BE
EXTREMELY DANGEROUS.
THIS APPLIANCE MUST BE
EARTHED.
IMPORTANT: The wires in the mains
lead are coloured in accordance with the
following code:
Blue - NEUTRAL
Brown - LIVE
Green-and-yellow - EARTH
If the supply cord on this appliance is
damaged, it must be replaced by a special
cord which is only available from GIAS
Service or an authorised Dealer.
Contents
Safety reminder 2
Electrical requirements 3
Installation requirements 4
Preparing the load 4
Clothes preparation 4
Maximum drying weight 4
Sorting the load 4
Do not tumble dry 5
Energy saving 5
Opening the door 5
Filter 6
Water container 6
Condenser 7
Drying guide 8
Controls & indicators 8
Operation 9
Cleaning the dryer 10
Technical specifications 10
Troubleshooting 11
05651181 25/6/01 8:33 pm Page 3

Installation
4
Installation requirements
IMPORTANT: This dryer must be
installed such that the air inlets and
outlets are not restricted (fig. 1).
There should be a gap of at least 12mm
(0.5 inches) between the sides rear and base
of the machine and the surrounding walls,
cabinets and floor.
To ensure adequate ventilation the space
between the bottom of the machine and the
floor must not be obstructed.
NEVER install the dryer up against
curtains.
Prevent items from falling or collecting
behind and beneath the dryer as these may
obstruct the air inlets and outlets.
Preparing the load
Before using the dryer for the first time
wipe the inside of the drum and door with a
damp cloth.
Make sure that the laundry you are going to
dry is suitable for drying in a tumble dryer,
as shown by the care symbols on each item.
Clothes preparation
Check that all fastenings are closed and that
pockets are empty. Turn the articles inside
out. Place clothes loosely in the drum to
make sure that they don’t get tangled.
Do not overload the drum, particularly
when drying large items, otherwise, the
laundry may stick to the drum and not dry
evenly.
Maximum drying weight
●Cottons Max. 6 kg
●Synthetics Max. 3 kg
Sort the load as follows:
A) By care symbols
On the collar or inside seam:
Suitable for tumble drying.
Tumble drying at high temperature.
Tumble drying at low temperature only.
Do not tumble dry.
B) By amount and thickness
Whenever the load is bigger than the
dryer capacity, separate clothes
according to thickness (e.g. towels from
thin underwear).
C) By type of fabric
Cottons/linen: Towels, cotton jersey,
bed and table linen.
AIR INLET
VENTS
SUPPLY CORD
AIR OUTLETS
IN BASE
1
Preparing the load
05651181 25/6/01 8:33 pm Page 4

Synthetics: Blouses, shirts, overalls, etc.
made of polyester or polyamid, as well
as for cotton/synthetic mixes.
D) By drying level
●Sort into: iron dry, cupboard dry, etc.
●For delicate articles press the ‘HEAT
SETTING’ button to select low drying
temperature.
Do not tumble dry:
Woollens, silk, delicate fabrics, nylon
stockings, delicate embroidery, fabrics with
metallic decorations, garments with PVC or
leather trimmings, training shoes, bulky
items such as sleeping bags, etc.
IMPORTANT: Do not dry articles which
have been treated with a dry cleaning
fluid or rubber clothes (danger of fire or
explosion).
Energy saving
Only put into the tumble dryer laundry
which has been thoroughly wrung or spin-
dried. The drier the laundry the shorter the
drying time thus saving electricity.
ALWAYS try to dry the maximum weight
of laundry, this will save time and
electricity.
NEVER exceed the maximum weight, this
will waste time and electricity.
ALWAYS check that the filter is clean
before every drying cycle as this aids
efficiency.
NEVER put dripping wet items into the
tumble dryer, this may damage the
appliance and waste time and efficiency.
Preparing the load Door
5
Opening the door
The door may be opened by pushing on the
textured panel of the door (fig 2). This is a
safety feature to prevent the entrapment of
minors in the drum.
To restart the dryer, close the door and
press the ‘ON’ button.
WARNING!
WHEN THE TUMBLE DRYER IS
IN USE THE DRUM AND DOOR
MAY BE VERY HOT.
2
05651181 25/6/01 8:33 pm Page 5

Filter Water container
6
Filter
IMPORTANT: To maintain the efficiency
of the dryer check that the fluff filter is
clean before each drying cycle.
Water Container
The water removed from the laundry
during the drying cycle is collected in a
container at the bottom of the dryer.
When the container is full the ‘EMPTY
WATER’ indicator on the control panel will
light, and the container MUST be emptied.
However, we recommend that the container
is emptied after each drying cycle.
NOTE: Very little water will collect during
the first few cycles of a new machine as an
internal reservoir is filled first.
To remove the container:
1. Gently pull the bottom of the kickplate
so that it unclips from the dryer. The top
section can then be unhinged allowing
the kickplate to be completely removed
(fig. 4).
2. Pull firmly on the handgrip and slide the
water container out of the dryer (fig. 5).
1. Gently remove lint using a soft brush or
your fingertips (fig 3).
Clean Filter Indicator lights when the
filter needs cleaning. If the laundry is not
drying check that the filter is not clogged.
4
5
3
05651181 25/6/01 8:33 pm Page 6

Condenser
7
Support the container with both hands.
When full, the water container will
weigh about 4kg (fig. 6).
3. Open the lid located on the top of the
container and empty the water (fig. 7).
4. Refit the lid and slide the water
container back into position. PUSH
FIRMLY INTO PLACE.
5. Refit the kickplate by engaging the
hinges at the top and ‘snapping’ the
lower clips into place.
Condenser
IMPORTANT: Always switch off and
remove the plug from the electricity
supply before cleaning the condenser.
To maintain the efficiency of the dryer
regularly check that the condenser is
clean.
To remove the condenser:
1. Remove the kickplate (fig. 4).
2. Turn the two locking levers anti-
clockwise (fig. 8).
3. Pull out the condenser unit (fig. 9).
4. Gently remove any dust or fluff with a
cloth, then wash the unit by holding it
under a running tap (fig. 10) turning it
so that water flows between the plates,
to remove any dust or fluff.
5. Refit the condenser ensuring it is
pushed firmly into place. Lock the two
levers by turning them clockwise.
6. Refit the kickplate.
68
9
10
7
05651181 25/6/01 8:33 pm Page 7

Drying guide Controls and indicators
8
Control panel and indicator lights
Drying guide
The table shows approximate drying times, depending on the type of fabric and dampness
of the clothes.
REMEMBER: During the last 15 minutes the load is always tumbled in cool air.
120-135 Min
70-85 Min
50-65 Min
70-80 Min
55-65 Min
40-50 Min
50-65 Min
40-55 Min
30-40 Min
HIGH
LOW
LOW
COTTON
SYNTHETICS
ACRYLIC
LIGHT LOADMEDIUM LOADHEAVY LOADHEAT SETTING
1
2
3
45
11
05651181 25/6/01 8:33 pm Page 8

Operation
9
1. Open the door and load the drum with
laundry. Ensure that garments do not
hinder closure of the door.
2. If drying delicate items press the
‘HEAT SETTING’ button to reduce the
heat level. Press again on completion, to
select high temperature.
3. Turn ‘DRYING TIME’ dial until the
required drying time aligns with the
symbol (▼).
4. Gently close the door pushing it slowly
until you hear the door ‘click’ shut.
5. Press the ‘ON’ button. The indicator
will light and the drying cycle begins.
6. The load is dried by tumbling in
thermostatically controlled warm air.
Cool air is used for the last 15 minutes
to reduce creasing and cool the load
ready for handling.
7. When the program is fully completed
the drum will stop rotating and the dial
will point to the symbol (▼).
Open the door and remove the load.
8. Clean the filter and empty the water
container after every drying cycle to
ensure maximum dryer efficiency.
(See ‘Filter’ and ‘Water Container’
sections).
9. Clean the condenser after
approximately every 10 drying cycles to
ensure maximum dryer efficiency.
(See ‘Condenser’ section).
1. ‘ON’ button and indicator – press to switch on, the indicator will light.
2. ‘HEAT SETTING’ button - press to reduce the heat level for delicate items, press
again to select high temperature.
3. ‘DRYING TIME’ dial - selects drying time or pre-ironing option (a).
4. ‘CLEAN FILTER’ indicator - lights when the filter needs cleaning.
5. ‘EMPTY WATER’ indicator - lights when water container is full.
Heat setting
Heat setting
Heat setting
Heat setting
Operation
WARNING!
THE DRUM, DOOR AND LOAD
MAY BE VERY HOT.
05651181 25/6/01 8:33 pm Page 9

Cleaning
10
Cleaning the dryer
IMPORTANT: Always switch off and
remove the plug from the electricity
supply before cleaning this appliance.
Clean the filter and empty the water
container after every drying cycle.
Regularly clean the condenser.
After each period of use, wipe the inside of
the drum and leave the door open for a
while to allow circulation of air to dry it.
Wipe the outside of the machine and the
door with a soft cloth.
DO NOT use abrasive pads or cleaning
agents.
To prevent the door sticking, periodically
clean the door gasket with a ‘non- scratch
cream cleaner.’
Technical
specifications
Drum capacity 115 litres
Maximum load 6 kg
Height 85cm
Width 60cm
Depth 60cm
Energy Label Band C
Note: For electrical data refer to the rating
label on the front of the dryer cabinet (with
the door open).
05651181 25/6/01 8:33 pm Page 10
