Cannon 1907000 User manual

Adjustable Dual Axis Rod Holder Shown
ROD HOLDER & DOWNRIGGER
TROLLING SYSTEM
CAUTION:
READ THIS MANUAL CAREFULLY
BEFORE OPERATING YOUR
NEW CANNON ACCESSORY.
RETAIN FOR FUTURE REFERENCE. NOTE: Do not return your CANNON accessory to your
retailer. Your retailer is not authorized to repair or re-
place this unit. You may obtain service by:
• calling CANNON at 1-800-227-6433;
• returning your accessory to the Factory Service Center;
121 Power Drive, Mankato, MN 56001
Please include proof of purchase and purchase date for
warranty service with any of the above options.
Owner’s Manual
Rod Holders:
ANGLED FIXED MOUNT
Adjustable Single Axis
Adjustable Rail Mount
Adjustable Clamp Mount
Adjustable Dual Axis
Adjustable Downrigger Mount
(METALLIC)
Adjustable Downrigger Mount
(BlACK)
1907000
1907001
1907020
1907021
1907002
1907022
1907023

2
1907002 Adjustable – Dual Axis Rod Holder
The Adjustable – Dual Axis Rod Holder is 10 inches in length and has 6 lock-
ing positions up and down with 360°rotation. Pistol grip release provides quick one
hand up and down angle adjustment with 360°rotation with the push of the release
button. Ratcheting adjustment system allows you to pull the rod holder straight up
for rod removal. Clear anodized aluminum is used for strength and corrosion resis-
tance and a UV resistant cap protects the finish of the rod and reel. This Adjust-
able Rod Holder is compatible with Cannon, Bert’s, and Traxstech track systems.
1907001 Adjustable – Single Axis Rod Holder
1907020 Adjustable – Rail Mount Rod Holder
1907021 Adjustable – Clamp Mount Rod Holder
The Adjustable – Single Axis Rod Holder is 10 inches in length and has 6 locking
positions up and down. Pistol grip release provides quick one hand up and down angle adjust-
ment while the ratcheting adjustment system allows you to pull the rod holder straight up for
rod removal. Adjustments can be made side to side by forty five degrees using the adjustable
thumb screws in conjunction with an aluminum track. Clear anodized aluminum is used for
strength and corrosion resistance and a UV resistant cap protects the finish of the rod and
reel. The Adjustable Rod Holder is compatible with Cannon, Bert’s, and Traxstech track sys-
tems.
Also available pre assembled to 1 1/4 inch rail mount and Clamp Mount.
Rod Holder Models & Features
1907000 Angled – Fixed Mount Rod Holder
The Angled - Fixed Mount Rod Holder is 10 inches in length and has a fixed 60°
angle. Adjustments can be made side to side by forty five degrees using the adjustable
thumb screws in conjunction with an aluminum track. Clear anodized aluminum is used
for strength and corrosion resistance and a UV resistant cap protects the finish of the rod
and reel. The Angled Rod Holder is compatible with Cannon track systems.

3
1904000 Deck Mount
The Cannon Deck Mount plate is a four inch by three inch clear
anodized aluminum plate which allows the hard mounting of Cannon Dual
Axis Rod Holders. The plate comes with a black protective mounting boot
and all mounting hardware.
1904015 Rail Mount 3/4” to 1-1/4”
1904016 Rail Mount 1-1/4” to 2”
Cannon Rail Mounts allow for the mounting of Cannon Single and Dual
Axis Rod Holders to round or square rail. Two sizes are available for round and
square tube styles. Components are made from clear anodized aluminum and
stainless steel for strength and corrosion resistance.
1904020 Clamp Mount
Cannon Rail Mounts allow for the mounting of Cannon single and
dual axis rod holders to any transom or allowable clamping edge.
Clamp opens to two and a half inches and is made from clear anodized
aluminum and stainless steel for strength and corrosion resistance.
1907022 Adjustable – Downrigger Mount Rod Holder - Metallic
1907023 Adjustable – Downrigger Mount Rod Holder - Black
The Adjustable – Dual Axis Rod Holder is also available on a Cannon
downrigger mount in a metallic or black finish (metallic finish shown right).

4
1904005 Pedestal Mount Track 12”
1904006 Pedestal Mount Track 18”
The pedestal mounting track is three inches high and allows for
mounting of Cannon’s track system accessories. Pedestal can be sur-
face mounted or slid into mounting track for a variety of mounting posi-
tions and easy removal. The system is compatible with Cannon, Bert’s,
and Traxtech track system products. Components are made from clear
anodized aluminum and stainless steel for strength and corrosion resis-
tance. Mounting hardware is included. Pedestal is available in twelve
and eighteen inch track lengths for mounting up to three track system rod holders.
1904010 Gimbal Mount Track – Side Gunnel
1904011 Gimbal Mount Track – Stern
Cannon’s Gimbal Mount Track allow for mounting of Cannon’s
track system accessories in flush mount rod holders. Thirty degree an-
gled gimbals have twelve inch tube length with an outer diameter of 1-1/2
inches. Eighteen inches of track allow for mounting up to three track
system rod holders. The system is compatible with Cannon, Bert’s, and
Traxtech track system products. Components are made from clear ano-
dized aluminum and stainless steel for strength and corrosion resistance.
1904025 Aluminum Mounting Track 6”
1904026 Aluminum Mounting Track 12”
1904027 Aluminum Mounting Track 18”
1904028 Aluminum Mounting Track 24”
1904029 Aluminum Mounting Track 36”
Cannon tracks allow for flexible mounting positions and easy
removal of Cannon’s track system accessories. Locking grooves allow
thumb screws to index with track and prevent accessories from twisting.
The system is compatible with Cannon, Bert’s, and Traxtech track sys-
tem products. Components are made from clear anodized aluminum
and stainless steel for strength and corrosion resistance. All mounting
hardware included. Available in 6, 12, 18, 24, and 36 inch lengths.
1904030 Fixed Base Downrigger Pedestal 4”
1904031 Fixed Base Downrigger Pedestal 6”
Cannon’s fixed base downrigger pedestals
can be surface mounted or track mounted for a vari-
ety of mounting positions and easy removal. The
3/4” thick aluminum top plate is pre-drilled and
tapped for mounting Cannon downriggers as well as
most Scotty®, Big Jon®, Penn®, Vector, Proos,
Fishlander and Walker downriggers. Components are made from clear ano-
dized aluminum and stainless steel for strength and corrosion resistance. The
fixed base downrigger pedestals are compatible with Cannon, Bert’s, and
Traxstech track systems. Available in 4” and 6” heights.
CAUTION:
The Cannon Pedestal
Mount is intended for
use with a Track that is
mounted directly to the
deck of the boat ONLY.

5
Replacement Parts
Rod Holder \ Accessory Compatibility
Mounts
Rod Holde r
●
- Compatible
○
- Not Compatible * - Compatible with removal of track mount plate
Adjustable Dual Axis
Track Mount Gimbal Track Mount Pedestal Track Mount
●●●
Angled Fixed Mount
Adjustable Single Axis
Rail Mount Clamp Mount Deck Mount
●●●○○○
●
*
●
*
○
●●●●
*
●
*
●
1904032 Swivel Base Downrigger Pedestal 4”
1904033 Swivel Base Downrigger Pedestal 6”
Cannon’s swivel base downrigger pedestals can be surface
mounted or track mounted for a variety of mounting positions and easy re-
moval. With 16 locking points, these downrigger pedestals allow for 360°
downrigger rotation with locking points every 22.5°. The 3/4” thick aluminum
top plate is pre-drilled and tapped for mounting Cannon downriggers as well
as most Scotty®, Big Jon®, Penn®, Vector, Proos, Fishlander and Walker
downriggers. Bearing system ensures smooth swivel action even while a
downrigger weight is attached. Components are made from clear anodized
aluminum and stainless steel for strength and corrosion resistance. The
swivel base downrigger pedestals are compatible with Cannon, Bert’s, and
Traxstech track systems. Available in 4” and 6” heights.
Mounts
Pedes tal
○○●
6" Sw ivel Mount
●○○
●
- Compatible
○
- Not Compatible
4" Sw ivel Mount
Track Mount Gimbal Track Mount Pedestal Track Mount
●○○
4" Fixed Mount
6" Fixed Mount
Rail Mount Clam p Mount Deck Mount
●○○○○●
○○●
●○○○○●
Pedestal Mount \ Accessory Compatibility
Part Part Number Description USED ON
3396562 END CAP 1904005, 1904006, 1904010, 1904018, 1904025,
1904026, 1904027, 1904028, 1904029
3390210 VINYL CAP 1907000
3393413 THUMB SCREW 1907000, 1907001, 1907002, 1904005, 1904006
3391515 CAP ROD HOLDER 1907001, 1907002, 1907020, 1907021, 1907022,
1907023
33986110 WEAR TIP 1907001, 1907002, 1907020, 1907021, 1907022,
1907023

6
WARNING: This product contains chemical(s) known to the state of California to cause cancer and/or reproductive toxicity.
Product protected by United States Patent number des. D573685, D573686, D574920
Form No. 3397120 Rev D
Johnson Outdoors, Inc. / Cannon Division
121 Power Drive, Mankato, MN 56001
1-800-227-6433
© 2008 Johnson Outdoors, Inc. All rights reserved.
