Page 1
I. Product Overview and Configuration
A. Overview
The imagePRESS C7000VPe is a Canon Certified Remanufactured
imagePRESS based on the imagePRESS C7000VP/C6000VP/C6000. The
remanufacturing process is comprehensive. A team of Canon trained
technicians thoroughly inspected, cleaned and remanufactured the
imagePRESS products. The imagePRESS C7000VPe remanufacturing
process adds value by providing new service parts to improve the quality to
that of the imagePRESS C7010VP.
This remanufactured model has been assigned a new model name and serial
number and has had its meter reset. Since this is not a brand new machine
but remanufactured, extensive testing must be performed to confirm the
machine quality and performance. Therefore, the remanufactured
imagePRESS C7000VPe 101 meter may read between 3,000 and 7,500
prints/copies. This model contains new and refurbished parts and fully meets
the original equipment manufacturer’s quality and operational standards for
this Factory Certified machine.
The POD Deck-A1 and Saddle Finisher-AB2 have been remanufactured into
the POD Deck-A1e, and Saddle Finisher-AB2e respectively and fully meets
the original equipment manufacturer’s quality and operational standards. In
addition, there is a new imagePRESS Server A2200e, a custom
imagePRESS Server configured specifically for the imagePRESS C7000VPe.
These Remanufactured accessories along with the imagePRESS Server are
available with the imagePRESS C7000VPe as standard items.
1. imagePRESS C7010VP Series features applied to the imagePRESS
C7000 VPe:
Reliability:
oParts Life improvement (using the imagePRESS C7010VP
service parts)
oThe maximum monthly volume was increased to 1,000,000
Letter sized impressions per month
Image Quality and Consistency:
oNew Airflow technology
oDensity Stabilization Technology & Hydro Thermal Sensor
Productivity:
oFaster printing speeds for jobs containing duplex and simplex
sheets
oFaster printing speeds for jobs containing multiple types of
media
oFaster printing speeds for jobs containing tabloid sheets

imagePRESS C7000VPe Service Guide
imagePRESS C7000VPe Service Guide April 2013
Page 2
Usability:
oThe mechanical adjustment for paper skew can be made from
the User Interface.
oAuto-ejection Feature will clear media from a jam to collect in
either the POD Escape tray, Duplex Paper Path or the Saddle
Finisher Tray
2. The Remanufacturing Process
1. All safety related parts are replaced (power cords, breakers, fuses,
thermostats and protective switches).
2. Pertinent engineering changes are implemented (updated parts,
firmware, etc.).
3. Hard disk drives are replaced or erased and reimaged.
4. Each module is inspected for damage during the remanufacturing
process. Subassemblies and parts are replaced as needed.
5. All paper path areas are thoroughly cleaned, and evaluated during
the reassembly process.
6. Almost all bearings are replaced in the Main Station, Finisher and
Sub Station. All bearings are replaced in the fixing units.
7. The fixing units are completely disassembled, cleaned and tested.
The fixing unit tests are the same as for a newly manufactured
fixing unit: a belt alignment test, pressure spring force test and a
complete function check test (checks sensors, web advancement,
temperature, refresh and cleaning roller engagement and belt
timing).
8. All of the reworked major sub-assemblies are inspected by the
operator performing the rework as well as an inspector.
9. After the entire module has been reworked and re-assembled it is
inspected as an assembly.
This model brings the following capabilities to commercial printers, In-plant
Central Reproduction Department (CRD) facilities, quick printers and digital
printers:
A Segment 5 device that prints and copies Color and Black & White
(B&W) sheets at speeds of up to 70 ppm (pages-per-minute).
Prints images at up to 1200 dpi (dots per inch) x 1200dpi with 256
halftones resolution.
A maximum paper size of 13" x 19.2” is supported. Standard paper
sources two paper trays with a capacity of up to 1,000-sheets each.
Adding the optional POD Deck-A1e, the device can hold a maximum of
6,000-sheets.
Canon’s oil-free V Toner utilizes exceptionally small particles containing
micro-dispersed wax so toner fixes evenly and lays flat, resulting in
sharp, vivid, dense images and a smooth finish that looks and feels like
offset printing.

imagePRESS C7000VPe Service Guide
imagePRESS C7000VPe Service Guide April 2013
Page 3
The ARCnet (Attachable Resource Computer Network) communication
cable connects the main engine to ARCnet compatible accessories.
Built-in Automatic Press Calibration sets the proper color densities
without operator intervention, while Canon’s Advanced Developer
technology maintains a constant supply of fresh developer to ensure
color consistency from side to side, page to page, and job to job.

imagePRESS C7000VPe Service Guide
imagePRESS C7000VPe Service Guide April 2013
Page 4
Table 1 – Model Comparison
Feature Model
imagePRESS C7000VP imagePRESS C7000 VPe imagePRESS C7010VP
Copy / Print Speed1
(LTR, Color / B&W) Up to 70 ppm (LTR) Up to 70 ppm (LTR) Up to 70 ppm (LTR)
Optimum Performance
Range (copies/prints) Approximately 70,000 to 300,000 Approximately 70,000 to 300,000 Approximately 70,000 to 300,000
Maximum Monthly Copy
Volume (copies/prints) Approximately 568,000 Approximately 1,000,000 Approximately 1,000,000
Paper Weight 17 lb bond to 110 lb cover
(64 g/m² to 300 g/m²) 17 lb bond to 110 lb cover (64 g/m² to 300 g/m²) 16 lb bond to 120 lb cover
(60 to 325 g/m2)
Standard Paper Capacity
(20 lb bond (80 g/m2)Main Unit2
up to 2,000 sheets
Main Unit +
POD Deck-A1e
up to 6,000 sheets
Main Unit
up to 2,000 sheets
POD Deck
up to 4,000 sheets Optional POD Deck-A1e (Standard) Optional
Secondary POD Deck
up to 4,000 sheets Optional Not Supported Optional
Paper Deck Unit Optional Not Supported Optional
Stack Bypass Optional Not Supported Optional
Finishing
Finisher-AB1
(Optional)
Saddle Finisher-AB2
(Optional)
Saddle Finisher-AB2e
(Standard)
Finisher-AJ1
(Optional)
Saddle Finisher-AJ2
(Optional)
imagePRESS Server Optional imagePRESS Server
A2200e (Standard) Optional
imagePRESS CR Server Optional Not Supported Optional
High Capacity Stacker Optional Optional Optional
Secondary High Capacity
Stacker Optional Not Supported Optional
Perfect Binder Optional Not Supported Optional
Booklet Trimmer Optional Optional Optional
Two Knife Booklet Trimmer Optional Optional Optional
Professional Puncher /
Integration Unit Optional Optional Optional
Color Image Reader Optional Optional Optional
DADF Optional Optional Optional
1 Maintains print speed regardless of paper weight based on LTR sized paper.
2 The Marking Engine, Fixing Unit, and Power Station Unit all make up what is hereinafter referred to as the “Main Unit.

imagePRESS C7000VPe Service Guide
imagePRESS C7000VPe Service Guide April 2013
Page 5
Table 2 – Model Features
Feature imagePRESS C7000 VPe
Copy / Print Speed1Up to 70 ppm (LTR)
Optimum Copy Volume (copies/prints)
(Approximately) Approximately 70,000 to 300,000
Scan Speed LTR, 300 dpi 80 ipm (images per minute)
LTR, 600 dpi 50 ipm
Resolution Scan / Copy Up to 600 x 600 dpi
Print Up to 1,200 x 1,200 dpi
ADF (Automatic Document Feeder) Duplexing ADF (Standard)
ADF Capacity (20 lb bond (80 g/m²)) Up to 100 sheets
Maximum Paper Size 13” x 19.2”
Paper Weight 17 lb bond to 110 lb cover (64 g/m² to 300 g/m²)
Paper Capacity
(20 lb bond (80 g/m2)Standard Two Paper Drawers: Up to 1,000 sheets each
POD Deck-A1e: Up to 4,000 sheets
Multiple Copies 1 to 9,999 sheets
Printer Memory 1.5 GB
Hard Disk Drive Two 80 GB hard disk drives
Warm Up Time
(@ 68°F (20°C)) From Power On Approximately 7 minutes
From Sleep Mode Approximately 7 minutes
FCOT (First Copy Output Time) Approximately 29 seconds
Toner Yield (LTR) Up to 35,500 images @ 10% image duty
Drum Yield (LTR) Up to 850,000 images
Print Standard
Copy Optional
Mail Box Standard
Universal Send Optional
Network Standard Ethernet 100Base-TX/10Base-T
USB 2.0 High Speed Interface
Remote UI Standard
MEAP Capability Standard
1 Maintains print speed regardless of paper weight based on LTR sized paper.

imagePRESS C7000VPe Service
Guide
B. Configuration
Note: Configurations shown are for reference purposes only and are subject
to change without notice
Central Website for the most up
Table 3 – Product
Configuration
imagePRESS C7000VPe
4
Table 4 –
Hardware Accessories
Color Image Reader-H1 Set
5
DADF-R1
Platen Cover Type K
Professional Puncher-
B1 with Professional Puncher Integration Unit
Plastic Comb 19-
Hole Punch LTR
Twin Loop 21-
Hole Punch LTR
Twin Loop 32-
Hole Punch LTR
Color Coil 44-
Hole Punch LTR
Velo Bind 11-
Hole Punch LTR
Loose Leaf 3-
Hole Punch LTR
Loose Leaf 5-
Hole Punch LTR
Pro Click 32-
Hole Punch LTR
High Durability Plastic Comb 19
High Durability Color Coil 44
High Durability Loose Leaf 3
Booklet Trimmer-D1
Two-Knife Trimmer-A1
3
Item Numbers and Part Numbers are subject to change without notice.
3
Item Numbers and Part Numbers are subject to change without notice.
4
Includes the imagePRESS C7000VPe, POD Deck
Eye-One Spectrophotometer
5 The set includes the Color Image R
eader
imagePRESS C70
00VPe
Guide
Note: Configurations shown are for reference purposes only and are subject
to change without notice
.
Please refer to the Dealer Price List on the ISG
Central Website for the most up
-to-date Item Numbers.
Configuration
Item
imagePRESS C7000VPe shown
Hardware Accessories
Hardware Accessories
Item
B1 with Professional Puncher Integration Unit
-A1
Hole Punch LTR
-A1 (Die for Professional Puncher-B1)
Hole Punch LTR
-A1 (Die for Professional Puncher-B1)
Hole Punch LTR
-A1 (Die for Professional Puncher-B1)
Hole Punch LTR
-A1 (Die for Professional Puncher-B1)
Hole Punch LTR
-A1 (Die for Professional Puncher-B1)
Hole Punch LTR
-A1 (Die for Professional Puncher-B1)
Hole Punch LTR
-A1 (Die for Professional Puncher-B1)
Hole Punch LTR
-A1 (Die for Professional Puncher-B1)
High Durability Plastic Comb 19
- Hole Punch LTR-A1(Die for Professional Puncher-
B1)
High Durability Color Coil 44
-Hole Punch LTR-A1(Die for Professional Puncher-B1)
High Durability Loose Leaf 3
-Hole Punch LTR-A1(Die for Professional Puncher-B1)
Item Numbers and Part Numbers are subject to change without notice.
Item Numbers and Part Numbers are subject to change without notice.
Includes the imagePRESS C7000VPe, POD Deck
-A1e, Saddle Finisher-
AB2e, imagePRESS Server A2200e, and the X
eader
-H1 and Reader Attachment Kit-
A1. Requires the Platen Cover Type K or DADF
00VPe
Service Guide
April 2013
Page 6
Note: Configurations shown are for reference purposes only and are subject
Please refer to the Dealer Price List on the ISG
Item Number
3
1394B045AA
Item Number
3
0468B006AA
0470B002AC
1121B001AA
2825B004AA
3028B001AA
3028B002AA
3028B003AA
3028B004AA
3028B005AA
3028B006AA
3028B022AA
3028B021AA
B1)
3028B033AA
3028B034AA
3028B035AA
2898B001AA
2827B002AA
AB2e, imagePRESS Server A2200e, and the X
-Rite
A1. Requires the Platen Cover Type K or DADF
-R1

imagePRESS C7000VPe Service Guide
imagePRESS C7000VPe Service Guide April 2013
Page 7
Table 4 – Hardware Accessories Continued
Hardware Accessories
Item
Item Number
3
Document Insertion Unit-C1 Set
6
,
7
0518B002AA
High Capacity Stacker-C1 1741B002AB
Stacker Dolly-A1 1091B001AA
Convenience Stapler-A1 1348V957
Tab Feeding Attachment-C1 2389B001AA
3 Item Numbers and Part Numbers are subject to change without notice.
Table 5 – System Options
System Options
Item
Item
Number
3
eLAN Number
8
Remote Operators Software Kit-B1 4001B002AA
Voice Guidance Kit-B1 9598A006AA
Barcode Printing Kit-D1 3999B001AA
ADF Access Handle-A1 1095B001AA
Key Switch Unit-A2 8203A002AA
Braille Label Kit-E1 7518A003AA
Card Reader-C1 6575A001AB
Basic Card Set 0500A002AC
Copy Card Set 1 (1-30) 0499A004AB
Copy Card Set 2 (31-100) 0499A005AA
Copy Card Set 3 (101-200) 0499A006AA
Reader Attachement-A1 1398B001AA
System Accessory Attachment Kit-A1 2380B001AB
Secure Watermark-B1 1082B006AA 1082B010AA
HDD Data Encryption Kit-B3 1897B002AA
HDD Data Encryption Kit-B9 1897B004AA
HDD Data Erase Kit-C1 4002B002AA 4002B004AA
Voice Guidance Kit-B1 9598A006AA
Access Management System Kit-B1 1642B008AB 1642B010AA
3 Item Numbers and Part Numbers are subject to change without notice.
6 Document Insertion Unit-C1 and Inserter Attachment Kit-A1
7 Option for the Saddle Finisher-AB2e
8 The eLAN (Electronic License Access Number) is delivered via the CNA (Canon Network Access) Web site.

imagePRESS C7000VPe Service Guide
imagePRESS C7000VPe Service Guide April 2013
Page 8
Table 6 – Print Controller Options
Print Controller Options
Item
Item Number
3
eLAN Number
8
Color Universal Send Kit-G1 1332B002AA 1332B006AA
Universal Send PDF Advanced Feature Set-A1
9
1323B002AA
Universal Send PDF Security Feature Set-A1
9
1324B002AA
Digital User Signature PDF Kit-A1
9
1326B002AA
Encrypted Secure Print Software-D1 1337B006AA 1337B011AB
Removable HDD Kit-B3 (for imagePRESS Server A2200e) 0134B005AA
Integrated Interface and Stand-A1 (Option for the imagePRESS
Server A2200e) 1099V652
Graphic Arts Package, Premium Edition V2.2 7752A022AA
SeeQuence Compose 2351B003AA
SeeQuence Impose 6596A035AA
SeeQuence Suite 6596A037AA
Braille Label Kit-E1 7518A003AA
3 Item Numbers and Part Numbers are subject to change without notice.
8 The eLAN (Electronic License Access Number) is delivered via the CNA (Canon Network Access) Web
site.
Table 7 – Consumables
Consumables
Item
Item Number
3
IPQ-2 Black Toner 0436B003AA
IPQ-2 Cyan Toner 0437B003AA
IPQ-2 Magenta Toner 0438B003AA
IPQ-2 Yellow Toner 0439B003AA
IPQ-2 Drum 0444B003AA
Black Starter 0440B001AA
Cyan Starter 0441B001AA
Magenta Starter 0442B001AA
Yellow Starter 0443B001AA
Staple-N1 1007B001AA
Staple-P1 1008B001AA
3 Item Numbers and Part Numbers are subject to change without notice.
9 Option for Color Universal Send Kit-G1

imagePRESS C7000VPe Service Guide
imagePRESS C7000VPe Service Guide April 2013
Page 9
II. Configured Accessories
A. POD Deck-A1e
Holds up to 4,000 sheets (@ 20 lb bond (80 g/m2))
Supports paper sizes up to 13" x 19 .2"
Paper Weight: 17 lb bond to 110 lb cover (64 g/m2to 300 g/m2)
The imagePRESS C7000VPe only supports only one (1) POD Deck
B. Saddle Finisher-AB2e
Contains two trays, which holds up to 5,000 sheets (LTR @ 20 lb bond
(80 g/m2)) (the top tray holds up to 3,000 sheets with the high volume
stack mode and the lower tray holds up to 2,000 sheets)
Can corner or double staple up to 100 sheets of paper (@ 20 lb bond
(80 g/m2))
Saddle Stitch Booklet Finishing capability for up to 20-sheets (@ 20 lb
bond (80 g/m2)) or 80 imaged sides.
Paper weight: 17 lb bond to 110 lb cover (64 g/m2to 300 g/m²)
The imagePRESS C7000VPe only supports the Saddle Finisher-AB2e
C. imagePRESS Server A2200e
A high-performance external print controller designed for corporate in-
plants, Pay-For-Print, and commercial printers.
Operates in both Windows and Macintosh environments
Supports PostScript 3, PPML 2, EPS, PDF Version 1.3-1.7, JPEG (with
GAPPE), TIFF 6.0 JDF, PDF-X1a
Preloaded features include the Graphic Arts Package, Compose and
Impose Production Printing Package (without Preflight functions)
Optional packages include the Graphic Arts Package Premium Edition
Utilities include Fiery Command WorkStation, Hot Folders, Fiery Remote
Scan, Fiery Clone Tool, Fiery Bridge
The optional Integrated Interface & Stand-A1 includes a furniture stand,
monitor, keyboard and mouse
The imagePRESS C7000VPe only supports the imagePRESS Server
A2200e

imagePRESS C7000VPe Service Guide
imagePRESS C7000VPe Service Guide April 2013
Page 10
III. Hardware Accessory Options
A. Color Image Reader-H1
Accepts originals Sheet, Book, 3D Objects Up to 4.4 lb (2 kg)
Resolution 600 dpi x 600 dpi, 256 graduations
Supports original paper sizes up to 11” x 17”
Scanning Speed: up to 80 ipm (300 dpi), 50 ipm (600 dpi) (with the
DADF-R1 attached)
B. DADF-R1
Duplexing Automatic Document Feeder
Up to 100 sheets capacity (@ 20 lb bond (80 g/m2))
Supports original paper sizes up to 11” x 17”
Scanning Speed: up to 80 ipm (300 dpi), 50 ipm (600 dpi)
Paper Weight: 13 lb bond to 80 lb cover (50 g/m2to 216 g/m2)
Requires the Color Image Reader-H1
C. Tab Feeding Attachment-C1
Installs to the paper drawers of the Main Unit and the POD Decks
Ensures reliable feeding of tab paper from the drawer.
D. High Capacity Stacker-C1
Provides large stacking for paper sizes up to 13" x 19 .2"
Capacity of up to 5,000 sheets (@ 20 lb bond (80 g/m2))
An output tray located on top of the stacker supports up to 1,000 sheets
The optional Stacker Dolly-A1 (a rolling removable dolly) transports large
amounts of output to off-line finishing devices
The imagePRESS C7000VPe Only supports one (1) High Capacity
Stacker.
E. Document Insertion Unit-C1
Option to insert pre-printed cover sheets into a saddle stitch job
Installs directly on top of the Saddle Finisher-AB2e
The upper tray and a lower tray have a capacity of up to 200 sheets
each (@ 20 lb bond (80 g/m2))
Supports 17 lb bond to 110 lb Cover (64 g/m2to 300 g/m2)
Requires the Saddle Finisher-AB2e

imagePRESS C7000VPe Service Guide
imagePRESS C7000VPe Service Guide April 2013
Page 11
F. Professional Puncher-B1 with Integration Unit-A1
Provides users with a variety of punch patterns, which are available as
die sets (replaced by the end-user)
Provides the end-user the ability to create off-line plastic spiral bound
books.
Supports LTR and Tab size paper 20 lb bond to 80 lb Cover (64 g/m2to
216 g/m2)
G. Booklet Trimmer-D1
Connects to the Booklet Tray of the Saddle Finisher-AB2e
Provides adjustable front trimming of saddle-stitched booklets
(approximately 100 pages)
The Conveyor Tray can hold approximately 30 booklets
Requires the Saddle Finisher-AB2e
H. Two-Knife Booklet Trimmer-A1
Connects to the Booklet Trimmer-D1
Provides adjustable top and bottom side trimming of a saddle stitch
saddle-stitched booklets (approximately 100 pages)
The Conveyor Tray can hold approximately 30 booklets (uses the
Conveyor Tray of the Booklet Trimmer-D1)
Requires the Booklet Trimmer-D1

imagePRESS C7000VPe Service Guide
imagePRESS C7000VPe Service Guide April 2013
Page 12
IV. Dealer Sales/Service Authorization
To obtain and maintain authorization to sell or service the imagePRESS
C7000VPe, every Authorized Reseller’s location must have at least two (2)
technicians who have successfully completed the imagePRESS C7000VPe update
training program. Additionally, a dealership must have at least one (1) Systems
Engineer that has successfully completed the imagePRESS C7000VP Systems
training program. By meeting this combination of requirements, a dealer can be
confident that their service department will have the skills and knowledge needed
to be successful in servicing and supporting this production product.

imagePRESS C7000VPe Service Guide
imagePRESS C7000VPe Service Guide April 2013
Page 13
V. Educational Training
A. imagePRESS C7000VPe Training
The learning path for the imagePRESS C7000VPe products has been
designed to build the knowledge and skills of your support professionals that
will affect your customers in the most positive manner, both in the support of
the product and the solutions you offer.
The learning path for service technicians without a certification for the
imagePRESS C7000VPe product starts with completion of the imagePRESS
C7000VP/C6000VP/C6000 blended training course, “Old” or “Current” course
format.
Using the Old course format (Figure 1)
The service technician would have completed the old format of the
imagePRESS C7000VP/C6000VP/C6000 blended training program (with
the 20-day or 18-day Classroom Course). The learning path continues
with the imagePRESS C7010VP/C6010VP/C6010 Hardware Update
course and concludes with the imagePRESS C7000VPe Update Course.
Using the Current course format (Figure 2)
The service technician will need to complete the comprehensive
imagePRESS C7000VP blended training program (with the 15-day
Classroom Course) and conclude with the imagePRESS C7000VPe
training program.
Figure 1 – Learning Path for Service Technicians using the “Old” Blended
Training Program
*No longer available
Figure 2 – Learning Path for Service Technicians using the “Current” Blended
Training Program
imagePRESS
C7000VPe
Update Course
Online Course
(19IPC7VPE00O)
imagePRESS C7000VP
Hardware Blended Training
Online Course
(19IPCC7000O)
and
15-Day Classroom Course
(09IPCIPC721C)
Non-Certified
Service
Technicians
imagePRESS
C7000VPe
Update Course
Online Course
(19IPC7VPE00O)
imagePRESS
C7010VP/C6010VP/C6010
Hardware Update Course
Online Course
(09IPCC7010U00E)
“OLD”
imagePRESS
C7000VP/C6000VP/C6000
Hardware Blended Training
*Online Course
(19IPCIP7S01E)
and
*20/18-Day Classroom
Course (09IPCIPC721C)
Non-Certified
Service
Technicians

imagePRESS C7000VPe Service Guide
imagePRESS C7000VPe Service Guide April 2013
Page 14
The learning path for Systems Engineers (see Figure 3 below) is the
imagePRESS C7000VP/C6000VP/C6000 Systems Blended Training
program. The program is designed for System Engineers who are required to
support the imagePRESS C7000VPe system in a connected environment.
Figure 3 – Learning Path for Systems Engineers
1. Learning Path for Service Technicians using the “Old” Blended
Training Program
This training program is a comprehensive blended learning program,
which will prepare the service technician to setup and service the
imagePRESS C7000VPe devices.
a) On-line Course Modules
On-line course modules are available on Canon USA’s e-Support
Web site. On-line course modules include a final examination.
The C7000VP/C6000VP/C6000 Hardware training course
provides technicians with the theoretical concepts to install,
configure, and support the imagePRESS C7010VP/C7000VP
Series machines.
The imagePRESS C7010VP/C6010VP/C6010 Hardware
Update Training Program focuses on the similarities and
differences when comparing the imagePRESS
C7010VP/C6010VP/C6010 Series to the imagePRESS
C7000VP/C6000VP/C6000 devices.
The imagePRESS C7000VPe Update Training Program
focuses on the similarities and differences when comparing
the imagePRESS C7000VPe to the imagePRESS
C7010VP/C6010VP/C6010 Series and the imagePRESS
C7000VP/C6000VP/C6000 Series.
Table 8 – Online Course Modules
Course Name Course Code
3
Required
imagePRESS C7000VP/C6000VP/C6000
On-line Training (no Longer Available) 19IPCIP7S01E Yes
imagePRESS C7010VP/C6010VP/C6010
Hardware Update Training Program 09IPCC7010U00E Yes
imagePRESS C7000VPe Update Training Program 19IPC7VPE00O Yes
3 Item Numbers and Part Numbers are subject to change without notice.
imagePRESS
C7000VP/C6000VP/C6000
Systems Blended Training
Online Course
(09IPCIP7S01E)
and
5-Day Classroom Course
(09IPCIP7S11C)
Non-Certified
Systems Engineer

imagePRESS C7000VPe Service Guide
imagePRESS C7000VPe Service Guide April 2013
Page 15
b) Classroom Courses
The 20-day or 18-day hardware classroom program blends
information taught online with the hands-on and practical
application in the classroom.
This program is no longer available.
Table 9 – Classroom Courses
Course Name Course Code
3
Required
imagePRESS C7000VP/C6000VP/C6000
Classroom (no Longer Available) 09IPCIPC721C Yes
3 Item Numbers and Part Numbers are subject to change without notice.
2. Learning Path for Service Technicians using the “Current” Blended
Training Program
This training program is a comprehensive blended learning program,
which will prepare the service technician to setup and service the
imagePRESS C7000VPe devices.
a) On-line Course Modules
On-line course modules are available on Canon USA’s e-Support
Web site. On-line course modules include a final examination.
The imagePRESS C7000VP Hardware course module
provides technicians with the theoretical concepts to install,
configure, and support the imagePRESS C7010VP/C7000VP
Series machines.
The imagePRESS C7000VPe Update Training Program
focuses on the similarities and differences comparing the
imagePRESS C7000VPe to the imagePRESS
C7010VP/C6010VP/C6010 Series and the imagePRESS
C7000VP/C6000VP/C6000 Series.
Table 10 – Online Course Modules
Course Name Course Code
3
Required
imagePRESS C7000VP On-line Training 19IPCC7000O Yes
imagePRESS C7000VPe Update Training Program 19IPC7VPE00O Yes
3 Item Numbers and Part Numbers are subject to change without notice.
b) Classroom Courses
The 15-day hardware classroom program blends information taught
online with the hands-on and practical application in the classroom.
Table 11 – Classroom Courses
Course Name Course Code
3
Required
imagePRESS C7000VP Classroom 09IPCIPC721C Yes
3 Item Numbers and Part Numbers are subject to change without notice.
