BRINGING INNOVATION TO EVERY HIGH-VOLUME CORPORATE OFFICE
Capture, create, and communicate at network speed with the Canon imageRUNNER®5570 and imageRUNNER 6570 devices.
From high-speed scanning and local document storage to advanced finishing, electronic distribution, and Internet-ready
capabilities, these next-generation imageRUNNER systems deliver unmatched performance, durability, and innovation.
Delivering output at speeds of up to 55 and 65 pages per minute, respectively, the imageRUNNER 5570 and imageRUNNER 6570
devices feature Canon’s MEAP®(Multifunctional Embedded Application Platform) architecture as well as enhanced device
management and security features. Send enhancements allow you to distribute documents instantaneously while usability
improvements ensure ease-of-use. Plus, these devices support integration with Web-based information systems. With all
these advanced features–and more–your office can achieve a new level of performance with the imageRUNNER 5570 and
imageRUNNER 6570 systems.
Accessories
Universal Send™ Kit-D1(Optional)
Sending Methods: E-mail, I-fax, Super G3 Fax (Optional),
File Server (IPX, FTP, SMB), User Inbox
Address Book Capacity: Max. 1,800 Destinations
File Format
Standard: TIFF, PDF,
Optional: PDF (OCR)
Sending Sizes: Statement to 11" x 17"
Duplexing Automatic Document Feeder (Standard)
Acceptable Originals: Statement to 11" x17"
Capacity: 100 Sheets (20lb. Bond)
Original Paper Weight: 13 lb. to 32 lb. Bond
Feeding Speed: 65Sheets/Minute(Letter)
Power Source: From Main Unit
Copy Tray-L1(Optional)
Capacity: 250 Sheets (20 lb. Bond)
Dimension (H x W x D): 7-3/8" x 17-5/8" x 13-3/8"
(186mmx446mmx340mm)
(When auxiliary tray and auxiliary
wire are extended)
Weight: Approx. 1.4 lb. (670g)
Finisher-T1and Saddle Finisher-T2(Optional)
Number of Trays: 3Trays
Tray Capacity
No-collate Mode
Tray A: 250 Sheets (Letter, Statement-R,
Executive)
125 Sheets (Legal, Letter-R, 11" x17")
Tray B: 1,300 Sheets (Letter, Statement-R,
Executive)
650 Sheets (Legal, Letter-R, 11"x17")
Tray C: 2,450 Sheets (Letter, Executive)
1,700 Sheets (Statement-R)
650 Sheets (Legal, Letter-R, 11"x17")
Collate and Group Mode
TrayB: 1,300 Sheets (Letter,Executive)
650 Sheets (Legal, Letter-R, 11"x17")
Tray C: 1,700 Sheets (Letter, Executive)
650 Sheets (Legal, Letter-R, 11"x17")
Staple Mode
Tray B/C: 1,300 Sheets/100 Sets (Letter,
Executive)
650 Sheets/50 Sets (Legal, Letter-R,
11"x17")
Max. Stapling Capacity
Corner/Double: 50 Sheets (Letter, Executive)
30 Sheets (Letter-R, Legal, 11"x17")
Type: Digital, Multifunction Imaging System
Imaging System: Laser Dry Electrostatic Transfer
Developing System: Dry Mono Component Developing
System
Fixing System: Induction Heating Fusing System
ImageServer Memory: Standard 512MBRAM/20GBHDD
First-copy Time: Approx. 3.3 Seconds or Less From
Platen Glass
Warm-up Time: Approx. 30 Seconds or Less
Copy/Print Speed: 55/65 cpm/ppm (Letter)
AcceptableOriginals: Sheets, Books, 3-dimensional Items
(Upto 4.4 lb.)
Max. Original Size: 11" x17"
Max. Copy Size: 11" x 17"
Min. CopySize:3-7/8" x5-7/8"
Max. Mail Boxes Supported: 100
Max. Copy Reservation: 5Jobs
Actual Resolution: 600 x600 dpi
Interpolated Resolution: 1200 x 600 dpi (Copy)
2400 x600 dpi (Print)
Halftones: 256 Gradations
Duplexing: Standard Automatic Trayless
Duplexing
Magnification: 25% to400% (Platen)
25% to200% (Feeder)
(in 1% Increments)
ExposureControl: Automatic or Manual (9Levels)
Paper Sources
Standard: Dual Front-loading Trays
(1,500 Sheets Each)
Dual Front-loading Cassettes
(550 Sheets Each)
50-sheet Stack Bypass
Optional: 3,500-sheet Paper Deck
(Total: 7,650 Sheets)
Multiple Copies: 1to 999
Paper Weights (From All Sources): 17 lb.Bond to110 lb.Index
Dimensions (H x W x D): 47" x 25-3/8" x 29-1/4"
(1192mm x 643mm x 743mm)
Weight: Approx. 474 lb. (215kg)
Power Requirements: 120VAC, 60Hz, 16A
Power Consumption: 1.85kW (Max.)
Plug: NEMA 5-20R
Drum: Amorphous Silicon – Estimated
Yield: 3,000,000 Impressions
Maximum Duty Cycle: 220,000/250,000 Impressionsper
Month
Toner Yield: 45,000 Images (at 6%Coverage)
imageRUNNER 5570/6570 Specifications
Saddle-stitching (Saddle Finisher-T2Only)
Acceptable Paper Sizes: Letter-R, Legal, 11"x17"
Capacity/Tray: 1to5Sheets/25 Sets
6to10Sheets/15Sets
11 to 15 Sheets/10 Sets
Max. Stapling Capacity/Set: 15Sheets
Folding: V-fold
Dimension (H xWxD): 42-3/4" x25-1/2" x25-7/8"
(1,085mmx648mmx657mm)
Weight
Finisher T1: Approx. 88.2 lb. (40kg)
Saddle Finisher T2:Approx. 163 lb. (74kg)
Attachable Accessories: Puncher Unit-M1
Puncher Unit-M1(Option for Finisher-T1/Saddle Finisher-T2)
Max. Paper Weight: 17lb. Bond to 110 lb. Index
Paper Sizes
2-hole: Letter-R, Legal, Executive
3-hole: Letter,11"x17"
Punch Method: Sequential Processing System
(One sheet atatime)
Punch Dust Stock: 3,000 Sheets
Power Source: From Main Unit
Dimension (H x W x D): 32-3/4" x 4-1/4" x 24-1/2"
(833mm x107mm x614.8mm)
Weight: Approx. 15.9 lb.
Paper Deck-V1 (Optional)
Number of Drawers: 1
Paper Capacity: 3,500 Sheets (20 lb.Bond)
Paper Size: Letter
Paper Weight: 17 lb. Bond to 110 lb. Index
Power Source: From Main Unit
Dimension (H x W x D): 22-5/8" x 12-3/4" x 23"
(574mm x323mm x583mm)
Weight: Approx. 101 lb. (46kg)
Super G3Fax Board-R1(Optional)
Applicable Line: Public Switched Telephone Network
(PSTN)
Connection Lines: 1
Sending/Original Size: Statement to 11" x 17"
Recording/Printing Size: Statement to 11" x 17"
Transmission Times**
ECM-MMR: Approx. 3.2 Seconds
G3MR: Approx. 13 Seconds
G3MH: Approx. 13 Seconds
JBIG: Approx. 2.6 Seconds
Scan Line Density
Standard: 8pels/mm x 3.85 lines/mm
Fine: 8pels/mm x 7.7 lines/mm
Super-Fine: 8pels/mm x 15.4 lines/mm
Ultra-Fine: 16 pels/mm x 15.4 lines/mm
Auto Dial Function: Address Book: 1,800 Destinations
Image Memory: Approx. 8,000 Pages

Saddle Finisher-T2Finisher-T1Puncher Unit-M1
Copy Tray-L1
Main Unit Paper Deck-V1
imagePASS-M3(V1.1)(Optional)
Type: External Stand-alone Controller
Processor: Intel®Celeron®2.5GHz
Memory: 256MB
Storage: 40GBHDD
PDL Support: Adobe®PostScript 3,PCL 5e, PCL 6
Interface Connections
Standard:10/100Base-T(RJ-45)
Optional: Parallel Interface Adapter
Internal Fonts
PS: Roman PS Font (Type
1)–126 Fonts
Roman PSFont (True Type) – 10 Fonts
PCL 5e/6:113 Fonts, 32 Barcode Fonts
ProtocolStacks
IPX/SPX: Ethernet II/Ethernet 802.2/Ethernet
802.3/Ethernet SNAP
TCP/IP: Ethernet II
AppleTalk: Ethernet SNAP
SMB: Ethernet II
Network OS: Novell NetWare v.3.2, 4.1, 4.11, 4.2,
5, 5.1, 6.0, 6.5 (IPX/SPX)
Windows 98/Me/2000/XP
WindowsNT 4.0
Solaris 2.5.1 or later
Apple®Macintosh OS 9.0 or later
Dimensions(H x W x D): 15-1/2"x6-3/8"x15-3/4"
(394mm x 162mm x 400mm)
Weight: 21 lb. (9.6kg)
Power Requirements: 110 to 240V, 1A
Utility Software: Network ScanGear
RemoteUI
NetSpot Console, NetSpot Job Monitor
NetSpot Resource Downloader
NetSpot Device Installer
JBIG ImageViewer
Canon LPR 2
Canon NDPS Gateway
Canon Font Manager
DSE (Device Status Extension)
Fiery®Downloader
Fiery Remote Scan
Command WorkStation®
E-mail Port Monitor
WebTools™
EFI Options: Data Center Package
Hot Folders
Impose
Canon Multi-PDL Printer Kit-G1(Optional)
Processor: Canon Custom Processor—Shared
Memory: 512MB—Shared
Storage: 20GB—Shared
PDL Support: PCL 5e/6,PostScript®3™
Emulation, UFR II (Ultra Fast
Rendering)
InterfaceConnections
Standard: 10/100Base-T (RJ-45),
USB 2.0 High Speed
Network OS: Windows®98/Me/2000/XP
Windows NT®4.0/Server 2003
Solaris™1.1x, 2.5x or later
Macintosh®OS 8.0 or later (PPD)
Novell®NetWare®v.3.2, 4.1, 4.11, 4.2,
5, 5.1, 6, 6.5 (IPX/SPX™)
Printer Drivers
UFR II: Windows 2000/XP
Windows Server 2003
CitrixMetaFrame
Macintosh OS X (OS 10.1.5 orlater)
PCL 5e/6:Windows98/Me/2000/XP
Windows NT 4.0/Server 2003
CitrixMetaFrame
PS 3Emulation: Windows 98/Me/2000/XP
Windows NT 4.0/Server 2003
Macintosh OS X (OS 10.2 or later)
Internal Fonts
PS: 136 Scalable Fonts
PCL 5e/6:80 Scalable Fonts, 30 Barcode Fonts,
2OCR Fonts, 10 Bitmap Fonts
Utility Software: Network ScanGear
Remote UI™
NetSpot®Console,
NetSpot Job Monitor
NetSpot Resource Downloader
NetSpot Device Installer
USB Class Driver, Fax Driver
JBIG ImageViewer
Canon LPR 2
Canon NDPSGateway
Canon Font Manager
Canon Watermark Add-in
DSE (Device Status Extension)
AddressBook Conversion Utility
imageRUNNER 5570/6570 Specifications (Continued)
Other Optional Accessories and Utilities
•Accessibility Handle-A1
•Barcode Printing Kit-B1*
•Braille Label Kit-A1
•Card Reader-C1
•Card Reader Attachment-C2
•Card Sets
•Cassette-AB1
•eCopy Suite
•Expansion Bus Board-C1
•imageRUNNER Security Kit-A2
•imageWARE™Suite
•NetSpot Suite
• RemoteOperator’s Software Kit-A1
• Removable HDD Kit*
•Tab Feeding Attachment-A1
•USB Application Interface Board-D1
•Universal Send PDF Enhancement Kit-B1
•Voice Guidance Kit-A1*
•Web Access Software-A1
* Not available at time of launch. Please check with your local
Authorized Canon Dealer.
** Approximate 3-second-per-page fax transmission time based on
ITU-T No. 1Chart (MMR, Standard Mode) at 33.6 Kbps modem
speed when transmitting to another V.34 machine. The Public
Switched Telephone Network (PSTN) currently supports 28.8 Kbps
modem speeds or lower, depending on telephone line conditions.

©2005 Canon U.S.A., Inc. All rights reserved.
As an ENERGY STAR®Partner, Canon U.S.A., Inc. has determined that these products meet the ENERGY STAR®guide-
lines for energy efficiency. ENERGY STAR and the ENERGY STAR certification mark are registered U.S. marks. Windows
and Windows NT are registered trademarks of Microsoft Corporation in the United States and/or other countries.
Adobe and PostScript are registered trademarks of Adobe Systems Incorporated in the United States and/or
other countries. Apple and Macintosh are registered trademarks of Apple Computer, Inc. Intel and Celeron are
registered trademarks of Intel Corporation. eCopy ShareScan is a trademark of eCopy, Inc. Novell and NetWare
are registered trademarks of Novell, Inc. in the United States and other countries. IPX/SPX is a trademark of
Novell, Inc. Solaris is a trademark of Sun Microsystems, Inc. in the United States and other countries. Fiery and
Command WorkStation are registered trademarks, and webTools is a trademark of Electronics for Imaging, Inc.
in the U.S. Patent and Trademark Office and/or certain other foreign jurisdictions. Canon, IMAGERUNNER, MEAP,
NetSpot, and Canon Know How are registered trademarks, and Universal Send and the GENUINE logo are trade-
marks of Canon Inc. in the United States and may also be registered trademarks or trademarks in other coun-
tries. IMAGEPASS is a trademark of Canon Inc. IMAGEWARE is a registered trademark of Canon U.S.A., Inc. in the
United States and is a trademark of Canon Inc. in certain other countries. Remote UI is a trademark of Canon
U.S.A., Inc. IMAGEANYWARE is a service mark of Canon U.S.A., Inc. in the United States. All referenced product
names and other marks are trademarks of their respective owners.
Specifications subject to change without notice.
