The Moving Image:
Powered by Canon
Crisply defined, brilliantly detailed video can transform a memory into a work of art. Making that
happen every time you pick up your camcorder is what Canon is all about. Canon camcorders,
powered by decades of optical superiority and technical dominance, deliver fully on the promise
of image quality. Unparalleled optics and the most advanced technology don’t just capture your
vision perfectly—they imbue it with the quality and lasting impact it deserves. An extensive array
of options in format, features and functionality ensure that the ideal Canon camcorder awaits,
ready to make your video everything it can be.
Standard Definition Camcorders High Definition Camcorders
(Misty Silver) (Sunrise Red) (Evening Blue)

4
VIXIA High Definition Camcorders
Standard Definition Camcorders
Professional Camcorders
FLASH
MEMORY
FLASH
MEMORY
Record stunning high definition video
directly to an internal flash drive or SDHC
memory card. The ultimate
in image quality
and flexibility.
VIXIA HF S11/HF S10/HF S100/
HF20/HF200 . . . . . . . . . . . . . . . . 6VIXIA HG21/HG20 . . . . . . . . . 10
With the ability to record to an internal
flash drive or SDHC memory card, these
camcorders represent the epitome of
performance, style
and convenience.
Capture your precious memories direct to
DVD, for easy and immediate playback in
your home theater.
A high quality, easy way to capture your
memories. These camcorders offer
exceptional value
and utilize
widely available
MiniDV tapes.
XL H1S/XL H1A/XH G1S/
XH A1S/XL2/GL2 . . . . . . 22
Canon Pro Camcorder
Technology . . . . . . . . . . . 25
Contents
DVD BURNER. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
WATERPROOF CASE . . . . . . . . . . . . . . . . . . . . . . . . . . 19
EOS DIGITAL SLR CAMERAS. . . . . . . . . . . . . . . . . . . . 26
POWERSHOT DIGITAL CAMERAS . . . . . . . . . . . . . . . . 27
CANON ADVANTAGE. . . . . . . . . . . . . . . . . . . . . . . . . . 28
CANON DIGITAL VIDEO TECHNOLOGY . . . . . . . . . . . . 32
RECORDING CHART . . . . . . . . . . . . . . . . . . . . . . . . . . 38
SOFTWARE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Record high definition video to a built-in
hard disk drive. Long recording time means
you’ll never miss
the action.
Capture high definition video to readily
available MiniDV cassette tapes for vast
editing options.
VIXIA HV40 . . . . . . . . . . . . . . . 12
Single camera or multi-camera shoots. Shoulder-mount or
handheld. Canon professional camcorders
have you covered.
DC420/DC410 . . . . . . . . . . . . 16 ZR960 . . . . . . . . . . . . . . . . . . . 17FS22/FS21/FS200. . . . . . . . . 14

76
HIGH DEFINITION
FLASH
MEMORY
• Record to a 64GB (VIXIA HF S11)/ 32GB (VIXIA HF S10) internal flash drive or
directly to an SDHC memory card (VIXIA HF S100: SDHC memory card slot only)
• Genuine Canon 10x HD Video Lens delivers unsurpassed image quality
• Canon 1/2.6" 8.59 Megapixel Full HD CMOS Image Sensor and RGB
Primary Color Filter capture video and photos with astonishing detail
• Canon DIGIC DV III Image Processor enables a variety of technologies including:
Genuine Canon Face Detection, an Advanced Auto Exposure System and
Simultaneous Photo Recording
• Dynamic SuperRange Optical Image Stabilizer (VIXIA HF S11) delivers the
ultimate in shake correction by providing continuous adjustment throughout
the entire zoom range
The Pinnacle of High Definition
Canon’s flagship VIXIA HF S11 and premium quality VIXIA HF S10/
VIXIA HF S100 camcorders blur the line between amateur and professional.
A Genuine Canon HD Video Lens and 8.59 Megapixel Full HD CMOS Image
Sensor deliver spectacular video and breathtaking 8.0 Megapixel photos.
And,
Genuine Canon Face Detection ensures perfect faces every time.
The VIXIA HF S11 features Advanced Video Snapshot Mode, which
allows you to create a series of 4-second video clips during recording
and playback, and Night Scene Mode for perfect nighttime exposure.
• VIXIA HF S11/HF S10/HF S100 Body
• Battery Pack BP-807
• Compact Power Adapter CA-570
• Wireless Controller WL-D88
• Component Cable CTC-100/S
• Stereo Video Cable STV-250N
• USB Interface Cable IFC-400PCU
• Digital Video Solution Disk
• Pixela ImageMixer 3SE Video Editing
Software
• Music CD
FEATURES
KIT CONTENTS
10X
Optical Zoom SDHC
Card Slot
32GB
Internal Memory
VIXIA HF S10
VIXIA HF S11 kit contents shown
Intelligent
Li-Ion
Batteries
Dynamic
SuperRange
OIS
24
Mbps
SuperRange
OIS
Full HD
CMOS
Multi-Angle
Vivid LCD RGB
Primary
Color Filter
30p
Progressive
Quick
Start
Program
AE HDMI
LED
Video Light
N igh t S c e ne
Mode
SDHC
Mini
Advanced
ACC Shoe
DVD Burner
DW-100
Compatible
Histogram
Display
Continuous
Grab
Face
Detection
Instant
AF
24p
Cinema Mode
Pict
Bridge
SDHC memory cards are recommended for capacity and guaranteed speed. Class 4 or higher speed required for 1920 x 1080 recording mode on VIXIA HF S11/HF S10/HF S100.
*Featured in VIXIA HF S11 only. ** “x.v.Color” and the “x.v.Color” logo are trademarks of Sony Corporation. † High Definition footage in the AVCHD format can be copied onto DVD media with
included software. However, DVD media containing AVCHD footage should only be used in AVCHD compatible players otherwise the DVD player may fail to eject the media and may erase its con-
tents without warning.
10X
Optical Zoom SDHC
Card Slot
VIXIA HF S100
DIGIC
DV III
1920 x 1080
Recording
9point
AiAF
USB 2.0
HS
Video
Snapshot
Mode
Advanced
Vi de o S naps h o t
Mode
Dual
Shot
Pre-
Record
Custom Key
and Dial
Still Image
Software
Video
Editing
Software
6
Canon 8.59 Megapixel Full HD
CMOS Image Sensor
†
†
**
10X
Optical Zoom SDHC
Card Slot
64GB
Internal Memory
VIXIA HF S11
†
** **
NEW
*
*
*
**

8
Compact,Lightweight, Incredibly Functional
9
HIGH DEFINITION
FLASH
MEMORY
SDHC memory cards are recommended for capacity and guaranteed speed. Class 4 or higher speed required for 1920 x 1080 recording mode on VIXIA HF20/HF200.
*“x.v.Color” andthe “x.v.Color” logo are trademarks of Sony Corporation. † High definition footage in the AVCHD format can be copied onto DVD media with included software. However, DVD
media containing AVCHD footage should only be used in AVCHD compatible players otherwise the DVD player may fail to eject the media and may erase its contents without warning.
15X
Optical Zoom SDHC
Card Slot
VIXIA HF200
†
*
†
*
•Record to a 32GB internal flash drive or directly to an SDHC memory card
(VIXIA HF 200: SDHC memory card slot only)
•Ultra-sleek, compact and lightweight design
•Genuine Canon 15x HD Video Lens delivers unsurpassed image quality
•Canon 3.89 Megapixel Full HD CMOS Image Sensor and RGB Primary Color
Filter capture incredibly lifelike video and photos
•Canon DIGIC DV III Image Processor provides the ultimate in color and
imaging performance
Reduced in size and lighter than ever, the VIXIA HF20 and VIXIA HF200
camcorders feature an integrated layout that puts major functionality in
the palm of your hand. The 15x HD Video Zoom Lens, 3.89 Megapixel
Full HD CMOS Image Sensor and DIGIC DV III Image Processor ensure
top-notch image quality. Fun features like Video Snapshot Mode and
seamless switching between video and photo make this go-anywhere
flash memory camcorder even more fun to take along.
•VIXIA HF20/HF200 Body
•Battery Pack BP-809
•Compact Power Adapter CA-570
• Wireless Controller WL-D88
•Component Cable CTC-100/S
•Stereo Video Cable STV-250N
• USBInterfaceCable IFC-400PCU
•Wrist Strap
•Digital Video Solution Disk
•Pixela ImageMixer 3SE Video
Editing Software
•Music CD
FEATURES
DIGIC DV III Image Processor
KIT CONTENTS
15X
Optical Zoom SDHC
Card Slot
32GB
Internal Memory
VIXIA HF20
VIXIA HF20 kit contents shown
Intelligent
Li-Ion
Batteries
1920 x 1080
Recording
Multi-Angle
Vivid LCD
RGB
Primary
Color Filter
30p
Progressive
Quick
Start
Program
AE HDMI LED
Video Light
SDHC Mini
Advanced
ACC Shoe
DVD Burner
DW-100
Compatible
9point
AiAF
Histogram
Display
Continuous
Grab
USB 2.0
HS
Face
Detection
SuperRange
OIS
24p
Cinema Mode
Pict
Bridge
DIGIC
DV III
Instant
AF
24
Mbps
SuperRange
OIS
Full HD
CMOS
Instant
AF
DIGIC
DV III
1920 x 1080
Recording
Video
Snapshot
Mode
Dual
Shot
Pre-
Record
Still Image
Software
Video
Editing
Software
The compact and lightweight WP-V1 Waterproof
Case provides protection down to 130 ft./40m.
Capture
Underwater Video
Tolearn more, see page 19.

VIXIA HG21
VIXIA HG20
120GB
60GB
Hard Disk Drive
11 hr. 5 min.
5 hr. 30 min.
MXP*
High Image Quality
(24Mbps, 1920 X 1080)
45 hr. 55 min.
22 hr. 55 min.
LP
Long Play
(5Mbps, 1440 X 1080)
* MXP mode requires class 4 or higher SDHC card
Large Capacity Hard Disk Drive
118SDHC memory cards are recommended for capacity and guaranteed speed. Class 4 or higher speed required for 1920 x 1080 recording mode on VIXIA HG21/HG20.
† High definition footage in the AVCHD format can be copied onto DVD media with included software. However, DVD media containing AVCHD footage should only be used in AVCHD
compatible players otherwise the DVD player may fail to eject the media and may erase its contents without warning.
HIGH DEFINITION
12X
Optical Zoom SDHC
Card Slot
60 GB
Internal Memory
VIXIA HG20
• Record to the 120GB (VIXIA HG21)/60GB (VIXIA HG20) hard disk drive or
directly to an SDHC memory card
• Brilliant clarity with a Genuine Canon 12x HD Video Lens
• Canon 3.3 Megapixel Full HD CMOS Image Sensor and RGB Primary Color
Filter for accurate color reproduction
• DIGIC DV II Image Processor for stunning color and clarity
• 24Mbps Recording for exceptional lifelike tone and detail
Long Recording to HDD
Convenience and flexibility are yours with an internal hard disk drive
that lets you capture up to 45 hours (VIXIA HG21)/22 hours (VIXIA HG20)
of vivid HD video and SDHC card compatibility. A Genuine Canon 12x HD
Video Lens and 24Mbps Recording deliver exceptional image quality. A
simple and intuitive interface makes operation a breeze, and a Mini
Advanced Accessory Shoe Terminal allows you to attach optional Canon
accessories for expanded shooting options.
• VIXIA HG21/HG20 Body
• Battery Pack BP-807
• Compact Power Adapter CA-570
• Wireless Controller WL-D88
• Component Cable CTC-100/S
• Stereo Video Cable STV-250N
• USB Interface Cable IFC-400PCU
• Digital Video Solution Disk
• Pixela ImageMixer 3SE Video
Editing Software
KIT CONTENTS
Multi-Angle
VividLCD* RGB
Primary
Color Filter
Quick
Start
Program
AE
HDMI SDHC
Mini
Advanced
ACC Shoe
DVD Burner
DW-100
Compatible
9point
AiAF
Histogram
Display
Grab
Pict
Bridge
Still Image
Software
Video
Editing
Software
USB 2.0
HS
Instant
AF
1920 x 1080
Recording
SuperRange
OIS
24p
Cinema Mode
FEATURES
24
Mbps
VIXIA HG21 features a 120GB
internal hard disk drive
12X
Optical Zoom SDHC
Card Slot
120 GB
Internal Memory
VIXIA HG21
Full HD
CMOS
DIGIC
DV II
VIXIA HG21 kit contents shown
Intelligent
Li-Ion
Batteries
30p
Progressive
* VIXIA HG21 only
†
10
†

12
• Genuine Canon 10x HD Video Lens delivers unsurpassed image quality
• Canon 2.96 Megapixel Full HD CMOS Image Sensor with RGB Primary Color
Filter for breathtaking resolution and vivid color
• Canon DIGIC DV II Image Processor for stunning color and clarity
• SuperRange Optical Image Stabilizer for steady video and photos
• Custom Key allows fast and easy access to frequently used features
The Complete HD Experience HIGH DEFINITION
The VIXIA HV40 delivers all the quality of the renowned Canon HD Camera
System as it records to convenient, widely available MiniDV tapes. With a
Genuine Canon 10x HD Video Lens, 2.96 Megapixel Full HD CMOS Image
Sensor and Canon DIGIC DV II Image Processor, all your video and photos
are captured with breathtaking clarity. Native 24p Mode allows 24 frames
to be captured and recorded and a handy Custom Key provides easy
access to frequently-used functions with one button. • VIXIA HV40 Body
• Battery Pack BP-2L13
• Compact Power Adapter CA-570
• Wireless Controller WL-D87
• Component Cable CTC-100/S
• Stereo Video Cable STV-250N
• USB Interface Cable IFC-400PCU
• Digital Video Solution Disk
KIT CONTENTS
SuperRange
OIS
Full HD
CMOS
Multi-Angle
Vivid LCD RGB
Primary
Color Filter
30p
Progressive
Program
AE HDMI LED
Video Light
MiniSD Advanced
ACC Shoe 9point
AiAF
Histogram
Display
Grab
Still Image
Software
USB 2.0
Instant
AF
Instant
AF
24p
Cinema Mode
FEATURES
DIGIC DV II Image Processor
Pict
Bridge
10X
Optical Zoom HDV 1080i
VIXIA HV40
Custom
Key
DIGIC
DV II

1514
• Record to the 32GB (FS22)/16GB (FS21) internal flash drive or directly to an
SDHC memory card (FS200: SDHC memory card slot only)
• Ultra-sleek, compact and lightweight design (7.9 oz)
• Genuine Canon 48x (FS22/FS21)/41x (FS200) Advanced Zoom gets you
closer and wider, while preserving image quality
• Canon DIGIC DV II Image Processor for stunning color and clarity for video
and photos
• Pre-Record lets you capture the action before it even starts, so you will never
miss a precious moment
Keep the Fun Going Longer
Capturing your precious memories has never been faster, easier or more
fun. These flash memory camcorders are super compact and lightweight
for go-anywhere convenience, and offer a host of Canon features for
recording beautiful quality video. Shooting is long and dependable,
even with a small charge, and the ability to record to a removable
SDHC memory card lets you share your memories quickly and easily.
Stabilizer
• FS22/FS21/FS200 Body
• Battery Pack BP-808
• Compact Power Adapter CA-570
• Wireless Controller WL-D88
(FS22 only)
• Stereo Video Cable STV-250N
• USB Interface Cable IFC-400PCU
• Wrist Strap
• Digital Video Solution Disk
• Pixela ImageMixer 3SE Video
Editing Software
• Music CD
KIT CONTENTS
Intelligent
Li-Ion
Batteries
Widescreen
HR
Program
AE
Quick
Start
LED
Video Light
SDHC 9point
AiAF
Histogram
Display
USB 2.0
HS
Advanced
Zoom
DIGIC
DV II
FEATURES
DVD Burner
DW-100
Compatible
Dark Shadow
Misty Silver
STANDARD DEFINITION
FLASH
MEMORY
41X
Advanced Zoom SDHC
Card Slot
FS200
48X
Advanced Zoom 32GB
Internal Memory SDHC
Card Slot
FS22
48X
Advanced Zoom 16GB
Internal Memory SDHC
Card Slot
FS21
FS22 kit contents shown
SDHC memory cards are recommended for capacity and guaranteed speed.
Class 2 or higher speed required for recording on FS22/FS21/FS200.
Misty Silver
Sunrise Red
Evening Blue
DIGIC DV II Image Processor
Video
Snapshot
Mode
Dual
Shot
Pre-
Record
Video
Editing
Software
Still Image
Software
Pict
Bridge

1716
• Genuine Canon 48x (DC420)/41x (DC410) Advanced Zoom gets you closer
and wider, while preserving image quality
• 1.07 Megapixel CCD Image Sensor for sharp video and photos (DC420)
• Canon DIGIC DV II Image Processor for stunning video color and clarity
• Quick Start to conserve battery power and be ready to record again in less
than a second
• MIC Terminal provides added audio flexibility (DC410)
Clear and Close-up, Straight to DVD
These camcorders record straight to DVD for immediate playback right in
your own home theater. Images are recorded in crisp and vivid
widescreen format thanks to Genuine Canon 48x (DC420) or 41x (DC410)
Advanced Zoom and high resolution widescreen mode. A high capacity
battery and low power consumption deliver long recording times, while
features like Quick Start and Easy Mode add up to true convenience.
LCD Video
Light
Stabilizer
• DC420/DC410 Body
• Battery Pack NB-2LH
• Compact Power Adapter CA-570
• Stereo Video Cable STV-250N
• USB Interface Cable IFC-300PCU
(DC420 only)
KIT CONTENTS
Quick
Start
MIC
Terminal†
Program
AE
SDHC 9point
AiAF
USB 2.0
HS*
Advanced
Zoom
FEATURES
DIGIC
DV II
DC420 kit contents shown
STANDARD DEFINITION
Pict
Bridge*
41X
Advanced Zoom DVD
-R/-RW/-R DL
DC410
48X
Advanced Zoom DVD
-R/-RW/-R DL
DC420
• Genuine Canon 41x Advanced Zoom gets you closer and wider, while pre-
serving image quality
• Canon DIGIC DV Image Processor for stunning video color and clarity
• Quick Start to conserve battery power and be ready to record again in less
than a second
• Widescreen HR Recording for high resolution playback on your 16:9
widescreen TV
• MIC Terminal provides added audio flexibility
Widescreen Video Made Easy
The value-packed ZR960 lets you capture stunningly clear, high-resolution
video to convenient MiniDV tapes in a 16:9 widescreen format that’s
perfect for viewing on your widescreen TV. Genuine Canon 41x
Advanced Zoom, Canon DIGIC DV Image Processor and Image Stabilizer
deliver beautiful image quality that’s clear and steady even at maximum
zoom. Quick Start and Easy Mode make shooting fun and simple,
while a microphone terminal and compatibility with optional Canon
lens accessories add superb flexibility.
LCD Video
Light
Stabilizer
• ZR960 Body
• Battery Pack BP-2L5
• Compact Power Adapter CA-590
• Stereo Video Cable STV-250N
KIT CONTENTS
Quick
Start
Program
AE MIC
Terminal
Advanced
Zoom
DIGIC
DV
Frost Silver/Dark Gray
Titanic Silver/Dark Gray
Titanic Silver/Middle Gray
ZR960 kit contents shown
41X
Advanced Zoom
MiniDV
ZR960
FEATURES
STANDARD DEFINITION
Widescreen
HR
Widescreen
HR
Genuine Canon Video Lens Advanced Zoom
†
* DC420 only † DC410 only

CREATE YOUR OWN DVD
WITH EASE
18
•AVCHD/MPEG-2 Burner
•Works with Canon flash memory and hard disk drive camcorders
•Super simple one-touch operation
•Playback your videos through your camcorder (AVCHD Only)*
•Flexible recording options add convenience
Create and Play Your Own DVDs
Canon simplifies your video experience with this one-touch DVD
burner. Just connect your Canon flash memory or hard disk drive
camcorder to record over two and one-half hours of footage onto
a standard 5" DVD. The burner can also be used to play AVCHD
DVDs on your television. Choose to record all, part, or previously
unrecorded video from your camcorder.
DVD BURNER
* Canon VIXIA HF S11, HF S10, HF S100, HF20, HF200, HF11, HF10, HF100, HG21, HG20, HG10. † DVD media containing AVCHD footage should only be used in AVCHD compatible players otherwise the DVD
player may fail to eject the media and may erase its contents without warning. AVCHD discs containing scenes recorded in MXP mode cannot be created with the optional DW-100 DVD Burner. Movies recorded
in MXP mode can be copied to Blu-ray Discs or a PC’s hard disk drive using the ImageMixer 3SE software that is bundled with the VIXIA HF S11, HF S10, HF S100, HF20, HF200, HF11, HG21, or HG20.
Records your
footage onto
standard 5" DVDs
3PLAY
2RECORD
1CONNECT
Connect the DW-100 to a compatible
Canon Camcorder.
Press to record your footage to a
standard 5" DVD.
Play back your DVD
at your convenience!
†
19
• Add exciting underwater capability to Canon VIXIA HF20 and VIXIA HF200
flash memory camcorders
• Provides waterproof protection up to 130 feet/40 meters
• Compact and lightweight design
• Buttons provide easy, accurate operation and control
High Definition Underwater Video
Preserve every amazing discovery on your diving and snorkeling
adventures! Canon’s WP-V1 Waterproof Case makes it easy to capture
vivid, high-definition video underwater. Compact and lightweight,
it’s a snap to pack on any trip. The case keeps your VIXIA HF20
or VIXIA HF200 waterproof all the way to 130 feet (40 meters) below
the surface.
Well-designed buttons allow you
to control the camcorder quickly
and easily
WP-V1
Capture the sea’s vibrant color and
amazing clarity in stunning high
definition.
CAPTURE ALL THE
WONDERS OF THE OCEAN
UNDERWATER
WATERPROOF
CASE
Record the delicate details of reef
life with ultra precision.
