Extraordinary HD in the Palm of Your Hand
• Records crisp high definition video to a 32GB (VIXIA HF M41)/
16GB (VIXIA HF M40) internal flash drive or directly
to 2 SDXC-compatible memory card slots (VIXIA HF M400:
2 SDXC-compatible memory card slots only)
• Genuine Canon 10x HD Video Lens
• Canon HD CMOS Pro Image Sensor
• Canon DIGIC DV III Image Processor
• Dynamic SuperRange OIS with Powered IS
• Instant AF
• 24Mbps Recording
• 3.0" Touch Panel LCD and Color Viewfinder (VIXIA HF M41 only)
• Smart Auto
• Touch & Track and Genuine Canon Face Detection
• Cinema-Look Filters
• Story Creator
• Touch Decoration
• Relay Recording
• HD-to-SD Downconversion (VIXIA HF M41/ VIXIA HF M40 only)
• 24p Cinema Mode and 30p Progressive Mode
Canon HD Technology at Your Fingertips
• Records crisp high definition video to a 32GB (VIXIA HF R21)/
8GB (VIXIA HF R20) internal flash drive or directly to 2 SDXC-
compatible memory card slots (VIXIA HF R200: 2 SDXC-
compatible memory card slots only)
• Genuine Canon HD Video Lens with 28x Advanced Zoom
• Canon 3.2-megapixel Full HD CMOS Image Sensor
• Canon DIGIC DV III Image Processor
• Dynamic Image Stabilization
• 24Mbps Recording
• 3.0" Touch Panel LCD
• Smart Auto
• Touch & Track and Genuine Canon Face Detection
• Touch Decoration
• Relay Recording
• HD-to-SD Downconversion (VIXIA HF R21/ VIXIA HF R20 only)
• Eye-Fi* SD Memory Card compatibility
• 1080p Output
• 24p Cinema Mode and 30p Progressive Mode
The Flash of Brilliance
• Records video directly to 8GB internal flash drive (FS40
only) or directly to an SDXC-compatible memory card
slot for fast and easy sharing of your memories
• Compact and Lightweight Design (7.8 oz.)
• Genuine Canon 41x Advanced Zoom
• Canon DIGIC DV II Image Processor
• Dynamic Image Stabilization
• Advanced Video Snapshot
• Eye-Fi* SD Memory Card compatibility
• Quick Start
• Widescreen HR Recording
• Quick Charge
• Intelligent Lithium-ion Battery
• 2.7" Widescreen LCD
• Built-in Video Light
• Pre-record
• Includes Pixela Video Browser Software Wireless Audio Capture Made Simple
• Compatible with Canon VIXIA HF G10, VIXIA HF M41, VIXIA
HF M40, VIXIA HF M400, VIXIA HF R21, VIXIA HF R20, and
VIXIA HF R200 Flash Memory camcorders
• Range up to 164 feet (50m)
• Bluetooth Version 2.0 technology
• Consists of wireless receiver and transmitter
• Built-in transceiver allows easy two-way communication
Professional-Quality High Definition
• Records crisp high definition video to a 32GB internal flash
drive or directly to 2 SDXC-compatible memory card slots
• Genuine Canon 10x HD Video Lens with 8-Blade Iris and
manual focus ring
• Canon HD CMOS Pro Image Sensor
• Canon DIGIC DV III Image Processor
• Dynamic SuperRange OIS with Powered IS
• Instant AF
• 24Mbps Recording
• 3.5" High Resolution Touch Panel LCD (922,000 dots)
• Color Viewfinder
• Touch & Track and Genuine Canon Face Detection
• Smart Auto
• Relay Recording
• Native 24p Mode
• 24p Cinema Mode & 30p Progressive Mode
• Professional Shooting Assist Functions
• Cinema-Look Filters
• Tele Macro
Impeccable HD Video and Photos
• Records crisp high definition video to a 32GB internal flash
drive or directly to 2 SDXC-compatible memory card slots
• Genuine Canon 10x HD Video Lens
• Canon 1/2.6" 8.59-megapixel Full HD CMOS Image Sensor
• Canon DIGIC DV III Image Processor
• Dynamic SuperRange OIS with Powered IS
• Instant AF
• 24Mbps Recording
• 3.5" High Resolution Touch Panel LCD (922,000 dots)
• Color Viewfinder
• Touch & Track and Genuine Canon Face Detection
• Smart Auto
• Native 24p Mode
• 24p Cinema Mode & 30p Progressive Mode
• Relay Recording
• HD-to-SD Downconversion
• Eye-Fi* SD Memory Card compatibility
• Professional Shooting Assist Functions
WP-V3 WM-V1
High Definition Flash Memory Camcorder Standard Definition Flash Memory Camcorder Wireless MicrophoneWaterproof Case High Definition Flash Memory CamcorderHigh Definition Flash Memory CamcorderHigh Definition Flash Memory Camcorder
Capture the sea's
vibrant color and
amazing clarity
in stunning high
definition.
CAPTURE ALL THE WONDERS OF THE OCEAN
Capture HD Underwater Video
• Compatible with Canon VIXIA HF M41, VIXIA HF M40,
VIXIA HF M400 Flash Memory camcorders
• Provides waterproof protection up to
130 feet (40m)
• Compact and lightweight design
• Buttons provide easy operation and control
WP-V3
* Canon camcorders are not guaranteed to support Eye-Fi card functions, including wireless transfer.
In case of an issue with the Eye-Fi card, please consult with the card manufacturer. The use of
Eye-Fi cards may not be approved in all regions, or from one region to another, please contact
the card manufacturer for status of approval in the country/region of use.
All images and effects simulated. Specifications and availability are subject to change without notice. Weight
and dimensions are approximate. Canon, VIXIA and DIGIC are registered trademarks of Canon Inc. in the United
States and may also be registered trademarks or trademarks in other countries. IMAGEANYWARE is a trade-
mark of Canon. HDMI, the HDMI logo and High Definition Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LLC. The Bluetooth word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks by Canon, Inc. is under license. AVCHD and the AVCHD logo are
trademarks of Matsushita Electric Industrial Co., LTD. and Sony Corporation. The SDXC logo is a trademark of
SD-3C, LLC. Other names and products not mentioned above may be registered trademarks or trademarks of
their respective companies. Canon camcorders are not guaranteed to support Eye-Fi card functions, including
wireless transfer. In case of an issue with the Eye-Fi card, please consult with the card manufacturer. The use
of Eye-Fi cards may not be approved in all regions, or from one region to another, please contact the card manu-
facturer for status of approval in the country/region of use. Warning: Unauthorized recording of copyrighted mate-
rials may infringe on the rights of copyright owners and be contrary to copyright laws. Use of genuine Canon
accessories is recommended: this product is designed to perform optimally when used with genuine Canon
accessories. Canon makes no representations or warranties with respect to any third party accessory or prod-
uct mentioned herein.
0150W446 1/11 ©2011 CANON U.S.A., INC. ALL RIGHTS RESERVED. PRINTED IN U.S.A.
1-800-OK-CANON
WM-V1
DIGITAL
CAMCORDER
R E F E R E N C E G U I D E
WINTER/SPRING 2011
Shoot. Capture. See. Be HD.

Dynamic SuperRange Optical
Image Stabilizer with Powered IS
Dynamic SuperRange OIS
takes shake correction to a
whole new level. It provides
continuous adjustment
throughout the entire zoom
range to correct an even broader range of
motion. Extra compensation is applied at
wide-angle focal lengths to help eliminate
unwanted vibration common with walking. Powered IS provides
an even higher level of compensation for subtle hand movement
at the telephoto end of the zoom range.
Smart Auto
Smart Auto makes shooting great video easier than
ever before. Using the power of Canon’s DIGIC DV III
Image Processor, the camcorder intelligently detects and
analyzes faces, brightness, color, distance and movement, then
automatically selects the best settings for the scene. Whether
capturing a sunset, a day at the beach, or a fast-paced soccer
game, Smart Auto delivers exceptionally accurate results.
Touch & Track
Touch & Track allows any subject (pets, vehicles, etc.) to be
the focal point of your video simply by selecting it on the
Touch Panel LCD. It continuously tracks your subject while
automatically adjusting focus and exposure.
Genuine Canon Face Detection
The same high quality Face Detection technology
used in Canon digital cameras is available in
Canon VIXIA camcorders. Up to 35 faces can
automatically be detected, and 9 detection frames can be
displayed at one time. It will recognize faces that are turned
down or sideways. In addition, a specific face may be selected
as the main subject for continuous tracking. Playback also
allows you to access specific scenes based on faces.
Cinema-Look Filters
Express your creative vision
through distinctive built-in
filters. Choose from among
nine filters as you record to
create video with a variety
of professional cinematic looks.
Cinema Standard — Recreates the warm tones and muted
highlights of classic film
Cool — Adds a bluish tint for cool, futuristic-looking scenes
Dramatic B&W — Creates bold black-and-white videos with
high contrast and grain
Dream — Adds a magical look (soft focus) for dream-like scenes
Memory — Produces a faded, misty look, such as for flashback scenes
Nostalgic — Recreates the look of old ‘70s TV programs
Old — Gives video the aged look of old cinema
Sepia — Applies a sepia tint for an antique, faded look
Vivid — Accentuates primary colors for a bright, cheerful look
Genuine Canon Optics
Canon optics are the backbone of Canon’s
superior image quality. Using many of the same
technologies that have made Canon lenses
legendary the world over – Super Spectra
multi-coating, aspherical elements and more – Canon’s video
lenses deliver unsurpassed detail, resolution, contrast and color.
Canon DIGIC DV III Image Processor
DIGIC DV III is Canon’s most
advanced HD image processor
ever, helping to deliver enhanced image
quality, true color production for both video
and photos, and a sophisticated noise reduction system for
exceptional low-light performance. It is also the high-speed
engine which powers a variety of Canon technologies including
Genuine Canon Face Detection, Smart Auto and 8.0-megapixel
photo capture, and Cinema-Look Filters.
Instant Autofocus
Sharp focus is crucial when shooting high
definition video. Canon’s proprietary Instant Autofocus system
delivers fast, accurate focus, even when you’re shooting in
bright light, at night, or with the camera in motion. The revolu-
tionary hybrid system combines an external sensor with
Canon’s proven high-performance through-the-lens AF system.
It uses both phase difference detection and the CMOS image
sensor to dramatically decrease focusing time and help ensure
consistently sharp video.
Canon HD CMOS Pro Image Sensor
Select VIXIA camcorders feature the
Canon HD CMOS Pro Image Sensor,
a 1/3-inch native 1920 x 1080 image
sensor that incorporates the same proven
technology at the heart of Canon’s pro-grade camcorders. The
HD CMOS Pro Image Sensor defies convention: using fewer
pixels than typical consumer camcorder sensors, it delivers far
superior video performance.
Outstanding Video Resolution – The effective number of
pixels in the HD CMOS Pro sensor is exactly equal to 1920 x 1080,
the resolution of Full High Definition video. Since resizing is
not needed, Full HD video is recorded with exceptionally high
resolution.
Superb Low-Light Performance – Because there are no more
pixels than needed to capture Full
HD, each pixel site is larger and
more sensitive to light. This makes it
possible to capture high-quality
video even in dim lighting.
Wide Dynamic Range – The larger pixel area also enables
more light to be stored, making it possible to detect and
capture a wider range of tonal
values. Both highlights and shadows
are thus reproduced more accurately,
and skin tones are captured with fine
gradation.
Specification Chart Accessory Chart
HD Model VIXIA HF G10 VIXIA HF S30 VIXIA HF M41 VIXIA HF M40 VIXIA HF M400 VIXIA HF R21 VIXIA HF R20 VIXIA HF R200
Recording Media Flash Memory Flash Memory Flash Memory Flash Memory
Memory Card Slot 2x SD/SDHC/SDXC 2x SD/SDHC/SDXC 2x SD/SDHC/SDXC 2x SD/SDHC/SDXC
Internal Storage 32GB 32GB 32GB 16GB – 32GB 8GB –
Image Sensor 1/3-inch HD CMOS Pro 1/2.6-inch CMOS 1/3-inch HD CMOS Pro 1/4.85 CMOS
Total Pixels 2.37 Megapixels 8.59 Megapixels 2.37 Megapixels 3.28 Megapixels
Effective Pixels
Video: Approx. 2.07
Megapixels (1920 x 1080)
Photo: Approx. 2.07
Megapixels (1920 x 1080)
Video: Approx. 6.01
Megapixels (3264 x 1840)
Photo: Approx. 8.02
Megapixels (3264 x 2456)
Video: Approx. 2.07 Megapixels (1920 x 1080)
Photo: Approx. 2.07 Megapixels (1920 x 1080)
Video: Approx. 2.07 Megapixels (1920 x 1080)
Dynamic IS ON: Approx. 1.47 Megapixels (1616 x 909)
Advanced Zoom ON: Approx. 1.04 Megapixels (1360 x 765)
Photo: 16:9 Approx. 2.07 Megapixels (1920 x 1080)
4:3 Approx. 2.41 Megapixels (1792 x 1344)
Full HD 1920x1080
Movie Recording Yes Yes Yes Yes
Image Processor DIGIC DV III DIGIC DV III DIGIC DV III DIGIC DV III
Image Stabilizer Dynamic SuperRange OIS
with Powered IS
Dynamic SuperRange OIS
with Powered IS Dynamic SuperRange OIS with Powered IS Dynamic Image Stabilizer
Zoom Ratio (Optical/Digital) 10x/200x (Video Only) 10x/200x (Video Only) 10x/200x (Video Only) 20x/28x (Advanced Zoom)/400x (Video Only)
24Mbps Recording Yes Yes Yes Yes
Instant AF Yes Yes Yes –
Face Detection Yes Yes Yes Yes
Touch & Track Yes Yes Yes Yes
Smart Auto Yes Yes Yes Yes
Native 24p Mode Yes Yes – –
HD-to-SD Downconversion Yes Yes Yes – Yes –
LCD Screen
3.5" High Resolution Touch
Panel Widescreen LCD
Approx. 922,000 dots
3.5" High Resolution Touch
Panel Widescreen LCD
Approx. 922,000 dots
3.0" Touch Panel Widescreen LCD
Approx. 230,000 dots
3.0" Touch Panel Widescreen LCD
Approx. 230,000 dots
Viewfinder Yes Yes Yes – –
Advanced Video Snapshot Yes Yes Yes Yes
Relay Recording Yes Yes Yes Yes
USB Terminal USB 2.0 Hi-Speed USB 2.0 Hi-Speed USB 2.0 Hi-Speed USB 2.0 Hi-Speed
MIC Terminal Yes
(Manual Audio Level Control)
Yes
(Manual Audio Level Control) Yes (Manual Audio Level Control) Yes (Manual Audio Level Control)
HDMI Terminal Yes (Supports 1080p
Output, CEC, X.V. Color)
Yes
(Supports CEC, X.V. Color) Yes (Supports 1080p Output, CEC, X.V. Color) Yes (Supports 1080p Output, CEC, X.V. Color)
SD Model FS40 FS400
Recording Media Flash Memory
Memory Card Slot SD/SDHC/SDXC
Internal Storage 8GB –
Image Sensor 1/6" CCD
Total Pixels 680,000 Pixels
Effective Pixels
Video: Advanced Zoom ON (16:9):
Approx. 450,000 pixels (937 x 480)
(Wide)/360,000 pixels (839 x 430)
(Tele); Advanced Zoom OFF/Dynamic IS
ON (16:9): Approx. 360,000 pixels
(839 x 430) Photo: Approx. 450,000
pixels (809 x 554)
Image Processor DIGIC DV II
Image Stabilizer Dynamic Image Stabilizer
Advanced Zoom (16:9) 41x
Zoom Ratio
(Optical/Digital) 37x/2000x
Quick Start Yes
Smooth Zoom Control Yes
LCD Screen 2.7" Widescreen LCD
Approx. 112,000 dots
Viewfinder –
Pre-Record Yes
Advanced
Video Snapshot Yes
Program AE Mode Yes
Video Light White LED
USB Terminal USB 2.0 Hi-Speed
MIC Terminal –
Model VIXIA
HF G10
VIXIA
HF S30
VIXIA
HF M41/HF M40/
HF M400
Batteries BP-808, BP-819, BP-827
Chargers/Adapters CG-800, CA-570
Cables STV-250N, CTC-100, HTC-100
Straps NS-10, SS-600, SS-650, WS-20
Cases SC-2000, SC-A1000, SC-A80, SC-A75, HC-300
LCD Hood 3.5"–
Lenses WD-H58W WD-H58 WD-H43, TL-H43, FS-43UII
TL-H58
Microphone DM-100, SM-V1, WM-V1
Video Light VL-5, VFL-2
Waterproof Case WP-V3 – Yes
Remote Control Adapter RA-V1 – Yes
Model VIXIA
HF R21/HF R20/HF R200 FS40/FS400
Batteries BP-110 BP-808
Chargers/Adapters CG-110, CA-110 CG-800, CA-570
Cables STV-250N, CTC-100, HTC-100 STV-250N
Straps NS-10, SS-600, SS-650, WS-20 WS-20
Cases SC-2000, SC-A1000, SC-A80, SC-A75
LCD Hood – 2.7"
Lenses WD-H34II, TL-H34II –
Microphone WM-V1 –
Video Light –
Cinema Standard
Cool
Canon Video Technology
