16x Manual Servo Zoom Lens
XL 5.4-86.4mm f/1.6
• Fully manual focus with markings.
• Power or manual zoom with markings.
• Auto or manual iris.
• (2) ND filters (ND2.7 and ND5).
20x Zoom Lens XL 5.4-108mm
f/1.6-3.5 L IS
• 20x professional L-series Fluorite zoom lens.
• Zoom and focus presets.
• Super Range Optical Image Stabilization,(2)
built-in ND filters,manual focus and zoom rings,
and a Push AF button.
Wide-Angle 3x Zoom Lens
XL 3.4-10.2mm f/1.8-2.2
• This 3.4mm–10.2mm short zoom lens is ideal
for shooting interior and studio shooting as well
as landscapes.
16x Zoom Lens XL 5.5-88mm
f/1.6-2.6 IS II
• 16x zoom lens.
• Resolves 600 TV lines exceeding the DV standard
of 500 TV lines for extraordinary sharpness.
• Super Range Optical Image Stabilization,
(1) built-in ND filter,manual focus and zoom
rings,and a Push AF button.
Professional Accessories
World Renowned Interchangeable Lens System for Unsurpassed Options.
75164 WF 2/10/05 10:24 AM Page 2

Extender XL 1.6x
• Increases the focal length of Canon
XL lenses by 1.6x.
• The Extender XL 1.6x is not compatible
with the Canon 3x Zoom lens.
EF Adapter XL
• Allows the attachment of Canon
photographic EF lenses to the XL2.
• The EF Adapter XL is not compatible
with Canon EF-S lenses.
Ratio Converter RC-72
• When shooting in 4:3 Mode, this 0.8x
converter provides the same angle of
view as 16:9 Mode.
• The Ratio Converter RC-72 is not
compatible with the Canon 3x Zoom
lens.
EF Lenses
• Select from over 50 high-quality
Canon EF lenses,ranging from
Fisheye to Super Telephoto to a
choice of versatile zoom models.
WD-58H
• Get closer to the subject and get
more in the shot with this wide-angle
converter for a 0.72x wider angle
of view.
75164 WF 2/10/05 10:25 AM Page 3

BP-915
This compact lithium ion battery pack has no
memory property, so you can charge at any
time without the worry of lowering battery
life expectancy.(1500mAh)
BP-930
This high capacity lithium ion battery pack doubles
the running time when compared to the BP-915.
It allows charging at any time without the worry
of lowering the battery life expectancy. (3000mAh)
BP-945
This allows the longest running time available. Its
no memory property allows charging at anytime
without the worry of lowering the battery life
expectancy.(4500mAh)
CH-910 Dual Battery
Charger/Holder
It holds two 900 series lithium ion batteries. Can
charge them consecutively or supply power to the
camcorder. Perfect for use with the MA-100/MA-200.
CA-920 Charger/Power Adapter
Small & lightweight,it allows you to charge 900
series lithium ion batteries or supply AC power to
the camcorder using the DC-920 Coupler.
DC-920 DC Coupler
Connects to the CA-920 Charger/ Power Adapter
to provide power to the camcorder.
CB-920 Car Battery Charger
Allows for the convenience of powering your
camcorder using the DC-920 or charging lithium
ion battery packs from a car's cigarette lighter.
FU-1000 Monochrome CRT
Viewfinder Unit
Professional style 1.5 inch monochrome CRT for
use in critical shooting situations.
DM-50 Directional Mic
The DM-50 Microphone is a directional stereo mic
which connects to the Advanced Accessory Shoe.
No cables or additional power required.
ZR-1000 Zoom Remote Controller
Controls Start/Stop,Focus,On-Screen, Record Search
(+/–) Variable and Single Speed Zoom.
Lithium Ion Batteries
Adapter
Battery Chargers & DC Coupler
Viewfinder Units
MicrophoneXLR Adapter
KATA Products FireStore ProductsLightwave System Products
MA-300 Microphone Adapter
Connects (2) XLR style microphones.It attaches to
the camcorder's Advanced Accessory Shoe,providing
power and connection without any wires.
TA-100 Tripod Adapter
Allows you to quickly mount/dismount the XL2 on
or from a tripod.
KATA Bag
This durable bag has a solid frame
that protects the camcorder while
in transport or storage. Has enough
space to fit the camcorder while
fully loaded with available
accessories for quick out of the
bag shooting. Small enough to
fit in most airline overhead bins.
KATA Raincover
This slick looking raincover
protects the camcorder from the
elements while still providing
plenty of space to use all camera
buttons for ease of operation.
EQ-XL/EQ-GL Equalizer
Equalizer will provide wind noise
protection to 40 mph (EQ-XL)
and 25 mph (EQ-GL) with no dB
loss (dialogue) in the mid-range
with a fully balanced frequency
response curve.
MM-XL1 Mini-Mount
Mini-mount will provide a true
foundation presence for high
quality audio recording, effec-
tively eliminating zoom motor
drone and gear tap noise.The
Mini-mount is of a universal and
modular design that enables you
to instantly switch to other mics
and will adapt to a boom pole.
Remote Controller
FireStore FS-4
Portable DTE Recorder
The FireStore FS-4 eliminates the
need to capture prior to editing and
provides a confidence,drop-out free
recording simultaneously to tape.
Compact,portable,and rugged,
it features a 40GB (about 3 hour)
disk drive with FireWire interface.
*Additional accessories are also available.
FireStore FS-4 Pro
Portable DTE Recorder
Offering all the benefits of the
FireStore FS-4,the Pro model adds
Avid support,multiple timecode
modes, retro-record, and scene
marking.Available in 40GB (about
3 hour) and 80GB (about 6 hour)
versions.
*Additional accessories are also available.
75164 WF 2/10/05 10:25 AM Page 4

Speedlite 420EX
It can unlock a videographer’s creative
capabilities while still maintaining
exceptional ease of use.
Speedlite 550EX
More powerful than the 420EX, it offers
strict professional specifications.
HC-4100
A solid,lockable case that allows you to
protect the contents of the kit. Certified
for airline overhead bins.
HC-3200
A solid,lockable case that allows you
to protect the contents of the kit.
FS-72U Filter Set
This FS-72U Filter Set includes three
filters for better image control under
difficult lighting:ultraviolet (UV),
neutral density (ND),circular polarizer.
Video Lights Speedlite Flashes
System Cases
Filters Digital Video/Head Cleaning Cassettes
Tiffen Products
VL-10Li
Powerful yet compact,the Battery Video
Light VL-10Li, with its 10-watt illumina-
tion ,improves lighting and image quality
whether you are shooting indoors or out.
A 900 series battery is required.
VL-3
The VL-3 Video Light, connected to the
Advanced Accessory Shoe,is powered
directly by the camcorder without
cables. Ideal for "filling" in shadows
on bright days.
VFL-1
Attaches to the Advanced Accessory Shoe
for cable-free operation. It can turn on
and off automatically. (The flash feature
is not compatible with the XL2)
DVM-E60/DVM-E80
60 and 80-minute digital video cassettes.
DVM-CL
Digital video head cleaning cassette .
72mm Soft FX 2 Filter
This filter is used for softening
unwanted details while retaining
overall image clarity. It is the
ideal filter for shooting portraits.
72mm BLK Pro Mist
1/2 Filter
Similar characteristics to Pro Mist,
this filter also is great for toning
down sharpness but provides a
more subtle effect. Less lightening
of shadows and reduction of
contrast.
72mm ND6 Filter
This filter eliminates overly
bright,washed out images. It is
excellent for providing balanced
exposures and depth-of-field
control. Absorbs 2 stops.
72mm Pro Mist
1/2 Filter
This filter is exceptional for creat-
ing a mood. Outdoors or indoors,
in broad scenes or portraits. It is
excellent for toning down excessive
sharpness and reducing contrast by
moderately lightening shadow areas
without detracting from the over-
all image .
72mm ND3 Filter
This filter eliminates overly
bright,washed out images. It is
excellent for providing balanced
exposures and depth-of-field
control. Absorbs 1 stop.
Steady Stick
This small,lightweight steady
stick supplies support for the
camcorder when shooting to give
you that rock solid shot. It can
be broken down in size to allow
easy transportation.
STV-150
This cable connector allows you to attach
your camcorder to composite connections
on your TV and VCR.
Cables
STV-250N
Another miniplug connector for composite
connections on your TV and VCR.
4-pin to 4-pin IEEE 1394 Cable
Allows the connection of a digital video
camcorder to another digital video
camcorder or a computer.
S-150
For greater quality,this accessory allows
you to connect your camcorder to TVs or
VCRs that are S-video compatible.
4-pin to 6-pin IEEE 1394 Cable
Allows the connection of a digital video
camcorder to a computer.
75164 WF 2/10/05 10:26 AM Page 5

XL2 System Diagram
MM-XL1 Mini-Mount
Ratio Converter RC-72
Digital Device
(Available
Commercially)
SS-1000
Shoulder Strap
TV/VCR
(Available
Commercially)
VL-10Li
Video Light
FU-1000
Monochrome CRT
Viewfinder Unit
S-150 S-video Cable
STV-150 Stereo Video Cable
4-pin to 4-pin IEEE 1394 Cable
CB-920
Car Battery Charger
CA-920
Compact Charger
DVM-CL
DV Head Cleaning Cassette
DVM-E60/E80
Digital Video Cassette
ZR-1000
Zoom Remote Controller
WL-D4000
Wireless Controller
HC-3200 System Case
BP-930/BP-945
Lithium Ion Battery Pack
DC-920
DC Coupler Adapter Holder
KATA BagKATA Raincover
FireStore FS-4 Pro
(40GB or 80GB)
FireStore FS-4
CH-910
Dual Battery Charger
EF Adapter XL
Extender
XL 1.6x
(Except 3x lens)
Wide-Angle 3x Zoom Lens
XL 3.4-10.2mm f/1.8-2.2
16x Zoom Lens
XL 5.5-88mm f/1.6-2.6 IS II
16x Manual Servo Zoom Lens
XL 5.4-86.4mm f/1.6
EF Lens Group
(Except EF-S lenses)
Pro Mist 1/2,
BLK Pro Mist 1/2,
Soft FX 2,
ND6/ND3 Filters
FS-72U Filter Set
4-pin to 6-pin IEEE 1394 Cable
MA-300
Microphone Adapter
DM-50
Directional Microphone
TA-100 Tripod Adapter
20x Zoom Lens
XL 5.4-108mm f/1.6-3.5 L IS
Steady Stick
EQ-XL Equalizer
75164 WF 2/10/05 10:26 AM Page 6

GL2 System Diagram
FireStore FS-4 Pro
(40GB or 80GB)
FireStore FS-4
EQ-GL
TV/VCR
(Available
Commercially)
Digital Device
(Available
Commercially)
S-150 S-video Cable
STV-250N Stereo Video Cable
4-pin to 4-pin IEEE 1394 Cable
4-pin to 6-pin IEEE 1394 Cable
550EX
Speedlite
420EX
Speedlite
KATA Raincover KATA Bag HC-4100
System Case
CB-920
Car Battery Charger
CA-920
Compact Charger
CH-910
Dual Battery Charger
VFL-1 Video Light
VL-10Li Video Light
VL-3 Video Light
MA-300
2XLR Audio Adapter
DM-50
Directional Microphone
WL-D77
Wireless Controller
Stereo Microphone
(Available Commercially)
ZR-1000
Zoom Remote Controller
Steady Stick
DVM-E60/E80
Digital Video Cassette
DVM-CL
DV Head Cleaning Cassette
WD-58H Wide Converter
SS-650
Shoulder Strap BP-915/BP-930/ BP-945
Lithium Ion Battery Pack
DC-920
DC Coupler
75164 WF 2/10/05 10:26 AM Page 7

CKNOW HOW®
1-800-OK-CANON / www.usa.canon.com
Canon U.S.A., Inc.
One Canon Plaza, Lake Success, NY 11042 U.S.A.
Canon Canada Inc.
6390 Dixie Road, Mississauga, Ontario L5T 1P7 Canada
Canon Mexicana, S. DE R.L. DE C.V.
Blvd. M. A. Camacho No. 138, Piso PB, 15, 16 y 17,
Col. Lomas de Chapultepec, C.P. 11000 México, D.F. México
Canon Latin America, Inc.
703 Waterford Way, Suite 400, Miami FL 33126 U.S.A.
Canon HongKong Co., Ltd.
19/F, The Metropolis Tower, 10 Metropolis Drive,
Hunghom, Kowloon, Hong Kong
0046W354 02/05
©2005 CANON U.S.A., INC. PRINTED IN U.S.A.
www.canondv.com
Canon and Canon Know How are registered trademarks of Canon Inc. in the United States
and may also be registered marks in other countries. Other names and products not mentioned
above may be registered trademarks or trademarks of their respective companies. Warning:
Unauthorized recording of copyrighted materials may infringe on the rights of copyright
owners and be contrary to copyright laws.
75164 WF 2/10/05 10:26 AM Page 8
