EOS C300 / EOS C300 PL DIGITAL CINEMA CAMERAS
Key Features
PROFESSIONAL PRODUCTS
Canon has created the Cinema EOS System –
a definitive HD motion picture system, conceived
as an extension of the cinematographer. The
new EOS C300 and EOS C300 PL cameras,
Canon EF Cinema lenses, our comprehensive
service and support network and educational
resources are all designed to help you tell your story
the way you imagined it.
The powerful EOS C300 and EOS C300 PL cameras
are centered on Canon’s unique Super 35mm CMOS
sensor, revolutionary Canon DV III Image Processor,
and 50Mbps 4:2:2 codec writing out to dual CF cards. Compact
and lightweight, modular in design, and compatible with Canon’s new EF Cinema
lenses, as well as third party accessories, the EOS C300 and EOS C300 PL are reliable in the studio and
rugged on location – no matter how far your assignment or imagination takes you. A family of Canon EF
and PL-mount lenses designed specifically for cinematography applications includes fast cine primes and
wide-tele zooms with the optical performance, controls and usability you need. Designed with SMPTE HD
production standards, these cameras’ MPEG-2 codec conforms to an internationally recognized standard
compatible with major NLE applications, and additional features such as Canon Log Gamma ensure
seamless integration with existing production workflows. And with an entire infrastructure designed to
support and educate, troubleshoot and repair, to listen and to innovate, you will get the most from your
equipment before, during and after production. The EOS C300 and EOS C300 PL are ready to go to work.
Leave No Story Untold
• New Canon Super 35mm CMOS Sensor
• Canon DV III Image Processor
• Canon XF Codec
• Two Camera Models – EF or PL mount
• Canon Log Gamma
• Wide Dynamic Range Even in Low-Light
• Compact and Modular Design
• Wireless Remote Control with WFT-E6A
• Multiple Recording Formats Including
True 24p & Advanced Recording
• Compatibility with Third-Party Accessories
• Dual CF Card Slots and Industry Standard
Video Terminals
• Compatible with Major NLE Applications
Recommended For:
• Cinematic Film Production
• Episodic TV Production
• Documentary Film Production
• Independent Film Production
• Advertising
• Commercial Video

OPTIONAL ACCESSORIES
TECHNOLOGY
PRODUCT NAME: EOS C300 / EOS C300 PL ITEM CODE: 5779B002 (EOS C300), 5819B002 (EOS C300 PL)
EOS C300 / EOS C300 PL DIGITAL CINEMA CAMERAS
SPECIFICATIONS
PROFESSIONAL PRODUCTS
Canon Super 35mm CMOS Sensor
Modeled on the Super 35mm 3-perf motion picture film standard, Canon’s
CMOS sensor has an active image size of 24.6 x 13.8mm. It utilizes
3840 (H) x 2160 (V) photosites to perform the crucial optoelectronic
transformation of digital imaging. Each photosite is a generous 6.4 x 6.4
micrometers in area and each has a microlens that ensures the highest
efficiency in light transfer to the individual photodiode. Proprietary
technologies within the photosite simultaneously lower the image sensor
noise floor while enhancing the photon capacity of the photodiode – a combination that assures
superb dynamic range. The image sensor utilizes an innovative readout technique that delivers full
bandwidth individual RGB video components without the need for any debayering algorithms. Each
of these components has a 1920 (H) x 1080 (V) sampling structure at up to 60 frames. From these
original video components, a 1080-line 60i format or a 1280 (H) x 720 (V) at 60P format is selectively
derived. A high-speed readout significantly reduces the subjective visibility of the vertical skewing on
fast-moving horizontal subjects that is characteristic of CMOS image sensors.
Wireless File Transmitter WFT-E6A*
Greater mobility when you need it –that’s the
advantage of Canon’s optional Wireless File
Transmitter WFT-E6A. The EOS C300 and EOS
C300 PL come preconfigured so that camera
settings can be viewed and securely controlled
on third-party devices with common web
browsers, including computers, smartphones
and tablets without the need for additional
software. With the WFT-E6A module, the camera can be controlled
from up to 150 feet away over an 802.11 b/g/n/a wireless network.
The WFT-E6A lets you start and stop recording and also adjust focus,
white balance, gain and other parameters as well as adjust the aperture
of Canon EF lenses. It also gives you input marking for metadata and
offers a live view of the composition. It even supports incorporating
GPS information into the file metadata – useful for general cinematic
applications, and essential for expedition filmmakers.
* As of October 18, 2011, the Wireless File Transmitter WFT-E6A has not been authorized as
required by the rules of the Federal Communications Commission. This device is not, and
may not be offered for sale or lease, or sold or leased, until authorization is obtained.
©2011 Canon U.S.A., Inc. All rights reserved. Not responsible for typographical errors.
Availability and specications subject to change without notice. Some of the images and
effects are simulated. Canon, DIGIC and EOS are registered trademarks of Canon Inc. in
the United States and may also be trademarks or registered trademarks in other countries.
IMAGEANYWARE is a trademark of Canon. All other products and brand names may be
registered trademarks, trademarks or service marks of their respective owners in the United
States and/or other countries.
For more info:
Call 1-855-CINE-EOS (1-855-246-3367)
pro.usa.canon.com
SPECIFICATIONS EOS C300 EOS C300 PL
STANDARD DEFINITION OR HIGH DEFINITION High Definition
RECORDING / CODEC
NTSC and PAL
8 Bit MPEG-2 Long GOP
4:2:2 at 50Mbps recording
50Mbps (CBR)
Available
MXF (OP-1a)
50Mbps (CBR) 4:2:2 422P@HL: 1920x1080: 59.94i / 29.97p / 23.98p; 50i / 25p;
True 24 (24.00); 1280x720: 59.94p / 29.97p / 23.98p; 50p / 25p; True 24 (24.00);
35Mbps (VBR) 4:2:0 MP@HL: 1920x1080: 59.94i / 29.98p / 23.98p; 50i / 25p;
1280x720: 59.94p / 29.97p / 23.98p; 50p / 25p;
25Mbps (CBR) 4:2:0 MP@H14: 1440x1080: 59.94i / 29.97p / 23.98p; 50i / 25p
AUDIO
Linear PCM; 2-Channel; 16-Bit; 48kHz
Built-in Microphone: None
External Audio Inputs: 2 – XLR inputs (Auto and Manual level settings)
Recording Channel Selection: Two channel recording
XLR Mic Trimming: Available; -12dB, -6 dB, 0dB or +12dB;
Recording Level Adjustment Range: - Infinity to +18dB
Phantom Power: Available: +48V
Headphone Adjustment: 16 Settings; Volume is muted at lowest setting
1KHz Tone: Available: -12, -18 or -20 dB
IMAGE SENSOR /
IMAGE PROCESSOR
CMOS sensor (single-panel), equivalent to Super 35mm
24.6 x 13.8mm effective screen size (6.4 x 6.4 micron pixel pitch)
Progressive
1
RGB Primary Color Filter (Bayer Array)
DV III
PIXELS Approx. 9.84 megapixels (4206 x 2340)
Approx. 8.29 megapixels (3840 x 2160)
MAX. MOVIE RECORDING TIME 64GB Compact Flash (CF) card; Greater capacity is possible when both slots are
used; 25Mbps: 310 minutes; 35Mbps: 225 minutes; 50Mbps: 160 minutes
LENS Interchangeable: Choice of EF or PL mount camera bodies
FOCUSING SYSTEM Manual; Autofocus system not available
MAX SHUTTER SPEED 1/2000 sec
ISO RANGE 320 to 20000, 1-stop or 1/3-stop
ND FILTER SETTINGS Off, 1/4, 1/16, 1/64
WHITE BALANCE Auto, Manual, 2 Custom (2000K - 15,000K in 100K increments), Daylight, Tungsten
FRAME RATE NTSC: 59.94p, 59.94i, 29.97p, 23.98p; PAL: 50p, 50i, 25p; Film: 24p
MINIMUM ILLUMINATION Full AUTO mode: TBA lux; Manual mode: TBA lux
GENLOCK TERMINAL BNC (input only)
HD/SD-SDI TERMINAL BNC (output only), with embedded audio
TIMECODE TERMINALS BNC (input/output), Sync Out (BNC)
VIEWFINDER 0.52-inch diagonal, color 16:9 rotatable LCD; +2.0 to -5.5 diopter eye adjustment
LCD SCREEN (MONITOR UNIT) 4.0-inch diagonal, 1.23 megapixel color 16:9 rotatable LCD; 100% field of view;
adj. brightness, contrast, color, sharpness and backlight
MICROPHONE None Built-in
RECORDING MEDIA
CF Card (Type 1 Only): 2 slots (Movie files); UDMA supported; SD Card: 1 slot: Still
images, Custom Picture Data*, Clip Metadata and menu settings. *Custom Picture
Data and settings are not compatible with data from other Canon models
USB TERMINAL N/A
VIDEO TERMINAL Same as HD/SD-SDI Terminal
AUDIO TERMINAL XLR 3-pin jack (2), Switchable between MIC/LINE
HDMI TERMINAL Yes (Type A), output only
AV MINI-TERMINAL/HEADPHONE TERMINAL 3.5mm stereo mini-jack
WFT TERMINAL For compatible Wi-Fi Accessory
BODY DIMENSIONS ( W x H x D) Approx. 5.2 x 7.0 x 6.7 in Approx. 5.2 x 7.0 x 7.0 in
(133 x 179 x 171 mm) (with thumb rest) (133 x 179 x 177 mm) (with thumb rest)
WEIGHT (BODY ONLY) Approx. 3.2 lb (1430 g) Approx. 3.6 lb (1630 g)
SIGNAL SYSTEM
COMPRESSION
COLOR SPACE
MAXIMUM BIT RATE
CANON LOG GAMMA
FILE FORMAT
RECORDING
OPTIONS
SENSOR TYPE
SENSOR SIZE
SCANNING SYSTEM
NO. OF SENSORS
FILTER
IMAGING PROCESSOR
TOTAL PIXELS
EFFECTIVE PIXELS
DYNAMIC RANGE CHART
18%
GRAY ISOGAIN
3.9 Stops8.1 Stops ISO
320
-6dB
4.2 Stops7.8 Stops ISO
400
-4dB
5.2 Stops6.8 Stops ISO
800
2dB
4.9 Stops6.8 Stops ISO
640
0dB
5.3 Stops6.7 Stops ISO
1600
8dB
5.3 Stops6.7 Stops ISO
3200
14dB
5.3 Stops6.7 Stops ISO
6400
20dB
5.3 Stops6.7 Stops ISO
12800
26dB
5.3 Stops6.7 Stops ISO
20000
30dB
Canon Log
Base
Sensitivity
5.3 Stops6.7 Stops ISO
850
S/N
Ratio
54dB
54dB
54dB
54dB
54dB
53dB
50dB
45dB
41dB
54dB 2.5dB
ISO and Dynamic Range Specifications
(Canon Log, Progressive Scan)
