Canon EOS Rebel T3 Installation guide

EnglishFrançaisEspañol
Mode d’emploi de base
Manual básico de instrucciones
Basic Instruction Manual
E
F
S
Ce manuel de base ne couvre que les opérations les plus élémentaires.
Pour d’autres fonctions et des informations plus détaillées, voir le mode
d’emploi de l’appareil photo au format pdf sur le CD-ROM.
Este manual básico cubre solamente las operaciones más básicas. Para
ver otras funciones e información más detallada, consulte el archivo pdf
del Manual de instrucciones de la cámara en el CD-ROM.
This basic manual covers only the most basic operations. For other features and
more details, see the Camera Instruction Manual pdf file in the CD-ROM.
COPY

COPY

English
Basic Instruction Manual
This basic manual covers only the most basic operations. For other
features and more details, see the Camera Instruction Manual
pdf file in the CD-ROM.
COPY

2
The EOS REBEL T3/1100D is a high-performance, digital single-lens
reflex camera featuring a fine-detail CMOS sensor with approx. 12.2
effective megapixels, DIGIC 4, high-precision and high-speed 9-point
AF, approx. 3 fps continuous shooting, Live View shooting, and High-
Definition (HD) movie shooting.
The camera is highly responsive for shooting at anytime, provides many
functions fitted for advanced shooting, and offers many other features.
Refer to This Manual while Using the Camera to Further
Familiarize Yourself with the Camera
With a digital camera, you can immediately view the image you have
captured. While reading this manual, take a few test shots and see how
they come out. You can then better understand the camera.
To avoid botched pictures and accidents, first read the “Safety
Warnings” (p.80, 81) and “Handling Precautions” (p.8, 9).
Testing the Camera Before Use and Liability
After shooting, playback and check whether the images have been
properly recorded. If the camera or memory card is faulty and the
images cannot be recorded or downloaded to a computer, Canon
cannot be held liable for any loss or inconvenience caused.
Copyrights
Copyright laws in your country may prohibit the use of your recorded
images of people and certain subjects for anything but private
enjoyment. Also be aware that certain public performances, exhibitions,
etc., may prohibit photography even for private enjoyment.
Introduction
This camera is compatible with SD memory cards, SDHC memory
cards, and SDXC memory cards. This manual will refer to all these
cards as just “card.”
* The camera does not come with a card for recording images.
Please purchase it separately.
COPY

3
This Basic Instruction Manual only explains the camera’s basic
operations and functions. For more detailed instructions,
advanced shooting and playback procedures, printing photos,
Custom Functions, and more, see the Camera Instruction Manual
CD-ROM.
The EOS REBEL T3/EOS 1100D’s instruction manuals consist of the
following:
Camera Instruction Manual
Software and Software Instruction Manual
See pages 76 to 78 for an
overview of the software
programs, installation procedure
for a personal computer, and
how to view the Software
Instruction Manual CD-ROM.
Instruction Manuals
CD-ROM Contents
Camera Instruction
Manual (PDF file)
Explains all the camera’s functions
and operation procedures. Includes
also all the contents in this Basic
Instruction Manual.
Quick Reference
Guide (PDF file)
Simple guide centering on shooting
procedures. Its A4 size enables easy
printing to carry it around.
See page 74 on how to view the Camera Instruction
Manual (PDF) in the CD-ROM.
Camera
Basic
Instruction
Manual
(this booklet)
Camera
Instruction Manual
(CD-ROM)
EOS DIGITAL
Solution Disk
(Software CD-ROM)
Software
Instruction Manual
(CD-ROM)
COPY

4
Before starting, check that all the following items have been included
with your camera. If anything is missing, contact your dealer.
* Battery Charger LC-E10 or LC-E10E is provided. (The LC-E10E comes with a
power cord.)
If you purchased a Lens Kit, check that the lens is included.
Be careful not to lose any of the above items.
Item Check List
Battery Pack
LP-E10
(with protective cover)
Battery Charger
LC-E10/LC-E10E*
Interface Cable
Wide Strap
EW-200D
Camera
(with eyecup and body cap)
EOS DIGITAL
Solution Disk
(Software CD-ROM)
Software
Instruction
Manual
(CD-ROM)
Camera
Basic Instruction Manual
(this booklet)
Camera
Instruction
Manual
(CD-ROM)
COPY

5
Icons in this Manual
<6> : Indicates the Main Dial.
<V> <U> : Indicates the <S> cross keys.
<0> : Indicates the setting button.
0, 9, 7, 8: Indicates that the respective function remains
active for 4 sec., 6 sec., 10 sec., or 16 sec.
respectively after you let go of the button.
* In this manual, the icons and markings indicating the camera’s buttons, dials,
and settings correspond to the icons and markings on the camera and on the
LCD monitor.
3: Indicates a function which can be changed by pressing the
<M> button and changing the setting.
(p.**) : Reference page numbers for more information.
(→): Indicates that there is more information in the Camera
Instruction Manual (PDF) in the Camera Instruction Manual
CD-ROM.
: Tip or advice for better shooting.
: Problem-solving advice.
: Warning to prevent shooting problems.
: Supplemental information.
Basic Assumptions
All operations explained in this manual assume that the power switch
has already been set to <1> (p.25).
It is assumed that all the menu settings and Custom Functions are
set to the default.
For explanatory purposes, the instructions show the camera attached
with an EF-S18-55mm f/3.5-5.6 IS II lens.
Conventions Used in this Manual
COPY

6
2
1
Introduction 2
Instruction Manuals ........................................................................................... 3
Item Check List.................................................................................................. 4
Conventions Used in this Manual ...................................................................... 5
Handling Precautions ........................................................................................ 8
Quick Start Guide ............................................................................................ 10
Nomenclature .................................................................................................. 12
Getting Started 19
Charging the Battery ....................................................................................... 20
Installing and Removing the Battery and Card................................................ 22
Turning on the Power ...................................................................................... 25
Setting the Date and Time............................................................................... 27
Selecting the Interface Language.................................................................... 28
Attaching and Detaching a Lens ..................................................................... 29
About the Lens Image Stabilizer...................................................................... 31
Basic Operation............................................................................................... 32
3Menu Operations................................................................................... 34
Formatting the Card......................................................................................... 36
Switching the LCD Monitor Display ................................................................. 38
Feature Guide ................................................................................................. 39
Basic Shooting 41
1Fully Automatic Shooting........................................................................... 42
1Full Auto Techniques................................................................................. 44
7Disabling Flash.......................................................................................... 45
CCreative Auto Shooting ............................................................................. 46
2Shooting Portraits....................................................................................... 49
3Shooting Landscapes................................................................................ 50
4Shooting Close-ups .................................................................................... 51
5Shooting Moving Subjects......................................................................... 52
6Shooting Portraits at Night ......................................................................... 53
QQuick Control ............................................................................................. 54
Contents
COPY

7
Contents
6
5
4
3Shooting with the LCD Monitor (Live View Shooting) 55
AShooting with the LCD Monitor ..................................................................56
Changing the Autofocus Mode.........................................................................59
MF: Focusing Manually ....................................................................................64
Shooting Movies 65
kShooting Movies ........................................................................................66
Image Playback 69
xImage Playback..........................................................................................70
kPlaying Movies...........................................................................................71
Viewing the Camera Instruction Manual CD-ROM / Software Start Guide 73
Viewing the Camera Instruction Manual CD-ROM...........................................74
Software Start Guide........................................................................................76
Safety Warnings...............................................................................................80
COPY

8
Camera Care
This camera is a precision instrument. Do not drop it or subject it to physical
shock.
The camera is not waterproof and cannot be used underwater. If you
accidentally drop the camera into water, promptly consult your nearest
Canon Service Center. Wipe off any water droplets with a dry cloth. If the
camera has been exposed to salty air, wipe it with a well-wrung wet cloth.
Never leave the camera near anything having a strong magnetic field such
as a magnet or electric motor. Also avoid using or leaving the camera near
anything emitting strong radio waves such as a large antenna. Strong
magnetic fields can cause camera misoperation or destroy image data.
Do not leave the camera in excessive heat such as in a car in direct sunlight.
High temperatures can cause the camera to malfunction.
The camera contains precision electronic circuitry. Never attempt to
disassemble the camera yourself.
Use a blower to blow away dust on the lens, viewfinder, reflex mirror, and
focusing screen. Do not use cleaners that contain organic solvents to clean
the camera body or lens. For stubborn dirt, take the camera to the nearest
Canon Service Center.
Do not touch the camera’s electrical contacts with your fingers. This is to
prevent the contacts from corroding. Corroded contacts can cause camera
misoperation.
If the camera is suddenly brought in from the cold into a warm room,
condensation may form on the camera and internal parts. To prevent
condensation, first put the camera in a sealed plastic bag and let it adjust to
the warmer temperature before taking it out of the bag.
If condensation forms on the camera, do not use the camera. This is to avoid
damaging the camera. If there is condensation, remove the lens, card and
battery from the camera, and wait until the condensation has evaporated
before using the camera.
If the camera will not be used for an extended period, remove the battery
and store the camera in a cool, dry, well-ventilated location. Even while the
camera is in storage, press the shutter button a few times once in a while to
check that the camera is still working.
Avoid storing the camera where there are corrosive chemicals such as a
darkroom or chemical lab.
If the camera has not been used for an extended period, test all its functions
before using it. If you have not used the camera for some time or if there is
an important shoot coming up, have the camera checked by your Canon
dealer or check the camera yourself and make sure it is working properly.
Handling Precautions
COPY

9
Handling Precautions
LCD Monitor
Although the LCD monitor is manufactured with very high precision
technology with over 99.99% effective pixels, there might be a few dead
pixels among the remaining 0.01% or less pixels. Dead pixels displaying
only black or red, etc., are not a malfunction. They do not affect the images
recorded.
If the LCD monitor is left on for a prolonged period, screen burn-in may occur
where you see remnants of what was displayed. However, this is only
temporary and will disappear when the camera is left unused for a few days.
In low or high temperatures, the LCD monitor display may seem slow or it
might look black. It will return to normal at room temperature.
Cards
To protect the card and its recorded data, note the following:
Do not drop, bend, or wet the card. Do not subject it to excessive force,
physical shock, or vibration.
Do not touch the card’s electronic contacts with your fingers or anything
metallic.
Do not store or use the card near anything having a strong magnetic field
such as a TV set, speakers, or magnet. Also avoid places prone to having
static electricity.
Do not leave the card in direct sunlight or near a heat source.
Store the card in a case.
Do not store the card in hot, dusty, or humid locations.
Lens
After detaching the lens from the camera, attach the lens
caps or put down the lens with the rear end up to avoid
scratching the lens surface and electrical contacts.
Cautions During Prolonged Use
If you use continuous shooting, Live View shooting, or
movie shooting for a prolonged period, the camera may
become hot. Although this is not a malfunction, holding the
hot camera for a long period can cause slight skin burns.
About smudges adhering to the front of the sensor
Besides dust entering the camera from outside, in rare cases lubricant from the
camera’s internal parts may adhere to the front of the sensor. If visible spots
remain on the image, having the sensor cleaned by a Canon Service Center is
recommended.
Contacts
COPY

10
Quick Start Guide
1Insert the battery. (p.22)
To charge the battery, see page 20.
2Insert the card. (p.22)
With the card’s label facing toward
the camera back, insert it into the
slot.
3Attach the lens. (p.29)
Align the lens’ white or red index
with the camera’s index in the
matching color.
4Set the lens focus mode switch
to <AF>. (p.29)
5Set the power switch to <1>.
(p.25)
When the LCD monitor displays the
Date/Time setting screen, see page
27.
White index Red index
COPY

11
Quick Start Guide
6Set the Mode Dial to <1> (Full
Auto). (p.42)
All the necessary camera settings
will be set automatically.
7Focus the subject. (p.33)
Look through the viewfinder and
aim the viewfinder center over the
subject.
Press the shutter button halfway,
and the camera will focus the
subject.
If necessary, the built-in flash will
pop-up automatically.
8Take the picture. (p.33)
Press the shutter button completely
to take the picture.
9Review the picture. (→)
The captured image will be
displayed for approx. 2 sec. on the
LCD monitor.
To display the image again, press
the <x> button (p.70).
To shoot while looking at the LCD monitor, see “Live View
Shooting” (p.55).
To view the images captured so far, see “Image Playback” (p.70).
COPY

12
Nomenclature
Mode Dial (p.16)
Power switch (p.25)
<D> Flash
button
<6> Main Dial
Shutter button
(p.33)
Red-eye
reduction/
Self-timer
lamp
Grip
Mirror
Lens lock pin
Lens mount
Contacts (p.9)
Remote control
terminal
HDMI mini OUT
terminal
Digital terminal
Built-in flash/AF-assist beam
EF Lens mount index (p.29)
EF-S Lens mount index (p.29)
Flash-sync contacts
Hot shoe
<V> Focal plane
mark (p.51)
Strap mount
(p.19)
Microphone
(p.66)
Terminal
cover
Lens release button
(p.30)
Body cap (p.29)
For camera controls without reference page numbers, see the Camera
Instruction Manual (PDF) in the Camera Instruction Manual CD-ROM.
COPY

13
Nomenclature
Card slot (p.22)
<S> Cross keys (p.34)
<WZ> ISO speed setting button
<XB> White balance selection button
<Yi/j> Drive mode selection button
<ZE> AF mode selection button
<0> Setting button (p.34)
<M> Menu button (p.34)
Tripod socket
<Q/l>
Quick Control button/
Direct print button (p.54)
LCD monitor
(p.34)
<A> Live View shooting/
Movie shooting button
(p.56/66)
<O/L> Aperture/Exposure
compensation button/
Erase button
Viewfinder eyepiece
Eyecup
Dioptric adjustment knob (p.32) <A/I> AE lock/
FE lock button/Index/
Reduce button
<S/u>
AF point selection
button/
Magnify button
<B> Display button
(p.38,58,67,70)
Speaker
(p.71)
DC cord
hole
Access lamp (p.24)
Card/Battery
compartment cover (p.22)
Card/Battery compartment
cover release lever (p.22)
<x> Playback button (p.70)
Battery compartment (p.22)
COPY

Nomenclature
14
Shooting Settings Display
The display will show only the settings currently applied.
2White balance correction
BWhite balance bracketing
White balance
Q Auto
W Daylight
E Shade
R Cloudy
Y Tungsten light
U White fluorescent light
I Flash
O Custom
Battery check (p.26)
zxcn
Drive mode
uSingle shooting
iContinuous shooting
jSelf-timer:10 sec
lSelf-timer:2 sec
qSelf-timer:Continuous
Eye-Fi transmission status
(Displayed if an Eye-Fi card is used.)
Metering mode
q
Evaluative metering
wPartial metering
eCenter-weighted average metering
Quick Control icon
(p.54)
AF mode
X
One-Shot AF
9
AI Focus AF
Z
AI Servo AF
g
Manual Focusing
Picture Style
Shutter speed
Aperture
cMain Dial pointer
Shooting mode
Exposure level
indicator
Exposure
compensation
amount
AEB range
Image-recording quality
73
Large/Fine
83 Large/Normal
74 Medium/Fine
84 Medium/Normal
7aSmall 1/Fine
8aSmall 1/Normal
bSmall 2 (Fine)
cSmall 3 (Fine)
1 RAW
1+73 RAW+Large/Fine
Number of possible shots
Self-timer countdown
Number of possible shots
during WB bracketing
Highlight tone priority
Raise built-in flash
yFlash exposure
compensation
0External flash
exposure compensation
Auto Lighting Optimizer
ISO speed
COPY

15
Nomenclature
Viewfinder Information
The display will show only the settings currently applied.
<A> AE lock/
AEB in-progress
<D> Flash-ready
Improper FE lock
warning
<e> High-speed sync
(FP flash)
<d> FE lock/
FEB in-progress
<y> Flash exposure
compensation
Shutter speed
FE lock (FEL)
Busy (buSY)
Built-in flash recycling (DbuSY)
Focusing screen
Card full warning (FuLL)
Card error warning (Card)
No card warning (Card)
Aperture
Exposure level indicator
Exposure compensation amount
AEB range
Red-eye reduction lamp-on indicator
<A> Highlight tone priority
ISO speed
< 0 > Monochrome shootin
g
Max. burst
<o> Focus
confirmation light
<2>
White balance
correction
<Z>
ISO speed
AF point activation indicator < >AF point activation indicator < >
AF points
COPY

Nomenclature
16
Mode Dial
The Mode Dial includes the Basic Zone modes, Creative Zone modes,
and the Movie shooting mode.
Basic Zone
All you do is press the shutter button.
The camera sets everything to suit the
subject.
1: Full Auto (p.42)
7: Flash Off (p.45)
C: Creative Auto (p.46)
Creative Zone (→)
These modes give you more control for
shooting various subjects.
d: Program AE
s: Shutter-priority AE
f: Aperture-priority AE
a: Manual exposure
8: Automatic depth-of-field AE
Image Zone
2: Portrait (p.49)
3: Landscape (p.50)
4: Close-up (p.51)
5: Sports (p.52)
6: Night Portrait (p.53)
k: Movie shooting
(p.65)
COPY

17
Nomenclature
Lens
Lens without a distance scale
Focusing ring (p.64)
Hood mount
Filter thread
(front of lens)
Image Stabilizer switch (p.31)
Lens mount index (p.29)
Contacts (p.9)
Focus mode switch (p.29)
Zoom ring (p.30)
Zoom position index (p.30)
COPY

Nomenclature
18
Battery Charger LC-E10
Charger for Battery Pack LP-E10 (p.20).
Battery Charger LC-E10E
Charger for Battery Pack LP-E10 (p.20).
Battery pack slot
Power plug
Charge lamp
Full-charge lamp
IMPORTANT SAFETY INSTRUCTIONS-SAVE THESE INSTRUCTIONS.
DANGER-TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
CAREFULLY FOLLOW THESE INSTRUCTIONS.
For connection to a supply not in the U.S.A., use an attachment plug adapter
of the proper configuration for the power outlet, If needed.
Power cord
Power cord socket
Battery pack slot
Charge lamp
Full-charge lamp
COPY
