Direct Print User Guide
Printing Using a Direct Camera/Printer Connection
Guide d’utilisation de l’impression directe
Imprimer au moyen d’une connexion directe appareil
photo/imprimante
Guía del usuario de impresión directa
Impresión mediante una conexión directa entre una
cámara y una impresora
zDepending on your camera model, some printing instructions may also be
included in the Camera User Guide. However, you must read this guide as well
for complete printing instructions.
zSelon le modèle d’appareil photo, certaines instructions d’impression peuvent
aussi se trouver dans le Guide d’utilisation de l’appareil photo. Vous devez
cependant lire également le présent guide pour disposer de l’ensemble des
instructions d’impression.
z Dependiendo de su modelo de cámara, algunas instrucciones de impresión
también pueden aparecer en la Guía de usuario de la cámara. Sin embargo, deberá
leer también esta guía para tener unas instrucciones de impresión completas.
ESPAÑOL
FRANÇAIS
ENGLISH

ENGLISH
Direct Print User Guide
Printing Using a Direct Camera/Printer Connection

2
Confirm Your Printer Model
The following printers can be connected to your camera. Printing
operations may vary depending on your printer model. After you
have connected the camera to the printer, check the icon that
appears in the upper left corner of the camera’s LCD monitor and
refer to the relevant pages accordingly.
*1When connecting a Non-Canon PictBridge Compliant camera, please refer
to the camera’s user guide.
*2CP-100/CP-10: Direct Interface Cable DIF-100 (Supplied with the printer)
*3Please also refer to the user guide that came with your printer.
PictBridge Compliance
This camera complies with the industry standard “PictBridge”*. This
allows you to also connect your camera to non-Canon PictBridge
compliant printers and print images with simple operations using
the camera buttons.
* PictBridge: PictBridge is a new industry standard for direct printing that
allows you to print images without using a computer by directly connecting
digital cameras and digital camcorders (hereafter “camera”) to a printer,
regardless of the devices’ brand and model.
Printer
Canon Printers
CP Printers
PictBridge Compliant*1Canon Direct Print
Compatible
Cable USB Interface Cable*2
(Supplied with the camera)
LCD Monitor Display
Canon Direct Printing with CP Printers
p. 8 – 15

3
zFor camera and printer connection instructions, please refer to
page 6.
Printing Selected Images with DPOF Settings
This option allows you to select images for printing and print
settings, such as the number of copies, with the camera
(DPOF* print settings). This is very convenient when you want
to print several images at once or have them printed at a photo
lab.
* Digital Print Order Format
Please see the Camera User Guide for details on how to select
DPOF print settings. This guide explains how to print images that
have already been selected.
Canon Printers
Non-Canon PictBridge
Compliant Printers*3
Bubble Jet Printers
PictBridge Compliant Bubble Jet Direct
Compatible
USB Interface Cable
(Supplied with the
camera)
See your Bubble Jet
printer’s user guide.
USB Interface Cable
(Supplied with the
camera)
PictBridge Printing
with Bubble Jet
Printers
p. 16 – 26
Bubble Jet Direct
Printing with
Bubble Jet Printers
p. 28
PictBridge Printing
with Non-Canon
Printers
p. 30

4
Table of Contents
Read This First . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Camera/Printer Connection . . . . . . . . . . . . . . . . . . . . . 6
Canon Direct Printing with CP Printers . . . . . . . . 8
PictBridge Printing with Bubble Jet Printers. . . 16
Bubble Jet Direct Printing with
Bubble Jet Printers . . . . . . . . . . . . . . . . . . . . . . . . . . 28
PictBridge Printing with Non-Canon Printers . . 30
Settings that Can Be Set with the Camera . . . . . . . . 31
Trademark Acknowledgements
zCanon and PowerShot are trademarks of Canon, Inc.
zOther names and products not mentioned above may be
registered trademarks or trademarks of their respective
companies.
Copyright © 2004 Canon Inc. All rights reserved.
Disclaimer
zNo part of this guide may be reproduced, transmitted,
transcribed, stored in a retrieval system, or translated into any
language in any form, by any means, without the prior written
permission of Canon.
zCanon reserves the right to change the specifications of the
hardware described herein at any time without prior notice.
zWhile every effort has been made to ensure that the information
contained in this guide is accurate and complete, no liability can
be accepted for any errors or omissions.
zCanon makes no warranties for damages resulting from
corrupted or lost data due to a mistaken operation or malfunction
of the camera, the software, the memory cards, personal
computers, peripheral devices, or use of non-Canon memory
cards.

5
Read This First
Printing Procedures
Preparing the Camera and the Printer
Connecting the Camera to the Printer
Please refer to page 6 to correctly connect your camera.
zFor details regarding the printer connection settings, refer to the
user guide that came with it.
Printing
Use the camera controls to select settings and start printing. Some
printers may be equipped with an operation panel, but printing
cannot be performed from the panel.
Printing operations may vary depending on your printer model.
Please refer to the reference pages in the Confirm Your Printer
Model section (p. 2).
Camera When printing, the use of the compact power adapter
(separately sold and/or included with the camera) is
recommended. If a battery pack or batteries are used,
be sure to use a fully charged battery pack or new
batteries. For details, see the Camera User Guide.
Printer Please refer to the user guide that came with your
printer and make the necessary preparations (paper, ink
cassette, cartridge, etc.).
For the latest information regarding connections between Canon
printers and cameras, please refer to the following URL:
http://web.canon.jp/Imaging/BeBit-e.html
http://www.canon.com/pictbridge/

6
Camera/Printer Connection
Connect the camera to the printer using the following procedures.
(Please refer to your printer user guide for details about the printer
connection.)
zOnce the camera and printer are ready for printing, the , or
icon appears on the camera’s LCD monitor.
zPrinting procedures differ according to the icon that appears on
the LCD monitor (p. 2).
Before You Connect the Camera
zPrepare the printer. (Refer to the printer’s user guide.)
zConfirm which connection cable should be used (see page 2).
1
Connect the camera to the printer.
2
Turn the printer’s power on.
3
Set the camera to Playback mode and turn the
power on.
Some camera models power up when the printer’s power is
turned on.
4
, or appears on the upper left corner of the
LCD monitor. You can now print.
Camera: Connect the cable to
the DIGITAL terminal.
To Printer
DIGITAL terminal
This illustration shows the PowerShot S400 DIGITAL ELPH/DIGITAL
IXUS 400 as an example.
Printer: Refer to the
printer’s user guide.

7
zThe following operations are not available during a camera/
printer connection.
• Movie playback.
• Language settings that use the SET button and the MENU
button.
Disconnecting the Camera and the Printer
1. Detach the cable from the printer.
2. Turn the camera’s power off.
3. Detach the cable from the camera.
• When you detach the cable, hold the plug and do not pull
by the cable.

8
Canon Direct Printing with CP Printers
Printing
1
Make sure that displays in the
upper left corner of the LCD
monitor.
2
Display the images you wish to
print and press the SET button.
The print order screen appears.
3
Select print settings as required.
4
Select [Print] and press the SET button.
You cannot print movies or images recorded in the RAW
format.
Cancel Printing
zTo cancel printing between images printed, press the SET
button. Once the current print is finished, a confirmation
dialog appears. Select [OK] and press the SET button.
Printing Errors
zAn error message appears if an error occurs for some
reason during the printing process. Select [Stop] or
[Resume] and press the SET button.
The [Resume] option may not appear with some types of
errors. In that case, select [Stop].
Print Order Screen
Setting the Print Style (p. 9)
Selecting the Number of Copies (p. 9)
Setting the Printing Area (Trimming) (p. 10)

9
Selecting Print Settings
Selecting the Number of Copies
Setting the Print Style
You can select from among the following print styles.
* This option can be selected when printing on card size paper.
1
In the print order screen, select [Copies] and specify
the number of copies.
You can specify from 1 to 99 prints.
Standard Prints one image per page.
Multiple* Prints eight copies of the same
image on one page.
Borders Borderless Prints right to the edges of the page.
Bordered Prints with a border.
Date On Adds the date to the print.
Off Prints without the date.
1
In the print order screen, select [Style] and press the
SET button.
2
Select [Image], [Borders], or
[Date].
3
Select settings as needed.

10
Setting the Printing Area (Trimming)
You can specify which portion of an image gets printed.
Please set the Print Style (Image, Paper, Borders and Date) first
before setting the trimming settings. If the print style is changed after
having made trimming settings, you must select the settings again.
4
Press the MENU button to end
the setting selection process.
With borderless or multiple prints, the
top, bottom and sides of the image may
be cropped slightly. If you have not
specified a trimming setting, a frame will
appear around the area of the image
that will be printed, allowing you to
check the portion that will be cropped.
zWhen printing multiple prints, the borders and the date
cannot be set. (Images are printed without any date or
borders.)
zPractically all of the image area displayed on the LCD
monitor is printed on bordered prints.
With the PowerShot A60, the printing area settings differ. Please
refer to the Specifying the Printing Area (PowerShot A60) section in
the Camera User Guide.
1
In the print order screen, select
[Trimming] and press the SET
button.
The trimming frame will appear at the
center of the image. If a trimming setting
has already been selected for the
image, the frame will appear around the
previously selected portion.
Print Area Frame
Canon Direct Printing with CP Printers (continued)

11
The trimming setting screen differs depending on the camera
model. Check which of the following screens appear before
selecting settings.
2a
Trim the image.
Changing the Size of the Trimming Frame
zPress the zoom lever or the zoom button to adjust the size of
the trimming frame.
zThe trimming frame can be changed to a minimum selection
of approximately half the displayed image or a maximum
selection that is virtually the same size as the image.
zExpanding the trimming frame beyond its maximum size
cancels the trimming setting.
zWhen printing an image that has been magnified using the
trimming option, the image quality may become coarser and
grainier depending on the level of magnification. If this
happens, the trimming frame displays in red.
Moving the Trimming Frame
zMove the trimming frame using the multicontroller or the up,
down, right and left buttons.
Rotating the Trimming Frame
zYou can rotate the trimming frame by pressing the DISP.
button or the DISPLAY button.
3a
Press the SET button to close the setting menu.
Pressing the MENU button cancels the settings.
Steps 2a and 3a
Trimming Frame
Steps 2b and 3b

12
2b
Trim the image.
Changing the Size of the Trimming Frame
zPress the up and down buttons to adjust the size of the
trimming frame.
zThe trimming frame can be changed to a minimum selection
of approximately half the displayed image or a maximum
selection that is virtually the same size as the image.
zExpanding the trimming frame beyond its maximum size
cancels the trimming setting.
zWhen printing an image that has been magnified using the
trimming option, the image quality may become coarser and
grainier depending on the level of magnification. If this
happens, the trimming frame displays in red.
Rotating the Trimming Frame
zYou can rotate the trimming frame using the left and right
buttons.
Moving the Trimming Frame
zPress the SET button and use the up, down, right and left
buttons to move the trimming frame. Pressing the SET button
again allows you to change the size of the frame and to rotate
it.
3b
Press the MENU button, select
[OK] and press the SET button.
Selecting [Cancel setting] cancels the
selected trimming setting. If [Edit] is
selected, the display returns to the
previous screen.
zThe trimming setting only applies to one image.
zThe trimming setting is canceled with the following
operations.
• When you set the trimming settings for another image.
• When you close the Print mode (when you turn the camera
power off, change the camera mode, or detach the
connection cable).
Canon Direct Printing with CP Printers (continued)

13
Printing with DPOF Print Settings
For instructions on how to set DPOF print settings, please refer
to the DPOF print settings section of the Camera User Guide.In
this section, we will explain how to print several images already
specified with DPOF print settings.
zThe selected image, paper and border settings determine
the shape of the trimming frame.
zPlease use the LCD monitor to set the trimming settings. The
trimming frame may not display correctly on a TV screen.
1
In the [ (Play)] menu, select
[Print Order] and press the SET
button.
2
Select [Print] and press the SET
button.
3
Set the print style settings as
required.
zSee Setting the Print Style (p. 9).
zA print style cannot be set if the print
type is set to [Index] in the DPOF print
setting.
4
Select [OK] and press the SET
button.
The image will start to print and, when it
is completely finished, the display will
revert to the standard playback mode.

14
zTo print the date, set the [Date] setting in the print order
menu in Step 2 to [On]. You cannot set the date to print with
the [Style] menu in Step 3.
zWhen the print type is set to Index, the date cannot be printed.
zWhen the print type is set to Standard, the file number
cannot be printed.
zThe maximum number of images printed on one page in the
Index print type depends on the selected paper size.
• Card Size: 20 images
• L Size: 42 images
• Postcard Size: 63 images
Cancel Printing
z
To cancel printing between images printed, press the SET button.
Once the current print is completed, a confirmation dialog
appears. Select [OK] and press the
SET button.
Restarting Printing
zIn the print order menu, select [Resume] and press the SET
button. The remaining images can be printed.
zPrinting cannot be restarted under the following
circumstances.
• If the print settings have been changed before restarting.
• If the image for which the print settings were set has been
deleted before restarting.
• If there was very little free space on the memory card when
the printing was canceled.
If these circumstances apply, you can select [OK] in the print
order menu and reprint starting from the first image.
z
If printing is canceled because the camera battery is depleted,
you are recommended to power the camera with a compact
power adapter (sold separately and/or included).
If you are using a battery pack or batteries, please use either a
fully charged battery pack or new batteries. After replacing the
spent battery pack or batteries, turn the camera power on again.
Printing Errors
zAn error message appears if an error occurs for some
reason during the printing process. Select [Stop] or
[Resume] and press the SET button.
zThe [Resume] option may not appear with some types of
errors. In that case, select [Stop].
Canon Direct Printing with CP Printers (continued)

15
List of Messages
The following messages may appear on the camera’s LCD monitor
when an error occurs during a camera and CP printer connection.
(Depending on the CP printer model, some messages may not
display.)
zPlease refer to the CP printer’s user guide for solutions.
No Paper Paper cassette is incorrectly inserted or out of paper.
Or the paper feed is not operating correctly.
No Ink The ink cartridge has not been inserted or has run
out of ink.
Incompatible paper
size
Wrong paper size is loaded in the printer.
Incompatible ink
size
Wrong ink cassette size is loaded in the printer.
Ink Cassette Error The ink cassette is experiencing a problem.
Paper and ink do not
match
The paper and ink are from different sets.
Paper Jam The paper jammed during printing.
Paper has been
changed
Paper was changed after the print menu was
displayed.
Recharge the printer
battery
The printer’s battery pack is depleted.
Communication
Error
The printer is experiencing a data transmission error.
Readjust trimming
You attempted to print the image with a different
style than the one used when the trimming settings
were set.
Cannot Print!
You attempted to print an image from another
camera, one recorded in a different format, or one
that has been edited on a computer.
Could not print xx
images
You attempted to use the DPOF print settings to
print xx images that are from another camera, that
have been recorded in a different format, or that
have been edited in a computer.

16
PictBridge Printing with Bubble
Jet Printers
PictBridge Printing
1
Make sure that displays in the
upper left corner of the LCD
monitor.
If appears on the LCD monitor,
please refer to Bubble Jet Direct
Printing with Bubble Jet Printers (p. 28).
2
Display the images you wish to
print and press the SET button.
The print order screen appears.
Depending on the Bubble Jet printer
model, some setting options may not
display.
3
Select print settings as needed.
4
Select [Print] and press the SET button.
The image will start to print and, when it is completely finished,
the display will revert to the standard playback mode.
You cannot print movies or images recorded in the RAW
format.
Sets the date
On or Off (p. 18)
Sets the print
effect (p. 18)
Sets the number of copies (p. 19)
Sets the trimming portion (p. 19)
Sets the paper size, type and layout
(p. 22)
Starts the printing process

17
Selecting Print Settings
Cancel Printing
zTo cancel printing between images, press the SET button. A
confirmation dialog will display. Select [OK] and press the
SET button.
The printer will stop printing the current image and eject the
paper.
Printing Errors
zAn error message appears if an error occurs for some
reason during the printing process. Select [Stop] or
[Continue] and press the SET button. Depending on the type
of error, printing may resume once the problem is solved.
See List of Messages (p. 26) for details.
zOn Bubble Jet printers equipped with an operation panel, an
error number displays on the panel. Please refer to the
Bubble Jet printer user guide for the remedies corresponding
to the error numbers.
Available settings differ depending on the Bubble Jet printer
model. Some settings are not available (they will not appear in
the menu). For details, refer to the user guide that came with
your Bubble Jet printer.
Default Setting
zThe Default option is a fixed setting of the Bubble Jet
printer.
zThe [Date], [Print Effect], paper setting [Paper Type] and
[Layout] options are available.
zThe setting contents of the Default option differ depending
on the Bubble Jet printer model. For details, please refer to
the Bubble Jet printer user guide.

18
Setting the Date Printing Option
Setting the Print Effect
This function uses the camera’s shooting information to optimize the
image data, yielding high quality prints. You can select the following
print effects.
1
Select [ ] and set [On], [Off] or
[Default].
On Uses the camera’s shooting information to deliver beautiful prints.
Off Prints without any effects.
VIVID Prints more vibrant colors, such as the green of trees or the blue
of the sea or sky, than the [On] option.
NR Prints with a noise reduction effect.
VIVID+NR Prints using both the [VIVID] and [NR] options.
Default Print settings differ according to your Bubble Jet printer model.
1
Select [ ] and choose a print
effect option.
PictBridge Printing with Bubble Jet Printers (continued)
