Canon PowerShot SX130 IS User manual

Canon
""Rwer5hot SX130 IS
Getting Started
Make sure you read this guide. including the Safely
Precautions before using the camera.
Store this guide safely so that you can use it in the future.
Ple<ise use this manual aloog with the PDF manuals
included on the CD-ROM (p. 2).
ENGLISH

Checking the Package Contents
Check ifthe following items are included in your camera package.
If anything is missing, contact the retailer from which you purchased the
camera.
Camera
AA Alkaline Batteries (x2)
Wrist Strap
WS-800
Stereo AV Cable
AVC·DC400ST
m
--- ----
~~~:: :~=:
--- ----
.----
---- ----
Interface Cable
IFC-400PCU
D
-----·
------
-----_.
D
-----·
------
-------
Getting Started
(This Guide) DIGITAL CAMERA
Solution Disk Warranty
Card
"Canon Customer
Support" Leaflet
Using the PDF Manuals
Also refer to the PDF manuals on the CD-ROM. After installation, shortcut icons
appear on the desktop. Ifthe software installation fails, you can find the manuals
in
the Readme folder on the CD-ROM.
Camera User Guide
Once you have mastered the basics, use the camera's many
features to shoot more challenging photos.
Personal Printing Guide
Read when you want to connect the camera to aprinter(sold
separately) and print.
Software Guide
Read when you want to use the included software.
• A memory card is not included.
•Adobe Reader
is required to view the PDF manuals.
2

Test Shots and Disclaimer
Take some initial test shots and play them back to make sure the images
were recorded correctly. Please note that Canon Inc., its subsidiaries and
affiliates, and its distributors are not liable for any consequential damages
arising from any malfunction
of acamera or accessory, including memory
cards, that results
in the failure of an image to be recorded or to be recorded
in away that is machine readable.
Warning Against Copyright Infringement
The images recorded with this camera are intended for personal use. Do not
record images that infringe upon copyright laws without the prior permission
of the copyright holder. Please be advised that in certain cases the copying
of images from performances, exhibitions, or commercial properties by
means
of acamera or other device may contravene copyright or other legal
rights even ifthe image was shot for personal use.
Warranty Limitations
This camera's warranty is only effective in the country of sale. Ifthere is a
problem with the camera while abroad, please return it to the country
of sale
before proceeding with awarranty claim to aCanon Customer Support Help
Desk. For Canon Customer Support contacts, please see the customer
support list supplied with your camera.
LCD Monitor (Screen)
The LCD monitoris produced with extremely high-precision manufacturing
techniques. More than
99.99%) of the pixels operate to specification, but
occasionally non-performing pixels mayappearas bright
or darkdots. This
is not amalfunction and has no effect on the recorded image.
The LCD monitor may be covered with athin plastic film for protection
against scratches during shipment. Ifso, remove the film before using the
camera.
Camera Body Temperature
Please take care when operating the camera for an extended period as the
camera body may become warm. This is not amalfunction.
3

Conventions Uae,d "'in This Guide
Icons are used in the text to represent the camera buttons and control dial.
Language that displays on the screen appears inside
[] (square brackets).
The directional buttons, control dial, and FUNC./SET button are
represented by the following icons.
Up button ... ---~
Left button ~
Control dial @---
_--@ FUNC.lSET button
~ Right button
------ TDown button
4
CD: Things you should be careful about
@: Troubleshooting tips
~ :Hints for getting more out of your camera
, : Supplemental information
(p. xx): Reference pages ("xx" stands for apage number)
This guide assumes all functions are at their default settings.
The various types
of memory cards that can be used in this camera are
collectively referred to as memory cards
in this guide.

Safety Precautions
Before using the product, please ensure that you read the safety precautions
described below. Always ensure that the product is used correctly.
The safety precautions noted on the following pages are intended to prevent injuries
to yourself and other persons, or damage to the equipment.
Be sure to also check the guides included with any separately sold accessories you
use.
A Warning
Denotes the possibility of serious.injury<~r·d.a.th .
... __ !<:~;.-- .. _-/
-;':',. ,
.<f"t.<
Do not trigger the flash in close proximity to human eyes.
Exposure to the intense light produced by the flash could damage eyesight. In particular,
remain at least one meter (39 inches) away from infants when using the flash.
~';"";";;";"';"'''''''>'>'N,,"'''''''''''''';_''','''''''''''''';'; ·;"","·""·;=;_"·;·",~,,.,,,;,w,'_,,,,,_· .. ,."",~""",.; .... ;;,\;";,,,,_,,,,,,, ... __ ,,,;.;; __ ;_<_,,,,,;~_,,,*,,,,,,,, __ i:'l'_"",c"""""",,,,,,,,,·=x·,;-,;'»<
Store this equipment out of the reach of children and infants.
Strap: Putting the strap around achild's neck could result in asphyxiation.
Time/date battery: Dangerous ifswallowed. Ifthis occurs, contact adoctor immediately.
-_"" -;'''_·~~·<'·~''''''",,",~-·1'''''';''';;~''',;,''''';''''_··~'''''''···'··'';~_;;;;";~;~;""';;;_lli~' "'~" .. ~_,,~,,~;;; "'~" ~:1'."" ... _.~ __ ,~_~ __ ,.,.,.. -...-..,~ __ • __ • ,
Use only recommended power sources.
Do
not attempt to disassemble, alter or apply heat to the product.
Avoid dropping or subjecting the product to severe impacts.
To avoid the risk
of injury, do not touch the interior of the product if it has been
dropped
or otherwise damaged.
Stop using the product immediately
if it emits smoke, astrange smell, or
otherwise behaves abnormally.
Do
not use organic solvents such as alcohol, benzine, or thinner to clean the
equipment.
Do
not let the product come into contact with water (e.g. sea water) or other
liquids.
Do
not allow liquids or foreign objects to enterthe camera.
This could result in electrical shock or fire.
Ifliquids or foreign objects come into contact with the camera interior, immediately turn
the camera power off and remove the batteries.
Do not playthe supplied CD-ROM(s) in any CD playerthatdoes not support data
CD-ROMs.
Playing the CD-ROM(s) in an audio CD player(music player) could damage the speakers.
It is also possible to suffer hearing lossfrom listening with headphones to the loud sounds
of aCD-ROM played on amusic CD player.
.Use only the recommended batteries.
Do
not place the batteries near or in direct flame.
The batteries may explode or leak, resulting in electrical shock or fire. This could cause
injury and damage the surroundings. In the event that batteries leak and the battery acid
contacts eyes, mouth, skin or clothing, immediately flush with water.
5

Safety Precautions
A Caution
Denotes the possibility of injury.
Be careful not to bang the camera or subject it to strong impacts or shockswhen
hanging
it by the strap.
Be careful
not to bump or push strongly on the lens.
This could lead to injury or damage the camera.
>":""~':*"'~"'<""""":"""'~:":::::::".:$>.>.<~#'N..'>,"'::"'::~:,::: ::::::::',':"::"'''~::'''':':':'''''" '" .. , .. ,'''' __ '''''' ,'''''' > ••••••••••. ''''._'''''''''.''~~ ,''''''~:: ", •• , •• > ••• ,._,.·'-_,_<",,=,'·"""""_:_"""._·,",_""'w~· ' :.: "'";.,.,".> .. _UlO.'*""'".~.""'=,.:'l<W":- .,,_;,,;... ,,""",,¥_"'~"".''''''''','''''~''''',4<','''_ *'4!l::»>'"M,_'.·.·,··,,=''"_'"'''''
When using the flash, be careful not to cover it with your fingers or clothing.
This could result in burns or damage to the flash.
.... ~_, .. ,_ .. ~,~_~-...,.~-.:_ .• ~ _" ,,"J .... ,_,'~1< ..., _,~""·.,..c~'.·;r_ .. >..,,'_.,,;""_~ __ · .... -~_~~~~_,. "I'Cv _.;x_""""_ .. ilIW'"A=.:", __ ~",,,,,,-· ."'.... =_ .. ' ':"'-,\< •• ~ •• __ ~~ •• ",_:. '''''~--_~'''''_~_'''''-'' '~""'''4
Avoid using, placing or storing the product in the following places.
•Places subject to strong sunlight.
•Places
subject to temperatures above 40°C (104 OF).
•Humid or dusty areas.
These could cause leakage, overheating or an explosion of the batteries, resulting in
electrical shock, fire, burns or other injuries.
~.~_'_-""=".",<,"~"". '''''''''~'''''''V;;«''H'-'·~~;;.;.c''''·'·''''''''~~'''''_' ".."""ax,','C_'" "~,,,-,"·'''''''_l __ =''''X'·''. __ '''~''''''X'''''_'l'w'''''''I. -',,-;±~ ,', ';>I<,,,,*, .• '~""*,,,"''''_'_C_''''_''_"''''*'I~'''-='~'''' __ ;; '_~''''''''''~~~ __ ,~_~~';;o ':~~""_"f~
The slideshow transition effects may cause discomfort when viewed for
prolonged periods.
Caution
Do not aim the camera at bright light sources (the sun, etc.).
Doing so may damage the image sensor.
~ '~A--;;-""""""" _r-"""""",__ ~... ti_ti _
When using the camera on abeach or at a windy location, be careful not to allow
dust or sand to enter the camera.
This may cause the product to malfunction.
- '~ """''' ~,_'''J'>'''_''_'_''' __ '''_'''''''i< ,,--- v·~ .::W~_-,"-"""",_"",¥l<';o;o,"t;.u~~w.--_,>.~~ __ "".-,,,-_,,_.-_,,,v.,,,,,,,,,,,_:-oo._,,,,,,,~~ ;o;,."' __ "";"""'_:X<-'="='* ''>l-'~ '''''''''''-'-''-",,''-_
In regular use, small amounts of smoke may be emitted from the flash.
This is dueto the high intensity of the flash burning dustand foreign materials stuck to the
front of the unit. Please use acotton swab to remove dirt, dust or otherforeign matterfrom
the flash to prevent heat build-up and damage to the unit.
1'<_,*""""H""~_'!'M""I' __ ~:\<_""=:~:,,,,,,:,~~=,:':"::"""_'"""'_l""'''II'_'_:"":_'''=_':>':;''' __ I<M""",'",,,,:>~~m''.' __ :''''''''''_~'' __ =-''X''~·_~',·"' ... -_oo-.,-_ •• """""'_'.... <',.,,,"""_·,.',_""' ._,,"' __ ·~w
Remove and store the batteries when you are not using the camera.
If the batteries are left inside the camera, damage caused by leakage may occur.
.l-'_""","'.,',"~"'~=.,, .... _,.~ ........ , . ,,""_ __-_ l .. _ ... _~ ::w .... ~- __
Before you discard the batteries, cover the terminals with tape or other
insulators.
Contacting other metal materials may lead to fire or explosions.
~."""'~~ .. --_~=-"''''__ _ ... ~. --..,~_ ... "',.'.~-,,,.,,t~ 'k",,- io'··~ ~'1. !o_.~ __ ._, _~.~ __
Do not charge batteries of differenttypes atthe same time, or useolderbatteries
together
with newer batteries.
Do
not insert the batteries with the +and -terminals reversed.
This may cause the product to malfunction.
6

Safety Precautions
Do
not sit down with the camera in your pocket.
Doing so may cause malfunctions or damage the screen.
When putting the camera in your bag, ensure that hard objects do not come into
contact with the screen.
Do
not attach accessories to the strap.
Doing so may cause malfunctions or damage the screen.
Trademark Acknowledgments
SDXC logo is atrademark of SD-3C, LLC.
This device incorporates exFAT technology licensed from Microsoft.
About MPEG-4 Licensing
This product is licensed under AT&T patents for the MPEG-4 standard and
may be used for encoding MPEG-4 compliant video and/or decoding
MPEG-4 compliant video that was encoded only (1) for apersonal and non-
commercial purpose or (2) by avideo provider licensed under the AT&T
patents to provide MPEG-4 compliant video.
No license is granted or implied for any other use for MPEG-4 standard.
*Notice displayed in English as required.
7

8

Table of Contellts
Checking the Package Contents 2
Read This First 3
Conventions Used
in This Guide 4
Safety Precautions 5
Attaching the Strap/Holding the Camera 9
Compatible Memory Cards (Sold Separately) 10
Inserting the Batteries and Memory Card 10
Setting the Date and Time 14
Setting the Display Language 16
Formatting Memory Cards 17
Pressing the Shutter Button 18
Taking Pictures (Smart Auto) 19
Viewing Images 22
Erasing Images 23
Shooting or Viewing Images
in Easy Mode 24
Shooting Movies 25
Viewing Movies 27
Transferring Images
to aComputer for Viewing 28
Accessories
~ 32
Separately Sold Accessories 33
Be sure to attach the supplied strap to the camera and wrap it around your
wrist when shooting to avoid dropping the camera.
Keep your arms tight against your bodywhile holding the camera firmly by
the sides. Be sure that your fingers
do not block the flash while it is raised.
Strap
9

·Compatible Memory Cards (Sold Separately)
SO memory cards (2 GB and less)*
SOHC memory cards
(more than 2GB, up to and including 32 GB)*
SOXC
memory cards ~~
(more than 32 GB)*
MultiMediaCards
MMCplus memory cards
HC MMCplus memory cards
*This memory card complies with the SO standards. Some cards may not operate
properly depending on the brand
of card used.
j([):, :,' I 'c ~lng onYou~ c(:l ~:QS:v~I6r1;_emen1ory'eartlsml!Y.not
;. bePfMni~~ \!h~ri u ""p(r)mm~rcially avaflabl,e carQ reader. Ch,ck to
m~kesure.thatyour as J'parts this ,functionbeforehan~. ,-
:~·'Ins.rling·th,· Ba~eri.s a~d>~;;;,~mo'i'J.~~q;l~d·.
< ~- - _.;. "F' '~'~I,," .. ~ '_
Insert the included batteries and amemory card (sold separately).
Check the card's write-protect tab.
If the memory card has awrite-protect tab,
you will not be able to record images
if the
tab is in the locked position. Slide the tab
up until you hear aclick.
Open the cover.
Slide and hold the cover lock (CD), then
slide and open the cover
(®) as shown.
~
I!
~ ~
l ~
I'
f---: ,,¥~J I
10

Inserting the Batteries and Memory Card
Insert the batteries.
Insert the batteries with (+) and (-) ends
oriented correctly.
Insertthe memory card.
Insert the memory card as shown until it
locks into place with aclick.
Be sure the memory card is oriented
correctly. Inserting the memory card
in the
wrong direction could damage the camera.
Label
Close the cover.
Close the cover ( CD ), and press downward
as you slide it until it clicks into place
(@) .
•What if.[Memory card locked] appears ollthe'scre.en1'
so, SOHC and SOXC memory cards have awrite-protect tab. Ifthis tab is in the
locked position" [Memory card locked] will appear on the screen and you will not
be able to take or erase images.
11

Inserting the Batteries and Memory Card
Removing the Memory Card
Push the memory card in until you hear a
click, then slowly release it.
The memory card will pop up.
Approximate Number of Shots That Can Be Taken
NiMH Batteries
(Sold Separately)
370
9hr.7hr.
Alkaline Batteries
(Supplied)
130
.;:; ,:'t~-.·.·.i· A"~ ~ ••...•• -........... .'."< ~'. '. '. ",- '
,·::' ... um· , h:a~f ·hots. ,
-t:.. ::.'P.>·' '-~ ....... 'i»i:'t ''1.;;;' . - .... ';;:'- ,:, '. .~ ~ '. .; <
'; '~·'f.. ,- ~~tti1' .,' -
, <:_-~<{:-- ~-'" ... _.' - - •
*The number of shots that can be taken is based on the Camera &Imaging Products
Association (CIPA) measurement standard.
Under some shooting conditions, the number
of shots that can be taken may be less
than mentioned above.
Depending on the brand
of alkaline batteries used, the number of shots that can be
taken
may vary widely. '
The values
for NiMH batteries are based on fully charged batteries.
Compatible Batteries
AA alkaline batteries and Canon AA NiMH batteries (sold separately) (pp. 32,
33).
ft
,·
: ".
We cannot recommend the use of any other batteries than those listed above
because performance varies widely.
NiMH batteries last much longer than alkaline batteries, especially in cold
weather.
12

Inserting the Batteries and Memory Card
Battery Charge Indicator
When battery charge is low, an icon and message will appear. Ifthe batteries
are charged, the icon and message will not appear.
Display Summary
[] Nearly depleted. Ready new batteries.
"Change the batteries" Depleted. Change the batteries.
Approximate Number of Shots per Memory Card
Memqry' ctard 4GB 16 GB
;Nl.lm.",.ofShots >. .•.• 1231 5042
Values are based on the default settings.
The number of shots that can
be taken will vary depending on camera settings, the
SUbject and the memory card used.
@~anYbuCheckthe number of shots that ~PJI>',,'
You can check the number of shots that can be taken when the camera is in a
Shooting mode (p. 19).
13

Setting the Date and Time
The DatelTime settings screen will appear the first time the camera is turned
on. Since the dates and times recorded into your images are based on these
settings,
be sure to set them.
Turn on the camera.
Press the power button.
The DatelTime screen will appear.
Set the date and time.
Press the ~ ~ buttons to choose an option.
Press
the."" buttons or turn the () dial
to set avalue.
Complete the setting.
Press the @button.
Once the date and time have been set, the
DatelTime screen will close.
Pressing the power button will turn off the
camera.
Reappearing DatelTime screen
Set the correct date and time. Ifyou have not set the date and time, the Date/Time
screen will appear each time you turn
on the camera.
\ I ,
@Daylight saving time settings
If you choose in Step 2and press the ...... buttons or turn the 0dial to
choose
;+~, you will set the time to daylight saving (1 hour ahead).
14

Setting the Date and Time
Changing the Date and Time
You can change the current date and time settings.
Display the menus.
Press the MEN Ubutton.
Choose [DatelTime] in the fT tab.
Press the ~ ~ buttons to choose the tT
tab.
Press the
...... buttons or turn the €) dial
to choose [DatelTime], then press the @
button.
Change the date and time.
Follow Steps 2and 3 on p. 14 to adjust the
setting.
Pressing the
MENU button will close the
menu.
~ DatelTime battery
If the Date/Time screen appears even when the date/time have been correctly set,
insert anew date/time battery (see Camera User Guide).
15

Setting the Display Language
You can change the language that displays on the screen.
Enter Playback mode.
Press the [E] button.
Display the settings screen.
Press and hold the @button, then
immediately press the
MENU button.
Set the display language.
Press the A T ~ ~ buttons or turn the @
dial to choose alanguage, then press the
@button.
Once the display language has been set,
the settings screen will close.
What ifthe clock appears when the @button is pressed?
The clock will appear iftoo much time passes between pressing the @button
and the
MENU button in Step 2. Ifthe clock appears, press the @button to
remove the clock and repeat Step
2.
You can also change the display language by pressing the MENU button,
choosing the
tT tab, and choosing the [Language] menu item.
16

Formatting Memory Cards
Before you use anew memory card or one that has been formatted in other
devices, you should format the card with this camera. Formatting (initializing) a
memory card erases all data
on the memory card. As you cannot retrieve the
erased data, exercise adequate caution before formatting the memory card.
f;,~
~
Display the menu.
Press the MEN Ubutton.
Choose [Format].
Press the ~ ~ buttons to choose the fT
tab.
Press the
......... buttons or turn the €) dial
to choose [Format], then press the @
button.
Choose [OK].
Press the ~ ~ buttons orturn the €) dial to
choose [OK], then press the @button.
Format the memory card.
Press the ......... buttons or turn the €) dial
to choose [OK], then press the @button.
The memory card will be formatted.
Complete formatting.
When formatting ends, [Memory card
formatting complete] will appear on the
screen.
Press the @button.
17

Pressing the Shutter Button
CD
Formatting or erasing data on amemory card merely changes the file
management information on the card and does not ensure its contents are
completely erased. Be careful when transferring
or disposing of amemory
card. When disposing
of amemory card, take precautions such as
physically destroying the card to prevent personal information leaks.
The total capacity
of the memory card displayed in the formatting screen
may be less than indicated on the memory card.
Pressing the Shutter Button
To take images that are in focus, be sure to first press the shutter button
lightly (halfway) to focus, then press fully to shoot.
Press halfway(Press lightly to focus).
Press lightly until the camera beeps twice
and AF frames appear where the camera
focused.
Press fully (Press fully to shoot).
The camera plays the shutter sound and
takes the shot.
Since the shot is being taken while the
shuttersound plays, be careful notto move
the camera.
Does the length of the shutter sound change?
Since the time required to shoot differs according to the scene you wantto take,
the length
of the shutter sound may change.
If the camera or subject moves while the shutter sound is playing, the recorded
image may be blurry.
JfJ) If you shoot without pressing the shutter button halfway, the image may not
Wbe in focus.
18

Taking Pictures (Smart Auto)
Since the camera can determine the subject and shooting conditions, you can
let it automatically select the best settings for the scene and just shoot. The
camera can also detect and focus on faces, setting the color and brightness
to optimal levels.
Focus range (approx.)
Zoom bar
Turn on the camera.
Press the power button.
The start-up screen will appear.
Choose fD) mode.
Set the mode dial to tmID.
When you point the camera toward the
subject, the camera will make aslight
noise as it determines the scene.
The icon for the determined scene will
appear
in the upper right of the screen.
The camera will focus on detected faces
and display frames on them.
Compose the shot.
Moving the zoom lever toward [tJ
(telephoto) will zoom in on your subject,
making it appear larger. Moving the lever
toward
IillI (wide angle) will zoom out from
your subject, making it appear smaller.
(The zoom bar showing the zoom position
appears on the screen.)
19

Taking Pictures (Smart Auto)
Focus.
Press the shutter button halfway to focus.
When the camera focuses, it will beep
twice and AF frames will appearwhere the
camera focused.
Several AF frames will appear when the '
camera focuses on more than one point.
AF Frame If [Raise the flash] appears
on the screen,
raise the flash manually to shoot.
If you manually lower the flash until it
closes, it will not fire.
Shoot.
Press the shutter button fully.
The camera will playthe shuttersound and
shoot. The flash will automatically fire
in
low light conditions if it has been raised.
The image will appear on the screen for
about two seconds.
You can take asecond picture even while
an image is displayed by pressing the
shutter button again.
~ What if an icon appears in the upper right of the screen?
The icon forthe determined scene will appear in the upper right of the screen. For
details on the icons that appear, see "Scene Icons" (see Camera User Guide).
20
