IRIScan Express 4
Quick User Guide

Contents
1. Introduction
2. Software Installation
2.1 Installation on Windows
2.2 Installation on Mac OS
3. Supported Documents
4. Using the Scanner
4.1 Top view
4.2 Rear view
4.3 Scanning with the IRIScan Express 4
5. Maintenance
5.1 Calibrate the scanner
5.2 Cleaning the scanner
6. Troubleshooting
6.1 Clearing a Paper Jam
6.2 Questions and Answers
6.3 Product Support
7. Specifications
8. Legal Information

1. Introduction
This User Guide helps you get started with the IRIScan Express 4.
Please read this guide before operating this scanner and its software. All information is subject
to change without prior notice.
The software delivered with this scanner is:
Windows:
Readiris Pro 14
Cardiris 5
Button Manager
Capture Tool
Mac OS:
Readiris Pro 14
Cardiris 4
Capture Tool
For detailed information about the full range of features of Readiris, Cardiris, the Button
Manager and the Capture tool, see their corresponding documentation on
www.irislink.com/support.
2. Software Installation
Important Notes
Install the software before you connect the scanner to your computer.
Check the System Requirements on the I.R.I.S. website to make sure your system is
compatible.
Precautions
Keep the scanner out of direct sunlight. Direct exposure to the sun or excessive heat
may cause damage to the unit.
Do not install the scanner in a humid or dusty place.
Place the scanner securely on an even, flat surface. Tilted or uneven surfaces may cause
mechanical or paper-feeding problems.
Retain the scanner box and packing materials for shipping purposes.

2.1 Installation on Windows
1. Go to www.irislink.com/download/iriscan-express-4.
2. Click the Windows link and download the IRIScan Express 4 package.
3. Once the download is complete, run the IRIScanExpress4.exe file.
4. The following setup screen is displayed:
5. Click "Readiris Pro 14” to install Readiris. Follow the on-screen instructions.
6. Return to the setup screen and click “IRIScan Express 4” to install the scanner driver.
7. Click “Next” until you reach the step “Plug in the USB Cable”.
Connect the micro USB connector to the USB port of the scanner.
Connect the other end of the USB connector to a USB port on your computer.
8. When the driver is successfully installed the following message appears: “This device is
now ready to use”.
9. Click “Finish” and return to the setup screen.
10. Click “Button Manager” to install the Button Manager. A language selection window
appears.
11. Choose the language you wish to install. The InstallShield wizard guides you through the rest
of the installation.
12. Click “Finish” to complete the installation.
13. Click "Cardiris Pro 5” to install Cardiris. Follow the on-screen instructions.
Note: all license numbers required to activate the software can be found on the license sheet
included in the box.

2.2 Installation on Mac OS
1. Go to www.irislink.com/download/iriscan-express-4.
2. Click the Mac link and download the IRIScan Express 4 package.
3. Once the download is complete, run the IRIScanExpress4.dmg file.
4. The following setup screen is displayed:
5. Run the Readiris Pro 14.pkg file and follow the on-screen instructions.
6. Then click “Install” to start the actual installation.
You might be asked to enter an Administrator Username and Password to install Readiris.
7. You are prompted to enter the serial number.
The serial number can be found on the license sheet inside the product box and contains
15 digits.
8. When the installation is finished, click “Close”.
The Readiris folder is added to the Applications folder by the installation program.
9. Return to the setup screen, run the IRIS Scanner.pkg file and follow the on-screen
instructions.
Again you might be asked to enter an Administrator Username and Password.
10. Connect the scanner to your computer.
11. Return to setup screen and install Cardiris 4.
Note: all license numbers required to activate the software can be found on the license sheet
included in the box.
3. Supported Documents
The scanner is designed to obtain the best scanning results with the following types of originals:
Photos and documents (3”x5”, 4”x6”, 5”x7”, 8.5”x14”) (76 x 127mm, 102 x 152 mm, 127 x
177 mm, 216 x 356 mm)
Business cards [standard 3.5”x 2” (88 x 50 mm) or larger]
Long page (8.5”x36”) (216 x 914 mm) for 300 dpi only
Paper Weight: 60~107 g/m2(16~28 lb)
Unsuitable Documents
Do not use the following types of originals for scanning, or the scanner may malfunction or
cause the original to jam in the slot.
Originals thicker than 0.8 mm
Originals with either side shorter than 50 mm
Originals with lots of black or dark colors
Originals with dark colors surrounding the edges
Printed media (newspapers, magazines, etc.)
Soft and thin materials (thin paper, cloth, etc.)

4. Using the Scanner
4.1 Top view
Item
Name
Description
1
Feed slot
Insert document into the feed
slot, printed side UP and aligned
with the left edge to begin
scanning.
2
Paper guide
Adjust to scan documents of
different size.
3
Power
button
Press lightly to power on the
scanner.
Press and hold for 3 seconds
to power off the scanner.
4.2 Rear view
Item
Name
Description
1
Micro USB
port
Connect to a computer via
the micro USB cable.
2 3
1
1

4.3 Scanning with the IRIScan Express 4
The IRIScan Express 4 can be used in several ways:
With the Button Manager (Windows only) to scan documents directly to Readiris for
text recognition, scan them to other applications of your choice, to multiple Cloud
destinations, etc.
From within Readiris or Cardiris.
From within the Capture Tool.
Important!
Insert only one page at a time, and insert the next one only when the previous one is done.
Otherwise, the scanner may malfunction.
The paper detector is quite sensitive. Please do not push your document into the feeding
slot or the top of your image will be cut. Simply let go the document when it begins to feed
into the slot.
1. Insert your document FACE UP into the feeder and align it to the left edge of the feeder.
Then, adjust the paper guide to the right-hand side of the document.
2. Gently push the document into the feed slot.
3. On Windows: press the Power button once to start scanning.
4. On Mac OS: click Scan from within Readiris or the Capture Tool.
In this User Guide we only describe the basics how to scan.
Separate User Guides are available for the Button Manager, the Capture Tool, Readiris and
Cardiris.
The documentation package can be found on in the installation package and on
www.irislink.com/support.

5. Maintenance
5.1 Calibrate the scanner
Calibrate only if the scanned image looks fuzzy, the color looks abnormal (e.g., darker than
normal), after more than 8,000 scans, or the scanner has been stored without use for a long
time. The calibration process resets the Contact Image Sensor to resume its color and sharpness
precision.
1. Power on the scanner.
2. Start the Capture Tool.
In Windows:
Click Start > All Programs > IRIScan Express 4 scanner > Capture Tool
Select your driver type and scanner model and click OK.
On Mac OS:
Click Finder > Applications > Capture Tool
3. The Capture Tool dialog box will be displayed.
4. Click the “Setup”button to open the Scanner Properties dialog box.
5. In Windows: click the “Settings”tab and then click the “Calibration”button.
6. On Mac OS: click the “Enhancement” tab and then click the “Calibration”button.
7. The “Insert calibration sheet”dialog box appears.
8. Hold the edges of the calibration sheet (included) and insert it with the text facing up and
the white area feeding first into the feeder (As shown below).
9. Click “OK”in the “Insert calibration sheet”dialog box to start calibrating the scanner.
10. When the calibration is finished, the scanner powers off automatically.
WARNING: If the calibration failed, the Red LED will be flashing and an error message will
be displayed on the screen. Power off the scanner and then repeat the calibration.
11. Power on the scanner to proceed with normal use.

5.2 Cleaning the scanner
In order to maintain an optimal scan quality and prevent dust accumulation, it is recommended
you clean the scanner (outer casing and feed rollers) approximately every 200 scans, or if
vertical lines or stripes appear on the scanned image.
Use only the recommended and supplied tools to clean the scanner.
WARNING: Do not use any solvents or corrosive liquid (i.e., alcohol, kerosene, etc.) to
clean any part of the scanner, otherwise the plastic material may be permanently damaged.
1. Open the cover by holding the scanner with one thumb on the feeder and another thumb on
the cover. Carefully and firmly press your thumb into the feeder and then raise the cover.
This will cause the top of the scanner to release from the bottom of the scanner.
2. Gently wipe the glass and feed rollers on the scanner, and the CIS cover with the cleaning
cloth (included).
Glass
Feed rollers

6. Troubleshooting
6.1 Clearing a Paper Jam
To clear a jam from the feeder, press and hold the Power button for 3 seconds to power off, then
press quickly to power on again. The jammed photo will be fed through automatically.
If the item is still jammed, follow these steps to remove the item:
1. Open the cover by holding the scanner with one thumb on the feeder and another thumb on
the cover. Carefully and firmly press your thumb into the feeder and then raise the cover.
This will cause the top of the scanner to release from the bottom of the scanner.
2. Remove the item.
3. Close the cover and reinsert the item to rescan.
Cover
