Canon imageFORMULA DR-M140II User manual

User Manual
• Please read this manual before operating this
scanner.
• After you finish reading this manual, store it in
a safe place for future reference.

2
FCC REGULATIONS (For 120 V model)
Document Scanner, Model 6130240
AC Adapter, Model 6G3-0267
Note: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the
equipment OFF and ON, the user is encouraged to try to correct the
interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
Use of shielded cable is required to comply with Class B limits in
Subpart B of Part 15 of FCC Rules.
Do not make any changes or modifications to the equipment unless
otherwise specified in the manual. If such changes or modifications
should be made, you could be required to stop operation of the
equipment.
Canon U.S.A. Inc.
ONE CANON PARK, MELVILLE, NY 11747, U.S.A.
Tel. No. [phone]
RADIO INTERFERENCE REGULATIONS (For 120 V
models)
This digital apparatus does not exceed the Class B limits for radio
noise emissions from digital apparatus as set out in the interference-
causing equipment standard entitled “Digital Apparatus”, ICES-003 of
the Industry Canada.
ENERGY STAR®Office Equipment Program
This program is for U.S.A and Canada.
As an ENERGY STAR®Partner, CANON
ELECTRONICS INC. has determined that this
machine meets the ENERGY STAR®Program
guidelines for energy efficiency.
The ENERGY STAR®Office Equipment Program is
an international program that promotes energy saving through the use
of computers and other office equipment. The program backs the
development and dissemination of products with functions that
effectively reduce energy consumption. It is an open system in which
business proprietors can participate voluntarily. The targeted products
are office equipment, such as computers, monitors, printers, fax,
machine, copiers, and scanners. The standards and logos are uniform
among participating nations.
This model doesn’t provide setting options for power management.

3
Für EMVG
Dieses Produkt ist zum Gebrauch im Wohnbereich, Geschäfts-und
Gewerbebereich sowie in Kleinbetrieben vorgesehen.
Model Names
The following name may be provided for the safety regulations in each
sales region of the Document Scanner.
DR-M140II: Model 6130240
Trademarks
• Canon and the Canon logo are registered trademarks, of Canon Inc.
in the United States and may also be trademarks or registered
trademarks in other countries.
• imageFORMULA is a trademark of CANON ELECTRONICS INC.
• Microsoft, Windows, PowerPoint, and SharePoint are registered
trademarks or trademarks of Microsoft Corporation in the United
States and other countries.
• Microsoft product screen shot(s) reprinted with permission from
Microsoft Corporation.
• ENERGY STAR®is a registered trademark of the United States
Environmental Protection Agency.
• ISIS is a registered trademark of Open Text in the United States.
• iDRSTM SDK 15 Windows 32 - 64 bit technology by Image
Recognition Integrated Systems S.A.
Copyright 1987 - 2019, I.R.I.S. S.A. All rights reserved.
• QR Code is a registered trademark of DENSO WAVE
INCORPORATED in Japan and in other countries.
• Other product and company names herein may be the trademarks
of their respective owners. However, the TM and ®symbols are not
used in this document.
Copyright
Copyright 2022 by CANON ELECTRONICS INC. All rights reserved.
No part of this publication may be reproduced or transmitted in any
form or by any means, electronic or mechanical, including
photocopying and recording, or by any information storage or retrieval
system without the prior written permission of CANON
ELECTRONICS INC.
Reproduction Warning
This device is designed to be used in a legal manner, in accordance
with all applicable laws, including, but not limited to, counterfeit and
copyright laws, as well as laws pertaining to national security.
Any person(s) found to have reproduced any of the following materials
(regardless of whether such reproduction was intentional or not) for
the purpose of misrepresenting such material as the original may be
prosecuted in accordance with the applicable laws and regulations.
• Paper money or bank notes (domestic and foreign)
• Postage stamps, revenue stamps, or other similar stamps
• Stock certificates, bond certificates, promissory notes, cheques, or
other valuable certificates
• Passports, licenses, or other certificates or documents issued by
government officials or agencies
This is not an exhaustive list.
Canon is not responsible for how this scanner is used by an individual.
Please note that certain intellectual property is protected by copyright
law, and copyrighted items may not be reproduced without the
express permission of the copyright holder except for personal or
household use under limited circumstances.

4
Disclaimers
The information in this document is subject to change without notice.
CANON ELECTRONICS INC. MAKES NO WARRANTY OF ANY
KIND WITH REGARD TO THIS MATERIAL, EITHER EXPRESS OR
IMPLIED, EXPECT AS PROVIDED HEREIN, INCLUDING WITHOUT
LIMITATION, THEREOF, WARRANTIES AS TO MARKETABILITY,
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE
OF USE OR NON-INFRINGEMENT. CANON ELECTRONICS INC.
SHALL NOT BE LIABLE FOR ANY DIRECT, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES OF ANY NATURE, OR LOSSES OR
EXPENSES RESULTING FROM THE USE OF THIS MATERIAL.
CANON ELECTRONICS INC. IS NOT LIABLE FOR THE STORAGE
AND HANDLING OF DOCUMENTS SCANNED WITH THIS
PRODUCT, OR THE STORAGE AND HANDLING OF RESULTING
SCANNED IMAGE DATA.
IF YOU INTEND TO DISCARD THE ORIGINALS OF SCANNED
DOCUMENTS, YOU THE CUSTOMER ARE RESPONSIBLE FOR
INSPECTING THE SCANNED IMAGES AND VERIFYING THAT
DATA IS INTACT.
THE MAXIMUM LIABILITY OF CANON ELECTRONICS INC.
UNDER THIS WARRANTY IS LIMITED TO THE PURCHASE PRICE
OF THE PRODUCT COVERED BY THE WARRANTY.

5
Introduction
Thank you for purchasing the Canon imageFORMULA DR-M140II
Document Scanner.
Please read the following manuals carefully and familiarize yourself
with the functions of the scanner before use to ensure you sufficiently
understand the functions and make the most of the scanner’s
capabilities. After reading the manuals, store them in a safe place for
future reference.
Manuals for the Scanner
Documentation for this scanner consists of the following manuals.
●Product Safety Guide
Before using the scanner, be sure to read and follow these
instructions.
●Setup Guide
This describes setup procedures for the scanner. Read this manual
when you first use the scanner.
●User Manual (this manual)
This manual contains the operating procedures of the scanner.
(PDF electronic manual only)
Hint
The User Manual (electronic manual) will be registered to the
following location when the software is installed.

6
Symbols Used in This Manual
The following symbols are used in this manual to explain procedures,
restrictions, handling precautions, and instructions that should be
observed for safety.
WARNING
Indicates a warning concerning operations that may lead to death
or injury to persons if not performed correctly. To use the scanner
safely, always pay attention to these warnings.
CAUTION
Indicates a caution concerning operations that may lead to injury to
persons, or damage to property if not performed correctly. To use
the scanner safely, always pay attention to these cautions.
IMPORTANT
Indicates operational requirements and restrictions. Be sure to
read these items carefully to operate the scanner correctly, and
avoid damaging the scanner.
Hint
Indicates a clarification of an operation, or contains additional
explanations for a procedure. Reading these notes is highly
recommended.

7
Table of Contents
Introduction ......................................................................... 5
Symbols Used in This Manual...................................................... 6
Before Using the Scanner............................ 8
System Requirements of Software............................... 8
Turning the Power ON................................................... 9
Turning Off the Power ............................................................. 9
Important Safety Instructions..................................... 10
Installation Location .............................................................. 10
AC Adapter............................................................................ 10
Moving the Scanner .............................................................. 11
Handling................................................................................ 11
Disposal ................................................................................ 12
When sending the scanner for repairs .................................. 12
Features of the Scanner.............................................. 13
Names and Functions of Parts ................................... 15
Basic Operation ......................................... 18
Documents ................................................................... 18
How to Place Documents............................................ 20
Switching the Feed and Eject Methods................................. 20
Placing Documents ............................................................... 21
Placing Cards........................................................................ 23
Placing Folded Documents ................................................... 23
Setting the Long Document Mode......................................... 24
Detecting a document double feed ....................................... 26
Detecting Skewed Documents .............................................. 29
Scanning methods ..................................... 31
Scanning with CaptureOnTouch ................................ 31
What is CaptureOnTouch?.................................................... 31
Setting the Scanner Driver.......................................... 32
Configuration and Functions of the Scanner Driver .............. 32
Setting Basic Scanning Conditions ....................................... 35
More Advanced Scanning Methods ........................... 45
Batch Separation (Insert blank page).................................... 45
Using a Patchcode for Scanning........................................... 45
Maintenance............................................... 48
Daily Maintenance........................................................ 48
Cleaning the Scanner............................................................ 48
Cleaning the Inside of the Scanner ....................................... 48
Cleaning the Sensor Glass and the Rollers .......................... 48
Replacing Consumable Parts................................................ 51
About the Canon imageFORMULA Driver Setting Tool ........ 54
Troubleshooting ......................................... 55
Common Problems and Solutions.............................. 55
Software Troubleshooting........................................... 57
Useful tips..................................................................... 58
Clearing Paper Jams and Skewed Documents ......... 60
Uninstalling the Software ............................................ 62
Appendix .................................................... 63
Specifications............................................................... 63
Replacement Parts................................................................ 64
Option.................................................................................... 64
About the Flatbed Scanner Unit ............................................ 64
Dimensions............................................................................ 65
Index...............................................................................66

8
Before Using the Scanner
System Requirements of Software
To use the scanner, your computer must satisfy the following system
requirements.
Computer
CPU:
Memory:
Hard disk:
installation of all software
USB interface: Hi-Speed USB2.0
Monitor: Resolution of 1024 × 768 (XGA) or better
recommended.
Operating system
•Microsoft Windows 10 (32-bit and 64-bit editions)
•Microsoft Windows 11
•Microsoft Windows Server 2012 R2
•Microsoft Windows Server 2016
•Microsoft Windows Server 2019
•Microsoft Windows Server 2022
This is the environment as of September 2023.
For the latest software support information, go to the Products page
on the Canon website.
Other requirements
•An ISIS-compatible application or a TWAIN-compatible application
that is compatible with the above operating systems.
•.NET Framework 4.8
Intel Core i3 2.13GHz or faster
4 GB or more
10 GB or more available space required for
IMPORTANT
• Use the USB interface provided as standard with your computer.
However, normal operation is not guaranteed with all USB
interfaces, even if present as standard equipment on the computer.
For details, consult your local authorized Canon dealer.
• Scanning speeds are lower if your computer’s standard USB
interface is USB Full-Speed (equal to USB 1.1.)
• The USB cable you are using should be the one originally included
with the scanner.
• If the CPU, memory, interface card, and other specifications do not
satisfy the installation requirements, the scanning speed may be
greatly reduced and transmission may take a long time.
• Even if the computer satisfies the system requirements, the
scanning speed may vary, depending on the specification of the
computer and the environment.
• The scanner drivers provided with the scanner do not necessarily
operate on all ISIS or TWAIN-compatible applications. For details,
contact your application software retailer.
• In Windows 10 tablet mode, the software may disrupt the display.
• The Desktop Experience feature must be enabled for Windows
Server 2012 R2.
Precautions for Use in 64-bit Operating Systems
• The ISIS driver supplied with this product supports scanning with
32bit applications only.

9
Turning the Power ON
The power of the scanner can be turned ON and OFF with the power
button on the front of the scanner.
1 Make sure that the scanner and computer are connected
properly.
2 Press the power button.
The power button lights blue when the power turns ON.
Hint
A balloon message such as shown below appears on the task bar. If
you wait a while, automatic scanner recognition will end and the
scanner will become ready to use.

When the scanner is properly connected to the computer, the
(CaptureOnTouch) icon appears on the taskbar as follows.
If the taskbar icon appears as , the scanner is not properly
connected to the computer. Check the status of the power switch and
USB cable.
Turning Off the Power
Press and hold the power button until the indicator goes out.
IMPORTANT
• After turning the scanner off, wait at least 10 seconds before turning
it back on.
• If you will not be using the scanner for an extended period, you
should disconnect the power cord from the AC outlet for safety.
Hint
The scanner’s auto power off setting is enabled by default, and the
scanner will turn off automatically if it is not operated for 4 hours.
For details on how to disable this setting, see “About the Canon
imageFORMULA Driver Setting Tool” on p. 54.
Power button

10
Important Safety Instructions
To ensure the safe operation of this scanner, be sure to read the
safety warnings and precautions described below.
Installation Location
The performance of this scanner is affected by the environment in
which it is installed. Make sure that the location where the scanner is
installed meets the following environmental requirements.
●Provide adequate space around the scanner for operation,
maintenance, and ventilation.
●When scanning documents using the straight path, provide
adequate space in back of the scanner for scanned document
output.
●Avoid installing the machine in direct sunlight. If this is unavoidable,
use curtains to shade the scanner.
●Avoid locations where a considerable amount of dust accumulates
as dust may adversely affect the inside of the scanner.
●Avoid warm or humid locations, such as in the vicinity of a water
faucet, water heater, or humidifier. Avoid locations where ammonia
gas is emitted. Avoid locations near volatile or flammable materials,
such as alcohol or paint thinner.
●Avoid locations that are subject to vibration.
●Avoid exposing the scanner to rapid changes in temperature. If the
room in which the scanner is installed is cold but rapidly heated,
water droplets (condensation) may form inside the scanner. This
may result in a noticeable degradation in scanning quality. The
following conditions are recommended for optimal scanning quality:
Room temperature: 10 °C to 32.5 °C (50 °F to 90.5 °F)
Humidity: 20% to 80% RH
●Avoid installing the scanner near equipment that generates a
magnetic field (e.g. speakers, televisions, or radios.)
AC Adapter
●Connect only to a power outlet of the rated voltage and power
supply frequency (120 V, 60 Hz or 220-240 V, 50/60 Hz depending
on your region).
●Do not connect other electrical equipment to the same power outlet
to which the scanner is connected. Also, when using an extension
cord, make sure that the extension cord is rated for the current
requirements of the scanner.
●Never try to take the AC adapter apart or modify it in any way, as
this is dangerous.
●The power cord may become damaged if it is often stepped on or if
heavy objects are placed on it.
●Do not use the power cord while it is coiled.
●Do not pull directly on the power cord. When disconnecting the
power cord, grasp the plug and remove it from the outlet.
●Keep the area around the power cord clear of objects so that the
power cord can be disconnected easily in an emergency.
●Do not use an AC adapter other than the one provided with the
scanner. Do not use the AC adapter provided with the scanner with
other products.
●If you have any questions regarding the power supply, contact your
local authorized Canon dealer or service representative for further
information.
100mm
(3.94")
100mm (3.94")
100mm
(3.94")
