E
Canon Video Visualizer
RE-450X
INSTRUCTION MANUAL
NTSC/PAL
English
RE-450XE01.10.2422:14ページA

1
Thank you for purchasing the Canon Video Visualizer RE-450X.
The RE-450X is a user-friendly portable image input device with a built-in video camera and a 12
×zoom lens. It projects images of flat documents, three-dimensional objects, film, etc., onto a
video monitor. Here are the main features:
• Quality images can be immediately projected by the auto focus, auto white balance, and auto
iris (automatic exposure) functions.
• This device has many terminals, including RGB OUT for high-definition XGA liquid-crystal
projectors and other devices, RGB IN, VIDEO OUT, and S-VIDEO OUT.
• This device has a backlight that allows it to project film and other transparent media.
• Functions of the RE-450X can be controlled via the RS-232C connection.
To use this product correctly, please read this Instruction Manual carefully before operation.
This Instruction Manual applies to both the NTSC model and the PAL model.
• This Instruction Manual may not be copied, in whole or part, without prior consent of Canon.
• The content of this manual is subject to change without notice.
• Canon is not responsible for any damage, direct or indirect, arising from or related to this
manual’s use.
© Copyright 2001 CANON INC.
ALL RIGHTS RESERVED
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the product’s
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock to persons.
The exclamation point, within an equilateral
triangle, is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
Confirm that the package contains the following items:
1. Canon Video Visualizer RE-450X.
2. Power cord (2 m/6.6 ft) ×1
3. RGB cable (one)
4. 3P to 2P adapter
* The ground wire has a cap.
5. Unit cover
6. Instruction Manual
IMPORTANT WARNINGS
Following signs are shown on the product.
CAUTION:
TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR
BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
INTRODUCTION
RE-450XE01.10.2422:14ページ1

2
E
IMPORTANT USAGE INSTRUCTIONS
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT EXPOSE THIS PRODUCT TO RAIN OR
MOISTURE.
FCC NOTICE
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
•Consult the dealer or an experienced radio/TV technician for help.
Do not make any changes or modifications to the equipment unless otherwise specified in the
manual. If such changes or modifications are made, you could be required to stop operation of the
equipment.
This digital apparatus does not exceed the Class B limits for radio noise emissions from a
digital apparatus as set out in the interference-causing equipment standard entitled “Digital
Apparatus”, ICES-003 of the Bureau of Industry and Science Canada.
The serial number of this product can be found on the back of the unit.
No other unit has the same serial number. You should record the number and other vital information
here and retain this book as a permanent record of your purchase to aid identification in case of
theft.
Date of Purchase
Dealer Purchased From
Dealer Address
Dealer Phone No.
Model No. RE-450X
Serial No.
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK
AND TO REDUCE ANNOYING INTERFERENCE,
USE THE RECOMMENDED ACCESSORIES ONLY.
RE-450XE01.10.2422:15ページ2

3
IMPORTANT SAFETY INSTRUCTIONS
In these safety instructions the word “product”refers to the Canon Video Visualizer RE-450X and
all its accessories.
1. Read Instructions—All the safety and operating
instructions should be read before the product is
operated.
2. Retain Instructions—The safety and operating
instructions should be retained for future reference.
3. Heed Warnings—All warnings on the product and in
the operating instructions should be adhered to.
4. Follow Instructions—All operating and maintenance
instructions should be followed.
5. Cleaning—Unplug this product from the wall outlet
before cleaning.
Wipe the product with a clean soft cloth. If
necessary, put the cloth in diluted neutral detergent
and wring it out well, before wiping the product.
Finally, clean the product with a clean dry cloth. Do
not use benzene, thinner or other volatile liquids or
pesticides as they may damage the product’s finish.
When using chemically-treated cleaning cloths,
observe their precautions accordingly.
6. Accessories—Do not use non Canon approved
accessories as they may be hazardous. Always use
the specified connection cables and be sure to
connect devices correctly.
7. Water and Moisture—Hazard of electric shock—Do
not use this product near water or in rainy/moist
situations. Do not put a heater near this product.
8. Placing or Moving—Do not place this product on an
unstable cart, stand, tripod, bracket or table. The
product may fall, causing serious injury to a child or
adult and serious damage to the product. A product
and cart combination should be
moved with care. Quick stops,
excessive force, and uneven
surfaces may cause the product
and cart combination to overturn.
9. Power Sources—This product should be operated
only from the type of power source indicated on the
marking label. If you are not sure of the type of
power supply in your home, consult your product
dealer or local power company.
10.Grounding—This product is equipped with a 3-
pronged grounding plug (the plug has a third
grounding pin).
The 3-pronged grounding plug will fit into a
grounding type power outlet. This is a safety feature.
If you are unable to insert the plug into the outlet,
contact your electrician to replace your obsolete
outlet. Do not defeat the safety purpose of the
grounding-type plug.
11.Power-Cord Protection—Power cords should be
routed so that they are not likely to be walked on or
pinched by items placed upon or against them. Pay
particular attention to plugs, and the point from
which the cords exit the product.
12.Outdoor Antenna Grounding—If an outside antenna
is connected to the product, be sure the antenna is
grounded so as to provide some protection against
voltage surges and built-up static charges. Section
810 of the National Electrical Code, ANSI/NFPA No.
70—1984, provides information with respect to
proper grounding of the mast and supporting
structure, grounding of the lead-in wire to an
antenna dischage unit, size of grounding
conductors, location of antenna dischage unit,
connection to grounding electrodes, and
requirements for the gounding electrode. See
figure 1.
B
E
N
Z
E
N
RE-450XE01.10.2422:15ページ3

4
E
13.Lightning—For added protection of this product
during a lightning storm, or when it is left unattended
and unused for long periods of time, disconnect it
from the wall outlet. This will prevent damage to the
product due to lightning and power-line surges.
14.Power Lines—An outside antenna system should
not be located in the vicinity of overhead power lines
or other electric light or power circuits, or where it
can fall into such power lines or circuits. When
installing an outside antenna system, extreme care
should be taken to keep from touching such power
lines or circuits as contact with them might be fatal.
15.Overloading—Do not overload wall outlets and
extension cords as this can result in a risk of fire or
electric shock.
16.Objects and Liquid Entry—Never push objects of
any kind into this product through openings as they
may touch dangerous voltage points or short out
parts that could result in a fire or electric shock. Be
careful not to spill liquid of any kind onto the
product.
17.Servicing—Do not attempt to service this product
yourself as opening or removing covers may expose
you to dangerous voltage or other hazards. Refer all
servicing to qualified service personnel.
18.Damage Requiring Service—Disconnect the product
from the wall outlet and refer servicing to qualified
service personnel under the following conditions:
a. When the power-supply cord or plug is
damaged.
b. If any liquid has been spilled onto, or objects
have fallen into the product.
c. If the product has been exposed to rain or
water.
d. If the product does not operate normally even if
you follow the operating instructions, adjust
only those controls that are covered by the
operation instructions. Improper adjustment of
other controls may result in damage and will
often require extensive work by a qualified
technician to restore the product to its normal
operation.
e. If the product has been dropped or the cabinet
has been damaged.
f. When the product exhibits a distinct change in
performance. This indicates a need for service.
19.Replacement Parts—When replacement parts are
required, be sure the service technician has used
replacement parts that are specified by Canon or
that have the same characteristics as the original
part. Unauthorized substitutions may result in fire,
electric shock or other hazards.
20.Safety Check—Upon completion of any service or
repairs to this product, ask the service technician to
perform safety checks to determine that the product
is in safe operating order.
Example of antenna grounding
as per National Electrical Code
Antenna lead-in wire
Ground clamp
Antenna discharge unit
(NEC section 810-20)
Grounding conductors
(NEC section 810-21)
Electric Service
Equipment
Ground clamps
NEC—National Electric Code
Power service grounding
electrode system
(NEC art 250, part H)
Fig. 1
RE-450XE01.10.2422:15ページ4

5
CONTENTS
IMPORTANT SAFETY INSTRUCTIONS ………3
1. NOMENCLATURE AND FUNCTIONS …………6
2.
ASSEMBLING, STORING AND CONNECTION …8
3. OPERATION ………………………………………11
Manual Focusing …………………………………………12
Film Projection ……………………………………………12
Readjusting the White Balance …………………………13
Changing the angle to Letter/A4 size …………………13
Freezing an output image ………………………………13
Projecting white documents ……………………………14
Adjusting Brightness and Picture Contrast …………14
4. SYSTEM CONNECTION …………………………15
Outputting to a video monitor ……………………………15
To Control by a Computer ………………………………15
Changing to Pictures via External Input Equipment …16
Recording by VCR …………………………………………17
Functions Controlled by a Computer …………………18
5. TROUBLESHOOTING ……………………………19
6. SPECIFICATIONS ………………………………20
RE-450XE01.10.2422:15ページ5

RE-350
VIDEO VISUALIZER
6
E
Power switch (see page 11)
Arm
Arm lock release
lever
Rear panel
Camera head
Lens cap Illumination lamp
Document table and Backlight
Carrying handle
Operation panel
After turning the power OFF, wait at least 5 seconds before turning the power
ON again. Turning the power ON too soon may cause a malfunction.
The illumination lamps do not light up immediately after the LIGHTS button is
pressed. To protect the lamps, the system preheats for 3 seconds, then turns
the lamps on.
Illumination lamp for reflection copies.
Pressing the LIGHTS button on the
operation panel turns the lamp on. The
angle of the lamp is adjustable.
Press to fold/unfold
the arm
Pull out to carry the unit.
NOTICE
NOMENCLATURE AND FUNCTIONS
1
VIDEO
OUT
S VIDEO
OUT
RGB OUT
RGB IN AC INLET
RS-232C
Rear Panel
VIDEO OUT terminal
S-VIDEO OUT terminal
RGB OUT terminals
RS-232C terminal
AC inlet
See page 15 for system construction.
Use this terminal when controling the RE-450X
by a computer (see page 15, 18).
RGB IN terminal
RE-450XE01.10.2422:15ページ6

7
LOW HIGH
RED BLUE
MANUALAUTO WHITE
PAPER
POWER LIGHT BACK
LIGHT INPUT
SELECT WHITE BALANCE EXPOSURE
HARD
WIDE TELE
NEAR FAR
MANUAL
AUTO
SOFT
DETAIL FOCUS ZOOM
STILL
ZOOM
PRESET
Operation Panel
LIGHTS button/indicator
Use this button to turn ON the
illumination lamps for reflection
copies. The indicator flashes
during preheating, and stays lit
after preheating.
BACK LIGHT button/indicator
Use this button to turn ON the backlight
for transparencies (see page 12). The
indicator lights up when the backlight is
used.
INPUT SELECT button/indicator
Use this button to select input source to switch between pictures
via internal input (the unit’s camera head) and pictures via
external input (such as a computer) (see page 16). The indicator
lights up when external input equipment is selected.
WHITE BALANCE
button/indicator/control
Use this button/knob to adjust color tone (see
page 13). To adjust manually, press the WHITE
BLANACE button and turn the WHITE BALANCE
knob. Turn the knob to the RED side to increase
red tone, or turn the knob to the BLUE side to
increase blue tone.
FOCUS buttons/indicator
Use this button to focus (see page 12). To
focus manually, press the FOCUS button and
then the NEAR button or the FAR button.
DETAIL control
Use this control to adjust picture quality (see page 14).
Turn the control to the HARD side to emphasize the
outline, turn to the SOFT side for softer outline.
ZOOM buttons
Press the WIDE button to change
the picture to wide-angle. Press the
TELE button to change the picture
to telephoto.
POWER indicator
Lights up when the power
is ON (see page 11).
WHITE PAPER button/indicator
Use this button to make a paper
document on the table appear whiter.
The indicator lights up when this function
is on.
EXPOSURE control
Use this knob to adjust image brightness (see
page 14). To increase brightness, turn the knob
to the HIGH side. To decrease brightness, turn
the knob to the LOW side. Brightness may not
be adjusted effectively using the EXPOSURE
knob if the image is too dark.
STILL PICTURE button/indicator
Press the STILL PICTURE button to freeze
a moving output image. When the button is
pressed again, the moving picture will start
running again (see page 13). The indicator
lights up when the picture is frozen.
ZOOM PRESET button/indicator
Press the ZOOM PRESET button to set
the angle for letter/A4 size paper (see page
13). The indicator lights up when the button
is pressed.
The illumination lamps and the backlight cannot be used at
the same time.
RE-450XE01.10.2422:15ページ7

8
E
Unfold and raise the pair of illumination lamps.
Raise the right-hand illumination lamp first (), then the left-
hand illumination lamp ().
Press the arm lock release lever, and raise the
arm until it stops.
Direct the camera head towards the document
table.
Remove the lens cap.
Keep the lens cap in a safe place.
1
2
3
4
Assembling


Arm lock release lever
ASSEMBLING, STORING AND CONNECTION
2
Make sure to hold the arm when pressing the arm lock
release lever. If the lever is pressed without holding the arm,
the arm jumps up and may result in injury or malfunction.
Please raise the arm slowly.
NOTICE
RE-450XE01.10.2422:15ページ8

9
Storing
Put the lens cap to the lens.
Direct the camera head sideways until it stops.
Hold the arm with your right hand and press
the arm lock release lever, then pull the arm
down to the document table very carefully.
Fold the pair of illumination lamps very carefully.
Fold the left-hand illumination lamp first (), then the right-
hand illumination lamp ().
1
2
3
4
Be sure to turn the power OFF before storing the unit.
Put the supplied unit cover on the RE-450X when the unit is not in use. The unit
cover has a pocket to store cords.
Place the unit horizontally when storing it. If the unit is stored
vertically, it may fall down and cause injury or malfunction. When
carrying the unit, turn the power OFF, disconnect the cords, fold the
arm and the illumination lamps, and pull out the carrying handle.
Do not touch the fluorescent lamps after the
illumination lamps are turned off, as they may still
be hot.
CAUTION


Make sure to hold the arm when stowing it. If the arm is
stowed without being held, the arm jumps up and may result
in injury or malfunction. Please stow it slowly.
Arm lock release lever
NOTICE
NOTICE
CAUTION
RE-450XE01.10.2422:15ページ9

10
E
VIDEO
OUT
S VIDEO
OUT
RGB OUT
RGB IN AC INLET
RS-232C
To connect the RE-450X to a liquid-crystal projector, use the RGB cable included in the package. Use the
power cable included in the package.
Connection
To protect the RE-450X as well as other equipment in use, make sure all the
equipment (if any) is OFF before connecting cables. Always hold onto the plug
section whenever connecting/disconnecting the cables.
See page 15 for connecting various equipment. For details of operation, refer to
the instruction manual of the equipment to be used.
Liquid-crystal projector
To RGB OUT
RGB cable
To RGB input terminal
Power cord
To AC
power outlet
Rear panel
NOTICE
NTSC
■ Installation Site and Environment
1. Connect the RE-450X to a correct
electronic source.
Source voltage: 120VAC ± 10%
Source frequency: 60 Hz
2. Install the RE-450X in a proper
environment.
Temperature: 41°F –95°F (5°C –35°C)
Humidity: 85% max (without condensation)
PAL
■ Installation Site and Environment
1. Connect the RE-450X to a correct
electronic source.
Source voltage: 220 –240VAC ± 10%
Source frequency: 50 Hz
2. Install the RE-450X in a proper
environment.
Temperature: 5°C –35°C (41°F –95°F)
Humidity: 85% max (without condensation)
RE-450XE01.10.2422:15ページ10

11
POWER
Turn the power ON.
When the power of the RE-450X is turned ON, the POWER
indicator on the operation panel lights up.
Turn ON the power source of the other equipment to be used.
Either the power of the RE-450X or other equipment may be turned on first.
Put the document at the center of the document
table.
If no image is displayed, check to see that the lens cap has been
removed.
1
2
3
POWER
The power of the RE-450X should be turned OFF when the unit is not used.
Disconnect the power cord if the unit will not be used for extended periods.
•When the power is turned on, it takes about 20 seconds to
show an image.
•When the power is turned on, white balance and focus are
automatically adjusted.
When operation is completed, turn the power
OFF.
The POWER indicator goes off. The illumination lamps or
backlight will go off (if they are on). Also turn OFF the power of
other equipment.
4
After turning the power OFF, wait at least 5 seconds before
turning the power ON again. Turning the power ON too soon
may cause a malfunction.
Document table
Power switch Operation Panel
OPERATION
3
NOTICE
RE-450XE01.10.2422:15ページ11

12
E
When trying to focus correctly or focusing on a particular point of three-dimensional objects, you can
achieve focusing by pressing the manual focusing buttons. The manual focusing is valid up to approx.
65mm above the document table.
HARD
WIDE TELE
NEAR FAR
MANUAL
AUTO
SOFT
DETAIL FOCUS ZOOM
STILL
ZOOM
PRESET
When focusing the lens
manually, press the FOCUS
button first and then the
NEAR button or the FAR
button. During manual focus
mode, the AUTO FOCUS
indicator turns off.
To return to auto focus
mode, press the FOCUS
button.
■Undesirable objects for focusing
Although the auto focus function of the RE-450X is capable of focusing on most objects, objects such as
those listed below may present some difficulty. If this happens, focus the lens manually by pressing the
FOCUS button first and then the NEAR button or the FAR button.
1. Objects with a low reflection factor (such as a dark cloth, hair, etc.)
2. Intangible objects (such as candle light, smoke, etc.)
3. Objects having a glossy surface (telephone receiver, glassware, etc.)
4. Objects viewed through glass.
5. Objects with low contrast.
Use the backlight to project transparencies, such as OHP film and slides.
LOW HIGH
RED BLUE
MANUALAUTO WHITE
PAPER
POWER LIGHT BACK
LIGHT INPUT
SELECT WHITE BALANCE EXPOSURE
BACK
LIGHT
Press the BACK LIGHT
button to project trans-
parencies. The BACK
LIGHT indicator lights up
and the document table
glows. If the illumination
lamps have been lighted,
they will go off.
Pressing the BACK LIGHT
button again, turns the
backlight off.
Film Projection
•Project the film to full monitor size by using the zoom button. If light from the
backlight appears in the monitor, the picture itself will not appear very sharp.
•If the color tone seems unnatural, adjust the white balance manually (see
page 13). If the auto focus function doesn’t operate accurately, focus the lens
manually.
•The illumination lamps and the backlight cannot be used at the same time.
Operation panel
Operation panel
FOCUS button
Manual Focusing
RE-450XE01.10.2422:16ページ12

13
D
WIDE TELE
NEAR FAR
MANUAL
AUTO
FOCUS ZOOM
STILL
ZOOM
PRESET
STILL
When an output image is a moving picture, if you press the STILL
PICTURE button, the output image will be frozen.
The STILL PICTURE indicator lights up while the image is frozen.
If you press the STILL PICTURE button again, the frozen picture
will start moving again.
To pause a moving output image, press the STILL PICTURE button. An indicator lights up and the output
image freezes.
If you press the button again, the frozen image will start moving again.
Freezing an output image
Operation panel
LOW HIGH
RED BLUE
MANUALAUTO WHITE
PAPER
POWER LIGHT BACK
LIGHT INPUT
SELECT WHITE BALANCE EXPOSURE
AUTO
WHITE BALANCE
To readjust the white balance, complete the following steps:
Press the WHITE BALANCE button (to turn on manual mode).
Turn the WHITE BALANCE knob to adjust to the desired color
tones. Turning the knob toward the RED side increases the red
tones. Turning the knob toward the BLUE side increases the
blue tones.
Readjust the white balance manually when the color tone seems unnatural or if you want to change it to
your desired tone.
Operation panel
Readjusting the White Balance
The set angle may be slightly different from Letter/A4 size.
D
WIDE TELE
NEAR FAR
MANUAL
AUTO
FOCUS ZOOM
STILL
ZOOM
PRESET
ZOOM
PRESET
Press the ZOOM PRESET button to make the angle Letter/A4 size.
The ZOOM PRESET indicator flashes when the ZOOM PRESET
button is pressed.
Use the ZOOM buttons to change the angle.
To make the angle Letter/A4 size, press the ZOOM PRESET button. An indicator lights up and output image
size will become Letter/A4 size. When changing the angle, use the ZOOM buttons.
Operation panel
Changing the angle to Letter/A4 size
•You cannot make adjustments such as zoom, focus, or white balance while
an image is frozen.
•You cannot save frozen pictures.
RE-450XE01.10.2422:16ページ13

14
E
LOW HIGH
E
WHITE
PAPER
EXPOSURE
HARD
NE
AUTO
SOFT
DETAIL FO
To adjust brightness, turn the EXPOSURE knob. Turn the knob
toward the HIGH side to brighten the image. Turn the knob toward
the LOW side to darken the image.
Use the DETAIL control to adjust picture quality. Turn the control
toward the HARD side to emphasize the outline of an object. Turn
the control towards the SOFT side for a softer outline.
The brightness of the picture can be controlled by the EXPOSURE control. When the document is dark, has
low cotrast, or is small and dim against a brighter background, use the EXPOSURE control to make the
image clearer.
Adjusting Brightness and Picture Contrast
Operation panel
LOW HIGH
RED BLUE
MANUALAUTO WHITE
PAPER
POWER LIGHT BACK
LIGHT INPUT
SELECT WHITE BALANCE EXPOSURE
WHITE
PAPER
EXPOSURE
To project white documents much whiter, press the WHITE PAPER
button.
If the button is pressed, the WHITE PAPER indicator lights up.
If the button is pressed again, the indicator turns off and returns to
regular mode.
To project white parts of white documents much whiter, press the WHITE PAPER button. If the button is
pressed, the WHITE PAPER indicator lights up. If the button is pressed again, the indicator turns off and
returns to regular mode.
Projecting white documents
Operation panel
Brightness may not be adjusted effectively using the EXPOSURE
knob if the image is too dark.
The effectiveness may vary depending on the document, including how dark it
is.
RE-450XE01.10.2422:16ページ14

15
To RGB input terminal
To S-video input terminal or video input terminal
VIDEO
OUT
S VIDEO
OUT
RGB OUT
RGB IN AC INLET
RS-232C
To output to a video monitor,
connect the RE-450X to a
monitor’s video input terminal
using a commercially available
video cable. The video monitor
projects images from the camera
head, regardless of the selected
input equipment.
The following equipment can be connected to the input and output terminals. Use the included power cord.
For cables other than the power cord and the RGB cable, use commercially available cables. For details of
operation, refer to the instruction manual of the equipment to be used.
Video monitor
Liquid-crystal
projector VCR
RGB monitor
Computer
RGB cable
Rear panel
Power cord
Outputting to a video
monitor
Output Equipment
To control by a computer
To control certain functions of the RE-450X by a computer,
complete the following steps:
Connect the RE-450X to the computer using a RS-232C
cable.
Turn ON the power to the equipment.
Operate the computer.
For details, please consult your dealer.
To AC
power outlet
Video
cable
RGB projector
Video camera,
speakers with an
amplifier, etc.
SYSTEM CONNECTION
4
S-video cable
When using video
output and S-video
output, dark areas
may appear on the
periphery of the
screen.
When connecting to equipment such as a video monitor or a
VCR, check if your RE-450X model uses NTSC or PAL
format, and use equipment compatible with the appropriate
format.
NOTICE
RE-450XE01.10.2422:16ページ15

16
E
LOW HIGH
RED BLUE
MANUALAUTO WHITE
PAPER
POWER LIGHT BACK
LIGHT WHITE BALANCE EXPOSURE
INPUT
SELECT
BACK
LIGHT INPUT
SELECT
To switch to pictures from external input equipment, press the
INPUT SELECT button.
The INPUT SELECT indicator lights up, and pictures are output
from the equipment connected to the RGB input terminal. To return
to pictures from the camera head, press the INPUT SELECT button
again.
If you connect a computer or other equipment to the RGB input terminal, you can project images from that
equipment simply by pressing a button.
Changing to Pictures via External Input Equipment
Regardless of the selected input equipment, pictures from the camera head will
be output to the video output terminal and S-video output terminal.
Operation panel
RE-350
VIDEO VISUALIZER
INPUT SELECT button
RGB IN
RGB OUT
Liquid-crystal projector
Computer
Camera of the RE-450X
External
input
RE-450XE01.10.2422:16ページ16

17
VIDEO
OUT
S VIDEO
OUT
RGB OUT
RS-232C
If you want to record using a VCR, connect the RE-450X to the VCR using a commercially available video
cable. For details of operation, refer to the instruction manual for the equipment to be used.
Recording by VCR
VCR
Video cable
To VIDEO IN
terminal
Rear panel
When you use a VCR with an S-video outlet, use S-video cables to connect to
the S-video outlet. This will enable you to project a high quality image.
Check if your RE-450X model is uses
NTSC or PAL format, and use a VCR
compatible with the appropriate format.
NOTICE
RE-450XE01.10.2422:16ページ17

18
E
Functions Controlled by a Computer
The following functions can be controlled by a computer. For more information, please contact your dealer.
Category Abbreviation Meaning
Camera
control
Zoom lens control
Focus control
White balance setting
Exposure compensation
Still picture
Outline adjustment
Input signal selection
Illumination control
Control mode selection
Information output
Zoom STOP
Zoom TELE
Zoom WIDE
Zoom positioning default position
Zoom positioning A4 landscape
Zoom positioning
Zoom speed
Focus AF
Focus MANUAL
Focus STOP
Focus NEAR
Focus FAR
White balance AUTO
White balance MANUAL
White balance value designation
Exposure value designation
Exposure mode NORMAL
Exposure mode WHITE PAPER
Still picture ON
Still picture OFF
DETAIL setting
Input selection CAMERA
Input selection EXTERNAL
Lights ON
Lights OFF
Backlight ON
Backlight OFF
Host control mode
Local control mode
Model name request
ROM version request
The zoom lens stops.
Moves the zoom lens toward telephoto.
Moves the zoom lens toward wide-angle.
Moves the zoom lens to default position.
Moves the zoom lens to A4 landscape position.
Moves the zoom lens to specified position.
Sets lens zooming speed.
Switches to auto focus mode.
Switches to manual focus mode.
Stops lens focus movement.
Moves lens focus closer.
Moves lens focus farther.
Adjusts white balance automatically.
Adjusts white balance manually.
Specifies white balance target value.
Specifies exposure value.
Switches exposure to NORMAL mode.
Switches exposure to WHITE PAPER mode.
Turns STILL PICTURE mode ON.
Turns STILL PICTURE mode OFF.
Sets picture quality adjustment values.
Selects the internal camera head as the input signal.
Selects external signal as the input signal.
Turns the illumination lamps on.
Turns the illumination lamps off.
Turns the backlight on.
Turns the backlight off.
Switches the RE-450X to be controlled by a computer.
Cancels the Host Control Mode.
Reads the RE-450X model information.
Reads ROM version information.
System
control
RE-450XE01.10.2422:16ページ18

19
The fluorescent illumination lamps and backlight are consumables.
Replace with a new lamp if a lamp starts flickering or becomes dark.
For details of replacement, please consult your dealer.
If the RE-450X does not function properly, check the following points before contacting your dealer.
Problem Possible cause Reference
page
If the problem cannot be solved after checking the above points, please contact your dealer.
TROUBLESHOOTING
5
No image appears on
the monitor
The picture cannot be
focused correctly
The zoom function
doesn’t work
Pictures appear
reddish/bluish
Pictures are too
bright/dark
The input source
cannot be changed
The screen doesn’t
change
The illumination lamps
do not light up
immediately when the
LIGHTS button is
pressed
The RE-450X cannot be
controlled by a
computer
•The lens cap has not been removed. 8
•The power of the RE-450X or other equipment has not been 11
turned ON.
•Connection may be incorrect. 15
•The input source is not selected correctly. 16
•The document may be too dark or glowing. 12
•Strong light may be reflected on the screen. 12
•The object has low contrast. 12
•Focusing has been set in manual mode. 12
•The image is frozen. 13
•The image is frozen. 13
•The white balance has been adjusted manually. 13
•The color tone of the video monitor is not correct. —
•The WHITE PAPER button is on. 14
•Exposure of the RE-450X or monitor has not been adjusted 14
correctly.
•The object is not illuminated properly. —
•The power of the RE-450X or other equipment has not been 11
turned ON.
•Connection may be incorrect. 15
•The image is frozen. 13
•To protect the lamps, the system preheats for 3 seconds,
then the lamps light up. During preheating, the LIGHT
indicator flashes. This is not a malfunction. —
•The power of the RE-450X or other equipment has not been 11
turned ON.
•Connection may be incorrect. 15
•Incorrect operation may be the cause. —
RE-450XE01.10.2422:16ページ19
