Canon 9540A003 - Optura 400 Camcorder User manual

Digital Video Software Version 13
Instruction Manual
If you are using Windows operating system, use the supplied
DIGITAL VIDEO SOLUTION DISK For Windows.
If you are using Macintosh operating system, use the supplied
DIGITAL VIDEO SOLUTION DISK For Macintosh.
Si vous travaillez avec le système d’exploitation Windows, utilisez le disque
DIGITAL VIDEO SOLUTION DISK For Windows fourni avec l’appareil.
Si vous travaillez avec le système d’exploitation Macintosh, utilisez le disque
DIGITAL VIDEO SOLUTION DISK For Macintosh fourni avec l’appareil.
Si está utilizando el sistema operativo Windows, use el disco
DIGITAL VIDEO SOLUTION DISK For Windows suministrado.
Si está utilizando el sistema operativo Macintosh, use el disco
DIGITAL VIDEO SOLUTION DISK For Macintosh suministrado.
Manuel d’instruction
Manual de Instrucciones
PUB. DIM-645
E
F
Es
This instruction manual explains how to install the software, connect the camcorder to a
computer, and download images from a memory card to a computer. For more detailed
operational instructions, refer to the PDF format manual provided on the DIGITAL VIDEO
SOLUTION DISK For Windows or DIGITAL VIDEO SOLUTION DISK For Macintosh.
Ce manuel d'instruction explique comment installer le logiciel, connecter le
camescope a l'ordinateur et telecharger des images a partir d'une carte memoire sur
un ordinateur. Pour des instructions de fonctionnement plus detaillees, reportez-vous
au manuel au format PDF fournie sur le disque DIGITAL VIDEO SOLUTION DISK
For Windows ou DIGITAL VIDEO SOLUTION DISK For Macintosh.
En este manual de instrucciones se explica como instalar el software, conectar la
videocamara a un ordenador, y descargar imagenes de una tarjeta de memoria a un
ordenador. Si desea instrucciones mas detalladas sobre el funcionamiento, consulte el
manual de formato PDF suministrado con el disco DIGITAL VIDEO SOLUTION DISK
For Windows o DIGITAL VIDEO SOLUTION DISK For Macintosh.
