CANOPY C. KING BED User manual

BOX #1
A . UPPER HEADBOARD SUPPORT
B. LOWER HEADBOARD SUPPORT
C. HEADBOARD PANEL
D. UPPER FOOTBOARD SUPPORT
E. FOOTBOARD PANEL
F. SLAT ROLL
BOX #2
CANOPY C. KING BED
ASSEMBLY INSTRUCTIONS
HARDWARE PACKED IN BOX #3
WOOD SCREW (M4X30)
1 PC
1ALLEN BOLT (M8X50) 16 PCS
5
31 PCS
ALLEN KEY
6
2ALLEN BOLT (M8X40) 4 PCS
FLAT WASHER (M8)
SPRING WASHER (M8)
3
424 PCS
24 PCS
BOX #3.
I. SIDE RAIL
J. CENTER SLAT SUPPORT
K. CENTER SLAT SUPPORT LEG
L. CANOPY RAIL
G1. LEFT VERTICAL HEADBOARD POST
G2. RIGHT VERTICAL HEADBOARD POST
H1. LEFT VERTICAL FOOTBOARD POST
H2. RIGHT VERTICAL FOOTBOARD POST
ALLEN BOLT (M8X20) 4 PCS
7
A
B
C
D
E
F
K
L
J
I
IMPORTANT NOTE! DUE TO THE SIZE OF THE BED WE RECOMMEND THE FOLLOWING TIPS TO ASSEMBLING
YOUR BED.
1. HELP FROM A SECOND PERSON IS REQUIRED TO INSURE A SAFE ASSEMBLY PROCESS.
2. WHEN STEP 1 AND STEP 2 ARE COMPLETED LEAN THE ASSEMBLIES AGAINST A WALL TO CLEAR THE
SPACE OF PARTS.
3. ASSEMBLE THE BED, STEP 3 AND FORWARD IN THE FINAL SPOT YOU WANT THE BED. MOVING THE BED
AFTER ASSEMBLY COULD BE DANGEROUS.
TOOL REQUIRED
PHILLIPS HEAD SCREW DRIVER AND LADDER
(NOT PROVIDED)
G1 G2 H2
H1

CANOPY BED FULLY ASSEMBLED
STEP 1: CONNECT THE HEADBOARD PANEL (C) TO THE LEFT (G1) AND RIGHT VERTICAL
HEADBOARD POST (G2) WITH FOUR M8X40 ALLEN BOLTS (2), SPRING WASHERS (4) AND FLAT
WASHERS (5). ONLY FINGER TIGHTEN THE BOLTS!
ATTACH THE LOWER HEADBOARD SUPPORT (B) TO THE HEADBOARD ASSEMBLY USING FOUR
M8X50 ALLEN BOLTS (1), SPRING WASHERS AND FLAT WASHERS. TIGHTEN ALL BOLTS,
INCLUDING THE PREVIOUS FOUR, COMPLETELY WITH THE PROVIDED ALLEN KEY (7)
STEP 1:
5
4
2
7
5
4
1
7
G2
G1

STEP 2:
STEP 3:
5
4
1
7
5
4
3
1
7
STEP 3: WITH THE HELP OF A SECOND PERSON, CONNECT THE HEADBOARD (STEP 1) AND
FOOTBOARD (STEP 2) ASSEMBLIES TO THE SIDE RAILS (I). FOLLOWING THE ILLUSTRATION,
CONNECT THE TOP SIDE RAIL BRACKET WITH ONE M8X20 ALLEN BOLT (3), SPRING WASHER
AND FLAT WASHER. CONNECT THE BOTTOM SIDE RAIL BRACKET WITH ONE M8X50 ALLEN
BOLT, SPRING WASHER AND FLAT WASHER. DO NOT TIGHTEN COMPLETELY UNTIL BOTH ENDS
OF EACH SIDE RAIL HAVE BEEN ATTACHED. ONCE ALL PIECES ARE CONNECTED, TIGHTEN ALL
BOLTS WITH THE ALLEN KEY.
STEP 2: CONNECT THE FOOTBOARD PANEL (3) TO THE LEFT (H1) AND RIGHT VERTICAL
FOOTBOARD POSTS (H2) WITH FOUR M8X50 ALLEN BOLTS, SPRING WASHERS AND FLAT
WASHSERS. TIGHTEN COMPLETELY WITH THE ALLEN KEY.
45
H2
H1
I
I

K
J
STEP 4:
STEP 5:
STEP 6: CONNECT THE CENTER SLAT SUPPORT
ASSEMBLY (STEP 5) TO THE SLAT CLEAT
ATTACHEMENT ON THE HEAD AND
FOOTBOARD, AS SHOWN IN THE
ILLUSTRATION. SECURE THE SLAT SUPPORT
TO THE BED USING TWO WOOD SCREWS (6).
6
L
5
4
1
7
STEP 4: WITH THE USE OF A STEP LADDER (NOT INCLUDED) AND FOLLOWING THE
ILLUSTRATION, CONNECT THE UPPER HEADBOARD SUPPORT (A) AND UPPER FOOTBOARD
SUPPORT (D) THEN THE CANOPY RAILS (L) TO THE VERTICAL HEADBOARD AND FOOTBOARD
POSTS. ONCE SUPPORTS AND RAILS ARE IN PLACE, SECURE THE COMPONENTS WITH FOUR
M8X50 ALLEN BOLTS, SPRING WASHERS AND FLAT WASHERS. TIGHTEN ALL BOLTS WITH THE
ALLEN KEY.
A
D
STEP 5: ATTACH THE CENTER SLAT SUPPORT
LEGS (K) TO THE CENTER SLAT SUPPORT (J).
K
J
K
STEP 6:

INSTRUCTIONS FOR ADJUSTING
LEVELER
POSITION THE BED IN YOUR
SPACE AND LOCATE THE
LEVELER UNDER EACH
SUPPORT LEG. TURN THE
LEVELER
COUNTER-CLOCKWISE TO
EXTEND THE LEVELER AND
CLOCKWISE TO RETRACT IT.
ADJUST EACH LEVELER UNTIL
EACH SUPPORT LEG IS APPLY
EQUAL, UPWARD PRESSURE ON
THE SUPPORT SLAT.
MAINTENANCE INSTRUCTIONS:
REMOVE YOUR MATTRESS, AND BOX
SPRING IF APPLICABLE, BEFORE
MOVING YOUR BED.
LIFT YOUR BED WHEN MOVING IT;
DRAGGING CAN DAMAGE THE
SUPPORTS.
RE-ADJUST THE LEVELERS AFTER
MOVING YOUR BED.
STEP 7:
6
F
STEP 7: ATTACH THE SLAT ROLL (F) TO THE BED ASSEMBLY AS SHOWN AND SECURE WITH
WOOD SCREWS.
