Canvas BROOKS 063-6341-2 User manual

ASSEMBLY INSTRUCTIONS
HAVING TROUBLE?
TOLL-FREE:
1-888-670-6684
IMPORTANT: Please read this manual carefully
before beginning assembly of this product.
Keep this manual for future reference.
BROOKS
30” (76.2 CM) WHITE BATHROOM
VANITY WITH REVERSIBLE DOORS
PRODUCT NO. 063-6341-2

We believe in the power of décor and its
ability to make up the fabric of your home.
That’s why
CANVAS® collections draw
inspiration from Canadians and the way
they live
.
From on-trend furniture pieces to holiday
décor and all your outdoor living essentials,
CANVAS®
makes it easy to refresh your space
to reflect
your unique style and the way you
live every day
.
We would love to hear from you and welcome
your thoughtful feedback. Visit our website
at
canadiantire.ca to tell us about your
experience, and share your photos with us
using
#myCANVASstyle.
Show us how you bring
CANVAS® products
to life. We can’t wait to see!

Parts List 4
Before You Begin Assembly 8
Step-by-step Guide 10
Technical Data 19
Troubleshooting 20
Caring for Your Item 20
Warranty 21
TABLE OF CONTENTS
TOOLS REQUIRED
No. 2 Cross-head Screwdriver
Tip Shown Actual Size
NOTE: Do not over-drill/
be aware of over-drilling
• Pleasereadandunderstandthisentiremanualbeforeattemptingtoassemble,
operate,orinstalltheproduct.
• Anyassemblyormaintenanceoftheproductmustbecarriedoutbyadultsonly.
• Somepartsmaycontainsharpedges.Wearprotectiveglovesifnecessary.
• Topreventdamage,placeallpartsonalevelsurfaceduringassembly.Adda
layer of protective surface if needed.
• Donotallowyourchildrentoclimborjumponfurnitureduetopossible
accident,injuryordeath.Achildclimbingonapieceoffurniturecanmakeit
top-heavy and cause the furniture to tip over.
• Keepchildrenandpetsawayduringassembly.
• Repairingandreplacingpartsshouldbedonebyaqualiedtechnician.
• Thisunitisintendedforuseonlywithinthemaximumweightindicated.Use
withloadsheavierthanthemaximumweightindicatedmayresultininstability
causingpossibleinjury.
• Failuretofollowthesewarningscouldresultinseriousinjury.
WARNING!TOREDUCETHERISKOFSERIOUSINJURY,
READTHEFOLLOWINGSAFETYINSTRUCTIONSBEFORE
ASSEMBLINGANDUSINGTHEPRODUCT.
HexWrench 2 People

BROOKS 30” (76.2 CM) WHITE BATHROOM VANITY WITH REVERSIBLE DOORS4
PARTS LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
7 LowerBackStretcher 1
8 UpperFrontStretcher 1
9 BottomFrontStretcher 1
10 Bottom Panel 1
11 BackPanel 1
12 AdjustableShelf 1
13 Left Door 1
14 Right Door 1
1 Backsplash 1
2Vanity Top 1
3Side Panel Left 1
4Side Panel Right 1
5 UpperBackStretcher 1
6 MiddleBackStretcher 1

BROOKS 30” (76.2 CM) WHITE BATHROOM VANITY WITH REVERSIBLE DOORS 5
EXPLODED PARTS
1
2
3
4
5
6
7
12
10
11
9
13 14
8

BROOKS 30” (76.2 CM) WHITE BATHROOM VANITY WITH REVERSIBLE DOORS6
HARDWARE LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
A CamLock 18
BCam Bolt 18
G M4x12mmScrew 24
H M3.5x15mmScrew 20
C M8x30mmWoodDowel 20
D 1/4”x32mmBolt 4
E M4x25mmScrew 2
F HandlewithBolts 2sets
I M3.5x12mmScrew 4
（GoldandBrushedNickel）

BROOKS 30” (76.2 CM) WHITE BATHROOM VANITY WITH REVERSIBLE DOORS 7
HARDWARE LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
J SlowCloseHinge 4
KShelf Support 4
LLeveller 4
M HexWrench 1
NGlue 1
O M4x50mmScrew 2
PPlastic anchor 2

BROOKS 30” (76.2 CM) WHITE BATHROOM VANITY WITH REVERSIBLE DOORS8
BEFORE YOU BEGIN ASSEMBLY
MAKE SURE ALL PARTS ARE PRESENT
Compareallpiecestothepartsandhardwarelists,and
makesureyouhavealltoolsrequiredforassembly.
REMOVE PACKAGING MATERIALS
Placepackingmaterialsbackinthebox.Donotdisposeof
packagingmaterialsuntilassemblyiscomplete.
READ EACH STEP CAREFULLY
Makesureyouunderstandeachstep.Ifyouhaveanyquestions,
contact CANVAS®customer service at 1-888-670-6684 (toll free).
ASSEMBLE IN A CLEARED AREA
Placeallpartsfromtheboxontheoorinfrontofyouonaclean,
dry,levelsurfacetoprotecttheproductasitisbeingbuilt.

BROOKS 30” (76.2 CM) WHITE BATHROOM VANITY WITH REVERSIBLE DOORS 9
BEFORE YOU BEGIN ASSEMBLY
CAM LOCK SYSTEM OPERATION
NOTE:ITISVERYIMPORTANTTOUSEGLUEWITHDOWELS.EXCESSGLUECAN
BEWIPEDOFFWITHDAMPCLOTH.
InsertdowelatleasthalfwaybytappinglightlywitharubbermalletIFNECESSARY.
GLUE
X
X
1 4
3
2
HOW THE KNOCK DOWN (KD) ASSEMBLY SYSTEM WORKS
1.Screwcamboltintothepre-drilledsmallholesonpanel.Alignthepanelstobejoined
so that the cam bolt goes into the pre-drilled hole on the edge of the second panel and
protrudesintotheholethatwillhousethecamlock.
2.Insertthecamlockintopre-drilledlargeholeonpanel.Makesurearrowonthecam
lockispointedtowardthecambolt.
3.Oncethecamboltisconnectedinsidecamlock,takeacross-headscrewdriverand
tightenthecamlockbyturningclockwise.
You are now ready to assemble the product.

BROOKS 30” (76.2 CM) WHITE BATHROOM VANITY WITH REVERSIBLE DOORS10
STEP-BY-STEP GUIDE
7X110 X1AX6BX6CX6 6X19X1
STEP 1
Attachmiddlebackstretcher6to bottom panel 10usingM8x30mmwooddowelsC
andM4x25mmscrewsE.
Attachlowerbackstretcher7and bottom front stretcher 9to bottom panel 10
usingcamlocksA,camboltsBandM8x30mmwooddowelsC.
Note:Makesurecam bolts Bare completely seated.
EX2
10
6
97
10
C
A
C
B
E

BROOKS 30” (76.2 CM) WHITE BATHROOM VANITY WITH REVERSIBLE DOORS 11
STEP-BY-STEP GUIDE
4X15X18X1 3X1AX12 BX12 CX14
DX4MX1
3
4
5
8
10
C
D
A
B
STEP 2
Attach upperbackstretcher5,upper front stretcher 8and bottom panel assembly to
side panel left 3and side panel right 4using camlocksA,cambolts B,M8x30mm
wood dowels Cand 1/4”x32mmboltsD.
Note:Makesure cam bolts Bare completely seated.

BROOKS 30” (76.2 CM) WHITE BATHROOM VANITY WITH REVERSIBLE DOORS12
STEP-BY-STEP GUIDE
HX20 11 X1LX4
H
L
4
11
STEP 3
Attachbackpanel11tothebackofthevanityassembly usingM3.5x15mmscrewsH.
Attach levellers Lto the bottom of the vanity assembly.

BROOKS 30” (76.2 CM) WHITE BATHROOM VANITY WITH REVERSIBLE DOORS 13
STEP-BY-STEP GUIDE
KX4 12 X1
3
12
K
I
STEP 4
Insert shelf supports Kinto the desired holes in the sides of the vanity assembly.
Makesureyouplacetheshelfsupportsatthesamelevelsotheshelfisnottilted.
Tiltandrestadjustableshelf12 onto shelf supports K.
IX4

BROOKS 30” (76.2 CM) WHITE BATHROOM VANITY WITH REVERSIBLE DOORS14
STEP-BY-STEP GUIDE
14 X1 13 X1
G
F
J
3
STEP 5
GX24
Attach slow close hinges Jto left door 13 and right door 14 usingM4x12mmscrewsG.
Remove preassembled bolts from handle F. Attach door handle F onto left door 13 and
right door 14,securingwithpreviouslyremovedbolts.
Attach the hinge bases of left door 13 and right door 14 tovanityassemblywithM4x12
mm screws Gusing the pilot holes as a guide.
Openandclosethedoorstomakesuretheyarealignedandshutcorrectly.Ifnecessary,
adjustthescrewsforagoodt.
Thisvanityincludesachoiceoftwodierenthandlenishes(goldandbrushednickel).
JX4 FX2

BROOKS 30” (76.2 CM) WHITE BATHROOM VANITY WITH REVERSIBLE DOORS 15
STEP-BY-STEP GUIDE
STEP 6
The door panels are reversible.
The doors of this unit are shipped with the pattern facing the front of the unit.
Youcankeepthedoorsastheyare,orreversethepanelinsertsothattheatpanel
isforward,dependingonthedesiredconguration.

BROOKS 30” (76.2 CM) WHITE BATHROOM VANITY WITH REVERSIBLE DOORS16
STEP-BY-STEP GUIDE
OX2PX2
Determinewherevanityistobeplacedandmarklocationonthewallforthe
mounting.
Drill a 3/8” hole in the wall. Press the plastic anchor Pinto the hole and gently tap
untiltheangeoftheanchorisagainstthewallsurface.
AttachVanitytothewallusingM4x50mmscrewsO.
3
O
P
STEP 7

BROOKS 30” (76.2 CM) WHITE BATHROOM VANITY WITH REVERSIBLE DOORS 17
STEP-BY-STEP GUIDE
2X1
2
Silicone (NOT Provided)
3
STEP 8
Apply silicone around the top edges of vanity assembly to secure the vanity top 2.

BROOKS 30” (76.2 CM) WHITE BATHROOM VANITY WITH REVERSIBLE DOORS18
STEP-BY-STEP GUIDE
1X1
STEP 9
1
Silicone (NOT Provided)
3
Applysiliconealongthebottomedgeofbacksplash1and attach it to the vanity
assembly.

BROOKS 30” (76.2 CM) WHITE BATHROOM VANITY WITH REVERSIBLE DOORS 19
TECHNICAL DATA
SPECIFICATIONS
ASSEMBLED DIMENSIONS (W x D x H) 30x20x341/2”
 76.2x50.8x87.6cm
ASSEMBLED WEIGHT 108 lb
 49kg
MAXIMUM WEIGHT CAPACITY 200 lb
 90.7kg
30”
76.2 cm
38 7/16”
97.6 cm
34 1/2”
87.6 cm
20”
50.8 cm

BROOKS 30” (76.2 CM) WHITE BATHROOM VANITY WITH REVERSIBLE DOORS20
CARING FOR YOUR ITEM
ASSEMBLY TROUBLESHOOTING
PRODUCT TROUBLESHOOTING
CALL US;
WE CAN HELP
BEFORE RETURNING
YOUR PRODUCT Ifyouhavequestionsregardingyourproductorrequire
warrantyassistance,pleasecallourcustomerservicehelpline.
TOLL-FREE:
1-888-670-6684
HAVING TROUBLE?
LET US HELP YOU!
1Rinsevanitytopwithclean,hotwaterfrequently.
2Blotspillsquickly,andwashwithmildsoapandwarmwater.
3Checkallnutsandboltsperiodicallyfortightness.Whenrequired,tightenthemagain.
PROBLEM POSSIBLE CAUSES SOLUTION
Vanity doors rub against
another surface.
There is an uneven gap
between the doors and
cabinet.
Adjusttheleglevellers
to ensure the vanity
combo is level.
Adjusttheleglevellers
to ensure the vanity
combo is level.
Theoorisnotlevel.
Theoorisnotlevel.
