Canvas CRESTON 063-6338-2 User manual

ASSEMBLY INSTRUCTIONS
HAVING TROUBLE?
TOLL-FREE:
1-888-670-6684
IMPORTANT: Please read this manual carefully
before beginning assembly of this product.
Keep this manual for future reference.
CRESTON
23 5/8” (60 CM) BATHROOM
VANITY
PRODUCT NO. 063-6338-2-WHITE
063-6345-4-ESPRESSO
063-6339-0-GREY

We believe in the power of décor and its
ability to make up the fabric of your home.
That’s why CANVAS® collections draw
inspiration from Canadians and the way
they live.
From on-trend furniture pieces to holiday
décor and all your outdoor living essentials,
CANVAS® makes it easy to refresh your space
to reflect your unique style and the way you
live every day.
We would love to hear from you and welcome
your thoughtful feedback. Visit our website
at canadiantire.ca to tell us about your
experience, and share your photos with us
using #myCANVASstyle.
Show us how you bring CANVAS® products
to life. We can’t wait to see!

Parts List 4
Before You Begin Assembly 7
Step-by-step Guide 9
Technical Data 15
Troubleshooting 16
Caring for Your Item 16
Warranty 17
TABLE OF CONTENTS
TOOLS REQUIRED
No. 2 Cross-head Screwdriver
Tip Shown Actual Size
NOTE: Do not over-drill/
be aware of over-drilling
• Please read and understand this entire manual before attempting to assemble,
operate, or install the product.
• Any assembly or maintenance of the product must be carried out by adults only.
• Some parts may contain sharp edges. Wear protective gloves if necessary.
• To prevent damage, place all parts on a level surface during assembly. Add a
layer of protective surface if needed.
• Do not allow your children to climb or jump on furniture due to possible
accident, injury or death. A child climbing on a piece of furniture can make it
top-heavy and cause the furniture to tip over.
• Keep children and pets away during assembly.
• Repairing and replacing parts should be done by a qualified technician.
• This unit is intended for use only within the maximum weight indicated. Use
with loads heavier than the maximum weight indicated may result in instability
causing possible injury.
• Failure to follow these warnings could result in serious injury.
WARNING! TO REDUCE THE RISK OF SERIOUS INJURY,
READ THE FOLLOWING SAFETY INSTRUCTIONS BEFORE
ASSEMBLING AND USING THE PRODUCT.
2 People

CRESTON 23 5/8” (60 CM) BATHROOM VANITY4
PARTS LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
7Upper Front Stretcher 1
8Bottom Panel 1
9Door 1
1Vanity Top 1
2Back Panel 1
3Side Panel Left 1
4Side Panel Right 1
5Upper Back Stretcher 1
6Lower Back Stretcher 1

CRESTON 23 5/8” (60 CM) BATHROOM VANITY 5
EXPLODED PARTS
1
3
2
4
5
6
8
7
9

CRESTON 23 5/8” (60 CM) BATHROOM VANITY6
HARDWARE LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
ACam Lock 14
BCam Bolt 14
GM3.5x15 mm Screw 16
HLeveller 4
CM8x30 mm Wood Dowel 14
DHandle with Bolts 1
ESlow Close Hinge 2
FM4x12 mm Screw 12
ITouch-up Pen 1
JGlue 1
(not included for Items
#063-6338-2—WHITE & #063-6339-0—GREY)

CRESTON 23 5/8” (60 CM) BATHROOM VANITY 7
BEFORE YOU BEGIN ASSEMBLY
MAKE SURE ALL PARTS ARE PRESENT
Compare all pieces to the parts and hardware lists, and
make sure you have all tools required for assembly.
REMOVE PACKAGING MATERIALS
Place packing materials back in the box. Do not dispose of
packaging materials until assembly is complete.
READ EACH STEP CAREFULLY
Make sure you understand each step. If you have any questions,
contact CANVAS®customer service at 1-888-670-6684 (toll free).
ASSEMBLE IN A CLEARED AREA
Place all parts from the box on the floor in front of you on a clean,
dry, level surface to protect the product as it is being built.

CRESTON 23 5/8” (60 CM) BATHROOM VANITY8
BEFORE YOU BEGIN ASSEMBLY
CAM LOCK SYSTEM OPERATION
NOTE: IT IS VERY IMPORTANT TO USE GLUE WITH DOWELS. EXCESS GLUE CAN
BE WIPED OFF WITH DAMP CLOTH.
Insert dowel at least half way by tapping lightly with a rubber mallet IF NECESSARY.
GLUE
X
X
1 4
3
2
HOW THE KNOCK DOWN (KD) ASSEMBLY SYSTEM WORKS
1. Screw cam bolt into the pre-drilled small holes on panel. Align the panels to be joined
so that the cam bolt goes into the pre-drilled hole on the edge of the second panel and
protrudes into the hole that will house the cam lock.
2. Insert the cam lock into pre-drilled large hole on panel. Make sure arrow on the cam
lock is pointed toward the cam bolt.
3. Once the cam bolt is connected inside cam lock, take a cross-head screwdriver and
tighten the cam lock by turning clockwise.
You are now ready to assemble the product.

CRESTON 23 5/8” (60 CM) BATHROOM VANITY 9
STEP-BY-STEP GUIDE
4X1BX14 HX4 3X18X1
3
8
4
H
B
B
Securely screw cam bolts Binto the designated small holes on the side panel left 3,
side panel right 4and bottom panel 8using a cross-head screwdriver.
Attach levellers Hto the base of the vanity assembly.
Note: Make sure cam bolts B are completely seated.
STEP 1

CRESTON 23 5/8” (60 CM) BATHROOM VANITY10
STEP-BY-STEP GUIDE
4X17X1AX14 3X15X1
C
4
3
8
6
8
5
7
A
C
A
Attach lower back stretcher 6to bottom panel 8using cam locks Aand M8x30 mm
wood dowels C.
Attach upper back stretcher 5, upper front stretcher 7and bottom panel assembly
to side panel left 3and side panel right 4using cam locks Aand M8X30mm wood
dowels C.
CX14 6X1
STEP 2

CRESTON 23 5/8” (60 CM) BATHROOM VANITY 11
STEP-BY-STEP GUIDE
GX16 2X1
Attach back panel 2to the back of the vanity assembly using M3.5x15 mm screws G.
4
2
G
STEP 3

CRESTON 23 5/8” (60 CM) BATHROOM VANITY12
STEP-BY-STEP GUIDE
9X1
9
3
9
E
FE
F
Attach slow close hinge Eto door 9 using M4x12mm screws F.
Remove preassembled bolts from handle D. Attach door handle D to door 9,
securing with previously removed bolts.
Attach the hinge bases on door 9to vanity assembly with M4x12 mm screws Fusing
the pilot holes as a guide.
Open and close the doors to make sure they are aligned and shut correctly. If
necessary, adjust the screws for a good fit.
D
STEP 4
EX2FX12 DX1

CRESTON 23 5/8” (60 CM) BATHROOM VANITY 13
STEP-BY-STEP GUIDE
3
STEP 5
Suggested way to attach vanity to wall.
(Hardware NOT provided.)

CRESTON 23 5/8” (60 CM) BATHROOM VANITY14
STEP-BY-STEP GUIDE
1X1
1
Silicone (NOT Provided)
3
STEP 6
Apply silicone around the top edge of vanity assembly to secure the vanity top 1.

CRESTON 23 5/8” (60 CM) BATHROOM VANITY 15
TECHNICAL DATA
SPECIFICATIONS
23 5/8 ”
60 cm 19 ”
48.2 cm
34 3/4 ”
88.2 cm
ASSEMBLED DIMENSIONS (W x D x H) 23 5/8 x 19 x 34 3/4 ”
60 x 48.2 x 88.2 cm
ASSEMBLED WEIGHT 69 lb 7 oz
31.5 kg
MAXIMUM WEIGHT CAPACITY 100 lb
45.4 kg

CRESTON 23 5/8” (60 CM) BATHROOM VANITY16
CARING FOR YOUR ITEM
ASSEMBLY TROUBLESHOOTING
PRODUCT TROUBLESHOOTING
CALL US;
WE CAN HELP
BEFORE RETURNING
YOUR PRODUCT If you have questions regarding your product or require
warranty assistance, please call our customer service helpline.
TOLL-FREE:
1-888-670-6684
HAVING TROUBLE?
LET US HELP YOU!
1Rinse vanity top with clean, hot water frequently.
2Blot spills quickly, and wash with mild soap and warm water.
3Check all nuts and bolts periodically for tightness. When required, tighten them again.
4Tips for using touch-up pen (I): For scratches, stroke in direction of scratch; for worn areas,
stroke in direction of wood grain. Remove excess colourant promptly with a soft cloth.
PROBLEM POSSIBLE CAUSES SOLUTION
Vanity doors rub against
another surface.
There is an uneven gap
between the doors and
cabinet.
Adjust the leg levellers
to ensure the vanity
combo is level.
Adjust the leg levellers
to ensure the vanity
combo is level.
The floor is not level.
The floor is not level.

CRESTON 23 5/8” (60 CM) BATHROOM VANITY 17
WARRANTY INFORMATION
This CANVAS®product carries a one (1) year warranty against defects in workmanship and
materials. Trileaf Distribution agrees to replace the defective product free of charge within the
stated warranty period, when returned by the original purchaser with proof of purchase. This
product is not guaranteed against wear or breakage due to misuse and/or abuse.
Made in Vietnam
Imported by Trileaf Distribution Trifeuil Toronto, Canada M4S 2B8
PRODUCT NO. 063-6338-2-WHITE
063-6345-4-ESPRESSO
063-6339-0-GREY
