Capcom CPS1 User manual

!
!
1!
!
!
!
CPS1!KICK!HARNESS!
!
Spare!parts!
Connector!
H10P-SHF-AA!-!10!Pin!Female!connector!
aka!JST-NH!10!Female!connector!
Pins!
SHF-001T-0.8BS!Female!
aka!!JST!NH!PIN!Female!
Wire!!
22!AWG!as!per!JST!recommendation!
!
Pinout!for!6!buttons!games!!
!
Wire!colors!
Pin!number!
Connections!
Black!
1!
GND!
Black!
2!
GND!
Purple!
3!
Player!1!button!4!
Gray!
4!
Player!1!button!5!
White!
5!
Player!1!button!6!
!
6!
NC!
Orange!
7!
Player!2!button!4!
Green!
8!
Player!2!button!5!
Blue!
9!
Player!2!button!6!
!
10!
NC!
!
Pinout!for!3/4!player!games!!
!
Wire!colors!
Pin!number!
Connections!
Black!
1!
GND!
Black!
2!
GND!
!
3!
Right!
!
4!
Left!
!
5!
Down!
!
6!
Up!
!
7!
Button!1!
!
8!
Button!2!
!
9!
Coin!
!
10!
Start!
!
Pictures!
!
H10P-SHF-AA!
!
SHF-001T-0.8BS!
!
WIRE!22!AWG!
!
!
!
ALL!THESE!SPARE!PARTS!ARE!AVAILABLE!ON!GATENINETY.COM!

!
!
2!
!
!
CONNECT!6!BUTTONS!
!
Spare!parts!
Terminals!
12!*! 2.8mm!Crimp!Terminals!Female!Spade!Connector
Ground!
Use!Standard!Female!Terminals!
or!!Crimp!Closed!End!Connectors!
Enclosure!
Optionnal)
Quick!Disconnect!Sleeve!!
or!Quick!Disconnect!Enclosure!
!
How!to!connect!to!buttons!?!
!
Using!Ground!wire!in!the!same!connector!
!
!
Figure)a)
!
!
!
!
!
!
!
ALL!THESE!SPARE!PARTS!ARE!AVAILABLE!ON!GATENINETY.COM!

!
!
3!
!
!
Using!crimp!closed!end!connectors!!
!
!
Figure)b)
!
!
Pictures!
!
2.8mm!Crimp!Terminals!
Female!Spade!Connector!
!
Crimp!Closed!End!
Connectors!
!
Quick!Disconnect!
Enclosure!
!
Quick!Disconnect!
Sleeve!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
ALL!THESE!SPARE!PARTS!ARE!AVAILABLE!ON!GATENINETY.COM!

!
!
4!
!
!
!
CONNECT!3!OR!4!PLAYER!
!
Spare!parts!if!using!microswitches!with!4.8!terminals!
Terminals!
8!* 4.8mm!Crimp!Terminals!Female!Spade!Connector!
and!8!*! 2.8mm!Crimp!Terminals!Female!Spade!Connector
Ground!
Use!Standard!Female!Terminals!
or!!Crimp!Closed!End!Connectors!
Enclosure!
Optionnal)
2.8mm!Quick!Disconnect!Sleeve!/!2.8mm!Quick!
Disconnect!Enclosure!for!2.8mm!Crimp!Terminals!Female!
Spade!Connector!
and!4.8mm!Quick!Disconnect!Sleeve!for!4.8mm!Crimp!
Terminals!Female!Spade!Connector!
!
How!to!connect!the!buttons!and!joystick!?!
Using!Ground!wire!in!the!same!connector!
!
!
!
Figure)C)
!
!
ALL!THESE!SPARE!PARTS!ARE!AVAILABLE!ON!GATENINETY.COM!

!
!
5!
!
!
!
Using!crimp!closed!end!connectors!!
!
The)only)difference)with)«)figure)c)»)is)the)ground)wire)using)Crimp)Closed)End)Connectors)
instead)of)linking)them)via)the)female)terminals.)Please)refer)to)«)figure)b)»)for)the)
principle.)
!
Pictures!
!
2.8mm!Crimp!Terminals!
Female!Spade!Connector!
!
4.8mm!Crimp!Terminals!
Female!Spade!Connector!
!
Crimp!Closed!End!
Connectors!
!
4.8!Quick!
Disconnect!Sleeve!
!
!
!
!
2.8!Quick!Disconnect!
Enclosure!
!
2.8!Quick!Disconnect!Sleeve!
!
!
!
!
!
!
!
SANWA!/!SEIMITSU!
Are!you!using!the!5-pin!wire!harness!for!joytick!?!
!
In!this!case,!please!use!this!picture!as!reference!to!connect!the!joystick!wires!to!your!CPS1!connector!!!
!
Full)guide)available)to)build)your)own)5-wire)harness!
