Caple DDMEXT3 Manual

DDMEXT3‐Productupdate
1.) Takeoffthecover‐by
removing8M4X10screws
BECAREFULNOTTODAMAGETHE
COVER
.2)
ONLYREMOVETHESCREWS
SHOWN
Thenremovethe2M4X6screws
thatholdthemotor,asshownin
thepicture.
Youcandiscardthe2screwsthat
havebeenremoved

DDMEXT3‐Productupdate
3.) Placethesuppliedplate
asshowninthefigure,
thetwosmallerholesof
theplatehaveto
correspondwiththe
holesofthescrews
removedinstep2.
4.) UsingthesuppliedM4X10screws
andthewashersfixtheplateonto
thebody,asshowninfigure4

DDMEXT3‐Productupdate
5.) Usinga2.5mmdrillbit
make5holesonthebody
asshowninfigure5
6.) Byusingthesuppliedself
tappingscrewssecurely
fixtheplatetothe
appliance

DDMEXT3‐Productupdate
7.) Reassembletheapplianceby
attachingthecovertothebody
usingthescrewsremovedinstep
1

New product information sheet
Product name: Motor 3
Description: Extraction motor
Product code: DDMEXT3
Features
Motor for use with all Caple downdraft hoods and Ceiling hoods
For installation on outside wall
7m long connection cable
Aluminium die-cast construction
Performance
Max. extraction 1000m3/h
Max. noise level 64 dB(A)

Item Part Code Description Qty
13 75097200003 SEM2 WIRING BOARD (To Feb-11) 1
13 44001299998 SEM8 WIRING BOARD (From Feb-11) 1
16 75070999999 MOTOR GROUP EBM R2E250 1
18 77007399999 ACCESSORIES BAG SEM 2 1
19 90004200372 INSTRUCTION MANUAL DDMEXT2 DDMEXT3 DDMEXT4 1
20 42429999999 CABLE WITH CONNECTION MT.7 SEM2 (To Feb-11) 1
20 42439999999 7mt CABLE FOR SEM2 ECO-AO75 (From Feb-11) 1
27 42041999999 CAPACITOR 5MF 1
36 60060099999 METAL CONNECTING-PIECE EMB96359-2- 1
DDMEXT3 - Caple external wall motor
