Caple C896IBK Manual

C896IBK
Caple 78cm induction + gas
Technical information
Technical information

Item Part Code Description
1A10154-0 CONNECTION CABLE
2A10712-0 CONNECTION BOX
3A11070-0 CABLE 4 WIRES FOR INDUCT.
4A11166-0 CABLE 4 WIRES
5A20064-0 CABLES 2 WIRES
6A20184-0 DUAL SINGLE BURNER GAS VALVE
7A20186-0 PAN SUPPORT DUAL
8A20189-0 5 WIRES CABLE
9A20190-0 CABLES 4 WIRES
10 A20292-0 INGNITER 2 CHANNEL
11 A20299-0 BURNERSKIRT + SEAL DUAL
12 A20300-0 SPREADER + CAPS DUAL
13 A20817-0 INNER PIPE INDUGAS5ZV2
14 A20818-0 OUTER PIPE INDUGAS5ZV2
15 A20819-0 TOUCH CONTROL G5
C896IBK - Caple 78cm induction + gas
16
A
20988-0 GPU
17 A21660-0 DUAL BURNER
18 A23077-0 GLASS COVER
19 AECO1001 INDUCTOR 200P/160 NIPS

2/3
CONFIGURATION PROCEDURE
What to do when the symbol [ E 4 ] appears :
I) The hob must be reconfigured according to the following procedure:
Before you start the procedure:
- Make sure that there is no more pot on the hob.
- Use a pan adapted to induction.
- Disconnect the appliance from the electrical network by removing the fuse or turning
the circuit breaker off
- Reconnect the table to the electrical network.
- It is necessary to start the procedure within 2 minutes after the connection of the
hob to the electrical network.
- Do not press the [ 0/I ] key.
II) Enter induction Service Menu :
1) Press the key B and hold down.
2) With your other hand, press key A during 2s.
Release the key A.A short beep is done, after the
release the rear half of the led ring is illuminated
3) The slider has to be touched in one cycle,
in counterclockwise sense, starting on the right,
ending at the left (sliding from position 4 o’clock to 8 o’clock)
4) After this sequence the gas menu is entered, the key B can be release, the menu is
activated. If no further action is done, the menu is left after 2min
5) To reach the Induction service menu touch slider and key B.
III) Erasure of the existing configuration:
1) After entering in the induction service menu, the Key A has to be pressed and kept for
2 seconds to erase the current configuration
2) As soon as the timer key is pressed the 7 segment displays show a static [ E ]. When
the 2 seconds are past the timer key can be released and the displays begin to blink
with an [ E ]. This signs the erasing process. After the old settings are erased all
displays show a [ C ] and the hob has to be configured again
VI) How to reconfigure the hob ?
1) Take a ferromagnetic pot with a minimum diameter of 16 cm
2) Select a cooking zone by pushing on the corresponding [ C ] display
3) Place the pot on the area to be set
4) Wait until the [ C ] display becomes a [ - ]. The selected cooking zone is now
configured.
5) Follow the same procedure for each cooking zone with a [ C ] display.
6) All the cooking zones are configured once all the displays are turned off.
Please use the same pot for the whole procedure.
Never put several pots together on the zones during the setup-process.
If [ E 4 ] displaying remains, please call the customer care
FR
GB
DE

2/3
GAS TYPE CONFIGURATION PROCEDURE
To change the gas type :
I) The hob must be reconfigured according to the following procedure:
Before you start the procedure:
- Make sure that there is no more pot on the hob.
- Disconnect the appliance from the electrical network by removing the fuse or turning
the circuit breaker off
- Reconnect the table to the electrical network.
- It is necessary to start the procedure within 2 minutes after the connection of the
hob to the electrical network.
- Do not press the [ 0/I ] key.
-
II) Enter Service Menu :
1) Press the key B and hold down.
2) With your other hand, press key A during 2s.
Release the key A.A short beep is done, after the
release the rear half of the led ring is illuminated
3) The slider has to be touched in one cycle,
in counterclockwise sense, starting on the right,
ending at the left (sliding from position 4 o’clock to 8 o’clock)
4) After this sequence the gas menu is entered, the key B can be release, the menu is
activated. If no further action is done, the menu is left after 2min
5) Choose the correct gas configuration using the slider and validate it by press the key
A
FR
GB
DE
Configuration
GAS
C0
G30 / 28 MBAR
C0
G31 / 37 MBAR
C1
G20 / 20 MBAR
C2
G25 / 25 MBAR
C3
G30 / 30 MBAR
C4
G31 / 30 MBAR
C5
G31 / 50 MBAR
C6
G30 / 50 MBAR

D44850-0
INDUGAS
12/30 Créé le 26/02/16
Modifié le
ERROR CODE
Legend:
Visual Control
No appropriated measure
Measure with multimetre
Error Code
Provisional error code
Description
Potential Failure
Measure
What to do…
E blinking
No error!
IHE configurations
have been erased
You are in the configuration menu:
See description of the configuration
procedure
C
No error!
Cooking zone can be
Configured
You are in the configuration menu:
See description of the configuration
procedure
-
No error!
Cooking zone is
configured
You are in the configuration menu:
See description of the configuration
procedure
C blinking
No error!
Cooking zone can be
configured
You are in the configuration menu:
See description of the configuration
procedure
TC = Touch Control panel
Cable LIN = White Cable 0.25 mm2 (ex : connection between TC and Filter Board PCB).
IHE = Induction Heating Element
GPU = Gas power unit
FR
GB
DE

D44850-0
INDUGAS
13/30 Créé le 26/02/16
Modifié le
Error Code
Provisional error code
Description
Potential Failure
Measure
What to do…
E 2
Temperature sensor
indicates overheat of
induction coil
IHE over
temperature Wrong
algorithm calculated
over-temperature at
coil sensor PT-1000
(only for
cooking level 9)
Cooking zone has
overheated (maybe pot
boiled without food...)
A cool down is necessary Error is
disappearing when cooling down
Replace IHE with sensor if E2
reappears after complete cooling down
of cooktop.
E 3
Not adapted pan
or
Component failure
Some pans lose their
magnetic properties due
to a overheat of the
bottom
The pan generates
interferences which
disturb the functioning
of the induction.
Some bad pans may
destroy some electronic
components.
Employment of suitable pan
⇨Replace the pan
Replace IHE
E 4
IHE is not configured
Communication
failure between TC
and IHE
Component failure
Defective or missing Lin
Bus cable between CU
and IHE
Missing voltage
supplying of the IHE
Failure on the IHE
Configure again, with the manual
procedure
Check and/or change the Lin Bus
cable
Check the voltage of the IHE
Replace the IHE

D44850-0
INDUGAS
14/30 Créé le 26/02/16
Modifié le
Error Code
Provisional error code
Description
Potential Failure
Measure
What to do…
E 5
Communication
failure between TC
and IHE
Defective Lin Bus cable
Absence of power
supply
IHE not connected
Check the mains connection
Check and/or change Lin Bus cable
Replace the IHE
E 6
Network failure
Frequency problem
Overvoltage
Check the frequency and voltage
Replace the IHE
E 7
Unknown error
Compatibility problems
between IHE and TC
Replace IHE or TC
E 8
Fan failure
Fan or control
electronics defect
Replace IHE
E 9
Temperature probe
PT 1000
Temperature probe PT
1000 is defective
Replace IHE
E A
Hardware failure
Hardware failure
Replace IHE
E C
Configuration failure
2 cooking zones are
connected on the same
key
Configure again with the manual
procedure
E H
Fixed resistor
recognition
If there is no
temperature
change at the cook
place after
activation of cooktop
within 5
Induction cooktop has to cool down

D44850-0
INDUGAS
15/30 Créé le 26/02/16
Modifié le
Error Code
Provisional error code
Description
Potential Failure
Measure
What to do…
minutes, error display
shows
message “E H“
No display /
Function
Wrong connection
Error on Touch
Control
Defect mains
connection
Component part error
on TC
Component part error
on IHE
As soon as the hob is installed, please
check if it works properly. If you cannot
turn on the appliance, please double
check the electrical connections on
both sides of the power cord. A wrong
connection that lasts more than 30
minutes will cause permanent damage
that is not covered by the warranty.
Check the mains connection
replace TC
replace IHE
Review or replacement of Lin Bus
Cable
Incorrect pot
detection
Pan not adapted
Component failure on
IHE
Use an adapted pan
Replace IHE

D44850-0
INDUGAS
16/30 Créé le 26/02/16
Modifié le
Error Code
Provisional error code
Description
Potential Failure
Measure
What to do…
Cyclic bar
display
Er31
Er47
TC
Defective or missing Lin
Bus cable between CU
and IHE
TC failure
Reconfigure the TC
Review or replacement of Lin Bus
Cable
Replace TC
Er22
Key evaluation defect,
Touch
Control switches off
after 3,5-
7,5s.
Short circuit or
interruption
around key evaluation
Replace TC
Er 03 +
continuously
“sound”
Or symbol:
Continuous key
activation,
Control switches off
after 10s
Liquid or cookware on
glass
above control
Clean glass ceramics
Er 20
Flash error
Data not plausible
Programming options
wrong
Component part error
on Touch Control
replace Touch Control
Cooking
level back to
0
Power level returns
automatically to zero
Component part error
on
IHE
Replace IHE
GE00
E065, E107
Ignition relay failed
Relay driver defective
Replace GPU

D44850-0
INDUGAS
17/30 Créé le 26/02/16
Modifié le
Error Code
Provisional error code
Description
Potential Failure
Measure
What to do…
GE01
E078, E121
Coil resistance of the
main valve out of range
No power supply at
main valve
Short-circuited coil
Supply line broken,
driver circuit defective,
main valve coil
broken/disconnected
Check main valve connection
Measure coil resistance
Replace main valve
Replace GPU
GE02
E066
Gas supply broken
Thermocouple short-
circuited
No flame detection
during safety time
Flame present but not
recognized
Retry, gas tube may need some time
to fill after installation
Check gas supply (bottle or line)
Check main valve connection
Replace main valve
Replace thermocouples
Replace GPU
GE03
E175
When switching the
switched +12V, the
power supply breaks
down to zero before
switching the burner
and motor valves
Maybe reset of
controller
Voltage level 12V of
power supply is
permanently out of
range
Switched +12V voltage
supply failed:
1. Short-circuit of
unipolar stepper
motor driver
2. Short-circuit in the
switched +12V
circuit
3. Failure in the current
control circuit of
bipolar stepper
motor driver
Power supply failure
Check wiring for short circuits
Replace GPU
GE03
E174
When switching the
switched +5V, the
power supply breaks
down to zero before
Switched voltage +5V
voltage supply failed:
1. Short-circuit of
Check wiring for short circuits
Replace GPU

D44850-0
INDUGAS
18/30 Créé le 26/02/16
Modifié le
Error Code
Provisional error code
Description
Potential Failure
Measure
What to do…
switching the burner
and motor valves
Maybe reset of
controller
Voltage level 5V of
power supply is
permanently out of
range
stepper motor driver
2. Short-circuit in
switched +5V circuit
Power supply failure
GE03
E176
Voltage Level 5V and
12V of power supply is
permanently out of
range
Power supply failure
Replace GPU
GE03
E042, E047
Failure in release of
voltage in the controller
communication
Unexpected failure in
software sequence
Replace GPU
GE04
E076
Self-test of voltage
monitoring failed
Failure in under, or over
voltage, or power failure
detection
Replace GPU
GE07
E178
NTC sensor broken
or short circuited
Broken or short-
circuited
Replace GPU
GE08
E037,E041,E140
Overheated GPU
NTC switch off level
exceeded
Cool down the system
Replace GPU
GE09
E130,E132
Failure in flame
detection
Failure in flame
detection amplifier
circuit, or defective
multiplexer
Replace GPU

D44850-0
INDUGAS
19/30 Créé le 26/02/16
Modifié le
Error Code
Provisional error code
Description
Potential Failure
Measure
What to do…
GE10
E008
Controller flash
defective, checksum
not correct
Programming option
not correct
GPU
Replace GPU
GE10
E044
EEPROM checksum
not correct
GPU
Replace GPU
GE10
E045
EEPROM data not
plausible
GPU
Replace GPU
GE10
E009,E010
E018,E029
RAM defective
GPU
Replace GPU
GE10
E011, E012
E014, E015
E016, E017
Controller self-test
failed
GPU
Replace GPU
GE10
E186, E187
Timeout failure for
self-tests
GPU
Disconnet Powerline for at least 1 Min.
Restart system
Replace GPU
GE10
E116
Digital input defective
GPU
Check wiring for short circuit
Replace GPU
GE10
E020, E023
E033, E110
Processor
communication
permanently disturbed
GPU
Replace GPU
GE10
E026, E027
E030, E031
E032,E146
No start up possible
GPU
Replace GPU
GE10
E118
Internal EEPROM
defective
GPU
Replace GPU

D44850-0
INDUGAS
20/30 Créé le 26/02/16
Modifié le
Error Code
Provisional error code
Description
Potential Failure
Measure
What to do…
GE10
E001, E002, E005,
E006, E007, E034,
E035, E036,
E038, E039,
E048, E049,
E050, E051,
E052, E120,
E124, E127,
E129, E137,
E139, E143,
E147, E151,
E152, E153,
E154, E155,
E156, E157,
E158, E162,
E164, E186
Timeout failure
during software
sequence
Severe external
disturbance or
GPU,MCU1 defective
Disconnect powerline for at least 1
min.Restart systeme
Replace GPU
GE11
E046, E115
Lin communication
error
Lin disconnected or Lin
cable defective
UL/GPU defective
(if the Lin bus does not
work, the failure cannot
be displayed)
Check Lin connections
Check UL / GPU
Replace UL / GPU
GE56
E081, E122
Driver of burner
valve defective, no
voltage on terminals or
voltage on valve while
valve is turned off
Short-circuit of valve coil
Short-circuit on GPU,
driver defective
Check wiring for short circuits
Replace burner valve
Replace GPU
GE66
E082, E083
Thermocouple has
high resistance
Thermocouple not
connected, or cable
interrupted, or
thermocouple defective
Check connection to the thermocouple
Replace corresponding thermocouple

D44850-0
INDUGAS
21/30 Créé le 26/02/16
Modifié le
Error Code
Provisional error code
Description
Potential Failure
Measure
What to do…
GE71
E043, E064
E059, E173
Burner circuits
locked
GPU
Check wiring for short circuits
Check valve unit
Replace GPU
GE81
E187
All burner circuits
locked
GPU defective
Replace GPU

6/15
ADVICE & HELP / AFTER SALES INDUCTION
TC MULTI LITE SLIDER
1. To detect the wrong breakdowns :
1-1 Connection to the electric network:
Control the tightening of the screws of the connection box
Control the section of the cables used (see manual of use)
Control if the earth wire (green/yellow) is connected
1+2 = phase
4 = neutral
3 = no connection
earth = obligatory
alimentation cable: advised with fasten terminal wires (see photograph)
tightening of the screws: either with a cross screwdriver (PZ N°2 highly
advised), or with a punt screwdriver.
The checking of the connection and tightening has to be made before any
intervention on the hob.
A bad tightening can be at the origin of a breakdown
If a bridging is not made correctly or if a screw is badly tightened, there can be
the following symptoms:
- If the terminals 1 or 4 are wrong connected, the hob does not switch on
(no reaction) because the touch control is not supplied.
- If the terminal 2 is wrong connected, “E5” will appear on the right hand
side displays on the right side.
FR
GB
DE

7/15
1-2 Gas connection:
This cooktop must be installing and connect by a qualified technicians,
installation of equipment must be in line with the relevant national standard.
Ensure that the local distribution conditions (nature of the gas and gas pressure)
and the adjustment of the appliance (indicate on the rating label) are compatible.
The main gas inlet of the hob is a G ½ screw thread.
Check the leakproofness of all connection using a soap solution.
In case of no gas detection, check the gas inlet. At delivery, a plastic plug closes
the gas inlet.
1-2 Installation:
Control the installation of the gasket under the glass.
If the glass is glued with silicone leave the glass in place and dismount the
steel case under the work plan.
Control the ventilation of the air coming in of the ventilators (minimum 2 cm of
space).
1-3 Quality of the pans:
Control if the pan is compatible with the heating by induction.
To check by using a „magnet“ that must remain hung on the bottom of the
pan or by putting a little water in the bottom of the pan and while making this
water heat in position „9“water must boil quickly.
The functioning of an induction generates certain sonority. This one depends
on the pans used.
Use only pans with flat bottoms. Others risk damaging the hob.
BAD GOOD
FR
GB
DE

8/15
1-4 Pan dimensions for gas:
The pan must be adapted to the burner.
The use of a too large pot can affect the performance of the burner.
The use of a too small pot can cause an overheating of the pot and therefore
damage it. There is a risk of burns.
1-4 Use of the wok adapter:
The wok adapter must only be used on the standard pan support. Do not
use it directly on the burner.
Before putting the wok adapter on the pan support, make sure that the burner
and the pan support are cold. There is a risk of burns.
1-4 Use:
To start the hob it is necessary to keep the key [ 0/I ] pressed during 2 to 3
seconds.
During the first times of use, the cooking appliance will release a smell of
„new“.
