Caple WD140BK User manual

WD140BK
Caple Warming Drawer 140mm
Technical Manual

WD140BK
Caple Warming Drawer 140mm

WD140BK
Caple Warming Drawer 140mm
Item
Product
Code
Description
Additional Info
Quantity
1
2170500201
Top Cover 1
1
2
2170100101
Top Cover 2
1
3
1350600302
PVC Pad
1
4
1150600105
Drawer bottom assembly
1
5
2170500103
Fan cover
1
6
WD-26-A
Fan cover(Grille)
1
7
2170800201
Fixing plate for thermostat
1
8
1450700101
Thermal protector
1
9
1450100101
Heating element
1
10
1450500114
Power Cord
1
11
1421600101
Power box
1
12
2170900105
fan box
1
13
115020010101
Runners
1
14
2170400103
Side Panel-Left
1
15
1450600101
Fan
1
16
2170800101
Fixing plate for heating element
1
17
1450300101
Thermostat 75°C
1
18
2171200205
Control Panel
1
19
132010015101
Knob
1
20
1450200201
Button Switch
1
21
1150800101
push-pop device
1
22
2171600101
Bracket for push-pop device
1
23
1150900101
push-pop device buckle
1
24
2171600102
Bracket for push-pop device buckle
1
25
2170200102
Bottom plate
1
26
1350700101
Light guide
1
27
1350600201
Fixing for light guide
1
28
2171700101
Back door frame
1
29
WD-14-B-02-02I Glass panel component
Bottom fixing plate for drawer
1
30
Glass Panel
1
31
Aluminium Strip
1
32
Top fixing plate for drawer
1
34
2170400104
Side Panel-Right
1
35
2171100101
Top frame
1
