Caple CAFF19BK Manual

CAFF19BK
Caple Side by Side Fridge Freezer
Technical information
Technical information

Item Part Code Description Qty
10060820104C freezer foamed door 1
20060617121 handle fix part 2
30060214613 bracket of touch switch 1
40064000270 filler lip switch 1
50060600070 spring of filler bracket 1
60060103988 Press Pad Filler Bracket 1
70064082811 Screw 1
80060806082 ELECTROMAGNETISM VALVE 1
90060600097 Screw 3
10 0060205622 filler cover 1
11 00606040068 cover heater of filler mouth 1
12 0060300254 SPONGE TRAY OF FILLER 1
13 0060300256 SEAL RING OF LEAKING MOUTH 1
14 0064082811 Screw 1
15 0060214992 Switch plywood 1
CAFF19BK - Caple Side by Side Fridge Freezer
16 0064000361 Microswitch 1
17 0060818958 bracket of control board 1
18 0060600097 Screw 4
19 0064000156 Lamp 1
20 0060214369 freezer lampshade cover 1
21 0060301125 protection cover tray of filler 1
22 0060215421 cover of filler 1
23 0060819041 dispenser outsider bucket 1
24 0060818280 freezer top bottle seat assembly 3
25 0064001168A Display panel 1
26 0060808721B display panel 1
27 0064082855 Screw 1
28 0060215419 small water tray 1
29 0060215418 big water tray 1
30 0060163046 handle 1
31 0060219681 handle seat 2
32 0064098047 Self-screw 4
33 0064082803 Screw 4
34 0060163770 handle fix pad 2
35 0060820384 freezer foamed door seal,black,for CAFF19BK 1
36 0060818280 freezer top bottle seat assembly 1
37 0060823523 fridge foam door 1
38 0060617121 handle fix part 2
39 0060163046 handle 1
40 0060219681 handle seat 2
41 0064098047 Self-screw 4
42 0060163770 handle fix pad 2
43 0064082803 Screw 4

Item Part Code Description Qty
CAFF19BK - Caple Side by Side Fridge Freezer
44 0060820385 fridge door seal assembly,black,for CAFF19BK 1
45 0060818999 fridge top bottle seat assembly 1
46 0060207543 Egg Rack 1
47 0060818348 fridge center bottle seat assembly 3
48 0060818349 fridge bottom bottle seat assembly 1
50 0060818314 container right slide way assembly 1
51 0060600097 Screw 2
52 0060600097 Screw 2
53 0060818315 container right slide way assembly 1
54 0060219817 Rohs-right slide way for vegetable box 1
55 0060600097 Screw 2
56 0060600097 Screw 2
57 0060219580 Rohs-left slide way for vegetable box 1
58 0060821346 drawer assembly 1
59 0060818292 vegetable container 1
60 0060818319 vegetable box shelf 1
61 00606050061 switch door 2
62 0060214565 Refrigerator shelf I 3
63
0060600097
Screw
1
63
0060600097
Screw
1
64 0060214966 tanker cover 1
65 0060819042 cold water jug assembly 1
66 00609380509 Foot Adjustable 1
67 0060600251 Screw 3
68 0060818825A fridge bottom hinge,right 1
69 0060214964 Bottom hinge stopper 1
70 00608020034 Center girder screw 1
71 0060500124 sponge pad 1
72 00602160263 deodorization box fixing cover 1
73 0060600097 Screw 1
74 0060204651 Cover Sensor 1
75 0060215432 dryer fix slip 1
76 0060214630 Refrigerator top lampshade 1
77 0064000610 bulb(25W Blue) 1
78 0060600097 Screw 2
79 0060818127 refrigerator wind passage cover assembly 1
80 0060214734 front foamed of refrigerator wind passage 1
81 0060818126 refrigerator wind passage assembly 1
82 00609340017 Damper Air 1
83 0060161090 Fridge top hinge 1
84 0060600251 Screw 4
85 0060215505 fridge top hinge box right 1
86 0060600097 Screw 1
87 0060600097 Screw 1
88 0060215504 freezer top hinge box 1
89 0060600251 Screw 4
90 0060161089 Freezer top hinge 1
91 0060214964 Bottom hinge stopper 1
92
0060818824A
lfb hi bl
1
92
0060818824A
l
e
ft
b
o
tt
om
hi
nge assem
bly
1

Item Part Code Description Qty
CAFF19BK - Caple Side by Side Fridge Freezer
93 00609380509 Foot Adjustable 1
94 00608020034 Center girder screw 1
95 0060600251 Screw 3
96 0060818729 defrost waterspout assembly 1
97 0060215938B down decorating strip assembly 1
98 0060801032 Screw 1
99 00609380551 Top Drawer Left Slide Way Assembly 1
100 0060600097 Screw 8
101 00609380552 Top Drawer Right Slide Way Assembly 1
102 00609380553 Bottom Drawer Left Slide Way Assembly 1
103 00609380554 Bottom Drawer Right Slide Way Assembly 1
104 0060818590 Bottom Drawer Assembly 1
105 0060818589 Freezer drawer II 1
106 0060818005 Freezer shelf assembly I 1
107 0060818006 Freezer shelf assembly II 2
108 0060818587 bottom freezer air tower assembly 1
109 0060214369 freezer lampshade cover 1
110 0064000607 bulb(40W Blue) 1
111
0060214368
Freezer lampshade
1
111
0060214368
Freezer
lampshade
1
112 00608010087 Fixing Piece 2
113 0060161498 anti-heat and glisten patch 1
114 00604050121 Soft Gasket 2
115 00602160304 screw cover 2
116 0064098047 Self-screw 2
117 0060818586 top freezer air passage board assembly 1
118 0060818585 freezer air passage board assembly 1
119 0060215323 evaporator fix foam 2
120 0060703456 evaporator 1
121 0064001016 heater 1
122 0060207848 Blade Fan Fc 1
123 0064082811 Screw 2
124 0060207845 freezer fan motor cover 1
125 0060301218 Grommet Condenser Fan 1
126 0064000459 freeze fan 1
127 0060215338 Mount Fan Rear 1
128 0060214364 freezer fan motor bracket 1
129 0064000891J control PCB 1
130 0060206822 control box 1
131 0060600097 Screw 4
132 0060400387 power cable assembly 1
133 0060801032 Screw 6
134 0060109707 compressor cover 1
135 0060214385 fan motor cover 1
136 0060215338 Mount Fan Rear 1
137 0064000460 cooling fan 1
138 0060301218 Grommet Condenser Fan 1
139 0060214382 cooling fan bracket 1
140
0060208240
li f
1
140
0060208240
coo
li
ng
f
an vane
1

Item Part Code Description Qty
CAFF19BK - Caple Side by Side Fridge Freezer
141 0060702951 Condenser assembly 1
142 0060214381 Water Tray 1
143 00601480004 pivot 2
144 0060801032 Screw 4
145 0060213173 roller 2
146 0060702848 connection tube for suction 1
147 0060210199A Grommet Compressor Mounting 4
148 0060145577 Bushing Copper 4
149 0060803303 Bolt Compressor 4
150 0060732592 compressor,EGYS100HLP (R134a) 1
151 0060106659 Injection Tube 1
152 00606020090 Power Panel 1
153 0060703265A Dryer Filter 1
154 0060801032 Screw 7
155 0060215014 Strip Clamping Long 1
156 0060215015 seal strip II 1
157 0060818345 compressor bracket assembly 1
158 0064082808 Screw 2
159
0060161557
ice maker pipe fixup board
1
159
0060161557
ice
maker
pipe
fixup
board
1
160 0060214635 Elbow of enter water pipe 1
161 0064000967 enter water pipe of ice maker assembly 1
162 0060205753 water pipe fixup nip 5
163 0060801032 Screw 5
164 0060205757 enter water pipe 1
165 0060214899 Jug Water Inlet Sleeve 1
166 0060212618 ice box slideway 1
167 0060600097 Screw 4
168 0060212618 ice box slideway 1
169 0060818598A Ice box 1
170 0060801032 Screw 1
171 0060806084 Water Valve 1
172 0060400035 Harness Inlet Valve 1
173 0060205614 Bracket Auger Motor 4
174 0060600097 Screw 8
175 0060600097 Screw 4
176 0060600077 Drive Auger Motor 1
177 0060600078 Locknut Auger Drive 1
178 0060214386 ice-crushed box 1
179 0064000955 ice box motor 1
180 0060205637 slide seat 1
181 0060205638 slide block 1
182 0060600075 spring column pin 1
183 0060205640 connecting gulide 1
184 0060205639 connecting cover 1
185 0060600074 compressed spring 1
186 0060600076 spring column pin 1
187 0060300257 CLIMINATING NOISE FOAM BLOCK 1
188
0060806081
lil
1
188
0060806081
e
l
ec
t
romagne
ti
sm va
l
ve
1

Item Part Code Description Qty
CAFF19BK - Caple Side by Side Fridge Freezer
189 0060204650 ice box 1
190 0060600097 Screw 1
191 0060219237 Arm Bail 1
192 0064001224 Icemaker Assy 1
193 0060600097 Screw 4
194 0060205021 Nut Fixing Ice Box 2
195 0060214376 ice-maker supporter 1
196 0060214377 ice store box 1
197 0060300270 ICE BOX SEAL RING 1
198 0060205623 Cover Push Shaft 1
199 0060161361 ice push screw 1
200 0060600067 Spring Crusher 1
201 0060103727 Bracket Dial Pole 1
202 0064082811 Screw 1
203 0060103725 Pad Link Arm 1
204 0060161948 Dial pole of push tongue 1
205 0060205605 Wheel Link Arm 1
206 0060802009 Screw 2
207
0060161303
ice
-
crushed clapboard
1
207
0060161303
ice crushed
clapboard
1
208 0060103724 Plate Cutter 1
209 0060205607 Bush Cutter Plate 1
210 0060103721 Plate Cutter Short 1
211 0060205609 Spacer Cutter Plate 1
212 0060205608 Washer Cutter Plate 1
213 0060103723 Plate Cutter Medium 1
214 0060205607 Bush Cutter Plate 1
215 0060103720 Plate Cutter 90 Degree 1
216 0060205608 Washer Cutter Plate 1
217 0060600082 Pin Spring Column 1
218 0060103722 Plate Cutter 1
219 0060205604 Cap Link Arm Screw 1
220 0060600072 Spring Crusher Door Flap 1
221 0060205606 Flap Door Ice Crusher 1
222 0060205616 Housing Ice Crusher 1
223 0060600083 Pin Door Flap Ice Crusher 1
224 0060802009 Screw 3
225 0060600069 Washer Ice Crusher 1
226 0060600071 Circlip Ice Crusher 1
227 0060214378A front lid of ice box 1

CAUTION
READ THIS MANUAL CAREFULLY T
O
DIAGNOSE TROUBLE CORRECTLY
BEFORE OFFERING SERVICE.
Refrigerator
SERVICE MANUAL
MODEL : CAFF19SI
1. Spacecraft insulation technology
2. Digital temperature with VEDA display
3. full-out fridge tray
4. Ica and water dispenser
5. Super freezing
6. Direct current variable-frequency
7. Direct current variable-frequency blower fan
8. Deluxe bar , ice machine
9. Cold drink outside access design
10. Deluxe deep bottle holder
11. Detachable door seal
Features:
1 of 48

1. This manual is NOT intended as a comprehensive repair/maintenance
g
uide to the appliances.
2. it should ONLY be used b
y
suitabl
y
qualified persons havin
g
the
technical competence, applicable product knowledge and suitable
tools and test equipment
3. Servicing of electrical appliances must be undertaken with the
appliance disconnected (unplugged) from the electrical supply
4. Servicing must be preceded by Earth Continuity and Insulation
Resistance checks.
5. Personal safety precautions MUST be taken to protect against
accidents caused by sharp edges on metal and plastic parts
6. After servicing the appliance must be rechecked for Electrical Safety.
7. Checks must be made for leaks from seals, gaskets and pipe work,
and rectification carried out where necessary
8. Whilst the company has endeavoured to ensure the accuracy of the
data within this publication, the
y
cannot hold themselves responsible
for any inconvenience or loss occasioned by any error within.
2 of 48

1 INTRODUCTION
2 SPECIFICATION
3 DOOR ADJUSTMENT
4 CONTROL PANEL FUNCTIONS
5 TEST PROCEDURES
6 SELF DIAGNOSIS
7 WIRING DIAGRAM
8 PCB DIAGRAM
9 PARTS LIST/DIAGRAM
10 USER GUIDE
11 PRODUCT TECHNICAL SUPPORT CONTACTS
CAFF19SI REFRIGERATOR
CONTENTS
3 of 48

CAFF19SI FRIDGE FREEZER
Introduction
The Caple CAFF19SI is an American side by side refrigerator. The
system uses a cold blown air system. The system has only one
evaporator situated in the freezer. A fan distributes the cold air around
the freezer. In the top of the freezer is a damper that opens into the
fridge cabinet. The cold air is blown in to the fridge cabinet by the
freezer fan. When the fridge temperature is reached the damper closes,
stopping the cold air entering the fridge.
FREEZER STORAGE
1 ICE MAKER
3 GLASS SHELVES
2 STORAGE DRAWERS
4 DOOR STORAGE SHELVES
FRIDGE STORAGE
4 GLASS SHELVES
2 SALAD DRAWERS
6 DOOR STORAGE SHELVES
1 WATER TANK
4 of 48

5 of 48

MODEL CAFF19SI
PART 1. Specifications
Unit Dimensions
WDH (mm X mm X mm)
Box Dimensions
WDH (mm X mm X mm)
Specifications are subject to change without prior notification.
Unit Weight (Kg)
Power Consumption (Kw.h/year)
Cavity Supply (V/Hz) 220~240/50
156
36
Model CAFF19SI
537
770 * 890 * 1768
138
960 * 770* 1894
Container Quantity (40' Hc)
Box Weight (Kg)
6 of 48

PART 2. Refrigeration Principle
2.1 Schematic Diagram of Refrigerating Principle
1 Compressor
2 Condenser
3 Dry Filter
4 Capillary Tube
5 Evaporator
6 Air Fan
2.2 Brief Description of Refrigerating Principle
For the forced air cooling single-system refrigerator, there is only
a finned evaporator mounted generally at the rear of its freezer
compartment. Refrigeration of both its refrigerator compartment and
freezer compartment is achieved by this evaporator and cooled air is
sent to its refrigerator and freezer compartments via air ducts. The
temperature inside its freezer compartment is regulated with the freezer
thermostat, whereas the temperature in its refrigerator compartment
is controlled by regulating the throttle, or alternatively, using a
refrigerator to control the start and stop of compressor, and matching
the evaporator to control the freezer temperature.
7 of 48

Choosing the right location
This appliance should be installed in a room,
which is dry and well ventilated.
In order to ensure adequate ventilation, the
appliance should be at least 1,5cm clear on all
sides from cabinetry, and any units placed above
the appliance must be clear by 1.5cm - allowing
adequate ventilation for the appliance.
see clearance diagram
if located close to a corner adequate spacing
must be left for door opening and removal of
shelves. Refer to diagram
The appliance should be 10cm at least from any
electric or gas cooker and 30cm from any coal
or oil stove. If it is not possible, ensure that
appropriate insulation is used.
Avoid exposing the appliance to direct sunlight,
and sources of heat (radiators, heaters, cookers etc)
if the appliance is situated in a cold environment
(shed, out house, garage etc.) it will affect its
performance. You may find that the performance
of the appliance is not consistent and this may
damage foods. Please ensure that the ambient
temperature does not drop below that specified
by the climate class and that temperature are
maintained as consistently as possible.
Connection to the electricity supply
Connect the appliance to the electrical supply
(220-240V ~ 50Hz) with the plug and lead, which
are fitted. Connections to the mains supply should
be in accordance with local regulations.
NB! This appliance will operate within a range of
187 - 253 V. Operation outside this range may
result in damage to the control panel, thermostat
or compressor, unless a regulator with a capacity
of 750W, or higher is installed.
The appliance must be plugged into an earthed socket.
Always make sure that the plug is accessible
after the appliance has been positioned.
Positioning Your Appliance
This appliance
must be earthed
!
8 of 48
