Impressa F7/F8 Quick Reference Guide
This Guide does not replace the Operating Instructions.
For details and cautions you must read all instructions.
Traces of Coffee Grounds in New Machine?
This is normal! Grinder was tested during assembly with beans.
Despite cleaning, traces of ground coffee may be found.
RED TEXT represents information in the display.
A) First Time Ever Preparation
Place machine on a flat, hardsurface.
1. Fill water in tank and beans in bean container.
2. DO NOT install the Water Filter Cartridge now!
3. Push ON/OFF button. OPEN TAP.Place a cup under-
neath the frother and turnthe SELECTOR to the water
symbol. SYSTEM FILLING.Water pumps through the
frother into the cup and stops automatically.CLOSE TAP.
Turn the SELECTOR to the Cup Symbol. SYSTEM FILLING.
HEATING.After two minutes PRESS RINSE.
4. Place a cup underneath the coffee spout and push the
RINSE button. READY.Place a large cup underneath the
coffee spout and press the 1-CUP button. The F7/F8
starts grinding and brews coffee. Discard the first two
cups. READY. You can only brew coffee when the display
shows READY.
B) Daily Preparation
• Fill fresh water in tank and check bean container.
• Push ON/OFF button: HEATING.RINSE.
•Place a cup under the coffee spouts and press the RINSE
button. READY.
READY
SELECTOR
(enlarged view)
a. Coffee
b.Steam / Hot Water
On/Off P Button 1-Cup 2-Cup Rinse Steam
DIAL
SELECTOR
Dual Frother PLUS
a
b
Impressa F7/F8
Control Panel
Dual Coffee
Dispenser Nozzels
Frother
sleeve
(slides up
and down)
mild
normal
strong

C) Factory Settings / Programming Functions
D) Grinding and Brewing
• Push the DIAL.Display shows the cup size, e.g. 4.0 OZ.
• Turn the DIAL to change the cup size from 1.0 to 8.0 OZ.
• Push the 1-CUP button once: MILD,twice NORMAL,
three times STRONG.
• When pushing the 2-CUP button, the machine will brew
twice as much coffee as set with the 1-CUP button.
HOTTER COFFEE? Pre-warm cup with hot water through
frother. See chapter F "Using Hot Water". Empty cup and
brew coffee.
E) Changing the Grinder Fineness
Important: You can only adjust the fineness during the actual
grinding process.
• Open the bean container lid and turn the dial while grinding:
thicker bars: coarser grind; thinner bars: finer grind.
• For darker,oily beans – grind somewhat coarser.
For lighter beans – grind somewhat finer.
F) Using Hot Water
• Place a cup underneath the frother. Turn the SELECTOR
to the water symbol, e.g. 5OZ.
•Turn the DIAL to select the desired amount of water from
1to 16 oz.. WATER.CLOSE TAP.Turn the SELECTOR to
the Coffee Symbol. You can always stop the hot water
flow before the display shows CLOSE TAP.
G) Using Steam (Frothing and Steaming)
Important: frother parts must be tightly connected and clean.
•Cappuccino:One shot espresso plus ~ 4 oz. of steamed
and frothed milk. Metal frother sleeve DOWN
•Latte: One shot espresso plus ~ 4 to 5 oz. of steamed
milk. Metal frother sleeve UP: steaming only (no frothing)
1. Push the STEAM button. HEATING.After ~ 20 sec.:
STEAM READY.
2. Immerse the frother into a pitcher with milk and turn the
SELECTOR to the water symbol, e.g. 40 SEC. Turn the
DIAL to select to desired steaming time (3 to 120 sec).
STEAM.Steam pushes into the milk.
3. CLOSE TAP.Turn the SELECTOR to the Cup Symbol.
You can always stop the steam output with the SELECTOR.
4. For additional steam repeat steps 1 through 3.
5. After steaming you can immediately brew coffee.
Knocking Noise during Frothing: The pumps dispenses
water droplets into the heating system.
Please note: Skim and 1% milk will produce more froth
than 2% and regular milk.
Filter: –
Hardness: Level 2
Aroma: ROBUST
Temperature: HIGH
Time: Not Set
Unit On: Not Set
Off Aft Hrs: 2 HRS
Cups Made:
Language: English
Display: OZ. and AM/PM

HOTTER MILK? After frothing the milk, use the steaming
position (Frother sleeve UP) to increase the milk temperature.
H) Cleaning the Frother
Within 10 min. after last use, place a cup under the frother.
Turn the SELECTOR for 5 sec. to the Hot Water symbol. For
thorough cleaning see page 15 of the Operating Instructions.
J) Programming
Push and hold the Pbutton until the display shows FILTER -.
Turn the DIAL to access the other functions: HARDNESS,
AROMA,TEMP.,TIME,UNIT ON,AUTO OFF,CUPS MADE,
LANGUAGE,DISPLAY.
Select the function, push the DIAL,turn DIAL to see or
select option. Push DIAL to confirm. Push Pbutton to get
back to READY.For details see Operating Instructions.
K) Installing and Activating the Clearyl Water Filter
1. Rinse cartridge under running water. Insert cartridge
into water tank reception and close the cartridge holder.
2. Fill tank with cold water. Push and hold the Pbutton:
FILTER -.Push the DIAL:NO -.Turn DIAL:YES ✔.
3. Push DIAL.INSERT / OPEN TAP.Place a container
(20 oz.) under the frother. Turn the SELECTOR to the
water symbol. FILTER RINSING.
4. After 90 sec.: CLOSE TAP. Turnthe SELECTOR to the
cup symbol. HEATING.READY.
The display will remind you when it’stime to replace the
cartridge. Please note: When the filter program is activated,
the decalcifying program (HARDNESS) is turned off.
Important: Do not let the filter dryout. Filter needs to be
submersed in water. See page 16, Operating Instructions.
L) Replacing and Activating the Clearyl Water Filter
When display shows CHANGE FILTER / READY
• Remove old filter, rinse new filter under running water and
insert(see above).
•Turn machine off. Push and hold the Rinse button until the
display shows CHG FILTER / OPEN TAP.
•Place a large container (20 oz.) under the frother and turn
the SELECTOR to the water symbol. FILTER RINSING.
•See Chapter K,4 above.
Important: If message CHANGE FILTER / READY does not
show up after 3 months, you must replace the filter.
M) Cleaning with Special Tablet
This cleaning cycle removes coffee oils inside the machine.
This message will appear after 200 cups of coffee:
CLEAN / READY.Takes less than 15 minutes!
Important: Only use the special white round cleaning tablet!
Important: Once started, do not interrupt the program!
1. Fill water tank. Push the RINSE button. EMPTY TRAY.
Please note: You must remove the drawer for
20 seconds even if it is empty. Replace complete drawer.

2. PRESS RINSE.Push the RINSE button. CLEANING.After
amoment the display shows ADD TABLET.
3. Open the ground coffee lid and drop one tablet into the
coffee funnel. Close lid. PRESS RINSE.Push the RINSE
button. CLEANING.After a few minutes: EMPTY TRAY.
Carefully lift, remove and empty drawer and replace.
READY.The machine resets itself and reminds you to
clean again after the next 200 cups.
N) Decalcifying DESCALE / READY
For different water hardness levels see Operating Instructions.
If a water hardness level is selected, the decalcifying monitor
is active. Decalcify when above message appears.
Important: If you use the Clearyl Filter and the above
message appears, then the Clearyl Installation procedure
was not performed properly.
Important: The decalcifying program must not be interrupted.
• Use only the special decalcifying tablets (not the cleaning
tablets!). For decalc tablet supply see next page.
1. Push the RINSE button; the display shows EMPTY TRAY.
2. Remove and empty drawer. You must remove the drawer
for 20 seconds, even if it is empty. Replace complete drawer.
Decalcifying Session:
3. SOLVENT IN TANK / OPEN TAP.Dissolve three large
squaretablets in 16 oz. of water, remove tank and pour
mixtureinto empty water tank and replace.
4. Place a container (at least 16 oz.) underneath frother.
Turn the SELECTOR to the water symbol. DECALC.ON.
After a few minutes: CLOSE TAP.Turn the SELECTOR to
the cup symbol. DECALC.ON.After a few minutes
EMPTY TRAY.
5. Carefully remove container and drawer, empty and replace.
Cleaning Session:
6. FILL WATER.Rinse water tank and fill with cold water
(16 oz.) and replace. Place a container under the frother.
7. OPEN TAP. Turn the SELECTOR to the water symbol.
DECALC.ON.After a few minutes: CLOSE TAP.Turn the
SELECTOR to the cup symbol. DECALC.ON.After a few
minutes EMPTY TRAY.Carefully remove container and
drawer, empty and replace.
8. HEATING.Then PRESS RINSE.Push the RINSE button.
The machine returns to READY and resets itself.
CAPRESSO CUSTOMER SERVICE 1-800-220-5701
M-F 9AM - 9PM; Sat. 9AM - 5PM EST
FAX: [phone] • email: [email protected]
O) Supplies can be ordered through:
Customer Service or Mail Order Form or www.capresso.com:
•Clearyl Water Filter Cartridge: #64553
•Special Cleaning Tablets: #62205
•Decalcifying Tablets: #61848
•Cappuccino Cleaner: #63801, removes milk fat from frother
•Grand Aroma Coffee Beans: #921, regular, decaf, espresso
