CapstanAG PinPoint II Installation instructions

APPLICATION SYSTEMS
FOR PROFESSIONALS™
www.capstanAG.com
How Can We Help?
855-628-7722
[e-mail]
P/N 122200-240 Rev. B | Revised 07/2017 | ©2016-2017 Capstan Ag Systems, Inc. All Rights Reserved.
PinPoint™ II
For
N-Ject™ NH3
Operator and Maintenance Manual

i ©2017 Capstan Ag Systems Inc. | PinPoint™ II for N-Ject™ NH3 Operator and Maintenance Manual
TM
Thank you for your business!
At CapstanAG, our goal is to redefine the way people do their chemical application. Our
PWM control systems have been setting the bar for maximum productivity for more than
20 years. Our focus on performance, support, and education have dramatically changed
the landscape of agricultural chemical application.
CapstanAG specializes in creating proprietary systems for the agricultural industry,
primarily focusing on chemical and fertilizer applications. Our inventive process involves
research, engineering, design, and lab and field testing.
Service Contact Information
If a problem occurs with your system that cannot be corrected with the information in this
manual, please contact your dealer for service and technical assistance. If further assis-
tance is needed, contact CapstanAG.
System Purchased: _____________________________________
Dealer: ______________________________________________
Contact: _____________________________________________
Phone: _______________________________________________
Address: _____________________________________________
City,State/Province, Zip: ________________________________
Factory Service/Repairs
CapstanAG
4225 S.W. Kirklawn Ave. | Topeka, KS 66609
Hours: 8:00 a.m. to 4:00 p.m. CST
Toll-free number: [phone] | Fax: [phone]
E-mail: [e-mail] | Online: www.CapstanAG.com
TM
All trademarks are owned by CapstanTM
Ag Systems Inc. All Rights Reserved
PinPointTM, SynchroTM, SharpShooterTM, N-JectTM
may be covered by one or more of U.S. Patent
For more information on patents, trademarks, and copyrights, visit www.BlendedPulse.com
© 2017 CapstanTM
Ag Systems Inc., All Rights Reserved

PinPoint™ II for N-Ject™ NH3 Operator and Maintenance Manual | ©2017 CapstanAg Systems Inc. ii
CONTENTS
TM
CONTENTS
SAFETY ................................................................................................................................................................. 1
Signal Words ...................................................................................................................................................... 1
Safety Signs ........................................................................................................................................................ 1
Pressurized Fluid Lines ...................................................................................................................................... 2
Personal Protective Equipment .......................................................................................................................... 2
Battery Safety ..................................................................................................................................................... 2
Chemical Safety .................................................................................................................................................. 2
Emergency Safety .............................................................................................................................................. 2
INTRODUCTION ................................................................................................................................................... 3
This Manual ........................................................................................................................................................ 3
System Identification ........................................................................................................................................... 3
OPERATION .......................................................................................................................................................... 5
CapView Button Descriptions ............................................................................................................................. 5
Start Up Procedure ............................................................................................................................................. 6
Shut Down Procedure ......................................................................................................................................... 6
Operate in Automatic Control (AUTO) Mode ...................................................................................................... 6
Nozzle Display .................................................................................................................................................... 7
Overlap Control ................................................................................................................................................... 8
Mapping .............................................................................................................................................................. 9
Download Maps ............................................................................................................................................ 9
Overlap Distance .............................................................................................................................................. 10
Change the Overlap Distance .................................................................................................................... 10
Flow Meter Signal ............................................................................................................................................. 10
Turn Compensation .......................................................................................................................................... 11
Counters ........................................................................................................................................................... 12
Gallon Counters ......................................................................................................................................... 12
Acre Counters ............................................................................................................................................ 12
Reset the Counters .................................................................................................................................... 12
Alarm ................................................................................................................................................................ 12
Vent and Drain the N-Ject™ System ................................................................................................................ 13
MAINTENANCE ................................................................................................................................................... 15
Service the System ........................................................................................................................................... 15
Clean the System ............................................................................................................................................. 15
Inspect the System ........................................................................................................................................... 15
Jump Start, Weld On, or Charge The Machine ................................................................................................. 15
Storage of the System ...................................................................................................................................... 15
Clean the Y-Strainer ......................................................................................................................................... 16
Clean the Inlet Strainer ..................................................................................................................................... 16
Nozzle Valves ................................................................................................................................................... 17
Clean the Nozzle Valve(s) .......................................................................................................................... 17
Inspect the Plunger Seal ............................................................................................................................ 18
TROUBLESHOOTING ......................................................................................................................................... 19
CapView System Error Chart ............................................................................................................................ 19
Over and Under Application .............................................................................................................................. 20
Rate Controller - Under Application ............................................................................................................ 22
Rate Controller - Over Application .................................................................................................................... 22
Rate Controller - Rate Instability ....................................................................................................................... 22
Liquid Level Sensor Alarm ................................................................................................................................ 23
Recommended Guidelines ............................................................................................................................... 24
Baseline Evaluation Process ............................................................................................................................ 24
Interchange the Components ........................................................................................................................... 24
Fuses ................................................................................................................................................................ 25
Coil Test ............................................................................................................................................................ 25
Circuit Breaker .................................................................................................................................................. 26
Check the battery Voltage ................................................................................................................................ 26
Check the System Load Capacity ..................................................................................................................... 27

CONTENTS
iii ©2017 CapstanAg Systems Inc. | PinPoint™ II for N-Ject™ NH3 Operator and Maintenance Manual
TM
Connector Pin Identification .............................................................................................................................. 27
Check the VCM Voltage ................................................................................................................................... 30
Check the Boom Shutoff Signal ........................................................................................................................ 30
Test the Pressure Sensor Signal ...................................................................................................................... 31
Check the Power to the Pressure Sensor Input ................................................................................................ 32
Liquid Level Sensor .......................................................................................................................................... 33
Test the Sensor Voltages ........................................................................................................................... 33
WARRANTY ........................................................................................................................................................ 35
SCHEMATICS ..................................................................................................................................................... 37
Manifold Schematics ......................................................................................................................................... 37
INSTALLATION AND SETUP .............................................................................................................................. 41
Install the N-Ject™ Manifold(s) ......................................................................................................................... 41
Install the Pressure Sensor ........................................................................................................................ 42
Install the N-Ject™ Manifold/Implement Plumbing ..................................................................................... 42
Splitter Installation (Optional) ..................................................................................................................... 43
Install the Gateway Hub .................................................................................................................................... 43
Install The VCMs .............................................................................................................................................. 44
Install the Extension Harnesses ................................................................................................................. 44
Install the Boom Shutoff Adapter ...................................................................................................................... 45
Install the Liquid Level Sensor (Optional) ......................................................................................................... 45
Install the Liquid Level Sensor Harness ..................................................................................................... 45
Install the Extension Harness ..................................................................................................................... 46
Install the Liquid Level Sensor Adapter ...................................................................................................... 46
Install the CapView ........................................................................................................................................... 46
Install the CapView Extension Harness ..................................................................................................... 47
Install the Battery Harness ................................................................................................................................ 47
Install the Power Disconnect Breaker Kit .......................................................................................................... 48
Install the Key Switched Power Cable .............................................................................................................. 48
Install the Circuit Breaker .................................................................................................................................. 48
System Setup ................................................................................................................................................... 49
Factory Reset ................................................................................................................................................... 49
Location Setup Procedure ................................................................................................................................ 50
Location Setup Table ................................................................................................................................. 51
Auto Location Setup ......................................................................................................................................... 52
System Setup ................................................................................................................................................... 53
System Setup Chart ................................................................................................................................... 53
Advanced Settings - N-Ject™ Operation Mode ......................................................................................... 56
Nozzle Setup Procedure ................................................................................................................................... 60
System Dry Test ............................................................................................................................................... 61
Boom Shutoff Dry Test ............................................................................................................................... 61
Look Ahead Time and Overlap Test ................................................................................................................. 62
Compass Calibration ........................................................................................................................................ 63
Setting the GPS Settings .................................................................................................................................. 64
Machine Specific Information ............................................................................................................................ 66
Location Setup Information ........................................................................................................................ 66
System Setup Information .......................................................................................................................... 68
Advanced System Setup Information - N-Ject™ Operation Mode ............................................................. 69
INDEX .................................................................................................................................................................. 71

PinPoint™ II for N-Ject™ NH3 Operator and Maintenance Manual | ©2017 CapstanAg Systems Inc. 1
SAFETY
TM
SAFETY
SIGNAL WORDS
FIGURE 1: Signal words designate a degree or level of
hazard seriousness.
DANGER: indicates an imminent hazard which, if not
avoided, will result in death or serious injury. This
signal word is limited to the most extreme situations,
typically for machine components that, for functional
purposes, cannot be guarded.
WARNING: indicates a potential hazard which, if not
avoided, could result in death or serious injury, and
includes hazards that are exposed when guards are
removed. It may also be used to alert against unsafe
practices.
CAUTION: indicates a potential hazard which, if not
avoided, may result in minor or moderate injury. It may
also be used to alert against unsafe practices.
FIGURE 2: Important and Note
IMPORTANT: This is used to draw attention to specific
information that is necessary for the operation,
setup, or service of the system.
NOTE: This is used for additional information that can
help understand or operate the system.
SAFETY SIGNS
FIGURE 3: The HCS aligned its provisions with the
United Nations’ Globally Harmonized System (GHS)
Classification and Labeling of Chemicals in 2012. This
is a GHS safety label example for a chemical hazard.
These labels and safety messages warn all personnel
about hazardous chemicals or potentially unsafe
chemical conditions that may exist while working around
agricultural application equipment.
CapstanAG add-on application systems for OEM and
retrofit agricultural application equipment (booms and
toolbars) may contain HCS pictographs and GHS safety
labels and safety signal word messages.
FIGURE 1
FIGURE 2
FIGURE 3

2 ©2017 CapstanAg Systems Inc.| PinPoint™ II for N-Ject™ NH3 Operator and Maintenance Manual
SAFETY
TM
PRESSURIZED FLUID LINES
Do not heat by welding, soldering, or using a torch near pressurized fluid lines or other flammable materials.
Pressurized lines can accidentally burst when too much heat is present
PERSONAL PROTECTIVE EQUIPMENT
Wear close fitting clothing and the correct personal protective equipment (PPE) for the job. See the manufacturer’s
manual or other information for correct PPE.
BATTERY SAFETY
Use the procedure in the appropriate agricultural equipment manual for connecting, disconnecting, and jump-starting
the machine’s battery.
Keep sparks and flames away from the battery. Battery gas can explode and cause serious injury. Do not smoke in the
battery charging area.
Remove jewelry, which might make electrical contact and create sparks.
CHEMICAL SAFETY
Chemicals used in agricultural applications can be harmful to your health and/or the environment if not used correctly.
Always follow all label directions for effective, safe, and legal use of agricultural chemicals.
EMERGENCY SAFETY
Fire extinguishing systems must meet the applicable OSHA requirements, and all users of portable/fixed fire
suppression equipment must know the types, limitations, and proper uses of this equipment; including hazards involved
with incipient stage firefighting.
Keep emergency numbers for doctors, ambulance service, hospital, and fire department near your telephone.
Know the location of fire extinguishers and first aid kits and how to use them.
Inspect the fire extinguisher and service the fire extinguisher regularly.
Follow the recommendations on the instructions plate.
Very small fires can be put out (extinguished) with a fire extinguisher. Use an appropriate method to extinguish a fire
(water for paper fires, and chemical extinguishers for electrical or chemical fires.

PinPoint™ II for N-Ject™ NH3 Operator and Maintenance Manual | ©2017 CapstanAg Systems Inc. 3
INTRODUCTION
TM
INTRODUCTION
THIS MANUAL
Make sure that all personnel has read this manual and thoroughly understand the safe and correct operation and
maintenance procedure. Failure to do so could result in personal injury or equipment damage.
This manual should be considered a permanent part of your system and should remain with the system when you sell it.
Right and left sides are determined by facing in the direction of forward travel of the machine the system is on.
The information, screen shots, and other illustrations were correct at the time of publication. Changes can occur without
notice.
This manual contains important information on how to safely and correctly install, operate, and maintain CapstanAG
equipment. These instructions will help keep personnel safe, reduce downtime, and increase the reliability and life of the
equipment, its components, and related systems.
Review the safety information in the Original Equipment Manufacturer (OEM) agricultural equipment manual(s).
Follow the instructions (in this manual) for each step to make sure that work conditions in and around the OEM
equipment are safe.
It is important for all individuals working with chemicals to understand the potential risks, necessary safety precautions,
and proper response in the event of accidental contact.
Review the OEM agricultural equipment manual(s) for chemical safety information.
Review, understand and read procedures and use Safety Data Sheets (SDS) and the required Personal Protective
Equipment (PPE) for hazardous chemicals.
Please keep this manual and all enclosed documentation in an accessible location known to all operators, installation,
and maintenance personnel.
If you do not understand the CapstanAG equipment after reading this manual, please obtain the proper training before
working with equipment to make sure of your own safety and well as your co-workers’ safety.
Do not attempt to operate any equipment or system until you completely understand why, when, and how it operates. If
you are uncertain after studying this manual, please contact CapstanAG.
SYSTEM IDENTIFICATION
Write the system name, serial number, and other information down in the Service Contact Information on the inside
cover of this manual. Your dealer will use these numbers when you order parts. File a copy of the identification numbers
in a secure place off the machine.
If you are not the original owner of this machine, it is in your interest to contact your local CapstanAG dealer to inform
them of this unit's serial number. Providing this information will help CapstanAG notify you of any issues or product
improvements.

INTRODUCTION
4 ©2017 Capstan Ag Systems Inc. | PinPoint™ II for N-Ject™ NH3 Operator and Maintenance Manual
TM
NOTES

PinPoint™ II for N-Ject™ NH3 Operator and Maintenance Manual | ©2017 CapstanAg Systems Inc. 5
OPERATION
TM
OPERATION
CAPVIEW BUTTON DESCRIPTIONS
FIGURE 4:
(1) POWER button
Press to turn on or off the CapView and the
Gateway hub.
(2) AUTO/MANUAL button
Press to change between Manual and Automatic
operation mode
(3) TURN button
Press to engage or disengage turn compensation
(4) OVERLAP button
Press to engage or disengage overlap control
(5) Arrow buttons
Press these buttons to move through menus items
(6) ENTER button
Press to open the selected menu screen or to
accept the selected value
(7) ESCAPE/MAP button
Press to exit the current screen or to not accept
selected field.Also used to access map menu
(8) Presets buttons
Used to store and utilize boom, tip size, and flow
profiles
(9) ALARM button
Press to stop an audible alarm
(10) LOCATION SETUP button
Press and hold for 10 sec to go to the Location
Setup Menu
(11) SYSTEM SETUP button
Press to go to the System Setup menu
(12) NOZZLE SETUP button
Press to go to the Nozzle Setup menu
FIGURE 4

OPERATION
6 ©2017 Capstan Ag Systems Inc. | PinPoint™ II for N-Ject™ NH3 Operator and Maintenance Manual
TM
START UP PROCEDURE
FIGURE 5: Before starting the machine engine, always
make sure that the CapView and rate controller are off.
1. Start the machine engine.
2. Press the POWER button (1) to start the CapView
and the rate controller.
3. Make sure that the rate settings are correct.
4. Press the AUTO/MANUAL button (2) to let the rate
controller control the duty cycles.
5. Press the TURN button (3) to activate the turn
compensation feature.
6. Press the OVERLAP button (4) to activate the
overlap feature.
7. Turn on the boom sections to spray.
SHUT DOWN PROCEDURE
FIGURE 6:
1. Turn off the sections.
2. Press the POWER button (1) to turn off the CapView
and the rate controller.
OPERATE IN AUTOMATIC CONTROL
(AUTO) MODE
FIGURE 7: The PinPoint™ II system default is manual
control mode. In manual mode, press the up or down
arrow buttons to change the nozzle duty cycle.
In Auto Mode, the rate controller changes the nozzle
duty cycle.
To change to auto mode:
1. Start the machine engine.
2. Press the POWER button (1) to start the CapView
and the rate controller.
3. Press the AUTO/MANUAL button (2) to let the rate
controller control the duty cycles.
The LED light (3) within the AUTO/MANUAL button
indicates that the system is in automatic mode.
FIGURE 5
FIGURE 6
FIGURE 7

PinPoint™ II for N-Ject™ NH3 Operator and Maintenance Manual | ©2017 CapstanAg Systems Inc. 7
OPERATION
TM
FIGURE 8: For the N-Ject™ operation mode, the
pressure will not automatically change. On the main
operation screen, the pressure is represented in three
ways:
(1) Green bar graph
(2) Yellow arrow
(3) P In value
NOZZLE DISPLAY
FIGURE 9: The duty cycle of each nozzle on the boom
is indicated with a blue tick mark (1) on the scale.
The bottom of the graphic is 0%, and the top is 100%.
The grid lines (2) are in 20% increments. A vertical grid
line (3) indicates the center of the boom.
The yellow arrow (4) indicates the average duty cycle of
all the nozzles. The text block (5) in the upper right corner
indicates the average system duty cycle.
The red arrow along (6) the bottom of the duty cycle
graphic moves from nozzle to nozzle, and left to right two
nozzles per second. The corresponding tick mark turns
yellow (7) as the red arrow moves along.
The text box (8) at the lower left side shows the nozzle
diagnostic information for the nozzle corresponding to the
red arrow and yellow tick mark.
If a nozzle error is detected, that nozzle’s tick mark will
blink yellow, the alarm will sound, and the alarm and
nozzle setup-# LEDs will blink.
The left and right arrows (9) will override the scrolling red
arrow so that the red arrow can move to the detected
nozzle. The text block at the lower left side may show one
of the following notices:
• Coil Open
• Coil Shorted Closed
• Plunger Lodged Open
• Plunger Stuck Closed
After a few seconds, the red arrow will begin to scroll
again.
FIGURE 8
FIGURE 9

OPERATION
8 ©2017 Capstan Ag Systems Inc. | PinPoint™ II for N-Ject™ NH3 Operator and Maintenance Manual
TM
OVERLAP CONTROL
FIGURE 10: Press the OVERLAP button (1) to turn the
overlap control on or off.
Overlap can be turned off for situations that can include:
• Spraying rinse water
• Troubleshooting
• No GPS signal
• Other
FIGURE 10

PinPoint™ II for N-Ject™ NH3 Operator and Maintenance Manual | ©2017 CapstanAg Systems Inc. 9
OPERATION
TM
MAPPING
Maps can be deleted, moved, copied, etc.
Maps are stored in bitmap format and can be viewed with
MS-Paint or a similar picture viewer program.
Anew map is started when the CapView is turned on and
the OVERLAP button is selected.
The system establishes a map origin and must stay within
a 3-mile radius of the origin point.
If the map range is exceeded, an error message will show
(Map out of bounds) and the alarm will sound.
FIGURE 11: If the Save Map #.bmp (1) is selected, the
map will be saved, and a new map will start.
Select Save Map As... (2) to give the map a specific
name.
Select Retrieve Map... (3) to load a map that has already
been made.
Select Delete Map... (4) to delete the current map.
FIGURE 12: Press the UP or DOWN arrow buttons (1)
to select the desired map setting.
Press the ENTER button (2) to save.
To shortcut to the Save Map Menu, press the ESCAPE
button (3).
Download Maps
1. Insert a USB device into the back of the CapView.
NOTE: Use a USB device no larger than 64GB in the CapView .
FIGURE 13: The USB Host Menu will show.
2. Select Download Maps (1).
3. Press the ESCAPE button (2) to close the USB Host
Menu.
You can now start spraying.
FIGURE 11
FIGURE 12
FIGURE 13

OPERATION
10 ©2017 Capstan Ag Systems Inc. | PinPoint™ II for N-Ject™ NH3 Operator and Maintenance Manual
TM
OVERLAP DISTANCE
The PinPoint™ II system uses 1-meter-squares to record
where spraying has occurred. Any spraying nozzle that
touches one of these squares will cause the system to
consider this as an area that has been sprayed. As the
machine travels along, each nozzle looks to see if the
approaching square has been sprayed or not. If not,
spraying continues. If so, the nozzle shuts off.
Change the Overlap Distance
FIGURE 14: Overlap Distance in the System Setup
menu can be set to skip or overlap. The value is in inches.
Positive numbers cause intentional overlap, and negative
numbers cause intentional skips.
1. Press the SYSTEM SETUP button (1).
2. Use the UP or DOWN arrow buttons (2) to move to
Overlap Distance (3).
3. Press the ENTER button (4).
4. Change the value of the overlap distance.
5. Press the ENTER button to save.
6. Press the ESCAPE button (5) to leave the System
Setup menu.
FLOW METER SIGNAL
When the operation mode is set to N-Ject, the system is
always calculating the flow.
The rate controller is sent a signal for the whole section if
the section is on.
The flow is calculated from the two pressure sensors
(Inlet/Outlet).
Flow meter type must be set as NH3 calculation (default
in N-Ject Mode). The system will not operate correctly if
the type is changed from the default.
FIGURE 14

PinPoint™ II for N-Ject™ NH3 Operator and Maintenance Manual | ©2017 CapstanAg Systems Inc. 11
OPERATION
TM
TURN COMPENSATION
With a standard spray boom, the flow rate is averaged over
the entire boom and that flow rate is based on the speed of
the machine chassis. This results in over application on the
inner radius of the turn and under application on the outer
radius of the turn because the nozzles are traveling at different
speeds than the chassis is during a turn. A tighter turn radius
results in a higher level of misapplication.
With the turn compensation feature engaged, each nozzle will
apply the correct amount of product based on each nozzle’s
speed, calculated using GPS.
The amount of correction available to each nozzle during a
turn compensation turn can be limited by the amount of
available duty cycle during the turn. The ideal target duty cycle
during a tight turn is 55%.
Nozzles determined to be moving backward will turn off. If
only part of the boom is spraying, the flow meter signal is
managed, so the correct rate is applied.
Turn compensation calculates a turn radius from a GPS signal
and adjusts the flow per nozzle to maintain a constant rate.
If you need more information about turn compensation,
contact your CapstanAG field representative or your servicing
dealer.
FIGURE 15: Press the TURN button (1) to turn on and off
the turn compensation feature.
Turn compensation can be turned off for situations like:
• Troubleshooting
•NoGPS
Shown is the turn compensation active with no other features
active
FIGURE 16: Turn Compensation with Overlap Control
active.
FIGURE 15
FIGURE 16

OPERATION
12 ©2017 Capstan Ag Systems Inc. | PinPoint™ II for N-Ject™ NH3 Operator and Maintenance Manual
TM
COUNTERS
FIGURE 17: The counters are shown on the System
Setup screen.
Gallon Counters
The PinPoint™ II system manages the flow meter signal to
keep the rate controller accurate when the N-Ject™ system
is turned off.
It is important to show the amount of manipulating that
has occurred.
The Controller Gallon Counter on the CapView should
match the values from the rate controller.
The Actual Gallon Counter values on the CapView
should match the tank volume.
The difference between the controller counters and the
actual counters is the amount of product saved by using
the PinPoint™ II system.
Acre Counters
The Controller Acre Counter on the CapView should
match the values from the rate controller.
Reset the Counters
1. Press the SYSTEM SETUP button.
2. Use the UP or DOWN arrow buttons to select the
desired counter.
3. Press the ENTER button.
4. Amenu will show, confirm your intention.
ALARM
If the alarm on the CapView sounds, press the ALARM
button to silence the alarm. The LEDs will continue to
blink. If the issue is not resolved after several minutes, the
alarm will sound again.
IMPORTANT: It is the responsibility of the operator to
stop using the system if the spray application is
not performing correctly.
FIGURE 17

PinPoint™ II for N-Ject™ NH3 Operator and Maintenance Manual | ©2017 CapstanAg Systems Inc. 13
OPERATION
TM
VENT AND DRAIN THE N-JECT™ SYSTEM
IMPORTANT: This procedure must be done before any service or maintenance is performed on the N-Ject™ system.
1. Close the tank manual shutoff valve.
2. Pull the application knifes through the soil.
3. Turn on the N-Ject™ system and the section and master switches to apply ammonia.
• Pressure will be relieved through the knifes and into the soil. When pressure is not shown on the inlet pressure
gauge, turn off the N-Ject™ system.
4. Make sure that there is no pressure on the inlet pressure gauge.
5. Open the bleeder valve located on the inlet end plate on the N-Ject™ manifold(s).
• Any pressure remaining in the N-Ject™ system inlet hoses is released.
6. The machine/implement can be moved to a safe place for service.

OPERATION
14 ©2017 Capstan Ag Systems Inc. | PinPoint™ II for N-Ject™ NH3 Operator and Maintenance Manual
TM
NOTES

PinPoint™ II for N-Ject™ NH3 Operator and Maintenance Manual | ©2017 CapstanAg Systems Inc. 15
Maintenance
TM
MAINTENANCE
SERVICE THE SYSTEM
Before operation or service to the system, read and understand the machine’s operator manual
and the PinPoint™ II for N-Ject™ NH3 operator and maintenance manual. Chemical residue
may be present on/in the OEM equipment. Use the correct personal protective equipment.
CLEAN THE SYSTEM
Thoroughly clean the system after each use.
Avoid high-pressure spray when cleaning the spray system components, valves, and wiring connectors.
INSPECT THE SYSTEM
Inspect hoses for cuts, nicks, or abrasions before each use. Replace any damaged hoses immediately.
Make sure that the strainers are clean.
Make sure that all hoses and wiring are secure.
Check for loose hoses, mounting hardware, and other components. Tighten if necessary.
Check for damaged or missing decals. Replace if necessary.
JUMP START, WELD ON, OR CHARGE THE MACHINE
If jump starting the machine, make sure that you trip the 80 Amp circuit breaker to prevent damage to the PinPoint™
system.
If charging the machine’s batteries or welding on the machine, trip the 80Amp circuit breaker or the machine’s
battery disconnect to prevent damage to the PinPoint™ control system.
STORAGE OF THE SYSTEM
Thoroughly clean the implement and the system before any long storage.
IMPORTANT: Use of N-Serve requires that the system is flushed with one or two tanks of ammonia without N-Serve at
the end of the season before long storage.

Maintenance
16 ©2017 Capstan Ag Systems Inc. | PinPoint™ II for N-Ject™ NH3 Operator and Maintenance Manual
TM
CLEAN THE Y-STRAINER
FIGURE 18: Remove the plug (1), magnet (2), and:
screen (3).
Clean the debris from the magnet and screen by washing
with a solution that will remove an oily residue.
Clean the strainers on a regular basis.
Install the screen, magnet, and plug before operation.
CLEAN THE INLET STRAINER
FIGURE 19: Disconnect the inlet plumbing (1) from the
N-Ject™ manifold.
FIGURE 20: Remove the strainer (1) and magnet (2)
from the manifold.
Clean the debris from the magnet and screen by washing
with a solution that will remove an oily residue.
Clean the strainers on a regular basis.
Install the strainer and magnet into the manifold and
connect the inlet plumbing before operation.
FIGURE 18
FIGURE 19
FIGURE 20
