Captiva Designs E02GR005 User manual

Questions, problems, missing parts? Before returning to the store,
please contact our Customer Service
h
[email protected]
inually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Captiva Desings!
THANK YOU
This appliance is for Household use only.
This is not a commercial appliance.
Assembly, Care And Use Instructions
Read Carefully Important:Retain These
Instructions For Future Reference.
USE AND CARE GUIDE
E02GR005
Enjoy Your

2
Safety Information
Warning
Components
Assembly Instructions
Igniting the Fuel
Cleaning and Maintenance
Environmental Protection & Disposal
2 22
322
22
4
4-5
6-21
Warranty 23
ENJOY YOUR CAPTIVA DESIGNS
Preparation
Assembler/Installer
This instruction manual contains important information necessary for the proper assembly and safe
use of this appliance. Read and follow all warnings and instructions before assembling and using this
appliance.
Leave these instructions with the consumer.
Consumer/User
Follow all warnings and instructions when using this appliance. Keep these instructions for future
reference.
Table of Contents
Safety Information
Proper Utilisation
The barbecue may only be used for preparing suitable foods. All requirements of this assembly and
operation manual must be complied with. Only for private domestic use!

3
ENJOY YOUR CAPTIVA DESIGNS
WARNING:
This barbecue will become very hot, do not move it during operation!
• Always wear barbecue gloves when grilling or adjusting the vents as well as when using a chimney
starter.
• When preparing food, adjusting the vents, placing charcoal and using the thermometer or lid always
wear barbecue gloves.
• Grill gloves must be tested in accordance with local code.
• For grilling use only qualied barbecue charcoal or barbecue charcoal briquettes.
• Do not BBQ before the fuel has a coating of ash.
• Use grilling tongs with long, heat-resistant handles.
• Allow the barbecue to cool down completely before cleaning it.
WARNING:
• Do not use spirit or petrol for lighting or
re-lighting!
• Never use water to extinguish the charcoal.
WARNING:
Risk of burning!
• Make sure that the barbecue is standing on a at and reproof surface that is not made of glass or
plastic.
WARNING:
DANGER to children and pets!
• Never leave the hot barbecue unattended.
• WARNING! Keep children and pets away!
Warning
WARNING:
Risk of carbon monoxide poisoning!
• Do not use indoors !
Information for safe operation of the barbecue
•The barbecue must be positioned in a stable and secure surface.
Do not use in enclosed areas or on covered areas.
•Only use safe lighting materials.
•The barbecue should be heated up and the fuel kept red hot at least 30 minutes before it is used for the rst
time.

4
Preparation
ENJOY YOUR CAPTIVA DESIGNS
Before beginning assembly of product, make sure all parts are present. Compare parts with package contents
list and hardware contents above. If any part is missing or damaged, do not attempt to assemble the product.
Contact customer service for replacement parts.
Estimated Assembly Time: 30 minutes.
Tools Required for Assembly: Wrench (not included) and Phillips Screwdriver (not included)
Hardware Contents
M6*45
4x
M5*30
2x
M6*12
34x
M6*14
8x
M6*15
2x
M6*35
4x
M5*16
10x
R Hinge
4x
M6
6x
Locking
Nut
M6 2x
M8
2x
AB C D E F G H I J K
Components
Package Contents
Part
2
3
4
5
6
7
8
9
10
11
1
Description
Temperature Gauge
Lid Handle
Lid Handle Sets
Lid
Up Hinges
Hinge Pins
Down Hinges
Back Body Plate
Left Body Plate
Air Vents
Front Body Plate
Quantity
1
1
2
1
2
2
2
1
1
2
1
Part
13
14
15
16
17
18
19
20
21
22
12
Description
Back long leg
Side Table
Hooks
Leg Pads
Bottom Shelf
Wheel Axle
Front Short Leg
Back Short Leg
Wheels
Ash Pan
Right Body Plate
Quantity
1
2
8
2
1
1
1
1
2
1
1
Part
24
25
26
27
28
29
30
31
23
Description
Charcoal Tray and
Lifting Machine
Cooking Grates
Warming Grates
Chimney
Charcoal Door
Handles
Lifting Handles
Beer Opener
Left Long Leg
Chimney Cover
Quantity
1
3
1
1
2
2
1
1
1

Components
5
ENJOY YOUR CAPTIVA DESIGNS

6
Assembly Instructions
Please read the assembly instructions carefully and follow the safety precautions. Allow sucient time for
assembly. Before starting assembly, clear an area measuring approximately two to three square meters.
Remove the item from the packaging. Lay out all of the parts and any necessary tools so that they are within
easy reach.
ENJOY YOUR CAPTIVA DESIGNS
1
E M6*12 4PCS

Assembly Instructions
7
ENJOY YOUR CAPTIVA DESIGNS
2
E M6*12 4PCS
3

Assembly Instructions
8
4
5
ENJOY YOUR CAPTIVA DESIGNS
E M6*12 8PCS
E M6*12 4PCS

Assembly Instructions
9
ENJOY YOUR CAPTIVA DESIGNS
7
6
O
H M8 2PCS
E M6*12 4PCS

Assembly Instructions
10
ENJOY YOUR CAPTIVA DESIGNS
8
9
K R-HINGE 1PC
K R-HINGE 1PC

Assembly Instructions
11
10
E M6*12 2PCS
ENJOY YOUR CAPTIVA DESIGNS
11
E M6*12 2PCS

Assembly Instructions
12
ENJOY YOUR CAPTIVA DESIGNS
12
13
E M6*12 1PC

Assembly Instructions
13
ENJOY YOUR CAPTIVA DESIGNS
14
E M6*12 1PC
15

Assembly Instructions
14
ENJOY YOUR CAPTIVA DESIGNS
16
17
F M5*30 2PCS

Assembly Instructions
15
ENJOY YOUR CAPTIVA DESIGNS
18
19
A M6*45 4PCS
E M6*12 2PCS
I M6 LOCK 2PCS

Assembly Instructions
16
ENJOY YOUR CAPTIVA DESIGNS
20
B M6*35 4PCS
J M6 4PCS
21
C M6*15 2PCS

Assembly Instructions
17
ENJOY YOUR CAPTIVA DESIGNS
22
23
K R-HINGE 2PCS
E M6*12 2PCS
J M6 2PCS

Assembly Instructions
18
ENJOY YOUR CAPTIVA DESIGNS
24
25
D M6*14 2PCS
D M6*14 2PCS

Assembly Instructions
19
ENJOY YOUR CAPTIVA DESIGNS
26
27
D M6*14 2PCS
G M5*16 4PCS

Assembly Instructions
20
ENJOY YOUR CAPTIVA DESIGNS
28
29
G M5*16 4PCS
D M6*14 2PCS
