Car-Interface v.LiNK CI-VL2-PC-HSD User manual

Version 07.09.2017
v.LiNK Video-inserter and navigation
CI-VL2-PC-HSD and CI-NAL-PC-HSD
Compatible with Citroen and Peugeot vehicles
with SMEG or SMEG+ navigation
with 4pin HSD LVDS connector on the monitor
VL2-PC-HSD: Video-inserter with 2 video + RGB + rear-view camera input and
CAN control
NAL-PC-HSD: Video-inserter with integrated navigation +2 video + rear-view
camera input and CAN control
Product features
Video-inserter for factory-infotainment monitors
2 CVBS video-inputs for after-market devices (e.g. DVD-Player, DVB-T tuner, …)
Built-in audio-switch (no audio-insertion)
Rear-view camera CVBS video-input
Automatic switching to rear-view camera input on engagement of reverse gear
Activatable parking guide lines for rear-view camera (not for all vehicles)
RGB-input for after-market navigation (VL2 only)
Video-in-motion (ONLY for connected video-sources)
Compatible with factory rear-view camera
AV-inputs PAL/NTSC compatible

Version 07.09.2017 CI-VL2-PC-HSD / CI-NAL-PC-HSD
Seite2
Contents
1. Prior to installation
1.1. Delivery contents
1.2. Checking the compatibility of vehicle and accessories
1.3. Boxes and connectors
1.3.1. CAN-bus box
1.3.2. Video-interface
1.3.2.1. Dip-switch settings
1.3.2.2. Enabling the interface’s video inputs (dip 1-3)
1.3.2.3. RGB-video input signal selection for after-market navigation (Dip 4)
1.3.2.4. Rear-view camera setting (dip 5)
1.3.2.5. Monitor selection (dip 7-8)
2. Installation
2.1. Place of installation
2.2. Connection schema
2.3. Connecting video-interface and CAN-box
2.4. Connection to the factory monitor
2.5. Connection to the head-unit
2.6. Connecting peripheral devices
2.6.1. After market RBG navigation (only VL2)
2.6.2. Video-sources to AV1 and AV2
2.6.3. Audio-switch and audio-insertion
2.6.4. After-market rear-view camera
2.6.4.1. Case 1: CAN-box detects reverse gear
2.6.4.2. Case 2: CAN-box does not detect reverse gear
2.6.4.3. Video signal connection
2.7. Connecting video-interface and keypad
2.8. Picture settings and guide lines
2.9. Connecting internal navigation (only NAL)
3. Interface operation
3.1. By LIST-key
3.2. By keypad
4. Specifications video-interface
5. Frequently asked questions
Appendix A –Internal Navigation (only NAL)

Version 07.09.2017 CI-VL2-PC-HSD / CI-NAL-PC-HSD
Seite3
Legal Information
By law, watching moving pictures while driving is prohibited, the driver must not be
distracted. We do not accept any liability for material damage or personal injury resulting,
directly or indirectly, from installation or operation of this product. This product should only
be used while standing or to display fixed menus or rear-view-camera video when the
vehicle is moving, for example the MP3 menu for DVD upgrades.
Changes/updates of the vehicle’s software can cause malfunctions of the interface. If
available, we offer free software-updates for our interfaces for one year after purchase. To
receive a free update, the interface must be sent in at own cost. Labor cost for and other
expenses involved with the software-updates will not be refunded.
1. Prior to installation
Read the manual prior to installation.
Technical knowledge is necessary for installation. The place of installation must be free of
moisture and away from heat sources.
1.1. Delivery contents
Take down the serial number of the interface and store this manual for support
purposes: ____________________

Version 07.09.2017 CI-VL2-PC-HSD / CI-NAL-PC-HSD
Seite4
Requirements
Vehicle Citroen and Peugeot
Head-unit/monitor Citroen SMEG+, Peugeot SMEG and SMEG+
with 4pin HSD LVDS connector on the monitor
Limitations
Video only The interface inserts ONLY video signals into the infotainment.
For audio insertion a factory audio-AUX input or FM-modulator
is required.
Factory rear-view camera Automatic switch-back from inserted video to factory rear-view
camera only while reverse gear is engaged. To extend the switch-
back additional electronics is required.
1.2. Checking the compatibility of vehicle and accessories
1.3. Boxes and connectors
1.3.1. CAN-bus box
The CAN-bus box reads digital signals from the CAN-bus and converts them for the video-
interface.

Version 07.09.2017 CI-VL2-PC-HSD / CI-NAL-PC-HSD
Seite5
1.3.2. Video-interface
The video-interface converts the connected after-market sources video signals to an LVDS
signal which is the inserted into the factory monitor on certain trigger options.
1.3.2.1. Dip-switch settings
Some settings must be selected by the dip-switches on the
video interface. Dip position down is ON and position up is OFF.
See following chapters for detailed information.
Dip
Function
ON (down)
OFF (up)
1
RGB-input
enabled
disabled
2
CVBS AV1-input
enabled
disabled
3
CVBS AV2-input
enabled
disabled
4
RGB-input resolution
800x480
400x240 or 480x240
5
Rear-view cam type
after-market
factory or none
6
No function
-
set OFF
7
No function
Set OFF
8

Version 07.09.2017 CI-VL2-PC-HSD / CI-NAL-PC-HSD
Seite6
1.3.2.2. Enabling the interface’s video inputs (dip 1-3)
Only the enabled video inputs can be accessed when switching through the interface’s video
sources. It is recommended to enable only the required inputs for the disabled will be
skipped when switching through the video interfaces inputs.
1.3.2.3. RGB-video input signal selection for after-market navigation (Dip 4)
If after-market RGB navigation or other RGB video source is connected, the source’s RGB
output signal must match the interface’s RGB video input setting.
1.3.2.4. Rear-view camera setting (dip 5)
If set to OFF, the interface switches to factory LVDS picture while the reverse gear is engaged
to display factory rear-view camera or factory optical park system picture.
If set to ON, the interface witches to its rear-view camera input CAM while the reverse gear
is engaged.
1.3.2.5. Monitor selection (dip 7-8)
Dips are not used.
2. Installation
Switch off ignition and disconnect the vehicle’s battery! The interface needs a permanent
12V source. If according to factory rules disconnecting the battery is to be avoided, it is
usually sufficient to put the vehicle is sleep-mode. In case the sleep-mode does not show
success, disconnect the battery with a resistor lead.
If power source is not taken directly from the battery, the connection has to be checked
for being start-up proven and permanent.
2.1. Place of installation
The interface is installed on the backside of the factory monitor and on the backside of the
head-unit.

Version 07.09.2017 CI-VL2-PC-HSD / CI-NAL-PC-HSD
Seite7
2.2. Connection scheme

Version 07.09.2017 CI-VL2-PC-HSD / CI-NAL-PC-HSD
Seite8
2.3. Connecting video-interface and CAN-box
The CAN-bus box reads digital signals from the CAN-bus and converts them for the video-
interface. ACC +12V max. 0.5A (red of 6pin) and reverse gear +12V max. 0.5A (green of 6pin)
constant signal. Video-source switching (white of 6pin) as +12V impulse.
Connect black female 10pin Micro-Fit connector of the Quadlock harness to the male
10pin Micro-Fit connector of the CAN-box.
Note: Check LEDs on CAN-box after reconnecting the battery, two must be on.
Connect white female 6pin Molex connector of the 6+2pin to 8pin cable to the male
6pin Molex connector of the video-interface.
Connect black female 8pin Micro-Fit connector of the 6+2pin to 8pin cable to male
8pin Micro-Fit connector of the CAN-box.
Note: Check LEDs on video-interface after reconnecting the battery, one must be on.
Note: The CAN-box is not compatible with all vehicles. If the CAN-box does not deliver ACC
to pin2 of the video-interface or blocks the vehicle CAN, it is possible to install without CAN-
box. In this case see also note in chapter after-market rear-view camera if one is supposed to
be connected.

Version 07.09.2017 CI-VL2-PC-HSD / CI-NAL-PC-HSD
Seite9
2.4. Connections to the factory monitor
Remove factory monitor.
Connect female 8pin Micro-Fit connector of the 4pin HSD LVDS cable to male 8pin
Micro-Fit connector of the video-interface.
Remove female 4pin HSD LVDS connector from the rear of the factory monitor and
connect it to the male 4pin HSD LVDS connector of the 4pin HSD LVDS cable.
Connect female 4pin connector of the 4pin HSD LVDS cable to the male 4pin HSD
LVDS connector of the factory monitor.

Version 07.09.2017 CI-VL2-PC-HSD / CI-NAL-PC-HSD
Seite10
2.5. Connections to the head-unit
Remove head-unit.
Remove the female Quadlock connector of the vehicle harness from the rear of the
navigation computer.
Connect female Quadlock connector of vehicle harness to the male Quadlock
connector of Quadlock harness.
Connect female Quadlock connector of Quadlock harness to the male Quadlock
connector of the head-unit.
2.6. Connecting peripheral devices
It is possible to connect an after-market RGB navigation (or other RGB video source, only
VL2), 2 after-market AV-sources and an after-market rear-view camera to the video-
interface.
Before final installation of the peripheral devices, we recommend a test-run of the
interface. Due to changes in the production of the vehicle manufacturer is always the
possibility of incompatibility.

Version 07.09.2017 CI-VL2-PC-HSD / CI-NAL-PC-HSD
Seite11
2.6.1. After-Market RGB navigation (only VL2)
Connect female 8pin connector of the RGB cable to the male 8pin connector of the
video-interface. The loose grey wires have no function and have to be isolated.
Connect male 6pin connector of the RGB cable to the after-Market navigation.

Version 07.09.2017 CI-VL2-PC-HSD / CI-NAL-PC-HSD
Seite12
2.6.2. Video-sources to AV1 and AV2
Connect female 6pin connector of the audio cable to male 6pin connector of the
video-interface.
Connect video RCA of the AV-source 1 to the female RCA connector Video 1 of the
video cable.
Connect video RCA of the AV-source 2 to the female RCA connector Video 2 of the
video cable.

Version 07.09.2017 CI-VL2-PC-HSD / CI-NAL-PC-HSD
Seite13
2.6.3. Audio-switch and audio insertion
This interface can only insert video signals into the factory infotainment and switch audio
signals. If an AV-source is connected to AV1 or AV2, audio insertion must be done by factory
audio AUX input or FM-modulator to which the interface’s sound-switch output is
connected. When the interface is switched from AV1 to AV2, the audio signal is switched
parallel to the corresponding video signal by the interface’s built-in audio-switch.
The inserted video-signal can be activated simultaneously to each audio-mode of the factory
infotainment.
Audio pins
Definition
1/2
Audio input signal R/L of source AV2
3/4
Audio input signal R/L of source AV1
5/6
Audio output signal R/L of factory audio AUX
or FM-modulator
7
Ground
Note: If only one AV-source shall be connected, it is possible to connect the video output of
the AV-source to the video input AV1 of the video-interface and the audio output of the AV-
source directly to the point of audio-insertion (e.g. audio AUX input).
Connect female 7pin connector of the audio cable to male 7pin connector of the
video-interface.
Connect the audio-RCA of the possibly existing factory AUX-input or the FM-
modulator to the female RCA port AV-Out of the audio cable.
Connect the audio-RCA of the AV-source 1 to the female RCA port AV1 of the audio
cable.
Connect the audio-RCA of the AV-source 2 to the female RCA port AV2 of the audio
cable.

Version 07.09.2017 CI-VL2-PC-HSD / CI-NAL-PC-HSD
Seite14
2.6.4. After-market rear-view camera
Some vehicles have a different reverse gear code on the CAN-bus which the included CAN-
box is not compatible with. Therefore there is two different ways of installation. If the CAN-
box can detect the reverse gear in the vehicle, the green wire of the 6pin to 8pin cable
should carry +12V while the reverse gear is engaged.
Note: Do not forget to set dip5 of video-interface to ON before testing.
2.6.4.1. Case 1: CAN-box detects reverse gear
If the CAN-bus interface delivers +12V on the green wire of the 6pin to 8pin cable when
reverse gear is engaged, the video interface will automatically be switched to the rear-view
camera input CAM while reverse gear is engaged.
Additionally, the +12V (max. 500mA) power supply for the rear-view camera can be
taken from the green wire of the 6pin to 8pin cable.

Version 07.09.2017 CI-VL2-PC-HSD / CI-NAL-PC-HSD
Seite15
2.6.4.2. Case 2: CAN-box does not detect reverse gear
If the CAN-bus interface does not deliver +12V on the green wire of the 6pin to 8pin cable
when reverse gear is engaged (not all vehicles are compatible) an external switching signal
from the reverse gear light is required. As the reverse gear light signal contains electronic
interference, a normally open relay (e.g AC-RW-1230 with wiring AC-RS5) or filter (e.g. AC-
PNF-RVC) is required. Below schema shows the use of a relay (normally open).
Cut the green cable of the 6pin to 8pin cable close to the at the black 8pin connector.
Isolate the short end of the green wire (CAN-box side).
Connect reverse gear light signal/power to coil (85) and ground to coil (86) of relais.
Connect rear-view camera power and green wire (video interface side) of 6pin to
8pin cable to output (87) of relay.
Connect permanent battery power to input (30) of relay.

Version 07.09.2017 CI-VL2-PC-HSD / CI-NAL-PC-HSD
Seite16
2.6.4.3. Video signal connection
Connect the video-RCA of the after-market rear-view camera to the female RCA port
of the video-interface which is labeled as CAM.
Note: Picture settings for CAM input must be done in AV2.
2.7. Connecting video-interface and keypad
Connect the female 4pin connector of the keypad to the male 4pin connector of the
video-interface.

Version 07.09.2017 CI-VL2-PC-HSD / CI-NAL-PC-HSD
Seite17
2.8. Picture settings and guide lines
The picture settings are adjusted by the 3 buttons on the video-interface. Press the MENU
button to open the OSD settings menu or to switch to the next menu item. Press UP and
DOWN change the selected value. The buttons are embedded in the housing to avoid
accidental changes during or after installation. Picture settings must be done separately for
RGB, AV1 and AV2 while the corresponding input is selected and visible on the monitor. AV2
and CAM share the same settings which must be adjusted in AV2.
Note: The OSD menu is only shown when a working video source is connected to the
selected video-input of the interface.
The following settings are available:
Contrast
Brightness
Saturation
Position H (horizontal)
Position V (vertical)
Guide-CNTRL (guide lines ON/OFF)
Note: If the CAN-box does not support the very vehicle, the guide-lines cannot be used.

Version 07.09.2017 CI-VL2-PC-HSD / CI-NAL-PC-HSD
Seite18
2.9. Connecting internal navigation (only NAL)
Connect the 4pin talkover cable from Quadlock harness to the male 4pin connector
of the video-interface.
Connect the antenna cable of the GPS-antenna to the male GPS-antenna connector
of the video-inerface.
Connect red-green drilled cable of 6+2pin of 8pin cable to the male 4pin connector of
the video-interface.
Connect the USB-cable to the male 5pin connector of the video-interface.
Insert SD-card (map) into the SD-card slot of the video-interface.

Version 07.09.2017 CI-VL2-PC-HSD / CI-NAL-PC-HSD
Seite19
3. Interface operation
3.1. By LIST-key
The LIST-key on the steering wheel is used to switch among all the inputs. The order is:
Factory video  RGB-in  video AV1  video AV2  factory video  …
Inputs which are not enabled are skipped. If the audio cable is connected, when switching
from video AV1 to video AV2, also the sound will be switched.
3.2. By keypad
Alternatively or additionally to the factory infotainment buttons the interface’s external
keypad can be used to switch the enabled inputs.
4. Specifications video-interface
VL2 NAL
BATT/ACC range 7V - 25V 7V - 25V
Stand-by power drain <10mA <10mA
Power 0.3A @12V 0.5A @12V
Video input 0.7V - 1V 0.7V - 1V
Video input formats PAL/NTSC PAL/NTSC
RGB-video amplitude 0.7V with 0.7V with
75 Ohm impedance 75 Ohm impedance
Temperature range -40°C to +85°C -30°C to +85°C
Dimensions video-box (W x H x D) 155 x 22 x 90 mm 155 x 22 x 90 mm
Dimensions CAN-box (W x H x D) 87 x 27 x 65 mm 87 x 27 x 65 mm
CPU - SiRF atlasVI 800 MHz
RAM - DDR3 256MB
Operating system - WinCE 6.0
GPS-antenna type - External active antenna
Antenna gain - 27 dB
Antenna operating voltage - 3.3V ± 5%
Antenna power consumption - 15mA

Version 07.09.2017 CI-VL2-PC-HSD / CI-NAL-PC-HSD
Seite20
5. FAQ –Trouble shooting Interface functions
For any troubles which may occur, check the following table for a solution before requesting
support from your vendor.
Symptom
Reason
Possible solution
No picture/black
picture (factory
picture).
Not all connectors have been
reconnected to factory head-
unit or monitor after
installation.
Connect missing connectors.
No power on CAN-bus box (all
LED CAN-bus box are off).
Check power supply of CAN-bus box. Check CAN-bus
connection of CAN-bus box.
CAN-bus box connected to
CAN-bus in wrong place.
Refer to the manual where to connected to the CAN-
bus. If not mentioned, try another place to connect to
the CAN-bus.
No power on video-interface
(all LED video-interface are
off).
Check whether CAN-bus box delivers +12V ACC on red
wire output of 8pin to 6pin cable. If not cut wire and
supply ACC +12V directly to video-interface.
No picture/black
picture/white picture
(inserted picture) but
factory picture is OK.
No picture from video source.
Check on other monitor whether video source is OK.
No video-source connected to
the selected interface input.
Check settings dips 1 to 3 of video interface which
inputs are activated and switch to corresponding
input(s).
LVDS cables plugged in wrong
place.
Double-check whether order of LVDS cables is exactly
connected according to manual. Plugging into head-
unit does not work when the manual says to plug into
monitor and vice versa.
Wrong monitor settings of
video-interface.
Try different combinations of dips 7 and 8 of video-
interface. Unplug 6pin power after each change.
Inserted picture totally
wrong size or position.
Inserted picture double
or 4 times on monitor.
Inserted picture
distorted, flickering or
running vertically.
Video sources output set to
AUTO or MULTI which causes
a conflict with the interfaces
auto detection.
Set video source output fixed to PAL or NTSC. It is best
to set all video sources to the same standard.
If error occurs only after
source switching: Connected
sources are not set to the
same TV standard.
Set all video sources to the same standard.
Some interfaces can only
handle NTSC input.
Check manual whether there is a limitation to NTSC
mentioned. If yes, set source fixed to NTSC output.
Inserted picture b/w.
Inserted picture qual.
bad.
Picture settings have not been
adjusted.
Use the 3 buttons and the interface's OSD to adjust the
picture settings for the corresponding video input.
Inserted picture size
slightly wrong.
Inserted picture
position wrong.
Camera input picture
flickers.
Camera is being tested under
fluorescent light which shines
directly into the camera.
Test camera under natural light outside the garage.
Camera input picture is
bluish.
Protection sticker not
removed from camera lens.
Remove protection sticker.
