Car Shades MB-CCLS-E-D User manual

Installation
Manual
MERCEDES C-CLASS EST
MB-CCLS-E-D
1
4
3
8
5
6
1 + 8
3 + 6
4 + 5
SHADES
COMPONENTS INCLUDED
FIXING CLIPS
www.carshades.com | [email protected] PAGE 1 OF 5
CL-M02 x 4 CL-M13 x 4 CL-M12 x 2CL-M04 x 4 CL-M14 x 1

Side Shade (A)
Installation
MERCEDES C-CLASS EST
MB-CCLS-E-D
COMPONENTS NEEDED:
1 + 8
STEP #1 STEP #2 ENSURE SECURELY FITTED IN PLACE
www.carshades.com | [email protected] PAGE 2 OF 5
POSITION THE SIDE SHADE
A
B

Side Shade (B)
Installation
MERCEDES C-CLASS EST
MB-CCLS-E-D
COMPONENTS NEEDED:
1 + 8
STEP #1 STEP #2
STEP #3 STEP #4 ENSURE SECURELY FITTED IN PLACE
www.carshades.com | [email protected] PAGE 3 OF 5
CL-M04 x 2
CL-M13 x 2
ATTACH CLIPS ON SHADE EDGES
INSERT CLIPS BEHIND INTERIOR TRIM
POSITION THE SIDE SHADE
CL-M04
CL-M04
CL-M13 CL-M13
A
B

Quarter Light Shade
Installation
MERCEDES C-CLASS EST
MB-CCLS-E-D
COMPONENTS NEEDED:
3 + 6
STEP #1 STEP #2
STEP #3 ENSURE SECURELY FITTED IN PLACE
www.carshades.com | [email protected] PAGE 4 OF 5
CL-M02 x 2
ATTACH CLIPS ON SHADE EDGES INSERT CLIPS BEHIND INTERIOR TRIM

Rear Shade
Installation
MERCEDES C-CLASS EST
MB-CCLS-E-D
COMPONENTS NEEDED:
4 + 5
STEP #1 STEP #2
STEP #3 STEP #4
STEP #5 ENSURE SECURELY FITTED IN PLACE
www.carshades.com | [email protected] PAGE 5 OF 5
CL-M12 x 2
CL-M14 x 1
ATTACH CLIPS ON SHADE EDGES
INSERT CLIPS BEHIND INTERIOR TRIM REPEAT THE PROCESS ON OTHER SHADE
POSITION THE REAR SHADE
