Carcomm CMPC-33 HTC Feeler User manual

1
Mobile PDA CradleMobile PDA Cradle
© Copyright Carcomm International BV 2006. Subject to change without previous notice.
All used brandnames are owned by their respective owners
Introduction
WARNINGS
This installation manual has been prepared to provide the basic information needed to
install the CMPC-33. This manual is not intended to be definitive, because there are
different models and types of vehicles which will require different installation work.
The information given is for general guidance only.
The terms of warranty demand that this mobile PDA cradle is installed by an experienced
installer. An end-user should never attempt to install this mobile PDA cradle without
professional assistance as the installation requires special tools and knowledge.
Note: Thoroughly read the manual before beginning the installation procedure.
1. Ensure that the vehicle’s battery is disconnected before you start the installation
procedure and that it remains disconnected during the procedure.
2. Do not smoke or use open flames when working near the vehicle’s fuel system.
3. Ensure that the vehicle’s electrical cables, hydraulic lines, fuel lines and safety
equipment are not damaged during the installation.
4. Ensure that normal control and operation of the vehicle is not obstructed by the
installation,particularly the brakes and steering. Ensure that airbag operation is not
obstructed.
5. Electronic and other sophisticated systems (for example speed control, ABS anti-lock
brake,fuel injection-, navigation- and airbag systems) are relatively immune to
malfunction caused by PDA or GPS receiver. However, should you experience false
operation of these systems or are in any doubt whatsoever as to their functionality,
please consult the vehicle’s dealer.
6. The mobile PDA cradle is suitable for use only in vehicles with a 12V negative
grounding. Use on other supply voltages or alternative polarity will damage the
equipment.
7. The PDA should not be left switched on for extended periods without running the
vehicle’s engine. Failure to comply could drain the vehicle’s battery.
Before starting the installation of the mobile PDA cradle please check if the following
contents are present :
- Mobile PDA Cradle
- Rotating Swivel
- Window Mount
- Suction Cup
- Fuse Holder cable with fuse
- Screw sets
- Surface cleaner
- Manual
www.carcomm.nlwww.carcomm.nl
Safety-Mount® pattern
Compatible devices
HTC Feeler / Amadeus
HTC Sonata / Tornado Tempo
O2 Xphone II / Xphone Iim
O2 XDA Phone
T-Mobile SDA / SDA Music
T-Mobile SDA II
i-mate SP3i / SP5m
Qtek 8020 / 8100 / 8300
Vodafone VDA
CMPC-33CMPC-33 HTC Feeler / Amadeus / Sonata / Tornado Tempo

2
Installing the Mobile PDA Cradle
Connecting a Carcomm Euro-Navigator GPS Receiver.
1. Mount the window suction mount or Safety-Mount® (sold seperataly, instructions
included with the product ) To mount the window mount please clean the window and
place the window mount in your preferred position. Tighten the nut on the base of the
mount to make it stick to the window. Place the window mount in a position where it
doesn’t interfere with the operation of the vehicle.
2. You can screw the cradle to your mounting part directly, or use the included swivel.
If you use a Safety-Mount® it may be necessary to drill holes in the Safety-Mount®
to be able to screw on the cradle with or without swivel. You can use the pattern on the
front page to see the positions where to drill the holes in the Safety-Mount®.
Adjust the swivel to optimize your view on the PDA screen and tighten it well.
3. Align the cradle on the rotating swivel or Safety-Mount® and screw the cradle onto it
with the enclosed screws through the 4 holes. Tighten the screws well.
4. Plug the Cigarette jack into the Cigarette plug adaptor, check if the red light of the
cigarette plug is lighted. Now you are able to charge your PDA in the mobile cradle.
5. Disassemble the Cigarette plug or cut it from the wiring loom and strip the wires.
(The cradle is also available with a fuse in the wiring loom instead of cigarette plug.)
6. Now the red wire (with fuse) needs to be connected to the red wire from the cradle
wiring loom. Then the other side of the fuse’s wire needs to be connected to the
vehicle’s 12V Ignition controlled voltage (+15) to avoid draining the vehicle’s battery
when the vehicle is not used for a long time.
The black wire needs to be connected to the Negative Ground of the vehicle.
7. Slide the PDA into the cradle slowly and make sure the PDA is centred well
above the connector. Then press it over the connector gently.
When removing the PDA from the cradle use one hand to hold the cradle and other
hand to pull the PDA out of it.
The phones supported by this cradle only support Bluetooth GPS Receivers.
When installing a Bluetooth GPS Receiver please follow the instructions supplied
with the product, phone and software to set it up.
For permanent installation and connection to the cars ignition power move on to step 5.
Move on to step 7.
(optional)
Connecting the Carcomm CIGM-918 Quad-Band Inside-Glass Antenna. (optional)
Connect the FME Female plug from the CIGM-918 to the FME Female connector of the
Smartphone cradle. The Antenna should be mounted onto the vehicle’s windscreen with
the VHB tape inside the vehicle.
Mobile PDA CradleMobile PDA Cradle
www.carcomm.nlwww.carcomm.nl
Step 1
Step 2
Step 3
Step 4
Step 7
CMPC-33CMPC-33 HTC Feeler / Amadeus / Sonata / Tornado Tempo
