CARETAKER SENTRY 40911 User manual

Quick Install Guide
Instructions for Installing Your New Personal Emergency Response System
LogicMark Disclaimers and Limited Warranty
COMMUNICATION AND RESPONSE LIMITATIONS: Purchaser acknowledges that signals which are transmitted over telephone lines, or other modes of
communication pass through communication networks wholly beyond the control of LogicMark LLC and are not maintained by LogicMark LLC, and, therefore,
LogicMark LLC shall not be responsible for any equipment or communication failure which prevents transmission signals from reaching your contact list including
emergency 911 operators or damages arising therefrom. Purchaser acknowledges that LogicMark LLC provides no response to the System’s equipment. The
equipment is designed to communicate with the a central station of your choice and LogicMark LLC is not and shall not be responsible for ambulance, police or other
emergency response time or that any response will be provided by the central monitoring station.
TESTING AND SERVICE OF THIS EQUIPMENT: The equipment, once installed, are in the exclusive possession and control of the Purchaser, and it is Purchaser’s sole
responsibility to test the operation of equipment and request warranty service if the equipment is under warranty.
PURCHASER’S EXCLUSIVE REMEDY: Purchaser’s exclusive remedy for LogicMark LLC’s default hereunder is to require LogicMark LLC to repair or replace, at
LogicMark LLC’s option, any equipment or part of the personal emergency alert system which is non-operational during LogicMark LLC’s warranty period.
LIMITATION OF LIABILITY: This equipment is not designed or guaranteed to prevent any loss or injury. This Limited Warranty and Disclaimer of Liability constitutes the
terms of sale and use of the equipment, and if there should arise any liability on the part of LogicMark LLC as a result of any cause whatsoever, regardless of whether
or not such loss, damage, or personal injury was caused by or contributed to by LogicMark LLC’s negligence to any degree or failure to perform any obligation or strict
products liability, such liability will be limited to an amount paid by the Purchaser to LogicMark LLC for the product, or to the sum of $350.00, whichever is greater.
For warranty information, see your dealer for details.
Backup Batteries
* Note the orientation
of the batteries
Base Bottom View
Master ON/OFF
Switch
Two-way Voice Pendant Battery
Charging Port (for optional accessory)
* Note the orientation of the battery
Pendant
Part #40915
Gray Emergency Button
2 Second Push
Red Status LED
Breakaway
Feature
Pendant on Lanyard
Base Top View
Part #40914
Red Emergency button
(Blue)
(Green)
(Red) Blue CareTaker
button
Microphone
(Yellow)
Speaker
Cancel (1 second)
System Check (8 seconds)
Base Back View
Telephone Jacks
Line IN To House
Phone
Programming Switch
Programming Mode “Emergency Call Mode”
Normal Operation
Reset
Power DC 7.5
800 mAh
Code Learn
(Red)
Cellular Accessory Jack
Base Side
View
© LogicMark, LLC v4.1
CaretakerSentry Base Unit - Model 40914
FCC ID: TYD-CS40914
IC: 8471A-CS40914
CaretakerSentry Basic Pendant - Model 40915
FCC ID: TYD-CS40915
IC: 8471A-CS40915
REN 3.7
Pendant on Wrist Strap
CARETAKERSENTRY

Plug Telephone Line and
Power Cord into Wall Jacks
3
CaretakerSentry Step-by-Step Installation
Place Green Rechargeable Batteries in the compartment on the bottom
of the base unit. Make sure to turn ON/OFF switch to ON. You will
hear the announcement “Running on Battery Power.” Unit will do
so until the AC Adapter power supply is plugged in.
Place Batteries in Unit
2
Confirm Accessories in Kit
1
Plug the AC Adapter
power cord into the
power jack and twist 1/4
turn clockwise to lock.
4 Rechargeable AA
Batteries
Telephone Cord
Wrist Strap
(Shown with basic
pendant)
AC Adapter
Lanyard
Test the Unit
4
Place call to Emergency Operator:
a. Push GRAY EMERGENCY button for 2 seconds on Pendant (RED LED
on the pendant should turn ON for 1 second)
b. You should hear a dial tone, dialing and then communication tones
between the CaretakerSentry and central station. Several seconds later
the operator should answer the call
c. Talk normally to the base unit – just like speaker phone
d. At the end of the conversation, the CaretakerAlert should automatically
hang-up – if not, push the CANCEL button for 1 second
Performing a System Test
a. PUSH and HOLD the CANCEL button for 8-10 seconds to enter “System Check”
b. Push GRAY EMERGENCY button for 2 seconds on Pendant
(RED LED on the pendant should turn ON for 1 second)
c. Listen for voice prompt from base unit:
i. “All Systems are OK – Battery is OK” is heard if the system is correctly installed
ii. If any other voice prompt is heard, the unit will describe the problem
d. Push and release the CANCEL button for 1 second to exit Test Mode
(unit will automatically exit in 3 minutes)
e. We recommend that you perform this System Test weekly
Model #40911
(OPTIONAL) Plug
the telephone
into the “To
House Phone”
jack.
CARETAKERSENTRY
