MODEL CDG003 INSTALLATION INSTRUCTIONS
Fixed Size 3 Closer c/w Fig. 6 Bracket
IMPORTANT INFORMATION
Max. Width of Door Max. Mass of Door
SELECTING THE CORRECT DOOR CLOSER TO SUIT DOOR SIZE
Minimum size 3 MUST be used on re doors.
Hold open arms must NOT be used on re doors.
* Minimum size for use on re doors.
Power Size
3* 950mm 60kg
PLEASE LEAVE THESE INSTRUCTIONS WITH THE END USER
Tel: [phone] Fax: [phone] Web: www.carlislebrass.com
CDG003
Fixed Size 3 Closer c/w Fig 6 Bracket
1121 - CPR - AD5232 15
Carlisle Brass Ltd.
Stanclie Street, Mill Hill, Blackburn, BB2 2QR
EN 1154:1996 + A1:2002 + AC:2006
3
Fig. 1 Fitting Fig. 6 Fitting
11384 3
11383

1. Ensure that the door and surrounding frame are in good condition, ush with one another and that the door
closes freely.
2. On the following pages there are tting dimensions for clockwise closing and anti-clockwise closing doors.
Ensure you select the correct details for the doors application and drill pilot holes in door and frame accordingly.
3. Detach the main arm from the threaded section at the knuckle joint, and attach the main arm onto the door
closer pinion at an angle of 90°, then fasten securely with machine bolt provided.
The end of the door closer with adjustement valves must be positioned towards the hinges (in Fig. 1) so ensure
the arm is tted with the correct pinion point.
4. Secure the closer body to the door, ensuring the adjustment valves face the direction of the hinges.
5. Fix the support bracket of the threaded arm section to the frame (long slot furthest from the hinge side).
The nal resting position of the threaded section once attached to the main arm should be 90° from door face.
Adjust the threaded section accordingly. When satised with position, attach both arm sections at the knuckle
joint and tighten bolt on screwed section. Fix dust cover to the bottom pinion.
6. Operate the door and adjust the closing and/or latching speed valves as necessary.
Do not unwind any of the valves completely as this will cause the unit to fail.
MAINTENANCE
INSTALLATION - FIG 1 APPLICATION - ANGLE OF OPENING LIMITED TO 180º
Fig 1 - Standard Application (Door closer tted on pull face of door)
Check that the door closer closes the door correctly and adjust as necessary.
Ensure xing screws are tight and periodically apply light oil or grease to arm pivot joints.
Failure to install this product as per these instructions and dimensions will negate guarantee.
1. Ensure that the door and surrounding frame are in good condition, plumb and that the door closes freely.
2. On the following pages there are tting dimensions for clockwise closing and anti-clockwise closing doors.
Ensure you select the correct details for the doors application and drill pilot holes in door and frame accordingly.
3. Secure the Fig. 6 bracket to the underside of the frame.
4. Detach the main arm from the threaded section at the knuckle joint, and attach the main arm onto the door
closer pinion at an angle of 45° (door opening direction), then fasten securely with machine bolt provided.
The end of the closer without adjustment valves must be positioned towards the hinges (in Fig.6) so ensure the
arm is tted on the correct pinion point.
5. Carefully, fully adjust (clockwise) closing speed valve 1, carefully pull the main arm back by approx 90° so it is
away from the doorside of the closer body. Secure closer body to the door.
6. Fix the support bracket of the threaded arm section to the Fig. 6 bracket (long slot nearest to hinge side). Attach
the threaded arm to the knuckle joint of main arm and adjust the length accordingly, then tighten bolt on
screwed section.
The nal resting position of the main arm should be horizontal with face of door.
Fix dust cover to the bottom pinion.
7. Operate the door and adjust the closing and/or latching speed valves as necessary.
Do not unwind any of the valves completely as this will cause the unit to fail.
INSTALLATION - FIG 6 APPLICATION - ANGLE OF OPENING LIMITED TO 160º
Fig 6 - Parallel Mount Application (Door closer tted on push face of door)
INSTALLATION - FIG 1 APPLICATION - ANGLE OF OPENING LIMITED TO 180º

FIG 1
ANTI-CLOCKWISE CLOSING DOORSET
FIG 1
CLOCKWISE CLOSING DOORSET
16mm
19mm 19mm
16mm
92.5mm
45mm
46mm
165mm
175mm
36mm
19mm
16mm
16mm
19mm
92.5mm
46mm
45mm
165mm
175mm
36mm
No. 1
No. 2
FAST SLOW
90°
No. 1 No. 2 No. 1 No. 2
No. 1 Latching Speed
No. 2 Closing Speed

FIG 6
CLOCKWISE CLOSING DOORSET
FIG 6
ANTI-CLOCKWISE CLOSING DOORSET
45°
35mm
29mm
35mm
45°
29mm
edge of door
under side of frame
230mm
68mm
19mm
19mm
35mm
148mm
No. 1No. 2
No. 1
No. 2
FAST SLOW
No. 1 = Closing Speed
No. 2 = Latching Speed
No. 1
No. 2
FAST SLOW
No. 1 = Closing Speed
No. 2 = Latching Speed
edge of door
68mm 19mm
148mm
230mm
35mm
19mm
No. 1
No. 2
under side of frame
