Broadmore Product Guide
Broadmore
Item Part Number Description
Configured Systems
Chassis
7665-17C 17-slot chassis with redundant -48vdc inputs. Supports up to (12) SAMs, (2) NIMs
7665-17B 17-slot chassis with redundant -48vdc inputs. Supports DS3, NIM, CPU
7665-05AC Chassis, 5-slot APM,110V
7665-05DC Chassis, 5-slot APM,48V
CPU & CPU I/O Modules
7660-007 Module, CPU, Ethernet with SAR
7660-204 Module, CPU with Security Feature
7660-411 I/O CPU - V2
Network Interface Modules (NIM) & NIM I/O Modules
7660-114 NIM, OC-12, SC, SM, Intermediate Reach
7660-113 NIM, OC-12, SC, MM, Premise Reach
7660-116 NIM, OC3 IR, S-Mode
7660-117 NIM, OC3 PR, M-Mode
7660-406 I/O 1 BITS port, one per OC3/OC12 NIM
All products are to be quoted with 120 day lead time.
The Broadmore lines of products offer solutions to aggregate and transport traffic from various user
circuits using ATM technologies in fully redundant, and protected chassises. The traffic from the user
circuits, DS1, DS3, V.35, RS-232, RS-422, RS-449, and RS-530, is aggregated and routed to the
network. The optical network interface cards include OC3c and OC12c.
Form #CF-118 Rev. C. Page 1
10-003
Updated 3/7/03

Item Part Number Description
sOC3 Service Access Modules (SAM) & SAM I/O Modules
7660-084 sOC3 SAM (2 slots)
7660-484 OC3 SAM I/O, 1 per OC3 SAM
sDS3 Service Access Modules (SAM) & SAM I/Os
7660-672 DS3 Structured Module
7660-416 I/O DS3 Structured
uDS3/uE3 Service Access Modules (SAM) & SAM I/O
7660-034 SAM, DS3, Unstructured 3-port
7660-045 SAM, E3, Unstructured 3-port
7660-403 DS3/E3 I/O for 1700 chassis
7660-409 I/O DS3 Working
7660-410 I/O DS3 protection (slot P only)
sT1 Service Access Modules (SAM) & SAM I/O
7660-004 SAM, T1 (DS-1), 8 Port Circuit, Nx64
7660-005 SAM, E-1, 8 Port Circuit, Nx64
7660-404 I/O N X 64 T1 8 RJ48
Multiple Bit Rate (MBR) Service Access Modules
7660-008 SAM, MBR, 4 port, prog, synch or asynch
7660-408 I/O HDB26 4port for MBR
7660-009 SAM, MBR, High Bit Rate
7660-418 I/O MBR High Bit Rate
Cell Bearing Interfaces & I/Os
7660-017 RS-530 Cell Bearing Interface (CBI) SAM & NIM
7660-417 RS-530 CBI IO
7660-020 RS-530 High Speed Serial Interface (HSSI) CBI SAM & NIM
Form #CF-118 Rev. C. Page 2
10-003
Updated 3/7/03

Item Part Number Description
7660-420 RS-530 HSSI I/O
7660-018 DS3 ATM SAM & NIM
7660-419 DS3 ATM IO
Software Features
751-0001-AA Security feature software upgrade
(Product) Accessories
7660-023 Alarm Power Module (17A/B) back fuses (current)
7660-025 I/O Alarm Power Module (rear fuses)
7665-17PS Power Supply/AC
7660-115 P/S Module/AC, 115/230 to 48 VDC
7660-024 Fan Tray (17A/C)
Universal Accessories
7660-501 RS-449 Cable, DB37 DCE
7660-502 EIA-530 Cable, DB25 DCE
7660-503 V.35 Cable, MRAC DCE
7660-504 RS0232 Cable, DB25 DCE
7660-511 RS-449 Cable, DB37 DTE
7660-512 EIA-530 Cable, DB25 DTE
7660-513 V.35 Cable, MRAC DTE
7660-514 RS0232 Cable, DB25 DTE
7660-520 CBI RS530 Cable, Male-Male, 5 feet
7660-521 CBI RS530 Cable, Male-Female, 5 feet
7660-522 CBI RS530 Cable, Female-Female, 5 feet
7660-523 HSSI Cable, HP-50 male SCSI to HP-50 male SCSI, 10ft
7660-524 HBR Adapter, RS422 25 pin 530 DCE to RJ45
7660-530 CBI RS530 Cable, Male-Male, Custom length
7660-531 CBI RS530 Cable, Male-Female, Custom length
7660-532 CBI RS530 Cable, Female-Female, Custom length
Form #CF-118 Rev. C. Page 3
10-003
Updated 3/7/03
