Carrier 24ABA4 Operation manual

24ABA4
BasetSeries 14 Air Conditioner
with PuronrRefrigerant
Product Data
A04030
the environmentally sound refrigerant
Carrier’s Air Conditioners with Puronrrefrigerant provide a
collection of features unmatched by any other family of
equipment. The 24ABA has been designed utilizing Carrier’s
Puron refrigerant. The environmentally sound refrigerant allows
you to make a responsible decision in the protection of the earth’s
ozone layer. Carrier’s air conditioning system with Puron
refrigerant meets the Energy Star rguidelines for energy
efficiency.
INDUSTRY LEADING
FEATURES / BENEFITS
Efficiency
S
14 SEER/11 EER
S Microtube Technologytrefrigeration system
S Indoor air quality accessories available
Sound
S
Sound level as low as 76 dBA
Comfort
S
System supports Thermidistattor standard thermostat
controls
Reliability
S
Puronrrefrigerant -- environmentally sound, won’t
deplete the ozone layer and low lifetime servce cost.
S Front--seating service valves
S Scroll compressor
S Internal pressure relief valve
S Internal thermal overload
S Filter drier
S Balanced refrigeration system for maximum reliability
Durability
WeatherArmortprotection package:
S Solid, Durable sheet metal construction
S Dense wire coil guard
S Baked--on, complete coverage, powder paint
Applications
S
Long--line -- up to 250 feet total equivalent length, up
to 200 feet condenser above evaporator, or up to 80 ft.
evaporator above condenser (See Longline Guide for
more information.)
S Low ambient (down to --20_F) with accessory kit
Warranty
S
5 year limited compressor warranty
S 5 year limited parts warranty

2
MODEL NUMBER NOMENCLATURE
12 3 4 5 6 78 9 10 11 12 13
N N A A A/N N N N A/N A/N A/N N N
24 A B A 4 36 A 0 0 3 0
Product
Series
Product
Family Tier Major Series SEER Cooling Capacity Variations Open Open Voltage Series
24=AC A=RES AC B=Base A=Puron 4=14 SEER A=Standard 0=Not
Defined
0=Not
Defined
3=208/230---1 0=
Original
Series
the environmentally sound refrigerant
REGISTERED
ISO 9001:2000
M
A
N
U
F
A
C
T
U
R
E
R
C
E
R
T
I
F
I
E
D
T
O
A
R
I
A
S
C
O
M
P
L
Y
I
N
G
W
I
T
H
A
R
I
S
T
A
N
D
A
R
D
2
1
0
U
N
I
T
A
R
Y
A
I
R
C
O
N
D
I
T
I
O
N
I
N
G
E
Q
U
I
P
M
E
N
T
STANDARD FEATURES
Feature 18 24 30 36 42 48 60
Puron Refrigerant XXXXXXX
14 SEER XXXXXXX
Scroll Compressor XXXXXXX
DenseWireCoilGuard XXXXXXX
FieldInstalledFilterDrier XXXXXXX
Front Seating Service Valves XXXXXXX
Internal Pressure Relief Valve XXXXXXX
Internal Thermal Overload XXXXXXX
Long Line capability XXXXXXX
Low Ambient capability with Kit XXXXXXX
24ABA4

3
PHYSICAL DATA
UNIT SIZE SERIES 18---30 24---30 30---30 36---30 42---30 48---30 60---30
Operating Weight (lb) 171 185 188 191 237 239 295
Shipping Weight (lb) 199 214 217 225 272 272 330
Compressor Type Scroll
REFRIGERANT Puron®(R--- 410A)
Control TXV (Puron®Hard Shutoff)
Charge (lb) 5.7 7.25 7.1 7.25 10.9 11 13.9
COND FAN Propeller Type, Direct Drive
Air Discharge Vertical
Air Qty (CFM) 2235 2615 3170 3800 3800 3800 4050
Motor HP 1/12 1/10 1/5 1/5 1/5 1/5 1/5
Motor RPM 800 1100 1100 800 800 800 800
COND COIL
Face Area (Sq ft) 19.40 23.71 23.71 22.63 30.18 20.12 30.18
Fins per In. 25 25 25 25 25 20 20
Rows 1 1 1 1 1 2 2
Circuits 3 4 4 5 7 7 7
VALVECONNECT.(In.ID)
Vapor 5/8 5/8 3/4 3/4 7/8 7/8 7/8
Liquid 3/8 3/8 3/8 3/8 3/8 3/8 3/8
REFRIGERANT TUBES* (In. OD)
Vapor (0---50 Ft Tube Length) 5/8 3/4 7/8 1 --- 1 / 8
Vapor(MaxDiameterfor
long--- Line applications 3/4 7/8 1 --- 1 / 8 1 --- 1 / 8
Liquid (0---50 Ft Tube Length) 3/8”
Liquid (For Long--- Line
applications) 3/8”
* For tubing sets between 80 and 200 ft. horizontal or 20 ft. vertical differential, consult the Longline Guideline.
Note: See unit Installation Instruction for proper installation.
VAPOR LINE SIZING AND COOLING CAPACITY LOSS
PURON 1--STAGE AIR CONDITIONER APPLICATIONS
LONG LINE APPLICATION: An application is considered
”Long line” when the total equivalent tubing length exceeds 80 ft
or when there is more than 20 Ft vertical separation between
indoor and outdoor units. These applications require additional
accessories and system modifications for reliable system
operation. The maximum allowable total equivalent length is
250Ft. The maximum vertical separation is 200 Ft when outdoor
unit is above indoor unit, and 50 Ft when the outdoor unit is
below the indoor unit. Refer to Accessory Usage Guideline below
for required accessories. See Long--Line Application Guideline
for required piping and system modifications. Also, refer to the
table below for the acceptable vapor tube diameters based on the
total length to minimize the cooling capacity loss.
Unit Nominal Size
(Btuh)
Acceptable
Vapor Line
Diameters
(In. OD)
Cooling Capacity Loss (%)
Total Equivalent Line Length (ft)
Standard Application Long Line Application Requires Accessories
25 50 80 80+ 100 125 150 175 200 225 250
18000
1StagePuronAC
1/2 1 2 4 4 5 6 7 8 10 11 12
5/8 0 1 1 1 2 2 2 3 3 3 4
24000
1StagePuronAC
5/8 1 1 2 2 3 3 4 4 5 6 6
3/4 0 1 1 1 1 1 1 2 2 2 2
7/8 0 0 0 0 1 1 1 1 1 1 1
30000
1StagePuronAC
5/8 1 2 3 3 4 5 6 7 8 9 9
3/4 0 1 1 1 1 2 2 3 3 3 4
7/8 0 0 1 1 1 1 1 1 1 2 2
36000
1StagePuronAC
5/8 1 3 4 4 5 7 8 9 11 12 13
3/4 1 1 2 2 2 3 3 3 4 4 5
7/8 0 1 1 1 1 1 2 2 2 2 3
42000
1StagePuronAC
3/4 1 1 2 2 3 3 4 5 5 6 7
7/8 0 1 1 1 1 2 2 2 3 3 3
11/8 0 0 0 0 0 1 1 1 1 1 1
48000
1StagePuronAC
3/4 1 2 3 3 3 4 5 6 7 8 8
7/8 0 1 1 1 2 2 3 3 3 4 4
11/8 0 0 0 0 1 1 1 1 1 1 1
60000
1StagePuronAC
3/4 1 3 4 4 5 6 8 9 10 11 13
7/8 1 1 2 2 3 3 4 4 5 6 6
11/8 0 0 1 1 1 1 1 1 1 2 2
Standard Length = 80 Ft or less total equivalvent length
Applications in this area are long line. Accessories are required as shown recommended on Long Line Application Guidelines
Applications in this area may have height restrictions that limit allowable total equivalent length, when outdoor unit is below indoor unit See Long Line Application
Guidelines
24ABA4

4
ACCESSORY THERMOSTATS
THERMOSTAT / SUBBASE PKG. DESCRIPTION
TSTATCCPRH01--- B Thermidistat Control --- Programmable / Non ---Programmable Thermostat with Humidity control
TSTATCCPAC01---B T h e r m o s t a t --- A u t o C h a n g e o v e r, 7 --- D a y P r o g r a m m a b l e , _F/_C , 1 --- S t a g e H e a t , 1 --- S t a g e C o o l
TSTATCCNAC01--- C T h e r m o s t a t --- A u t o C h a n g e o v e r, N o n --- P r o g r a m m a b l e , _F/_C , 1 --- S t a g e H e a t , 1 --- S t a g e C o o l
TSTATCCBAC01--- B Builder’s Thermostat --- Manual Changeover, Non---Programmable, _F/_C , 1 --- S t a g e H e a t , 1 --- S t a g e C o o l
TSTATCCSEN01--- B Outdoor Air Temperature Sensor
TSTATXXBBP01 Backplate for Builder’s Thermostat
TSTATXXNBP01 Backplate for Non ---Programmable Thermostat
TSTATXXPBP01 Backplate for Programmable Thermostat
TSTATXXCNV10 Thermostat Conversion Kit (4 to 5 wires) --- 10 Pack
ACCESSORIES
KIT NUMBER DESCRIPTION 18 --- 30 24 --- 30 30 --- 30 36 --- 30 42 --- 30 48 --- 30 60 --- 30
KAAFT0101AAA FREEZE THERMOSTAT XXXXXXX
KAATD0101TDR TIME DELAY RELAY XXXXXXX
KAAWS0101AAA WINTER START XXXXXXX
KSALA0301410 LOW AMBIENT PSW XXXXXXX
KSALA0601AAA MOTORMASTER 230V XXXXXXX
HC32GE234 MOTOR FAN BALL BEARING X
HC34GE239 MOTOR FAN BALL BEARING X X
HC40GE226 MOTOR FAN BALL BEARING X X
HC38GE219 MOTOR FAN BALL BEARING X
HC40GE228 MOTOR FAN BALL BEARING X
KSAHS1701AAA HARD START (CAP / RELAY) XXXXXXX
KSACY0101AAA CYCLE PROTECTOR XXXXXXX
KSASF0101AAA SUPPORT FEET XXXXXXX
KAACS0201PTC START ASSIST PTC XXXXXXX
KAACH1201AAA CRANKCASE HTR XXX
KAACH1401AAA CRANKCASE HTR XXXX
KSATX0201PUR TXV PURON HSO XXX
KSATX0301PUR TXV PURON HSO X X
KSATX0401PUR TXV PURON HSO X
KSATX0501PUR TXV PURON HSO X
KSASH0601COP SOUND HOOD XXXXXX
KSASH2101COP SOUND HOOD X
KAALP0301PUR LOW PRESSURE SWITCH XXXXXXX
KAAHI0401PUR HIGH PRESSURE SWITCH XXXXXXX
x = Accessory
ACCESSORY USAGE GUIDELINE
ACCESSORY
REQUIRED FOR LOW--- AMBIENT
COOLING APPLICATIONS
(Below 55°F)
REQUIRED FOR
LONG LINE
APPLICATIONS*
(Over 80 Ft.)
REQUIRED FOR
SEA COAST
APPLICATIONS
(Within 2 miles)
Crankcase Heater Yes Yes No
Evaporator Freeze Thermostat Yes No No
Accumulator No No No
Compressor Start Assist Capacitor and Relay Yes Yes No
Motor Master
®
Control or Low---ambient
Pressure Switch Yes No No
Support Feet Recommended No Recommended
Liquid Line Solenoid Valve No S e e L o n g --- L i n e A p -
plication Guideline No
Ball Bearing Fan Motor Yes{No No
* For tubing line sets between 80 and 200 ft. and/or 20 ft. vertical differntial, refer to Residential Split---System Longline Application Guideline.
{Required for Low---Ambient Controller (full modulation feature) and MotorMasterrControl only.
24ABA4

5
Accessory Description and Usage (Listed Alphabetically)
1. Ball--Bearing Fan Motor
A fan motor with ball bearings which permits speed reduction
while maintaining bearing lubrication.
Usage Guideline:
Required on all units when MotorMasterr—
2. Compressor Start Assist -- Capacitor and Relay
Start capacitor and relay gives a ”hard” boost to compressor
motor at each start up.
Usage Guideline:
Required for reciprocating compressors in the
following applications:
Long line
Low ambient cooling
Hard shut off expansion valve on indoor coil
Liquid line solenoid on indoor coil
Required for single--phase scroll compressors in the
following applications:
Long line
Low ambient cooling
Suggested for all compressors in areas with a history of
low voltage problems.
3. Compressor Start Assist — PTC Type
Solid state electrical device which gives a ”soft” boost to the
compressor at each start--up.
Usage Guideline:
Suggested in installations with marginal power supply.
4. Crankcase Heater
An electric resistance heater which mounts to the base of the
compressor to keep the lubricant warm during off cycles.
Improves compressor lubrication on restart and minimizes the
chance of liquid slugging.
Usage Guideline:
Required in low ambient cooling applications.
Required in long line applications.
5. Cycle Protector
The cycle protector is designed to prevent compressor short
cycling. This control provides an approximate 5--minute delay
after power to the compressor has been interrupted for any
reason, including power outage, protector control trip, thermostat
jiggling, or normal cycling.
Suggested in all commercial applications.
6. Evaporator Freeze Thermostat
An SPST temperature--actuated switch that stops unit operation
when evaporator reaches freeze--up conditions.
Usage Guideline:
Required when low ambient kit has been added.
7. Low--Ambient Pressure Switch Kit
A long life pressure switch which is mounted to outdoor unit
service valve. It is designed to cycle the outdoor fan motor in
order to maintain head pressure within normal operating limits
(approximately 100 psig to 225 psig). The control will maintain
working head pressure at low--ambient temperatures down to 0_F
when properly installed.
Usage Guideline:
A Low--Ambient Pressure Switch or MotorMasterr
Low--Ambient Controller must be used when cooling
operation is used at outdoor temperatures below 55_F
(12.8_C).
8. MotorMasterrLow--Ambient Controller
A fan--speed control device activated by a temperature sensor,
designed to control condenser fan motor speed in response to the
saturated, condensing temperature during operation in cooling
mode only. For outdoor temperatures down to --20_F (--28.9_C),
it maintains condensing temperature at 100_F±10_F (37.8_C±
-- 1 2 _C).
Usage Guideline:
A MotorMasterrLow Ambient Controller or
Low--Ambient Pressure Switch must be used when
cooling operation is used at outdoor temperatures
below 55_F (12.8_C).
Suggested for all commercial applications.
9. Outdoor Air Temperature Sensor
Designed for use with Carrier Thermostats listed in this
publication. This device enables the thermostat to display the
outdoor temperature. This device also is required to enable
special thermostat features such as auxiliary heat lock out.
Usage Guideline:
Suggested for all Carrier thermostats listed in this
publication.
10. Sound Hood
Wraparound sound reducing cover for the compressor. Reduces
the sound level up to 2 dBA.
Usage Guideline:
Suggested when unit is installed closer than 15 ft to
quiet areas, bedrooms, etc.
Suggested when unit is installed between two houses less
than 10 ft apart.
11. Support Feet
Four stick--on plastic feet that raise the unit 4 in. above the
mounting pad. This allows sand, dirt, and other debris to be
flushed from the unit base, minimizing corrosion.
Usage Guideline:
Suggested in the following applications:
Coastal installations.
Windy areas or where debris is normally circulating.
Rooftop installations.
For improved sound ratings.
12. Thermostatic Expansion Valve (TXV)
A modulating flow--control valve which meters refrigerant liquid
flow rate into the evaporator in response to the superheat of the
refrigerant gas leaving the evaporator.
Kit includes valve, adapter tubes, and external equalizer tube.
Hard shut off types are available.
NOTE: When using a hard shut off TXV with single phase
reciprocating compressors, a Compressor Start Assist Capacitor
and Relay is required.
Usage Guideline:
Required to achieve ARI ratings in certain equipment
combinations. Refer to combination ratings.
Hard shut off TXV or LLS required in air conditioner
long line applications.
Required for use on all zoning systems.
24ABA4

6
Accessory Description and Usage (Listed Alphabetically) -- Continued
13. Time--Delay Relay
An SPST delay relay which briefly continues operation of indoor
blower motor to provide additional cooling after the compressor
cycles off.
NOTE: Most indoor unit controls include this feature. For those
that do not, use the guideline below.
Usage Guideline:
For improved efficiency ratings for certain
combinations of indoor and outdoor units. Refer to
ARI Unitary Directory.
14. Winter Start Control
This control is designed to alleviate nuisance opening of the
low--pressure switch by bypassing it for the first 3 minutes of
operation.
ELECTRICAL DATA
UNIT SIZE V/PH
OPER
VOLTS* COMPR FAN MCA
MIN WIRE
SIZE{
60°C
MIN WIRE
SIZE{
75°C
MAX
LENGTH
(FT)}
60°C
MAX
LENGTH
(FT)}
75°C
MAX FUSE**
or CKT BRK
AMPS
MAX MIN LRA RLA FLA
18
208/230/1 253 197
48.0 9.0 0.5 11.7 14 14 67 64 15
24 58.3 13.5 0.7 17.6 14 14 45 43 25
30 73.0 14.1 1.1 18.7 14 14 42 40 30
36 79.0 16.7 1.2 22.0 12 12 57 54 35
42 112.0 17.9 1.2 23.6 10 10 85 81 40
48 117.0 21.8 1.2 28.4 10 10 70 67 40
60 134.0 26.4 1.2 34.2 8 8 91 86 50
* Permissible limits of the voltage range at which the unit will operate satisfactorily
{If wire is applied at ambient greater than 30˚C(86˚F), consult table 310 ---16 of the NEC (ANSI/NFPA 70). The ampacity of non ---metallic---sheathed cable
(NM), trade name ROMEX, shall be that of 60˚C (140˚F) conditions, per the NEC (ANSI/NFPA 70) Article 336---26. If other than uncoated (no---plated), 60
or 75˚C (140 or 167˚C) insulation, copper wire (solid wire for 10 AWG or smaller, stranded wire for larger than 10 AWG) is used, consult applicable tables
of the NEC (ANSI/NFPA 70).
}Length shown is as measured 1 way along wire path between unit and service panel for voltage drop not to exceed 2%.
** Time---Delay fuse.
FLA --- F u l l L o a d A m p s
LRA --- L o c k e d R o t o r A m p s
MCA --- Minimum Circuit Amps
RLA ---RatedLoadAmps
NOTE: Control circuit is 24---V on all units and requires external power source. Copper wire must be used from service disconnect to unit.
All motors/compressors contain internal overload protection.
A--WEIGHTED SOUND POWER (DBA)
UNIT SIZE STANDARD
RATING
TYPICAL OCTAVE BAND SPECTRUM (without tone adjustment)
125 250 500 1000 2000 4000 8000
18 76 56.0 60.0 65.0 72.0 65.0 60.5 53.5
24 76 52.5 62.5 66.0 69.5 66.5 62.0 57.0
30 76 53.5 64.5 69.0 70.0 68.5 66.0 59.5
36 76 52.0 60.0 65.5 69.5 64.0 63.0 56.0
42 77 50.5 58.5 63.0 72.0 66.0 62.5 57.5
48 78 58.0 64.5 66.5 69.0 65.0 63.5 59.0
60 78 53.5 67.0 65.5 67.5 65.5 63.0 60.0
A--WEIGHTED SOUND POWER (DBA) WITH ACCESSORY SOUND HOOD
UNIT SIZE STANDARD
RATING
TYPICAL OCTAVE BAND SPECTRUM (without tone adjustment)
125 250 500 1000 2000 4000 8000
18 74 56.0 60.0 65.0 69.0 63.0 60.0 52.5
24 74 52.0 62.0 66.5 68.5 66.0 61.0 56.5
30 75 53.5 64.5 69.0 69.5 68.0 65.5 59.0
36 75 52.0 62.0 65.5 67.5 63.0 61.0 53.5
42 75 51.0 60.0 62.5 68.5 64.0 61.0 55.0
48 75 59.5 63.5 66.5 67.5 64.0 62.0 55.5
60 75 54.0 63.5 65.0 66.0 63.5 61.0 57.0
CHARGING SUBCOOLING (TXV--TYPE EXPANSION DEVICE)
UNIT SIZE ---SERIES REQUIRED SUBCOOLING (_F)
18---30 10
24---30 11
30---30 8
36---30 10
42---30 12
48---30 9
60---30 9
24ABA4

7
DIMENSIONS
UNIT SERIES ELECTRICAL
CHARACTERISTICS A B C D E F G H J K L M N P
24ABA418 0 X 0 0 0 31 3/16” 35 3/4” 33/4” 5/8” 6 9/16” 24 11/16” 91/8” 5/16” 3” 2 13/16” 1/2” 16 1/4” 16” 16 5/8” 24ABA424 0 X 0 0 0 31 3/16” 42 1/2” 33/4” 5/8” 6 9/16” 24 11/16” 91/8” 5/16” 3” 2 13/16” 1/2” 16” 16” 19” 24ABA430 0 X 0 0 0 31 3/16” 42 1/2” 33/4” 3/4” 6 9/16” 24 11/16” 91/8” 5/16” 3” 2 13/16” 1/2” 14 7/8” 15 1/4” 19 3/8” 24ABA436 0 X 0 0 0 35” 35 3/4” 33/4” 3/4” 6 9/16” 28 7/16” 91/8” 5/16” 3” 2 13/16” 1/2” 18 1/4” 18 1/2” 17 1/2” 24ABA442 0 X 0 0 0 35” 45 5/16” 37/8” 7/8” 6 9/16” 28 7/16” 91/8” 5/16” 3” 2 15/16” 5/8” 18 3/4” 17” 20 7/8” 24ABA448 0 X 0 0 0 35” 32 5/16” 37/8” 7/8” 6 9/16” 28 7/16” 91/8” 5/16” 3” 2 15/16” 5/8” 17 3/4” 18 3/4” 15 1/2” 24ABA460 0 X 0 0 0 35” 45 15/16” 37/8” 7/8” 6 9/16” 28 7/16” 91/8” 5/16” 3” 2 15/16” 5/8” 17 7/8” 18 5/8” 20 1/4”
2 0 8 --- 2 3 0 --- 1 --- 6 0
2 3 0 --- 1 --- 6 0
208/230--- 3---60
4 6 0 --- 3 --- 6 0
X=YES 0=NO 1. Allow 30” clearance to service side of unit, 48” above unit, 6” on one side, 12”
on remaining side, and 24” between units for proper airflow.
2. Minimum outdoor operating ambient in cooling mode is 55 _F, max. 125_F. 3. Series designation is the 13th position of the unit model number. 4. Center of gravity 5. For hurricane tie downs, contact distributor for details and PE Certification
(Professional Engineer), if required.
UNIT SIZE MINIMUM MOUNTING
PAD DIMENSIONS
—26” X 26”
18, 24, 30, 31 1/2” X 31 1/2”
36, 42, 48, 60 35” X 35”
24ABA4

8
COMBINATION RATINGS
Unit Size
--- S e r i e s Indoor Model To t a l C a p . B T U H Factory Supplied Enhancement
SEER
EER Furnace Model
Standard
Rating TDR†
18---30
*CAP**2414A** 18,000 TXV 14.00 11.5
CAP**1814A** 17,600 TDR&TXV 15.00 12.50 58CV(A,X)070---12
CAP**1814A** 17,800 TXV 13.50 11.20
CAP**2414A** 17,900 TDR&TXV 15.00 13.00 58CV(A,X)070---12
CAP**2417A** 17,900 TDR&TXV 15.00 13.00 58CV(A,X)090---16
CAP**2417A** 17,900 TDR&TXV 15.00 13.00 58MVB060---14
CAP**2417A** 18,000 TXV 14.00 11.50
CNPF*2418A** 18,000 TXV 13.50 11.20
CNPH*2417A** 17,900 TDR&TXV 15.00 13.00 58CV(A,X)070---12
CNPH*2417A** 17,900 TDR&TXV 15.00 13.00 58CV(A,X)090---16
CNPH*2417A** 17,900 TDR&TXV 15.00 13.00 58MVB040---14
CNPH*2417A** 17,900 TDR&TXV 15.00 13.00 58MVB060---14
CNPH*2417A** 17,900 TDR&TXV 15.00 13.00 58MVB080---14
CNPH*2417A** 18,000 TXV 13.50 11.20
CNPV*1814A** 17,600 TDR&TXV 15.00 12.50 58CV(A,X)070---12
CNPV*1814A** 17,800 TXV 13.50 11.20
CNPV*2414A** 17,900 TDR&TXV 15.00 13.00 58CV(A,X)070---12
CNPV*2414A** 18,000 TXV 14.00 11.50
CNPV*2417A** 17,900 TDR&TXV 15.00 13.00 58CV(A,X)090---16
CNPV*2417A** 17,900 TDR&TXV 15.00 13.00 58MVB060---14
CNPV*2417A** 18,000 TXV 13.50 11.20
CSPH*2412A** 17,900 TDR&TXV 15.00 13.00 58CV(A,X)070---12
CSPH*2412A** 17,900 TDR&TXV 15.00 13.00 58CV(A,X)090---16
CSPH*2412A** 17,900 TDR&TXV 15.00 13.00 58MVB040---14
CSPH*2412A** 17,900 TDR&TXV 15.00 13.00 58MVB060---14
CSPH*2412A** 17,900 TDR&TXV 15.00 13.00 58MVB080---14
CSPH*2412A** 18,000 TXV 14.00 11.50
FF1ENP018 17,800 TDR&TXV 13.50 11.20
FF1ENP024 18,000 TDR&TXV 13.50 11.20
FV4BNF002 18,200 TDR&TXV 15.00 13.20
FX4CNF018 18,000 TDR&TXV 15.00 13.00
FX4CNF024 18,300 TDR&TXV 15.00 13.00
FY4ANF018 17,800 TDR&TXV 13.50 11.20
FY4ANF024 17,900 TDR&TXV 13.50 11.20
24---30
CAP**2414A** 23,600 TXV 14.00 11.50
CAP**2414A** 23,200 TDR&TXV 15.00 12.50 58CV(A,X)070---12
CAP**2417A** 23,600 TXV 14.00 11.50
CAP**2417A** 23,400 TDR&TXV 15.00 12.50 58MVB060---14
*CAP**3014A** 24,000 TXV 14.00 11.5
CAP**3014A** 24,400 TDR&TXV 15.00 13.00 58CV(A,X)070---12
CAP**3017A** 24,000 TXV 14.00 11.50
CAP**3017A** 24,400 TDR&TXV 15.00 13.00 58MVB060---14
CAP**3017A** 24,400 TDR&TXV 15.00 13.00 58CV(A,X)090---16
CNPV*2414A** 23,600 TXV 14.00 11.50
CNPV*2414A** 23,200 TDR&TXV 15.00 12.50 58CV(A,X)070---12
CNPV*2417A** 23,600 TXV 14.00 11.50
CNPV*2417A** 23,400 TDR&TXV 15.00 12.50 58MVB060---14
CNPV*2417A** 23,600 TDR&TXV 15.00 12.50 58CV(A,X)090---16
CNPV*3014A** 24,000 TXV 14.00 11.50
CNPV*3014A** 24,400 TDR&TXV 15.00 12.50 58CV(A,X)070---12
CNPV*3017A** 24,000 TXV 14.00 11.50
CNPV*3017A** 24,400 TDR&TXV 15.00 13.00 58MVB060---14
CNPV*3017A** 24,400 TDR&TXV 15.00 13.00 58CV(A,X)090---16
See notes on pg. 13
24ABA4

9
COMBINATION RATINGS -- CONTINUED
U n i t S i z e ---
Series Indoor Model To t a l C a p . B T U H Factory Supplied Enhancement
SEER
EER Furnace Model
Standard
Rating TDR†
24---30
CNPH*2417A** 23,600 TXV 14.00 11.50
CNPH*2417A** 23,400 TDR&TXV 15.00 12.50 58MVB040---14
CNPH*2417A** 23,400 TDR&TXV 15.00 12.50 58CV(A,X)070---12
CNPH*3017A** 24,000 TXV 14.00 11.50
CNPH*3017A** 24,400 TDR&TXV 15.00 13.00 58MVB040---14
CNPH*3017A** 24,400 TDR&TXV 15.00 13.00 58CV(A,X)070---12
CNPF*2418A** 23,600 TXV 14.00 11.50
CSPH*2412A** 23,600 TXV 14.00 11.50
CSPH*2412A** 23,200 TDR&TXV 15.00 12.50 58MVB040---14
CSPH*2412A** 23,200 TDR&TXV 15.00 12.50 58CV(A,X)070---12
CSPH*2412A** 23,200 TDR&TXV 15.00 13.00 58CV(A,X)110---20
CSPH*2412A** 23,200 TDR&TXV 15.00 13.00 58CV(A,X)135---22
CSPH*2412A** 23,200 TDR&TXV 15.00 13.00 58CV(A,X)155---22
CSPH*3012A** 24,000 TXV 14.00 11.50
CSPH*3012A** 24,400 TDR&TXV 15.00 13.00 58MVB040---14
CSPH*3012A** 24,400 TDR&TXV 15.00 13.00 58MVB060---14
CSPH*3012A** 24,400 TDR&TXV 15.00 13.00 58MVB080---14
CSPH*3012A** 24,400 TDR&TXV 15.00 13.00 58MVB080---20
CSPH*3012A** 24,400 TDR&TXV 15.00 13.00 58MVB100---20
CSPH*3012A** 24,400 TDR&TXV 15.00 13.00 58MVB120---20
CSPH*3012A** 24,400 TDR&TXV 15.00 13.00 58CV(A,X)070---12
CSPH*3012A** 24,400 TDR&TXV 15.00 13.00 58CV(A,X)090---16
CSPH*3012A** 24,400 TDR&TXV 15.00 13.00 58CV(A,X)110---20
CSPH*3012A** 24,400 TDR&TXV 15.00 13.00 58CV(A,X)135---22
CSPH*3012A** 24,400 TDR&TXV 15.00 13.00 58CV(A,X)155---22
FY4ANF024 23,400 TDR&TXV 13.50 11.20
FY4ANF030 23,600 TDR&TXV 14.00 11.50
FX4CNF024 23,800 TDR&TXV 15.00 12.50
FX4CNF030 24,000 TDR&TXV 15.00 13.00
FF1ENP024 23,400 TDR&TXV 13.50 11.20
FF1ENP030 23,400 TDR&TXV 13.50 11.20
FV4BNF002 23,800 TDR&TXV 15.00 13.00
FV4BNF003 23,800 TDR&TXV 15.00 13.20
30---30
*CAP**3014A** 29,000 TXV 14.00 12
CAP**3014A** 28,800 TDR&TXV 15.00 12.50 58CV(A,X)070 ---12
CAP**3017A** 29,000 TXV 14.00 11.50
CAP**3017A** 28,800 TDR&TXV 15.00 12.50 58MVB060---14
CAP**3017A** 28,800 TDR&TXV 15.00 13.00 58CV(A,X)090 ---16
CAP**3614A** 28,200 TXV 14.00 11.50
CAP**3614A** 27,800 TDR&TXV 15.00 12.50 58CV(A,X)070 ---12
CAP**3617A** 29,200 TXV 14.00 11.50
CAP**3617A** 28,800 TDR&TXV 15.00 13.00 58MVB060---14
CAP**3617A** 29,000 TDR&TXV 15.00 13.00 58CV(A,X)090 ---16
CAP**3621A** 29,200 TXV 14.00 11.50
CAP**3621A** 29,000 TDR&TXV 15.00 12.50 58MVB080---14
CAP**3621A** 29,000 TDR&TXV 15.00 13.00 58CV(A,X)110 ---20
CNPV*3014A** 29,000 TXV 14.00 11.50
CNPV*3014A** 28,800 TDR&TXV 15.00 12.50 58CV(A,X)070---12
CNPV*3017A** 29,000 TXV 14.00 11.50
CNPV*3017A** 28,800 TDR&TXV 15.00 12.50 58MVB060---14
CNPV*3017A** 28,800 TDR&TXV 15.00 12.50 58CV(A,X)090---16
CNPV*3617A** 29,200 TXV 14.00 11.50
CNPV*3617A** 28,800 TDR&TXV 15.00 12.50 58MVB060---14
CNPV*3617A** 29,000 TDR&TXV 15.00 12.50 58CV(A,X)090---16
CNPV*3621A** 29,200 TXV 14.00 11.50
CNPV*3621A** 29,000 TDR&TXV 15.00 12.50 58MVB080---14
CNPV*3621A** 29,000 TDR&TXV 15.00 12.50 58CV(A,X)110---20
See notes on pg. 13
24ABA4

10
COMBINATION RATINGS -- CONTINUED
U n i t S i z e ---
Series Indoor Model To t a l C a p . B T U H Factory Supplied Enhancement
SEER
EER Furnace Model
Standard
Rating TDR†
30---30
CNPH*3017A** 29,000 TXV 14.00 11.50
CNPH*3017A** 28,800 TDR&TXV 15.00 12.50 58MVB040---14
CNPH*3017A** 28,800 TDR&TXV 15.00 12.50 58MVB120---20
CNPH*3017A** 28,800 TDR&TXV 15.00 12.50 58CV(A,X)070---12
CNPH*3617A** 29,200 TXV 14.00 11.50
CNPH*3617A** 28,800 TDR&TXV 15.00 12.50 58MVB040---14
CNPH*3617A** 28,800 TDR&TXV 15.00 12.50 58CV(A,X)070---12
CNPF*3618A** 29,200 TXV 14.00 11.50
CSPH*3012A** 29,000 TXV 14.00 11.50
CSPH*3012A** 28,800 TDR&TXV 15.00 12.50 58MVB040---14
CSPH*3012A** 28,800 TDR&TXV 15.00 12.50 58CV(A,X)070---12
CSPH*3612A** 29,200 TXV 14.00 11.50
CSPH*3612A** 28,800 TDR&TXV 15.00 13.00 58MVB040---14
CSPH*3612A** 28,800 TDR&TXV 15.00 13.00 58CV(A,X)070---12
FY4ANF030 28,800 TDR&TXV 14.00 11.50
FY4ANF036 29,000 TDR&TXV 14.00 11.50
FX4CNF030 29,200 TDR&TXV 15.00 12.50
FX4CN(B,F)036 29,600 TDR&TXV 15.00 12.50
FF1ENP030 28,600 TDR&TXV 14.00 11.50
FF1ENP036 29,200 TDR&TXV 14.00 11.50
FV4BNF002 29,000 TDR&TXV 15.00 12.50
FV4BNF003 29,200 TDR&TXV 15.00 13.00
FV4BNF005 30,000 TDR&TXV 15.00 13.20
36---30
CAP**3614A** 35,000 TXV 14.00 11.50
CAP**3614A** 35,000 TDR&TXV 14.50 11.70 58CV(A,X)070---12
CAP**3617A** 35,400 TXV 14.00 11.50
CAP**3617A** 35,000 TDR&TXV 15.00 12.00 58MVB060---14
CAP**3617A** 35,000 TDR&TXV 15.00 12.00 58CV(A,X)090---16
CAP**3621A** 35,400 TXV 14.00 11.50
CAP**3621A** 35,000 TDR&TXV 14.50 11.70 58MVB080---14
CAP**3621A** 35,000 TDR&TXV 15.00 12.00 58MVB080---20
CAP**3621A** 35,200 TDR&TXV 15.00 12.00 58MVB100---20
CAP**3621A** 35,200 TDR&TXV 15.00 12.00 58CV(A,X)110---20
*CAP**4221A** 35,800 TXV 14.00 11.5
CAP**4221A** 35,200 TDR&TXV 14.50 11.70 58MVB080---14
CAP**4221A** 35,400 TDR&TXV 15.00 12.00 58MVB080---20
CAP**4221A** 35,400 TDR&TXV 15.00 12.00 58MVB100---20
CAP**4221A** 35,400 TDR&TXV 15.00 12.00 58CV(A,X)110---20
CAP**4224A** 35,800 TXV 14.00 11.50
CAP**4224A** 35,200 TDR&TXV 15.00 12.00 58MVB040---14
CAP**4224A** 35,400 TDR&TXV 15.00 12.00 58MVB120---20
CAP**4224A** 35,400 TDR&TXV 15.00 12.00 58CV(A,X)135---22
CNPV*3617A** 35,400 TXV 14.00 11.50
CNPV*3617A** 35,000 TDR&TXV 14.50 11.70 58MVB060---14
CNPV*3617A** 35,000 TDR&TXV 15.00 12.00 58CV(A,X)090---16
CNPV*3621A** 35,400 TXV 14.00 11.50
CNPV*3621A** 34,800 TDR&TXV 14.50 11.70 58MVB080---14
CNPV*3621A** 35,000 TDR&TXV 15.00 12.00 58CV(A,X)110---20
CNPV*4221A** 35,800 TXV 14.00 11.50
CNPV*4221A** 35,400 TDR&TXV 15.00 12.00 58MVB080---14
CNPV*4221A** 35,600 TDR&TXV 15.00 13.00 58CV(A,X)110---20
CNPH*3617A** 35,400 TXV 14.00 11.50
CNPH*3617A** 34,800 TDR&TXV 14.50 11.70 58MVB040---14
CNPH*3617A** 35,000 TDR&TXV 14.50 11.70 58CV(A,X)070---12
CNPH*4221A** 35,800 TXV 14.00 11.50
CNPH*4221A** 35,400 TDR&TXV 15.00 12.00 58MVB040---14
CNPH*4221A** 35,400 TDR&TXV 15.00 12.00 58CV(A,X)070---12
CNPH*4221A** 35,600 TDR&TXV 15.00 13.00 58CV(A,X)135---22
See notes on pg. 13
24ABA4

11
COMBINATION RATINGS -- CONTINUED
U n i t S i z e ---
Series Indoor Model To t a l C a p . B T U H Factory Supplied Enhancement
SEER
EER Furnace Model
Standard
Rating TDR†
36---30
CNPH*4221A** 35,600 TDR&TXV 15.00 13.00 58CV(A,X)155---22
CNPF*3618A** 35,400 TXV 14.00 11.50
CSPH*3612A** 36,200 TXV 14.00 11.50
CSPH*3612A** 35,600 TDR&TXV 15.00 12.00 58MVB040---14
CSPH*3612A** 35,800 TDR&TXV 15.00 12.00 58CV(A,X)070---12
CSPH*4212A** 36,600 TXV 14.00 11.50
CSPH*4212A** 35,800 TDR&TXV 15.00 12.00 58MVB040---14
CSPH*4212A** 36,000 TDR&TXV 15.00 12.00 58MVB120---20
CSPH*4212A** 36,000 TDR&TXV 15.00 12.00 58CV(A,X)070---12
FY4ANF036 34,800 TDR&TXV 14.00 11.50
FY4ANF042 36,000 TDR&TXV 14.00 11.50
FX4CN(B,F)036 36,000 TDR&TXV 15.00 12.00
FX4CN(B,F)042 36,600 TDR&TXV 15.00 12.00
FF1ENP036 35,000 TDR&TXV 14.00 11.50
FV4BNF002 35,200 TDR&TXV 15.00 12.00
FV4BNF003 35,400 TDR&TXV 15.00 12.00
FV4BNF005 36,600 TDR&TXV 15.00 13.00
42---30
CAP**4221A** 39,500 TXV 14.00 11.20
CAP**4221A** 39,000 TDR&TXV 14.20 11.50 58MVB080---14
CAP**4221A** 40,000 TDR&TXV 14.20 11.50 58MVB080---20
CAP**4221A** 40,000 TDR&TXV 14.20 11.50 58MVB100---20
CAP**4221A** 40,000 TDR&TXV 14.50 12.00 58CV(A,X)110---20
CAP**4224A** 39,500 TXV 14.00 11.50
CAP**4224A** 39,500 TDR&TXV 14.50 12.00 58MVB040---14
CAP**4224A** 40,000 TDR&TXV 14.50 12.00 58MVB120---20
CAP**4224A** 40,000 TDR&TXV 14.50 12.00 58CV(A,X)135---22
CAP**4817A** 41,000 TXV 14.00 11.50
CAP**4817A** 40,000 TDR&TXV 15.00 12.50 58MVB060---14
CAP**4817A** 41,000 TDR&TXV 14.50 12.00 58CV(A,X)090---16
*CAP**4821A** 40,500 TXV 14.00 11.5
CAP**4821A** 40,000 TDR&TXV 15.00 13.20 58MVB080---14
CAP**4821A** 40,000 TDR&TXV 15.00 13.20 58CV(A,X)110---20
CAP**4824A** 40,500 TXV 14.00 12.00
CAP**4824A** 39,500 TDR&TXV 15.00 13.20 58MVB040---14
CAP**4824A** 41,000 TDR&TXV 15.00 13.20 58CV(A,X)135---22
CNPV*4221A** 40,000 TXV 14.00 11.50
CNPV*4221A** 39,500 TDR&TXV 14.50 12.00 58MVB080---14
CNPV*4221A** 40,500 TDR&TXV 15.00 12.50 58CV(A,X)110---20
CNPV*4821A** 40,500 TXV 14.00 11.50
CNPV*4821A** 40,000 TDR&TXV 14.50 12.00 58MVB080---14
CNPV*4821A** 41,000 TDR&TXV 14.50 12.00 58CV(A,X)110---20
CNPV*4824A** 40,500 TXV 14.00 12.00
CNPV*4824A** 40,000 TDR&TXV 14.50 12.00 58MVB040---14
CNPV*4824A** 41,000 TDR&TXV 15.00 12.50 58CV(A,X)135---22
CNPH*4221A** 40,000 TXV 14.00 12.50
CNPH*4221A** 40,000 TDR&TXV 14.50 12.00 58MVB040---14
CNPH*4221A** 39,500 TDR&TXV 15.00 13.20 58CV(A,X)070---12
CNPH*4821A** 40,500 TXV 14.00 11.50
CNPH*4821A** 40,000 TDR&TXV 14.50 12.00 58MVB040---14
CNPH*4821A** 40,000 TDR&TXV 14.50 12.00 58CV(A,X)070---12
CNPF*4818A** 40,000 TXV 14.00 11.95
CSPH*4212A** 40,500 TXV 14.00 11.50
CSPH*4212A** 40,000 TDR&TXV 14.50 12.00 58MVB040---14
CSPH*4212A** 40,000 TDR&TXV 14.50 12.00 58CV(A,X)070---12
CSPH*4812A** 41,000 TXV 14.00 12.05
See notes on pg. 13
24ABA4

12
COMBINATION RATINGS -- CONTINUED
U n i t S i z e ---
Series Indoor Model To t a l C a p . B T U H Factory Supplied Enhancement
SEER
EER Furnace Model
Standard
Rating TDR†
42---30
CSPH*4812A** 40,000 TDR&TXV 15.00 13.20 58MVB040---14
CSPH*4812A** 40,000 TDR&TXV 14.50 12.00 58CV(A,X)070---12
FY4ANF042 40,000 TDR&TXV 13.50 11.20
FY4ANF048 41,000 TDR&TXV 14.00 11.50
FX4CN(B,F)042 40,500 TDR&TXV 14.50 12.00
FX4CN(B,F)048 40,500 TDR&TXV 15.00 12.50
FV4BNF003 39,500 TDR&TXV 15.00 12.50
FV4BNF005 41,000 TDR&TXV 15.00 13.00
FV4BNB006 41,500 TDR&TXV 15.00 13.00
48---30
CAP**4817A** 46,500 TXV 13.50 11.20
CAP**4817A** 46,000 TDR&TXV 14.20 11.50 58CV(A,X)090---16
CAP**4821A** 47,500 TXV 13.50 11.20
CAP**4821A** 46,500 TDR&TXV 14.20 11.50 58MVB080---20
CAP**4821A** 46,500 TDR&TXV 14.20 11.50 58MVB100---20
CAP**4821A** 46,500 TDR&TXV 14.20 11.50 58CV(A,X)110---20
CAP**4824A** 47,500 TXV 13.50 11.20
CAP**4824A** 46,500 TDR&TXV 14.20 11.50 58MVB120---20
CAP**4824A** 47,000 TDR&TXV 14.50 12.00 58CV(A,X)135---22
CAP**4824A** 47,000 TDR&TXV 14.50 12.00 58CV(A,X)155---22
CAP**6021A** 47,000 TXV 14.00 11.50
CAP**6021A** 46,500 TDR&TXV 14.20 11.50 58MVB080---20
CAP**6021A** 46,500 TDR&TXV 14.50 12.00 58MVB100---20
CAP**6021A** 47,000 TDR&TXV 14.50 12.00 58CV(A,X)110---20
*CAP**6024A** 48,000 TXV 14.00 11.5
CAP**6024A** 47,500 TDR&TXV 14.50 11.20 58MVB120---20
CAP**6024A** 48,000 TDR&TXV 14.50 12.00 58CV(A,X)135---22
CAP**6024A** 48,000 TDR&TXV 15.00 12.50 58CV(A,X)155---22
CNPF*4818A** 46,500 TXV 13.50 11.20
CNPH*4821A** 47,500 TXV 13.50 11.20
CNPH*4821A** 46,500 TDR&TXV 14.20 11.50 58MVB080---20
CNPH*4821A** 46,500 TDR&TXV 14.20 11.50 58CV(A,X)090---16
CNPH*6024A** 48,000 TXV 14.00 11.50
CNPH*6024A** 47,500 TDR&TXV 14.20 11.50 58MVB080---20
CNPH*6024A** 47,500 TDR&TXV 14.50 12.00 58CV(A,X)090---16
CNPV*4821A** 47,500 TXV 13.50 11.20
CNPV*4821A** 46,500 TDR&TXV 14.20 11.50 58MVB080---20
CNPV*4821A** 46,500 TDR&TXV 14.20 11.50 58MVB100---20
CNPV*4821A** 46,500 TDR&TXV 14.20 11.50 58CV(A,X)110---20
CNPV*4824A** 47,500 TXV 13.50 11.20
CNPV*4824A** 46,500 TDR&TXV 14.50 12.00 58MVB120---20
CNPV*4824A** 47,000 TDR&TXV 14.50 12.00 58CV(A,X)135---22
CNPV*4824A** 47,000 TDR&TXV 14.50 12.00 58CV(A,X)155---22
CNPV*6024A** 48,000 TXV 14.00 11.50
CNPV*6024A** 47,500 TDR&TXV 14.50 12.00 58MVB120---20
CNPV*6024A** 48,000 TDR&TXV 14.50 12.00 58CV(A,X)135---22
CNPV*6024A** 48,000 TDR&TXV 15.00 12.50 58CV(A,X)155---22
CSPH*4812A** 47,000 TXV 13.50 11.20
CSPH*4812A** 47,000 TDR&TXV 14.20 11.50 58MVB080---20
CSPH*4812A** 47,000 TDR&TXV 14.20 11.50 58CV(A,X)090---16
CSPH*6012A** 47,500 TXV 14.00 11.50
CSPH*6012A** 47,500 TDR&TXV 14.20 11.50 58MVB080---20
CSPH*6012A** 48,000 TDR&TXV 14.50 12.00 58CV(A,X)090---16
FV4BNB006 48,500 TDR&TXV 15.00 12.50
FV4BNF005 48,000 TDR&TXV 15.00 12.50
FX4CN(B,F)048 48,500 TDR&TXV 14.50 12.00
FX4CN(B,F)060 49,500 TDR&TXV 14.70 12.50
FY4ANB060 48,500 TDR&TXV 14.00 11.50
FY4ANF048 47,500 TDR&TXV 13.50 11.20
See notes on pg. 13
24ABA4

13
COMBINATION RATINGS -- CONTINUED
U n i t S i z e ---
Series Indoor Model To t a l C a p . B T U H Factory Supplied Enhancement
SEER
EER Furnace Model
Standard
Rating TDR†
60---30
CAP**6021A** 58,000 TXV 14.00 11.50
CAP**6021A** 55,000 TDR&TXV 14.20 11.50 58MVB080---20
*CAP**6024A** 59,000 TXV 14.00 11.5
CAP**6024A** 58,000 TDR&TXV 14.50 12.00 58CV(A,X)135---22
CAP**6024A** 58,000 TDR&TXV 14.50 12.00 58CV(A,X)155---22
CNPV*6024A** 58,500 TXV 14.00 11.50
CNPV*6024A** 55,500 TDR&TXV 14.50 12.00 58MVB120---20
CNPV*6024A** 57,500 TDR&TXV 14.50 12.00 58CV(A,X)135---22
CNPV*6024A** 58,000 TDR&TXV 14.50 12.00 58CV(A,X)155---22
CNPH*6024A** 58,500 TXV 14.00 11.50
CNPH*6024A** 55,500 TDR&TXV 14.20 11.50 58MVB080---20
CNPH*6024A** 55,500 TDR&TXV 14.50 12.00 58MVB100---20
CNPH*6024A** 55,500 TDR&TXV 14.50 12.00 58MVB120---20
CNPH*6024A** 57,500 TDR&TXV 14.20 11.50 58CV(A,X)110---20
CNPH*6024A** 57,500 TDR&TXV 14.50 12.00 58CV(A,X)135---22
CNPH*6024A** 58,000 TDR&TXV 14.50 12.00 58CV(A,X)155---22
CSPH*6012A** 59,000 TXV 14.00 11.50
CSPH*6012A** 56,000 TDR&TXV 14.20 11.50 58MVB080---20
CSPH*6012A** 56,000 TDR&TXV 14.50 12.00 58MVB100---20
CSPH*6012A** 56,000 TDR&TXV 14.50 12.00 58MVB120---20
CSPH*6012A** 58,000 TDR&TXV 14.20 11.50 58CV(A,X)110---20
CSPH*6012A** 58,000 TDR&TXV 14.50 12.00 58CV(A,X)135---22
CSPH*6012A** 58,000 TDR&TXV 14.50 12.00 58CV(A,X)155---22
FY4ANB060 59,000 TDR&TXV 13.50 11.20
FX4CN(B,F)060 59,500 TDR&TXV 14.00 11.50
FV4BNB006 59,000 TDR&TXV 14.50 12.00
* Tested combination
{In most cases, only 1 method should be used to achieve TDR function. Using more than 1 method in a system may cause degradation in performance. Use
either the accessory Time---Delay Relay KAATD0101TDR or a furnace equipped with TDR. Most Carrier furnaces are equipped with TDR.
EER — Energy Efficiency Ratio
SEER — Seasonal Energy Efficiency Ratio
TDR — T i m e --- D e l a y R e l a y
TXV — Thermostatic Expansion Valve
NOTES:
1. Ratings are net values reflecting the effects of circulating fan motor heat. Supplemental electric heat is not included.
2. Tested outdoor/indoor combinations have been tested in accordance with DOE test procedures for central air conditioners. Ratings for other
combinations are determined under DOE computer simulation procedures.
3. Determine actual CFM values obtainable for your system by referring to fan performance data in fan coil or furnace coil literature.
4. Do not apply with capillary tube coils as performance and reliability are significantly affected.
24ABA424ABA4

14
DETAILED COOLING CAPACITIES
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES deg F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
To t a l Sens
‡To t a l Sens ‡To t a l Sens ‡To t a l Sens ‡To t a l Sens ‡To t a l Sens ‡
24ABA418A30 Outdoor Section With CAP**2414A** Indoor Section
525
72 21.57 11.21 1.17 20.52 10.80 1.32 19.45 10.39 1.49 18.33 9.97 1.67 17.18 9.55 1.88 15.93 9.09 2.11
67 19.60 13.63 1.18 18.65 13.23 1.33 17.67 12.81 1.50 16.65 12.40 1.69 15.60 11.96 1.90 14.46 11.51 2.13
62 17.82 16.04 1.19 16.96 15.63 1.34 16.08 15.22 1.51 15.18 14.79 1.70 14.29 14.29 1.91 13.44 13.44 2.13
57 17.16 17.16 1.20 16.49 16.49 1.35 15.79 15.79 1.51 15.06 15.06 1.70 14.29 14.29 1.91 13.44 13.44 2.13
600
72 22.01 11.78 1.19 20.92 11.37 1.34 19.79 10.95 1.51 18.62 10.52 1.70 17.42 10.09 1.91 16.12 9.62 2.14
67 20.03 14.54 1.21 19.03 14.13 1.36 18.00 13.71 1.53 16.94 13.28 1.71 15.84 12.84 1.92 14.66 12.37 2.15
62 18.27 17.29 1.22 17.38 16.86 1.37 16.50 16.41 1.54 15.70 15.70 1.72 14.86 14.86 1.93 13.95 13.95 2.16
57 17.96 17.96 1.22 17.23 17.23 1.37 16.48 16.48 1.54 15.70 15.70 1.72 14.87 14.87 1.93 13.95 13.95 2.16
675
72 22.34 12.32 1.22 21.20 11.90 1.37 20.03 11.47 1.54 18.83 11.04 1.72 17.58 10.60 1.93 16.24 10.13 2.16
67 20.35 15.42 1.23 19.31 15.00 1.38 18.25 14.57 1.55 17.15 14.13 1.74 16.02 13.68 1.95 14.80 13.21 2.18
62 18.68 18.46 1.24 17.86 17.86 1.39 17.06 17.06 1.56 16.22 16.22 1.75 15.33 15.33 1.95 14.37 14.37 2.18
57 18.63 18.63 1.24 17.86 17.86 1.39 17.06 17.06 1.56 16.22 16.22 1.75 15.33 15.33 1.95 14.37 14.37 2.18
Multipliers for determining the performance with other indoor sections.
Cooling
Indoor Model Capacity Power Furnace Model
*CAP**2414A** 1.00 1.00
CAP**1814A** 0.99 1.02
CAP**2417A** 1.00 1.00
CNPF*2418A** 1.00 1.03
CNPH*2417A** 1.00 1.03
CNPV*1814A** 0.99 1.02
CNPV*2414A** 1.00 1.00
CNPV*2417A** 1.00 1.03
CSPH*2412A** 1.00 1.00
FF1ENP018 0.99 1.02
FF1ENP024 1.00 1.03
FV4BNF002 1.01 0.88
FX4CNF018 1.00 0.88
FX4CNF024 1.02 0.90
FY4ANF018 0.99 1.02
FY4ANF024 0.99 1.02
CAP**1814A** 0.98 0.90 58CV(A,X)070---12
CAP**2414A** 0.99 0.88 58CV(A,X)070---12
CNPH*2417A** 0.99 0.88 58CV(A,X)070---12
CNPV*1814A** 0.98 0.90 58CV(A,X)070---12
CNPV*2414A** 0.99 0.88 58CV(A,X)070---12
CSPH*2412A** 0.99 0.88 58CV(A,X)070---12
CAP**2417A** 0.99 0.88 58CV(A,X)090---16
CNPH*2417A** 0.99 0.88 58CV(A,X)090---16
CNPV*2417A** 0.99 0.88 58CV(A,X)090---16
CSPH*2412A** 0.99 0.88 58CV(A,X)090---16
CNPH*2417A** 0.99 0.88 58MVB040---14
CSPH*2412A** 0.99 0.88 58MVB040---14
CAP**2417A** 0.99 0.88 58MVB060---14
CNPH*2417A** 0.99 0.88 58MVB060---14
CNPV*2417A** 0.99 0.88 58MVB060---14
CSPH*2412A** 0.99 0.88 58MVB060---14
CNPH*2417A** 0.99 0.88 58MVB080---14
CSPH*2412A** 0.99 0.88 58MVB080---14
See notes on pg. 20
24ABA4

15
DETAILED COOLING CAPACITIES
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES deg F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
To t a l Sens
‡To t a l Sens ‡To t a l Sens ‡To t a l Sens ‡To t a l Sens ‡To t a l Sens ‡
24ABA424A30 Outdoor Section With CAP**3014A** Indoor Section
700
72 28.59 14.92 1.54 27.34 14.44 1.73 26.02 13.94 1.95 24.62 13.41 2.19 23.11 12.85 2.45 21.45 12.25 2.74
67 25.94 18.18 1.55 24.78 17.69 1.74 23.56 17.18 1.96 22.27 16.64 2.19 20.88 16.08 2.46 19.35 15.46 2.75
62 23.61 21.43 1.55 22.55 20.93 1.75 21.45 20.41 1.96 20.30 19.86 2.20 19.15 19.15 2.46 18.01 18.01 2.75
57 22.84 22.84 1.56 22.01 22.01 1.75 21.12 21.12 1.96 20.18 20.18 2.20 19.15 19.15 2.46 18.01 18.01 2.75
800
72 29.18 15.68 1.58 27.87 15.19 1.77 26.49 14.68 1.98 25.03 14.15 2.22 23.46 13.58 2.48 21.74 12.96 2.77
67 26.48 19.38 1.58 25.27 18.88 1.78 24.00 18.36 1.99 22.66 17.82 2.23 21.22 17.24 2.49 19.64 16.61 2.78
62 24.19 23.07 1.59 23.12 22.54 1.78 22.00 22.00 2.00 21.01 21.01 2.23 19.91 19.91 2.50 18.69 18.69 2.78
57 23.86 23.86 1.59 22.97 22.97 1.78 22.02 22.02 2.00 21.01 21.01 2.23 19.91 19.91 2.50 18.69 18.69 2.78
900
72 29.62 16.40 1.61 28.26 15.90 1.80 26.84 15.38 2.02 25.33 14.84 2.26 23.71 14.26 2.52 21.93 13.64 2.81
67 26.89 20.53 1.62 25.64 20.02 1.81 24.33 19.50 2.03 22.95 18.94 2.27 21.46 18.35 2.53 19.85 17.71 2.82
62 24.74 24.57 1.62 23.77 23.77 1.82 22.77 22.77 2.03 21.70 21.70 2.27 20.54 20.54 2.53 19.25 19.25 2.82
57 24.71 24.71 1.62 23.77 23.77 1.82 22.77 22.77 2.03 21.70 21.70 2.27 20.54 20.54 2.53 19.25 19.25 2.82
Multipliers for determining the performance with other indoor sections.
Cooling
Indoor Model Capacity Power Furnace Model
*CAP**3014A** 1.00 1.00
CAP**2414A** 0.98 0.98
CAP**2417A** 0.98 0.98
CAP**3017A** 1.00 1.00
CNPF*2418A** 0.98 0.98
CNPH*2417A** 0.98 0.98
CNPH*3017A** 1.00 1.00
CNPV*2414A** 0.98 0.98
CNPV*2417A** 0.98 0.98
CNPV*3014A** 1.00 1.00
CNPV*3017A** 1.00 1.00
CSPH*2412A** 0.98 0.98
CSPH*3012A** 1.00 1.00
FF1ENP024 0.98 1.00
FF1ENP030 0.98 1.00
FV4BNF002 0.99 0.88
FV4BNF003 0.99 0.86
FX4CNF024 0.99 0.91
FX4CNF030 1.00 0.88
FY4ANF024 0.98 1.00
FY4ANF030 0.98 0.98
CAP**2414A** 0.97 0.89 58CV(A,X)070 ---12
CAP**3014A** 1.02 0.90 58CV(A,X)070 ---12
CNPH*2417A** 0.98 0.90 58CV(A,X)070---12
CNPH*3017A** 1.02 0.90 58CV(A,X)070---12
CNPV*2414A** 0.97 0.89 58CV(A,X)070---12
CNPV*3014A** 1.02 0.94 58CV(A,X)070---12
CSPH*2412A** 0.97 0.89 58CV(A,X)070---12
CSPH*3012A** 1.02 0.90 58CV(A,X)070---12
CAP**3017A** 1.02 0.90 58CV(A,X)090 ---16
CNPV*2417A** 0.98 0.90 58CV(A,X)090---16
CNPV*3017A** 1.02 0.90 58CV(A,X)090---16
CSPH*3012A** 1.02 0.90 58CV(A,X)090---16
CSPH*2412A** 0.97 0.86 58CV(A,X)110---20
CSPH*3012A** 1.02 0.90 58CV(A,X)110---20
CSPH*2412A** 0.97 0.86 58CV(A,X)135---22
CSPH*3012A** 1.02 0.90 58CV(A,X)135---22
CSPH*2412A** 0.97 0.86 58CV(A,X)155---22
CSPH*3012A** 1.02 0.90 58CV(A,X)155---22
CNPH*2417A** 0.98 0.90 58MVB040---14
CNPH*3017A** 1.02 0.90 58MVB040---14
CSPH*2412A** 0.97 0.89 58MVB040---14
CSPH*3012A** 1.02 0.90 58MVB040---14
CAP**2417A** 0.98 0.90 58MVB060---14
CAP**3017A** 1.02 0.90 58MVB060---14
CNPV*2417A** 0.98 0.90 58MVB060---14
CNPV*3017A** 1.02 0.90 58MVB060---14
CSPH*3012A** 1.02 0.90 58MVB060---14
CSPH*3012A** 1.02 0.90 58MVB080---14
CSPH*3012A** 1.02 0.90 58MVB080---20
CSPH*3012A** 1.02 0.90 58MVB100---20
CSPH*3012A** 1.02 0.90 58MVB120---20
See notes on pg. 20
24ABA4

16
DETAILED COOLING CAPACITIES
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES deg F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
To t a l Sens
‡To t a l Sens ‡To t a l Sens ‡To t a l Sens ‡To t a l Sens ‡To t a l Sens ‡
24ABA430A30 Outdoor Section With CAP**3014A** Indoor Section
875
72 34.45 18.04 1.98 32.96 17.47 2.19 31.38 16.87 2.43 29.70 16.24 2.69 27.90 15.57 2.98 25.90 14.84 3.29
67 31.35 22.06 1.98 29.98 21.48 2.19 28.53 20.87 2.43 26.98 20.23 2.69 25.32 19.56 2.97 23.50 18.82 3.29
62 28.63 26.08 1.98 27.39 25.49 2.19 26.10 24.87 2.43 24.74 24.19 2.69 23.36 23.36 2.97 21.98 21.98 3.29
57 27.79 27.79 1.98 26.80 26.80 2.19 25.74 25.74 2.43 24.61 24.61 2.69 23.37 23.37 2.97 21.98 21.98 3.29
1000
72 35.09 18.92 2.02 33.53 18.33 2.24 31.88 17.72 2.47 30.14 17.08 2.73 28.26 16.40 3.02 26.19 15.66 3.34
67 31.95 23.46 2.02 30.51 22.87 2.24 29.00 22.25 2.47 27.40 21.61 2.73 25.69 20.92 3.02 23.80 20.17 3.33
62 29.30 27.99 2.02 28.05 27.36 2.23 26.73 26.73 2.47 25.55 25.55 2.73 24.22 24.22 3.02 22.74 22.74 3.33
57 28.96 28.96 2.02 27.89 27.89 2.23 26.76 26.76 2.47 25.55 25.55 2.73 24.22 24.22 3.02 22.75 22.75 3.33
1125
72 35.55 19.73 2.07 33.94 19.14 2.28 32.23 18.52 2.52 30.44 17.87 2.78 28.51 17.18 3.07 26.38 16.43 3.38
67 32.39 24.79 2.07 30.91 24.19 2.28 29.36 23.57 2.52 27.71 22.91 2.78 25.95 22.21 3.07 24.03 21.43 3.38
62 29.94 29.71 2.07 28.80 28.80 2.28 27.60 27.60 2.52 26.31 26.31 2.78 24.91 24.91 3.07 23.36 23.36 3.38
57 29.92 29.92 2.07 28.80 28.80 2.28 27.60 27.60 2.52 26.31 26.31 2.78 24.91 24.91 3.06 23.36 23.36 3.38
Multipliers for determining the performance with other indoor sections.
Cooling
Indoor Model Capacity Power Furnace Model
*CAP**3014A** 1.00 1.00
CAP**3017A** 1.00 1.04
CAP**3614A** 0.97 1.01
CAP**3617A** 1.01 1.05
CAP**3621A** 1.01 1.05
CNPF*3618A** 1.01 1.05
CNPH*3017A** 1.00 1.04
CNPH*3617A** 1.01 1.05
CNPV*3014A** 1.00 1.04
CNPV*3017A** 1.00 1.04
CNPV*3617A** 1.01 1.05
CNPV*3621A** 1.01 1.05
CSPH*3012A** 1.00 1.04
CSPH*3612A** 1.01 1.05
FF1ENP030 0.99 1.03
FF1ENP036 1.01 1.05
FV4BNF002 1.00 0.96
FV4BNF003 1.01 0.93
FV4BNF005 1.03 0.94
FX4CN(B,F)036 1.02 0.98
FX4CNF030 1.01 0.97
FY4ANF030 0.99 1.04
FY4ANF036 1.00 1.04
CAP**3014A** 0.99 0.95 58CV(A,X)070---12
CAP**3614A** 0.96 0.92 58CV(A,X)070---12
CNPH*3017A** 0.99 0.95 58CV(A,X)070---12
CNPH*3617A** 0.99 0.95 58CV(A,X)070---12
CNPV*3014A** 0.99 0.95 58CV(A,X)070---12
CSPH*3012A** 0.99 0.95 58CV(A,X)070---12
CSPH*3612A** 0.99 0.92 58CV(A,X)070---12
CAP**3017A** 0.99 0.92 58CV(A,X)090---16
CAP**3617A** 1.00 0.92 58CV(A,X)090---16
CNPV*3017A** 0.99 0.95 58CV(A,X)090---16
CNPV*3617A** 1.00 0.96 58CV(A,X)090---16
CAP**3621A** 1.00 0.92 58CV(A,X)110---20
CNPV*3621A** 1.00 0.96 58CV(A,X)110---20
CNPH*3017A** 0.99 0.95 58MVB040---14
CNPH*3617A** 0.99 0.95 58MVB040---14
CSPH*3012A** 0.99 0.95 58MVB040---14
CSPH*3612A** 0.99 0.92 58MVB040---14
CAP**3017A** 0.99 0.95 58MVB060---14
CAP**3617A** 0.99 0.92 58MVB060---14
CNPV*3017A** 0.99 0.95 58MVB060---14
CNPV*3617A** 0.99 0.95 58MVB060---14
CAP**3621A** 1.00 0.96 58MVB080---14
CNPV*3621A** 1.00 0.96 58MVB080---14
CNPH*3017A** 0.99 0.95 58MVB120---20
See notes on pg. 20
24ABA4

17
DETAILED COOLING CAPACITIES
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES deg F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
To t a l
Sys-
tem
KW**
Capacity
MBtuh†
To t a l
Sys-
tem
KW**
Capacity
MBtuh†
To t a l
Sys-
tem
KW**
Capacity
MBtuh†
To t a l
Sys-
tem
KW**
Capacity
MBtuh†
To t a l
Sys-
tem
KW**
Capacity
MBtuh†
To t a l
Sys-
tem
KW**
To t a l Sens‡ To t a l Sens‡ To t a l Sens‡ To t a l Sens‡ To t a l Sens‡ To t a l Sens‡
24ABA436A30 Outdoor Section With CAP**4221A** Indoor Section
1050
72 42.83 22.38 2.35 40.92 21.65 2.63 38.92 20.89 2.94 36.78 20.09 3.29 34.47 19.23 3.68 31.94 18.31 4.12
67 38.83 27.27 2.35 37.06 26.52 2.63 35.20 25.74 2.94 33.22 24.93 3.29 31.08 24.06 3.68 28.75 23.12 4.12
62 35.34 32.16 2.35 33.74 31.40 2.63 32.07 30.59 2.94 30.32 29.72 3.29 28.58 28.58 3.68 26.83 26.83 4.12
57 34.26 34.26 2.35 32.98 32.98 2.63 31.63 31.63 2.94 30.17 30.17 3.29 28.58 28.58 3.68 26.83 26.83 4.12
1200
72 43.66 23.46 2.40 41.67 22.71 2.68 39.58 21.94 2.99 37.36 21.12 3.34 34.96 20.26 3.73 32.33 19.32 4.17
67 39.58 28.97 2.40 37.74 28.21 2.68 35.80 27.42 2.99 33.75 26.59 3.34 31.55 25.71 3.73 29.14 24.76 4.17
62 36.18 34.48 2.40 34.56 33.67 2.68 32.87 32.87 2.99 31.35 31.35 3.34 29.67 29.67 3.73 27.80 27.80 4.17
57 35.72 35.72 2.40 34.36 34.36 2.68 32.91 32.91 2.99 31.36 31.36 3.34 29.67 29.67 3.73 27.80 27.80 4.17
1350
72 44.27 24.46 2.45 42.22 23.70 2.73 40.06 22.91 3.05 37.77 22.09 3.40 35.31 21.21 3.79 32.61 20.26 4.22
67 40.14 30.57 2.45 38.24 29.80 2.73 36.25 29.01 3.04 34.15 28.17 3.39 31.89 27.28 3.78 29.44 26.29 4.22
62 36.97 36.59 2.45 35.49 35.49 2.73 33.97 33.97 3.04 32.33 32.33 3.39 30.56 30.56 3.78 28.59 28.59 4.22
57 36.94 36.94 2.45 35.50 35.50 2.73 33.97 33.97 3.04 32.34 32.34 3.39 30.56 30.56 3.78 28.60 28.60 4.22
Multipliers for determining the performance with other indoor sections.
Cooling
Indoor Model Capacity Power Furnace Model
*CAP**4221A** 1.00 1.00
CAP**3614A** 0.98 0.98
CAP**3617A** 0.99 0.99
CAP**3621A** 0.99 0.99
CAP**4224A** 1.00 1.00
CNPF*3618A** 0.99 0.99
CNPH*3617A** 0.99 0.99
CNPH*4221A** 1.00 1.00
CNPV*3617A** 0.99 0.99
CNPV*3621A** 0.99 0.99
CNPV*4221A** 1.00 1.00
CSPH*3612A** 1.01 1.01
CSPH*4212A** 1.02 1.02
FF1ENP036 0.98 0.98
FV4BNB006 1.03 0.90
FV4BNF002 0.98 0.94
FV4BNF003 0.99 0.95
FV4BNF005 1.02 0.90
FX4CN(B,F)036 1.01 0.96
FX4CN(B,F)042 1.02 0.98
FY4ANF036 0.97 0.97
FY4ANF042 1.01 1.01
CAP**3614A** 0.98 0.96 58CV(A,X)070---12
CNPH*3617A** 0.98 0.96 58CV(A,X)070---12
CNPH*4221A** 0.99 0.95 58CV(A,X)070---12
CSPH*3612A** 1.00 0.96 58CV(A,X)070---12
CSPH*4212A** 1.01 0.96 58CV(A,X)070---12
CAP**3617A** 0.98 0.94 58CV(A,X)090---16
CNPV*3617A** 0.98 0.94 58CV(A,X)090---16
CAP**3621A** 0.98 0.94 58CV(A,X)110---20
CAP**4221A** 0.99 0.95 58CV(A,X)110---20
CNPV*3621A** 0.98 0.94 58CV(A,X)110---20
CNPV*4221A** 0.99 0.88 58CV(A,X)110---20
CAP**4224A** 0.99 0.95 58CV(A,X)135---22
CNPH*4221A** 0.99 0.88 58CV(A,X)135---22
CNPH*4221A** 0.99 0.88 58CV(A,X)155---22
CAP**4224A** 0.98 0.94 58MVB040---14
CNPH*3617A** 0.97 0.96 58MVB040---14
CNPH*4221A** 0.99 0.95 58MVB040---14
CSPH*3612A** 0.99 0.95 58MVB040---14
CSPH*4212A** 1.00 0.96 58MVB040---14
CAP**3617A** 0.98 0.94 58MVB060---14
CNPV*3617A** 0.98 0.96 58MVB060---14
CAP**3621A** 0.98 0.96 58MVB080---14
CAP**4221A** 0.98 0.97 58MVB080---14
CNPV*3621A** 0.97 0.96 58MVB080---14
CNPV*4221A** 0.99 0.95 58MVB080---14
CAP**3621A** 0.98 0.94 58MVB080---20
CAP**4221A** 0.99 0.95 58MVB080---20
CAP**3621A** 0.98 0.94 58MVB100---20
CAP**4221A** 0.99 0.95 58MVB100---20
CAP**4224A** 0.99 0.95 58MVB120---20
CSPH*4212A** 1.01 0.96 58MVB120---20
See notes on pg. 20
24ABA4

18
DETAILED COOLING CAPACITIES
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES deg F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
To t a l Sens
‡To t a l Sens ‡To t a l Sens ‡To t a l Sens ‡To t a l Sens ‡To t a l Sens ‡
24ABA442A30 Outdoor Section With CAP**4821A** Indoor Section
1225
72 48.69 25.68 2.57 46.44 24.82 2.93 44.08 23.93 3.33 41.59 23.01 3.79 38.92 22.03 4.34 36.24 21.06 4.88
67 44.08 31.40 2.60 42.00 30.53 2.95 39.82 29.63 3.35 37.54 28.70 3.81 35.09 27.71 4.39 32.52 26.69 4.98
62 40.13 37.15 2.61 38.27 36.26 2.96 36.35 35.33 3.35 34.37 34.37 3.81 32.57 32.57 4.40 30.57 30.57 5.00
57 39.17 39.17 2.61 37.67 37.67 2.96 36.09 36.09 3.35 34.41 34.41 3.81 32.57 32.57 4.40 30.57 30.57 5.00
1400
72 49.63 26.97 2.62 47.28 26.10 2.98 44.82 25.19 3.38 42.24 24.26 3.84 39.47 23.26 4.38 36.72 22.29 4.90
67 44.93 33.44 2.65 42.75 32.56 3.00 40.50 31.65 3.40 38.13 30.70 3.86 35.60 29.69 4.43 32.98 28.65 5.02
62 41.12 39.90 2.66 39.26 38.92 3.01 37.52 37.52 3.41 35.73 35.73 3.87 33.77 33.77 4.46 31.68 31.68 5.04
57 40.82 40.82 2.66 39.21 39.21 3.01 37.52 37.52 3.41 35.73 35.73 3.87 33.77 33.77 4.46 31.68 31.68 5.04
1575
72 50.34 28.18 2.68 47.90 27.30 3.03 45.37 26.38 3.43 42.70 25.43 3.88 39.87 24.43 4.42 37.06 23.45 4.91
67 45.57 35.39 2.70 43.33 34.49 3.05 41.01 33.57 3.46 38.58 32.60 3.92 35.99 31.57 4.48 33.34 30.50 5.07
62 42.20 42.20 2.71 40.50 40.50 3.06 38.71 38.71 3.46 36.82 36.82 3.92 34.75 34.75 4.50 32.59 32.59 5.08
57 42.20 42.20 2.71 40.50 40.50 3.06 38.72 38.72 3.46 36.82 36.82 3.92 34.76 34.76 4.50 32.59 32.59 5.08
Multipliers for determining the performance with other indoor sections.
Cooling
Indoor Model Capacity Power Furnace Model
*CAP**4821A** 1.00 1.00
CAP**4221A** 0.98 1.00
CAP**4224A** 0.98 0.98
CAP**4817A** 1.01 1.01
CAP**4824A** 1.00 0.96
CNPF*4818A** 0.99 0.95
CNPH*4221A** 0.99 0.91
CNPH*4821A** 1.00 1.00
CNPV*4221A** 0.99 0.99
CNPV*4821A** 1.00 1.00
CNPV*4824A** 1.00 0.96
CSPH*4212A** 1.00 1.00
CSPH*4812A** 1.01 0.97
FV4BNB006 1.02 0.91
FV4BNF003 0.98 0.90
FV4BNF005 1.01 0.90
FX4CN(B,F)042 1.00 0.96
FX4CN(B,F)048 1.00 0.92
FY4ANF042 0.99 1.01
FY4ANF048 1.01 1.01
CNPH*4221A** 0.98 0.85 58CV(A,X)070---12
CNPH*4821A** 0.99 0.95 58CV(A,X)070---12
CSPH*4212A** 0.99 0.95 58CV(A,X)070---12
CSPH*4812A** 0.99 0.95 58CV(A,X)070---12
CAP**4817A** 1.01 0.97 58CV(A,X)090---16
CAP**4221A** 0.99 0.95 58CV(A,X)110---20
CAP**4821A** 0.99 0.86 58CV(A,X)110---20
CNPV*4221A** 1.00 0.92 58CV(A,X)110---20
CNPV*4821A** 1.01 0.97 58CV(A,X)110---20
CAP**4224A** 0.99 0.95 58CV(A,X)135---22
CAP**4824A** 1.01 0.88 58CV(A,X)135---22
CNPV*4824A** 1.01 0.93 58CV(A,X)135---22
CAP**4224A** 0.98 0.93 58MVB040---14
CAP**4824A** 0.98 0.85 58MVB040---14
CNPH*4221A** 0.99 0.95 58MVB040---14
CNPH*4821A** 0.99 0.95 58MVB040---14
CNPV*4824A** 0.99 0.95 58MVB040 ---14
CSPH*4212A** 0.99 0.95 58MVB040---14
CSPH*4812A** 0.99 0.86 58MVB040---14
CAP**4817A** 0.99 0.91 58MVB060---14
CAP**4221A** 0.96 0.96 58MVB080---14
CAP**4821A** 0.99 0.86 58MVB080---14
CNPV*4221A** 0.98 0.93 58MVB080 ---14
CNPV*4821A** 0.99 0.95 58MVB080 ---14
CAP**4221A** 0.99 0.99 58MVB080---20
CAP**4221A** 0.99 0.99 58MVB100---20
CAP**4224A** 0.99 0.95 58MVB120---20
See notes on pg. 20
24ABA4

19
DETAILED COOLING CAPACITIES
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES deg F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
To t a l
Sys-
tem
KW**
Capacity
MBtuh†
To t a l
Sys-
tem
KW**
Capacity
MBtuh†
To t a l
Sys-
tem
KW**
Capacity
MBtuh†
To t a l
Sys-
tem
KW**
Capacity
MBtuh†
To t a l
Sys-
tem
KW**
Capacity
MBtuh†
To t a l
Sys-
tem
KW**
To t a l Sens‡ To t a l Sens‡ To t a l Sens‡ To t a l Sens‡ To t a l Sens‡ To t a l Sens‡
24ABA448A30 Outdoor Section With CAP**6024A** Indoor Section
1400
72 60.16 31.56 3.28 57.50 30.54 3.65 54.64 29.46 4.05 51.60 28.32 4.50 48.30 27.10 4.99 44.61 25.76 5.51
67 55.07 38.75 3.27 52.61 37.72 3.64 50.00 36.62 4.05 47.20 35.47 4.49 44.18 34.24 4.98 40.83 32.90 5.51
62 50.45 45.90 3.27 48.23 44.83 3.64 45.88 43.71 4.04 43.41 42.48 4.49 40.91 40.91 4.98 38.37 38.37 5.51
57 48.92 48.92 3.27 47.14 47.14 3.63 45.23 45.23 4.04 43.17 43.17 4.49 40.91 40.91 4.98 38.37 38.37 5.51
1600
72 61.17 33.06 3.37 58.39 32.02 3.73 55.41 30.92 4.14 52.25 29.77 4.58 48.82 28.53 5.07 45.00 27.17 5.59
67 56.03 41.17 3.36 53.46 40.12 3.72 50.73 39.00 4.13 47.83 37.84 4.57 44.70 36.59 5.06 41.24 35.22 5.59
62 51.54 49.21 3.35 49.27 48.08 3.72 46.90 46.90 4.12 44.73 44.73 4.57 42.31 42.31 5.06 39.58 39.58 5.59
57 50.90 50.90 3.35 48.99 48.99 3.72 46.94 46.94 4.12 44.73 44.73 4.57 42.31 42.31 5.06 39.58 39.58 5.59
1800
72 61.90 34.47 3.45 59.02 33.42 3.81 55.95 32.30 4.22 52.69 31.14 4.66 49.16 29.88 5.15 45.24 28.51 5.67
67 56.72 43.47 3.44 54.07 42.40 3.80 51.26 41.28 4.21 48.28 40.10 4.66 45.07 38.82 5.14 41.52 37.41 5.67
62 52.54 52.16 3.43 50.46 50.46 3.80 48.29 48.29 4.20 45.95 45.95 4.65 43.40 43.40 5.14 40.51 40.51 5.67
57 52.49 52.49 3.43 50.46 50.46 3.80 48.29 48.29 4.20 45.96 45.96 4.65 43.40 43.40 5.14 40.52 40.52 5.67
Multipliers for determining the performance with other indoor sections.
Cooling
Indoor Model Capacity Power Furnace Model
*CAP**6024A** 1.00 1.00
CAP**4817A** 0.97 0.99
CAP**4821A** 0.99 1.02
CAP**4824A** 0.99 1.02
CAP**6021A** 0.98 0.98
CNPF*4818A** 0.97 0.99
CNPH*4821A** 0.99 1.02
CNPH*6024A** 1.00 1.00
CNPV*4821A** 0.99 1.02
CNPV*4824A** 0.99 1.02
CNPV*6024A** 1.00 1.00
CSPH*4812A** 0.98 1.01
CSPH*6012A** 0.99 0.99
FV4BNB006 1.01 0.93
FV4BNF005 1.00 0.92
FX4BNB060 1.01 1.04
FX4BNF048 1.00 1.03
FX4CN(B,F)048 1.01 0.97
FX4CN(B,F)060 1.03 0.95
FY4ANB060 1.01 1.01
FY4ANF048 0.99 1.02
CAP**4817A** 0.96 0.96 58CV(A,X)090---16
CNPH*4821A** 0.97 0.97 58CV(A,X)090---16
CNPH*6024A** 0.99 0.95 58CV(A,X)090---16
CSPH*4812A** 0.98 0.98 58CV(A,X)090---16
CSPH*6012A** 1.00 0.96 58CV(A,X)090---16
CAP**4821A** 0.97 0.97 58CV(A,X)110---20
CAP**6021A** 0.98 0.94 58CV(A,X)110---20
CNPV*4821A** 0.97 0.97 58CV(A,X)110---20
CAP**4824A** 0.98 0.94 58CV(A,X)135---22
CAP**6024A** 1.00 0.96 58CV(A,X)135---22
CNPV*4824A** 0.98 0.94 58CV(A,X)135---22
CNPV*6024A** 1.00 0.96 58CV(A,X)135---22
CAP**4824A** 0.98 0.94 58CV(A,X)155---22
CAP**6024A** 1.00 0.92 58CV(A,X)155---22
CNPV*4824A** 0.98 0.94 58CV(A,X)155---22
CNPV*6024A** 1.00 0.92 58CV(A,X)155---22
CAP**4821A** 0.97 0.97 58MVB080---20
CAP**6021A** 0.97 0.97 58MVB080---20
CNPH*4821A** 0.97 0.97 58MVB080---20
CNPH*6024A** 0.99 0.99 58MVB080---20
CNPV*4821A** 0.97 0.97 58MVB080---20
CSPH*4812A** 0.98 0.98 58MVB080---20
CSPH*6012A** 0.99 0.99 58MVB080---20
CAP**4821A** 0.97 0.97 58MVB100---20
CAP**6021A** 0.97 0.93 58MVB100---20
CNPV*4821A** 0.97 0.97 58MVB100---20
CAP**4824A** 0.97 0.97 58MVB120---20
CAP**6024A** 0.99 1.02 58MVB120---20
CNPV*4824A** 0.97 0.93 58MVB120---20
CNPV*6024A** 0.99 0.95 58MVB120---20
See notes on pg. 20
24ABA4

20
DETAILED COOLING CAPACITIES
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES deg F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
To t a l
System
KW**
Capacity
MBtuh†
To t a l
System
KW**
Capacity
MBtuh†
To t a l
System
KW**
Capacity
MBtuh†
To t a l
System
KW**
Capacity
MBtuh†
To t a l
System
KW**
Capacity
MBtuh†
To t a l
System
KW**
To t a l Sens‡ To t a l Sens‡ To t a l Sens‡ To t a l Sens‡ To t a l Sens‡ To t a l Sens‡
24ABA460A30 Outdoor Section With CAP**6024A** Indoor Section
1750
72 70.52 37.08 3.97 67.20 35.81 4.38 63.70 34.48 4.83 59.99 33.10 5.32 55.97 31.62 5.86 51.51 30.01 6.45
67 64.33 45.47 3.92 61.31 44.20 4.33 58.13 42.87 4.78 54.75 41.49 5.27 51.12 40.02 5.82 47.11 38.42 6.40
62 58.81 53.84 3.87 56.12 52.55 4.28 53.31 51.19 4.73 50.40 49.71 5.23 47.55 47.55 5.78 44.50 44.50 6.38
57 57.17 57.17 3.86 55.01 55.01 4.27 52.72 52.72 4.73 50.25 50.25 5.23 47.55 47.55 5.78 44.50 44.50 6.38
2000
72 71.76 38.86 4.07 68.29 37.57 4.48 64.63 36.22 4.93 60.76 34.81 5.43 56.59 33.31 5.96 51.97 31.67 6.55
67 65.49 48.34 4.02 62.33 47.04 4.43 59.00 45.69 4.88 55.50 44.28 5.37 51.73 42.78 5.92 47.58 41.13 6.50
62 60.13 57.72 3.98 57.39 56.32 4.38 54.66 54.66 4.84 52.02 52.02 5.34 49.12 49.12 5.89 45.84 45.84 6.48
57 59.48 59.48 3.97 57.15 57.15 4.38 54.68 54.68 4.84 52.03 52.03 5.34 49.12 49.12 5.89 45.85 45.85 6.48
2250
72 72.67 40.54 4.17 69.08 39.23 4.58 65.29 37.86 5.03 61.30 36.43 5.52 57.00 34.90 6.06 52.25 33.24 6.64
67 66.34 51.06 4.12 63.07 49.75 4.53 59.64 48.38 4.98 56.04 46.94 5.47 52.17 45.40 6.01 47.92 43.68 6.60
62 61.32 61.32 4.08 58.90 58.90 4.49 56.27 56.27 4.95 53.45 53.45 5.45 50.38 50.38 6.00 46.91 46.91 6.59
57 61.37 61.37 4.08 58.90 58.90 4.49 56.27 56.27 4.95 53.46 53.46 5.45 50.38 50.38 6.00 46.92 46.92 6.59
Multipliers for determining the performance with other indoor sections.
Cooling
Indoor Model Capacity Power Furnace Model
*CAP**6024A** 1.00 1.00
CAP**6021A** 0.98 0.98
CNPH*6024A** 0.99 0.99
CNPV*6024A** 0.99 0.99
CSPH*6012A** 1.00 1.00
FV4BNB006 1.00 0.96
FX4CN(B,F)060 1.01 1.01
FY4ANB060 1.00 1.03
CNPH*6024A** 0.97 0.97 58CV(A,X)110---20
CSPH*6012A** 0.98 0.98 58CV(A,X)110---20
CAP**6024A** 0.98 0.94 58CV(A,X)135 ---22
CNPH*6024A** 0.97 0.93 58CV(A,X)135---22
CNPV*6024A** 0.97 0.93 58CV(A,X)135---22
CSPH*6012A** 0.98 0.94 58CV(A,X)135---22
CAP**6024A** 0.98 0.94 58CV(A,X)155 ---22
CNPH*6024A** 0.98 0.94 58CV(A,X)155---22
CNPV*6024A** 0.98 0.94 58CV(A,X)155---22
CSPH*6012A** 0.98 0.94 58CV(A,X)155---22
CAP**6021A** 0.93 0.93 58MVB080---20
CNPH*6024A** 0.94 0.94 58MVB080---20
CSPH*6012A** 0.95 0.95 58MVB080---20
CNPH*6024A** 0.94 0.90 58MVB100---20
CSPH*6012A** 0.95 0.91 58MVB100---20
CNPH*6024A** 0.94 0.90 58MVB120---20
CNPV*6024A** 0.94 0.90 58MVB120---20
CSPH*6012A** 0.95 0.91 58MVB120---20
NOTE: When the required data fall between the published data, interpolation may be performed. Extrapolation is not an acceptable
practice.
* Detailed cooling capacities are based on indoor and outdoor unit at the same elevation per ARI standard 210/240--94. If additional
tubing length and/or indoor unit is located above outdoor unit, a slight variation in capacity may occur.
{Total and sensible capacities are net capacities. Blower motor heat has been subtracted.
}Sensible capacities shown are based on 80_F (27_C) entering air at the indoor coil. For sensible capacities at other than 80_F(27_C),
deduct 835 Btuh (245 kW) per 1000 CFM (480 L/S) of indoor coil air for each degree below 80_F(27_C),oradd835Btuh(245kW)
per 1000 CFM (480 L/S) of indoor coil air per degree above 80_F(27_C).
When the required data fall between the published data, interpolation may be performed.
** Total system kW is total of indoor and outdoor unit kilowatts.
24ABA4
