Carrier XARIOS X150-04 User manual

XARIOS Single T° ROAD/STANDBY
X150-04/200-04/300-05/350-05/500-04 & 600
SYSTEM
ON / OFF
¡ F ¡C
0
OPERATOR'S MANUAL
MANUEL OPERATEUR
BEDIENUNGSANLEITUNG
MANUAL DEL OPERADOR
MANUALE UTILIZZATORE
BEDIENNIGSHANDLEIDING
BETJENINGSVEJLEDNING
INSTRUKTIONSBOK
ÐÓÊÎÂÎÄÑÒÂÎ ÎÏÅÐÀÒÎÐÀ
NÁVOD K OBSLUZE
INSTRUKCJA OBSŁUGI
MANUAL DO UTILIZADOR
© Carrier Corporation - Carrier Transicold Europe S.C.S. au cap i tal de 16 090 700 euros
R.C.S. Pontoise B 410 041 776 - Code APE 518 M - VAT: FR52410041776
The infor ma tion con tained in this doc u ment is not con trac tu al ly bind ing,
and may not be repro duced with out pri or approv al. Printed in France (05/05) 62-61177-01
CARRIER TRANSICOLD EUROPE S.C.S.
10, bou le vard de l’Oise
F-95031 CERGY PONTOISE CEDEX
Phone: [phone]
Fax: [phone]
www.carrier-transicold-europe.com
Our company is constantly seeking to improve the quality of its products and,
therefore, reserves the right to modify its products without prior notice.
500 Carrier service stations
in Europe, Russia,
Middle East and Africa
Xarios 150/200
Xarios 300/350
LWA
XX . X dB
1a
1b
2.2
Xarios 500/600

1
2
3
4
56
9
8
7
10 a
b
c
d
e
f
2.3 INSTALLATION
g

3
62--61177--01
OPERATING INSTRUCTIONS english
XARIOS MONO TEMPERATURE ROAD / STANDBY
X150--04 / X200--04 X300--05 / X350--05 X500--04 / X600
1. INTRODUCTION
This guide has been prepared for the operator of Carrier Transicold refrigeration units. It contains basic
instructions for the daily operation of the refrigeration unit as well as safety information, troubleshooting tips,
and other information that will help you to deliver the load in the best possible condition.
Xarios range is simple, tried and tested design; low--cost purchase and operation to equip middle size delivery
vehicles.
Please take the time to read the information contained in this booklet and refer to it whenever you have a
question about the operation of your Carrier Transicold unit. This manual refers to the standard model. Some
options may not appear in it, and in such cases you are requested to consult our Technical Services.
Your refrigeration unit has been engineered to provide long, trouble--free performance when it is properly
operated and maintained. The checks outlined in this guide will help to minimize on the road problems. In
addition, a comprehensive maintenance program will help to insure that the unit continues to operate reliably.
Such a maintenance program will also help to control operating costs, increase the unit’s working life, and
improve performance.
When having your unit serviced, be sure to specify genuine Carrier Transicold replacement parts for the
highest quality and best reliability.
At Carrier Transicold, we are continually working to improve the products that we build for our customers. As
a result, specifications may change without notice.
CONTENTS
1. Introduction 3..................................................
2. Identification 5..................................................
2.1. Nameplate 5..................................................
2.2. Noise level sticker (fixed if available) 5.............................
2.3. Installation 5..................................................
3. Warnings and precautions 5......................................
3.1. Warning stickers maintenance 9..................................
4. Product loading 9...............................................
5. Recommended transport temperatures 11..........................
6. Quick glance on the display board 11..............................
6.1. Cab control 11..................................................
7. Operation 12....................................................
7.1. Operating principle 12...........................................
7.1.1. In ROAD mode 12.........................................
7.1.2. In STANDBY mode 12.....................................
7.1.3. Temperature control 12.....................................
7.1.4. Defrost 12................................................
7.1.5. Heating 13...............................................

462--61177--01
7.1.6. Control components 13.....................................
7.2. Operation on ROAD mode 13.....................................
7.2.1. Starting the unit 13.........................................
7.2.2. Stoping the unit 13.........................................
7.3. Operation on STANDBY mode 14............................
7.3.1. Starting the unit 14.........................................
7.3.2. Stoping the unit 14.........................................
7.3.3. Standby operation guidelines 14.............................
7.4. To change display brightness 16...................................
7.5. To change setpoint temperature 16.................................
7.6. To change defrost parameters 16..................................
7.7. To change other datas 17.........................................
7.8. To change default parameters 17..................................
7.9. Fault alarm display 18...........................................
8. Maintenance 19..................................................
8.1. Maintenance schedule 20........................................
8.2. Services description 20..........................................
9. A.T.P. Europe Regulation extract 21................................
10. 24h Assistance 22................................................

5
62--61177--01
2. IDENTIFICATION
Keep the fold out sheet while reading the instructions.
2.1. Nameplate
Each unit is identified by a nameplate attached to the frame of the unit.The nameplate identifies the complete
model number of the unit, the serial number and some other information.
If a problem occurs, please refer to the information on this plate, and make a note of the model and serial
number before calling for assistance. This information will be needed when you contact a technician so that
he may properly assist you.
The complete nameplate is fixed on the frame (1a) and the Serial Number is fixed on unit side (1b) : easily
readable.
2.2. Noise level sticker (fixed if available)
This sticker indicates the noise level in Lwa (accoustic pressure).
2.3. Installation
Xarios are manufactured as a split--system, enabling them to adapt to any vehicle and any configuration.
a. Evaporator
b. Condenser
c. Cab control
d. Compressor mounting kit
e. Vehicle battery
f. Standby plug
g. Main road fuse
3. WARNINGS AND PRECAUTIONS
This manual contains safety and service instructions to follow in order to prevent any accident. Some of
following stickers have been placed on the product for your SAFETY.
BEFORE USING THIS REFRIGERANT UNIT, read carefully all safety information
explained in this manual and indicated on the product. Be sure that everybody who will
use this refrigeration unit has been trained to use it in a safe way.
DURING THE USE OR MAINTENANCE OF THIS REFRIGERATION UNIT, the notes on safety are to
be considered.
Personal Protective Equipment :
Always use adequate Personal Protective Equipment before doind anything on this
refrigerant unit, as explained in this manual.
Working at height :
Take all necessary safety precautions when accessing this refrigeration unit : use safe
ladders, working platforms with appropriate guards.

662--61177--01
Automatic start :
This refrigeration unit is equipped with Auto--Start/Stop, a valuable fuel saving feature.
When this refrigeration unit is set for Auto--start/Stop operation it may start at any time
and without warning.
Before servicing refrigeration unit, make sure the main power switch is on the OFF position. Ensure the
unit will not restart.
Lock--out / Tag--out can be performed by disconnecting and enclosing :
-- The negative battery cable in diesel mode
-- The electrical plug in electrical mode.
Belts and fans :
This refrigeration unit is equipped with Auto--start/stop, it may start at any time and
without warning.
When the unit is running beware of belts and fans that are moving.Before servicing refrigeration unit,
make sure the main power switch is on the OFF position.
Ensure the unit will not restart. Lock--out / Tag--out can be performed as described above.
When there is protective structure (fan grid or guard for example) make sure they are in place. Never
removed them when the refrigeration unit is running.
Always keep your hands, body parts, clothes, hairs and tools far from moving parts.
Electricity :
When this refrigeration unit is running in electrical operation, some devices are powered
up especially in the electrical control box.
Before servicing refrigeration unit, make sure the main power switch is on the OFF
position. Ensure this refrigeration unit is disconnected from the local electrical
network.Lock--out / Tag--out can be performed as described above.
Before working in the electrical control box, it is required to control the lack of tension.
WHEN IT IS NECESSARY TO WORK IN THE ELECTRICAL CONTROL BOX UNDER
TENSION, PEOPLE MUST BE QUALIFIED FOR WORKS UNDER LOW OR HIGH
VOLTAGE.
Always use adequate tools and Personal Protective Equipment when working on
electrical devices : safety gloves and safety glasses.

7
62--61177--01
Engine coolant :
This refrigeration unit is equipped with a pressurised cooling system. Under normal
operating conditions, the coolant in the engine and radiator is under high pressure and
very hot.
Coolant is very slippery. It can be harmful in case of ingestion.
Never remove the cap from a hot radiator when this refrigeration unit is running or
immediately after.
If the cap must be removed, wait at least 10 minutes and then do so very slowly in
order to release the pressure without spray.
In case of leakage, immediatly clean the floor to prevent slipping.
Avoid contact with the skin and eyes. Always use Personal Protective Equipment when
handling engine coolant : safety clothes, safety gloves and safety glasses.
Refrigerant :
The refrigerant contained in this refrigeration unit can cause frosbite, severe burns or
blindness in case of projection and direct contact with the skin or eyes.
In contact with flame or heat refrigerant generate toxic gas.
Refrigerant handling must be done by qualified people.
Keep any flame, any lighted object or any source of sparks away from the refrigerant
unit.
Always use Personal Protective Equipment when handling refrigerant : safety clothes,
safety gloves and safety glasses.
First aid in case of frost--bite :
a. Cover up the frost--bitten part.
b. Quickly warm up the frost--bitten part by dipping it into lukewarm water (not hot). If you
don’t have water, wrap the injured part in a clean cloth.
c. If refrigerant fluid has been splashed into your eyes, rinse them immediately with clean
water. As a precaution, you are recommended to have a medical examination as well.
Burning with hot and cold :
When this refrigeration unit is running or even after, different components can be very
cold or hot (exhaust pipe, tubes, coils, receiver, accumulator or engine for example)
Beware when operating closed from cold or hot components.
Always use adequate safety gloves when doing any maintenance on this refrigeration
unit.
Cuttings :
Beware when handling or operating closed from parts that could be sharp (coils,
evaporators, clamps for example).
Always use adequate safety gloves when doing any maintenance on this refrigeration
unit.

862--61177--01
Battery :
This refrigeration unit may be equipped with a lead--acid type battery. When charging
the battery normally vents small amounts of flammable and explosive hydrogen gas.
Projections of acids on the skin or eyes can cause severe burns.
Keep any flame, any lighted object or any source of sparks away from the battery
elements.
Always use Personal Protective Equipment when handling and charging battery: safety
clothes, safety gloves and safety glasses.
Cooling oil :
-avoid prolonged or repeated contact with the skin.
-wash carefully after handling.
“Low pollution” engine :
-The TRI--VORTEX--type indirect injection system minimizes exhaust fume pollution.
-NEVER START THE ENGINE IN A CLOSED ROOM, EXHAUST GAS IS
POISONOUS.
-It is colorless and odorless and created by the incomplete combustion of
hydrocarbons.
-Exhaust gas is poisonous, breathing it in induces drowsiness and may lead to
loss of consciousness.
The following symptoms indicate exhaust gas has been inhaled :
-Blackout, intense headache, sudden weakness and sleepiness, vomiting, muscular
contractions, beating temples.
If you feel one of the above mentioned symptoms, go out and breathe fresh air.
If you notice a noise or modification of the exhaust system, immediately stop the engine
and call your service centre for checking and repair.
Environment :
Think about protection of environment during all the life of this refrigeration unit.
To prevent environmental damages NEVER release refrigerant in the atmosphere, NEVER throw
coolant, oil, battery and chemicals in the nature. It must be recuperate and recycle according to current
regulations.
When disposing this refrigerant unit do it in an environmentally sound way and in accordance with
current regulations.

9
62--61177--01
CAUTION
Under no circumstances should anyone attempt to repair the Logic or Display
Boards. Should a problem develop with these component, contact your nearest
Carrier Transicold dealer for replacement.
Under no circumstances should a technician electrically probe the processor at any point, other
than the connector terminals where the harness attaches. Microprocessor components operate at
different voltage levels and at extremely low current levels. Improper use of voltmeters, jumper
wires, continuity testers, etc. could permanently damage the processor.
Most electronic components are susceptible to damage caused by electrical static discharge
(ESD). In certain cases, the human body can have enough static electricity to cause resultant
damage to the components by touch. This is especially true of the integrated circuits found on the
truck/trailer microprocessor.
3.1. Warning stickers maintenance
a. Keep the warning pictograms clean and without any obstruction material.
b. Clean the pictograms with water and soap and wipe them with soft fabric.
c. Replace damaged or missing pictograms with new pictograms available in Carrier network.
d. If a component having a pictogram is replaced by a new one, be sure that the new component has the
right pictogram.
e. Place a warning pictogram by applying it on a dry surface. Press to external sides to eliminate air bubbles.
4. PRODUCT LOADING
Proper air circulation in the insulated box, air that can move around and through the load, is a critical element
in maintaining product quality during transport. If air cannot circulate completely around the load, hot spots or
top--freeze can occur.
The use of pallets is highly recommended. Pallets, when loaded so air can flow freely through the pallets to
return to the evaporator, help protect the product from heat passing through the floor of the truck. When using
pallets, it is important to refrain from stacking extra boxes on the floor at the rear of the truck, because this will
cut off the airflow.
Product stacking is another important factor in protecting the product. Products that generate heat, fruits and
vegetables for example, should be stacked so the air can flow through the product to remove the heat; this
is called “air stacking” the product. Products that do not create heat, meats and frozen products, should be
stacked tightly in the center of the box. All products should be kept away from the sidewalls of the body, allo-
wing air to flow between the body and the load; this prevents heat filtering through the walls from affecting the
product.
It is important to check the temperature of the product being loaded to ensure that it is at the correct
temperature for transport. The refrigeration unit is designed to maintain the temperature of the product at the
temperature at which it was loaded; it was not designed to cool a warm product.

10 62--61177--01
SOME ADVICE
Before loading
DPre--cool the inside of the insulated body by lowering the temperature for about 15 minutes.
DEvacuate the humidity existing inside the box by carrying out a manual defrost. This can only take place
when enabled by the defrost thermostat (box temperature lower than 3_C.
DEvaporator fans are protected by safety grills. In the event of heavy duty use of the unit, ice can accumulate
on the grills. It is therefore recommended to clean them regularly by means of a small brush. The operation
MUST be done when the unit has been SHUT DOWN.
When loading
DTo be carried out with the unit stopped.
DIt is recommended to open doors as little as possible to avoid the intake of hot air and humidity.
DSelect the temperature by means of the thermostat, according to the transported goods.
DCheck the internal temperature of the goods being loaded (using a probe thermometer).
Load spacers
Load on pallets
DTake care not to obstruct the air intakes on
the evaporator section and the ventilation
ducts.
DLeave a free space of about :
- 6 to 8 cm between load and frontwall,
- 20 cm between the top of the load and the
roof,
- between the floor and the load (gratings,
pallets).
DDo not forget to close the doors.
DBefore closing the doors, check your load once more and see that nobody is shut inside the box.
NOTE :
For stationnary utilization, we recommend
to place the body in the shade.
IMPORTANT
Never leave your unit more than a month
without running.

11
62--61177--01
5. RECOMMENDED TRANSPORT TEMPERATURES
Below are some general recommendations on product transport temperatures and operating modes for the
unit. These are included for reference only and should not be considered pre--emptive of the setpoint required
by the shipper or receiver.
More detailed information can be obtained from your Carrier Transicold dealer.
Product Set--point Range
Bananas 15_C60_F
Fresh fruits and vegetables +4_Cto+6_C+39_Fto+43_F
Fresh meats and seefood +2_C+36_F
Dairy Products +2_Cto+6_C+36_Fto+43_F
Ice -- 2 0 _C15_Fto20_F
Frozen fruits and vegetables -- 1 8 _C 0_F
Frozen meats and seafood -- 2 0 _C-- 1 0 _Fto0_F
Ice cream -- 2 5 _C-- 2 0 _F
* During delivery cycles that include frequent stops and door openings, it is recommended that the unit always
be operated in the continuous run mode to help insure product quality. It is essential to shut down the unit during
the periods when the body doors are open, in order to maintain the temperature of the cargo and keep the unit
operating correctly.
6. QUICK GLANCE ON THE DISPLAY BOARD
Keep the fold out sheet while reading the instructions.
6.1. Cab control
Keep the fold out sheet while reading the instructions.
This functionnal accessory simplifies all control operations. From his seat, the driver can carry out all the
control operations : shut--down, automatic start--up in road mode, adjusting the setpoint, defrost.
The driver can display the box temperature and see whether the setpoint is being maintained by checking the
green indicator. The indicator lights up red in the event of a malfunction. When the battery voltage is too low,
a fail--safe system shuts down the unit. Unit restart is automatic and time--delayed if the voltage rises to the
normal level.
1. Display
2
S
t
a
n
d
b
y
o
p
e
r
a
t
i
o
n
L
E
D
6. Set key
7
+
k
2. Standby operation LED
3. Road operation LED
7. +key
8
.
O
FF k
e
y
3
.
R
o
a
d
o
p
e
r
a
t
i
o
n
L
E
D
4. Manual defrost key
8
.
O
F
F
k
e
y
9. ON key
5. -- key 10. Unit operation display
G
r
e
e
n
:
o
f
f
c
y
c
l
e
(
l
e
f
t
h
a
l
f
)
G
reen : o
f
f
cyc
l
e
(
l
e
f
t
h
a
l
f
)
Red : malfunction (right half)

12 62--61177--01
7. OPERATION
Keep the fold out sheet while reading the instructions.
7.1. Operating principle
After starting up, the refrigeration unit by pressing the ON (9.) key, unit start--up and shut--down are automatic.
7.1.1. In ROAD mode
An open--type compressor is driven by the engine of the vehicle. The vehicle battery (alternator) powers the
evaporator and condenser fans. The unit automatically shuts down when the engine is switched off with the
ignition key.
7.1.2. In STANDBY mode
A standby compressor is energized, and a transformer is used to power the evaporator and condenser fans.
The power network connection is detected by the Cab Command which automatically starts up the unit in
Standby mode.
If the ignition key is switched on while the unit is connected to the power network, or vice--versa, the Cab
Command triggers a visual alarm, in the form of a flashing red malfunction light and readout.
As soon as one operating mode is inhibited, the unit automatically starts up in the other mode. An output for
a buzzer alarm is available on the unit.
In all cases the unit can be completely shut down manually by pressing the OFF key on the Cab Command.
7.1.3. Temperature control
As soon as the set--point temperature has been reached, temperature control is obtained by the start--up and
shut--down of the standby compressor. On road mode, this shut-down is done by the road compressor
electro-magnetic clutch.
The condenser and evaporator fans cut out during regulation. When transporting fragile loads such as fresh
meat, vegetables and cheese, it is possible to program the microprocessor to obtain continuous ventilation
by the evaporator during regulation.
7.1.4. Defrost
-Defrost operation is fully automatic but can be manually controlled if enabled by the defrost
thermostat.
-Defrost cycles are fully controlled by the integrated microprocessor.
-During the defrost cycle, the evaporator fan shuts down. The condenser fan is controlled by the
microprocessor.
-Defrost cycle termination is controlled by a defrost thermostat.
-During the defrost cycle, the Cab Command display indicates “d F”.

13
62--61177--01
7.1.5. Heating
-The heating option (by hot gas) is delivered STANDARD on XARIOS 600 and only on REQUEST
on other units.
-The evaporator fan operates, the condensor fan is controlled by the microprocessor.
7.1.6. Control components
Cab control :
-Automatic selection of road or standby operation.
-Shut--down.
-Manual defrost.
-Thermostat control.
-Error messages in the event of unit malfunction.
-Programming to customize unit operation to your own requirements.
7.2. Operation on ROAD mode
7.2.1. Starting the unit
1. Check the belt tension of the charge alternator and road compressor drive belts.
2. Start the vehicle engine.
3. Start the unit by pressing the ON key (9.). Start--up is time--delayed for 40 seconds.
4. The digital display (1.) of the cab control displays the box temperature.
5. Check the temperature setpoint is correct by pressing the SET key (6.). The setpoint temperature is
highlighted on the digital display.
6. Enter a new setpoint if necessary (see temperature setpoint adjustment 7.5. -- page 16).
In the event of difficulty on start--up, check that :
The main road fuse has not blown (g. -- p. 5)
The temperature selected by the cab control has not been affected.
7.2.2. Stoping the unit
1. For a short stop (ie : delivery) : switch off by the vehicle ignition key.
2. For a long stop : press the OFF key (8.).

14 62--61177--01
7.3. Operation on STANDBY mode
VERY IMPORTANT
THE UNIT MUST BE SHUT--DOWN BEFORE CONNECTING OR DISCONNECTING THE
STANDBY SUPPLY CABLE !
1. Before starting :
-On the power network : check that the type of current corresponds to the characteristics of the
unit (see paragraph 7.3.3.).
-On the unit : connect the unit to the power network.
7.3.1. Starting the unit
2. Start the unit by pressing the ON key (9.). Start--up is time--delayed for 10 seconds.
3. The digital display (1.) of the cab control displays the box temperature.
4. Check the temperature setpoint is correct by pressing the SET key (6.). The setpoint temperature is
highlighted on the digital display.
5. Enter a new setpoint if necessary (see temperature setpoint adjustment 7.5. -- page 16).
In the event of difficulty on start--up, check that :
Network supply is ok.
The control box fuses have not blown (refer to the electric schematic supplied with the unit).
The temperature selected by the cab control has not been affected.
7.3.2. Stoping the unit
1. Press the OFF key (8.).
7.3.3. Standby operation guidelines
For safe, reliable operation in Standby mode, it is important to consider the following guidelines :
a. ALWAYS CHECK that the unit if OFF (Cab command) before connecting or disconnecting it from the
power source.
b. The extension cable and fuse used for network connection must comply with the legislation currently appli-
cable on the site of use (minimum H07 RNF CEI 245--4) and with the unit specifications as described in
the table below :

15
62--61177--01
M
a
x
i
m
u
m
a
m
p
e
r
a
g
e
f
o
r
o
p
e
r
a
t
i
o
n
e
q
u
i
p
m
e
n
t
M
a
x
i
mum amperage
f
or operat
i
on equ
i
pment
Operating voltage XARIOS 500--04 XARIOS 600
230/1/50Hz 17.2 amps 17.2 amps
230/3/60Hz 16.6 amps 16.6 amps
208-230/1/60Hz 20 amps 20 amps
400/3/50Hz 8amps 10.7 amps
Operating voltage XARIOS 300--05 XARIOS 350--05
230/3/50Hz/60Hz Not available 8.8 amps
400/3/50Hz/60Hz 4.9 amps 5amps
230/1/50Hz 5.6 amps 11 amps
208/230/1/60Hz Not available 11.7 / 10.7 amps
115/1/60Hz Not available 18.3 amps
Operating voltage XARIOS 150--04 XARIOS 200--04
400/3/50Hz 2.4 amps 2.4 amps
230/1/50Hz 8amps 8amps
208/230/1/60Hz Not available 9amps
c. The unit connection cable must be fitted with a ground connection. The cable must be connected to earth.
d. When performing service and/or maintenance procedures on a refrigeration unit, make certain that the
unit is disconnected from the power source and that the keypad correctly indicates “OFF”, and that it is
impossible for the unit to start up automatically during the maintenance operation.
e. The user is liable for ensuring that the above measures are taken.
f. An internal sensor protects the standby compressor from overtensions or overheating.

16 62--61177--01
7.4. To change display brightness
1. Press the ON (9.) to start the unit.
2. Press the -- or + key (5. or 7.) during 5 seconds to increase or decrease the display brightness.
7.5. To change setpoint temperature
IMPORTANT
If, when settings are adjusted, no key is activated within 5 sec. the system reverts to displaying
the box temperature. All changes made are recorded.
If the cab command is built into the vehicle control panel, the command unit must be located as far as
possible from the heating ducts. Maximum temperature of exposure : 70_C.
NOTE : Set the cab command to road or standby operation before programming.
1. Press the SET key (6.) to display setpoint temperature.
2. Press the -- or + key (5. or 7.) to change the setpoint.
3. Press the SET key (6.) to return to box temperature display.
7.6. To change defrost parameters
IMPORTANT
If, when settings are adjusted, no key is activated within 5 sec. the system reverts to displaying
the box temperature. All changes made are recorded.
1. Press the OFF key (8.) to shut--down the unit.
2. Press simultaneously the DEFROST key (4.) AND the ON key (9.) to display last selected defrost
interval.
3. Press the -- or + key (5. or 7.) to change the defrost interval :
00 : inhibit defrost function.
0,5 to 0,9 : Decrease time interval between 2 automatic defrost cycles in relation to calculated time.
AUT (coefficient 1) : microprocessor--optimized automatic defrost according to type of cargo
transported. (Variable intervals)
1,1 à 1,5 : Increase time interval between 2 automatic defrost cycles in relation to calculated time.
1 H, 2 H,... 6 H : Fixed defrost interval in hours.
4. Press the SET key (6.) to return to box temperature display.

17
62--61177--01
7.7. To change other datas
IMPORTANT
If, when settings are adjusted, no key is activated within 5 sec. the system reverts to displaying
the box temperature. All changes made are recorded.
1. Press the SET key (6.) during 5 seconds to enable access to malfunction codes (see 7.9. for alarm
list).
2. Press the -- or + key (5. or 7.) to display alarms
3. Press the SET key (6.) to display software versions.
4. Press the + key (7.) to display cab command software version.
5. Press the SET key (6.) to display road hourmeter.
6. Press the SET key (6.) to display standby hourmeter.
7. Press the DEFROST key (4.) to display the defrost interval (mn) calculated by the microprocessor
between 2 defrosts.
8. Press the DEFROST key (4.) again to display elapsed time (mn) since the last defrost.
9. Press the SET key (6.) to return to box temperature display.
7.8. To change default parameters
IMPORTANT
If, when settings are adjusted, no key is activated within 5 sec. the system reverts to displaying
the box temperature. All changes made are recorded. Malfunction codes remain displayed.
1. Press simultaneously the -- and + and DEFROST keys (5. and 7. and 4.) to display minimum setpoint.
2. Press the -- or + key (5. or 7.) to change the minimum setpoint : 0_C, - 20_Cor-29_C (default value
-- 2 9 _C)
3. Press the SET key (6.) to display maximum setpoint.
4. Press the -- or + key (5. or 7.) to change the maximum setpoint : + 20_Cor+30_C (default value
+20_C)
5. Press the SET key (6.) to display differential parameter .
6. Press the -- or + key (5. or 7.) to adjust the differential value : Dif1 (1_C), Dif2 (2_C) or Dif3 (3_C)
(default value Dif2).
7. Press the SET key (6.) to display evaporator fan operating mode during off--cycle.
8. Press the -- or + key (5. or 7.) to change the evaporator fan operating mode : FOFF or F On (FOFF by
default).
9. Press the SET key (6.) to return to box temperature display.

18 62--61177--01
7.9. Fault alarm display
a. Access by the SET key
1. Press the SET key (6.) during 5 seconds to access to malfunction codes.
2. Press the -- or + key (5. or 7.) to display alarms
-Current malfunctions: AXX
-Past malfunctions : PXX
3. If several malfunctions occur simultaneously, list them using the -- or + keys (5. or 7.).
MALFUNCTION CODE -- Red LED flashes
CODE DESCRIPTION
AL00 No malfunction. Unit in operation
AL01 Low pressure switch open
AL02 High pressure switch open
AL03 Standby compressor over heated
AL04 Clutch compressor fault
AL05 Contactor fault
AL06 Condenser fault
AL07 Evaporator fan fault
AL08 Hot water solenoid fault
AL09 Defrost valve (HGS1) fault
AL10 Liquid injection valve fault
AL11 Hot gas valve (HGS2) fault
AL12 High temperature alarm
AL13 Low temperature alarm
AL14 Defrost alarm > 45 minutes
AL15 Setpoint adjusted out of the range -29_C/+30_C
AL16 Drain water resistor fault
AL17 Thermal break down standby transformer or diode bridge protection fault
AL18 Electrical heating relay fault
AL19 Liquid solenoid valve fault
AL20 LP standby pressure switch opened
AL21 Open circuit contactor compressor

19
62--61177--01
MALFUNCTION CODE -- Red LED flashes
AL22 Open circuit condenser fan
AL23 Open circuit hot water solenoid
AL24 Open circuit defrost valve (HGS1)
AL25 Open circuit liquid injection valve
AL26 Open circuit hot gas valve (HGS2)
AL27 Open circuit drain water resistor (DWR1)
AL28 Open circuit electrical heating relay (EHR)
b. Direct access
EE Malfunction : evaporator temperature probe (open circuit)
bAt Battery low voltage alarm
-- -- --
-- -- --
-- -- --
Twin power supply (road and standby)
Err Programming mistake of the maximum setpoint by the user
-- -- -- Setpoint lower than maximum setpoint but in the range - 29_C/+30_C
NOTE :
Direct access malfunction messages are displayed instead of temperature read--out as soon as the
malfunction is detected, and remain displayed as long as malfunction persists.
The unit does not run until the malfunction has disappeared or been corrected.
8. MAINTENANCE
A comprehensive maintenance program will help to insure that the unit continues to operate reliably. Such a
maintenance program will also help to control operating costs, increase the unit’s working life, and improve
performance.
NOTE
All maintenance services must be done by a technician trained on Carrier products respecting
all safety and quality standards of Carrier.
Before any operation requiring an intervention on the unit, check that :
-the unit (cab command) is OFF.
-it is impossible for the unit to automatically start--up during maintenance.

20 62--61177--01
8.1. Maintenance schedule
Service operations are to be carried out according to this schedule : Interval = road + standby hourmeters.
Unit Hours 100 1000 2000 3000 4000 5000 6000 7000
X
arios Initial service H
X
a
r
i
o
s
150/200/300/350/ Service A HHHHHH H
1
5
0
/
2
0
0
/
3
0
0
/
3
5
0
/
500 & 600 Service B H H H
8.2. Services description
Initial Service
Check that the road compressor RPM high and low are correct.
Check the compressor kit is correctly tightened / belt tension.
Check the tightness of bolts and screws and that the unit is correctly fastened onto the
box.
Service A
Check pressure switches, injection thermostats and defrost system.
Clean up battery and battery clamps.
Replace belt(s) compressor(s).
Check for refrigerant leaks.
Check the refrigerant level.
Check the standby compressor oil level.
Check the operation of the cab control.
Service B Replace condenser fan motor brushes.
Replace idler pulley bearings if any.
EVERY
YEAR
Replace filter drier.
Clean up the TXV orifice filter.
EVERY TWO
YEARS
Replace compressor(s) oil -- only use Ester oil (POE) approved by Carrier Transicold.
Replace refrigerant.
Replace orifice expansion valve.
Refrigerant : type R404A
Road compressor oil type : The road compressors are supplied with CARRIER POLYOLESTER (POE) oil.
The presence of a sticker indicates that oil--change has been correctly carried out in our Carrier Transicold
plant. Oils of PAG type are strictly incompatible with the operation of our units : never use an oil other than
that approved by Carrier.
Oil analysis : on request, we can analyze your compressor oil.
To do this, we send a small drum with a label on which you should indicate : the type of compressor, the lapse
time or mileage since the last oil change, the type of Carrier equipment, the date of initial operation
