Carrot LA3-TBL5D User manual

1
QUICK START GUIDE
用戶使用手冊

2
QUICK START GUIDE 用戶使用手冊
Thank you for your purchase of Carrot Home Starter Kit. This kit contains the Carrot Touch and an
IR Repeater. Carrot Touch is a powerful touch screen tablet that can be used for control and setting
of up the Carrot Home Automation (HA) System. The IR Repeater extends the control of infrared
aware appliances to areas away from your Carrot Touch. By using additional IR Repeaters as needed
(purchased separately), you can control IR-aware appliances throughout your home.
感谢您选购家乐屋家居系统。本产品能完美地融入家乐屋智能家居系统，令用户能使用 Carrot Touch
智能平板来遥控家中的红外線家电设备。家乐屋智能系统可同时使用多台红外线信号转发器以达到全屋无缝
覆盖。

1
QUICK START GUIDE 用戶使用手冊
Thank you for your purchase of Carrot Home Starter Kit. This kit contains the Carrot Touch and an
IR Repeater. Carrot Touch is a powerful touch screen tablet that can be used for control and setting
of up the Carrot Home Automation (HA) System. The IR Repeater extends the control of infrared
aware appliances to areas away from your Carrot Touch. By using additional IR Repeaters as needed
(purchased separately), you can control IR-aware appliances throughout your home.
感谢您选购家乐屋家居系统。本产品能完美地融入家乐屋智能家居系统，令用户能使用 Carrot Touch
智能平板来遥控家中的红外線家电设备。家乐屋智能系统可同时使用多台红外线信号转发器以达到全屋无缝
覆盖。

2
CARROT HOME STARTER KIT FEATURES
家乐屋入門套装功能
 Control functions for air conditioning with settings for heat, cool, fan, dry and o modes; temperature
and fan speed settings; end user can designate locations and names for the airconditioners
 Control functions for Audio-visual or other appliances that are controllable via infrared (IR) codes,
either downloaded from the Carrot Cloud or learned by the users directly using Carrot Touch
 Control functions for lighting ON/OFF, and dimming; end user can designate locations and names
for the light circuits (Optional with Carrot Light Switch)
 Control functions for open and close of motor curtain; end user can designate locations and names
for the curtain motors (Optional with Carrot Curtain Switch)
 User dened scenario including control functions from lighting, aircon, curtain and other
IR controllable appliances. User can dene time delays between IR commands
 User can dene time schedules to trigger scenarios automatically
 User can perform pairing of Carrot switches, dimmers, and IR-repeaters directly from Carrot Touch
 Digital picture frame function
 Language supported English, Traditional Chinese and Simplied Chinese
 iOS and Android App for lighting, aircon, curtain, scenario and IR appliance control using Carrot
Cloud Services
 Download IR codes using Carrot Cloud Services
 空调控制功能，可调节暖风、冷风、送风、除湿及关闭模式，以及温度及风速等，用户更可自订空调位处
的房间及名称
 用从 Carrot Cloud (家乐屋云端)下载或用户自行＂学习＂的红外线代码来控制影音电器的功能
 电灯开关及光度调节控制功能，用户可自订电灯电路的位置和名称(此自选项目需另购家乐屋电灯开关)
 电动窗帘开关控制功能。用户可自订电动窗帘的位置和名称(此自选项目需另购家乐屋电灯开关)
 用户自订电子情景，包括电灯、空调、电子窗帘及其他可通过红外线控制的电器。用户可以指定红外线指
令之间的时延
 用户可自订运行时间表，系统将自行启动不同情景
 用户可以直接从 Carrot Touch 执行家乐屋开关、光暗调节开关和红外线重复器的配对
 数码相框
 支持英文，繁体中文和简体中文
 利用家乐屋云端服务的 iOS 及 Android 流动应用程式，可遥控电灯、空调、窗帘、情景及红外线(IR)
可控的电器
 利用家乐屋云端服务下载红外线代码

3
CARROT HOME STARTER KIT FEATURES
家乐屋入門套装功能
 Control functions for air conditioning with settings for heat, cool, fan, dry and o modes; temperature
and fan speed settings; end user can designate locations and names for the airconditioners
 Control functions for Audio-visual or other appliances that are controllable via infrared (IR) codes,
either downloaded from the Carrot Cloud or learned by the users directly using Carrot Touch
 Control functions for lighting ON/OFF, and dimming; end user can designate locations and names
for the light circuits (Optional with Carrot Light Switch)
 Control functions for open and close of motor curtain; end user can designate locations and names
for the curtain motors (Optional with Carrot Curtain Switch)
 User dened scenario including control functions from lighting, aircon, curtain and other
IR controllable appliances. User can dene time delays between IR commands
 User can dene time schedules to trigger scenarios automatically
 User can perform pairing of Carrot switches, dimmers, and IR-repeaters directly from Carrot Touch
 Digital picture frame function
 Language supported English, Traditional Chinese and Simplied Chinese
 iOS and Android App for lighting, aircon, curtain, scenario and IR appliance control using Carrot
Cloud Services
 Download IR codes using Carrot Cloud Services
 空调控制功能，可调节暖风、冷风、送风、除湿及关闭模式，以及温度及风速等，用户更可自订空调位处
的房间及名称
 用从 Carrot Cloud (家乐屋云端)下载或用户自行＂学习＂的红外线代码来控制影音电器的功能
 电灯开关及光度调节控制功能，用户可自订电灯电路的位置和名称(此自选项目需另购家乐屋电灯开关)
 电动窗帘开关控制功能。用户可自订电动窗帘的位置和名称(此自选项目需另购家乐屋电灯开关)
 用户自订电子情景，包括电灯、空调、电子窗帘及其他可通过红外线控制的电器。用户可以指定红外线指
令之间的时延
 用户可自订运行时间表，系统将自行启动不同情景
 用户可以直接从 Carrot Touch 执行家乐屋开关、光暗调节开关和红外线重复器的配对
 数码相框
 支持英文，繁体中文和简体中文
 利用家乐屋云端服务的 iOS 及 Android 流动应用程式，可遥控电灯、空调、窗帘、情景及红外线(IR)
可控的电器
 利用家乐屋云端服务下载红外线代码

4
CARROT TOUCH™
IR transmitter and receiver
红外线收发器
LED indicator for charging
LED指示灯
MicroSD memory card slot
MicroSD 记忆咭插槽
Main switch
主开关
Main touch screen
主触摸屏幕
Base station connection point
机座连接点
TECHNICAL INFORMATION 技术规格
Catalogue Number 目录编号 LA3-TBL5D
Operating Frequency 工作频率 433.05 MHz–434.79 MHz
Output RF Power 输出射频功率 <10mW
Resolution 屏幕分辨率 800 x 480 Landscape Mode
Operating Temperature Range 工作温度范围 00–400C
Operating Humidity Range 工作湿度范围 0–95% RH non-condensing
Connectivity 连通性 Wireless LAN
Video intercom function 可视对讲功能 Yes
Speaker 扬声器 Yes
Microphone 麦克风 Yes
Color Options 颜色选项 White: LA3-TBL5D-W or Black: LA3-TBL5D-B
Compliance 合规 IEC 60950-1

5
CARROT TOUCH™
TECHNICAL INFORMATION 技术规格
Catalogue Number 目录编号 LA3-TBL5D
Operating Frequency 工作频率 433.05 MHz–434.79 MHz
Output RF Power 输出射频功率 <10mW
Resolution 屏幕分辨率 800 x 480 Landscape Mode
Operating Temperature Range 工作温度范围 00–400C
Operating Humidity Range 工作湿度范围 0–95% RH non-condensing
Connectivity 连通性 Wireless LAN
Video intercom function 可视对讲功能 Yes
Speaker 扬声器 Yes
Microphone 麦克风 Yes
Color Options 颜色选项 White: LA3-TBL5D-W or Black: LA3-TBL5D-B
Compliance 合规 IEC 60950-1

6
ACCOUNT REGISTRATION 登记账户
Follow on-screen steps to nish registration
按画面指示完成登记
Language–Select desired language
语言–选择操作系统之语言
WiFi–Join your home WiFi network with the wireless network password
无线网络–连接家居无线网络
If you are a rst time user, you need to rst create a new Carrot Cloud account. Please ll in your email address and type a new
password. Then, select “Create Account”to create a new account.
If you already have an existing Carrot Cloud account, or you are setting up additional Carrot Touch to use in the same system, please
just ll in the email address you used previously to create the account, and then enter the previous password. This time, please select
“Login” to log into the system directly. If, however, you know you had an existing account but forgot its password, please enter the
email address you used previously to create the account, then select the icon to have the password sent to your email address.
如果你是首次用户，你需要首先开设新的 Carrot 云端帐户。请填妥你的电邮地址及输入新密码。然后，选择「建立新帐户」以开设新帐户。如果你
已经有一个 Carrot 云端帐户，或你正在同一系统中使用额外的 Carrot Touch，请填妥你原有的电邮地址以开设帐户，接着输入原有的密码。这时，
请选择「登入」以直接登入系统。但如果你是现有用户，但忘记密码，请输入你开设帐户时使用的电邮地址，然后按下相关图示 以便把密码发送至
你的电邮地址。
CHARGING THE DEVICE 为你的产品充电
Connect your Carrot
Touch to Base station
把Carrot Touch连接至机座
Connect your A/C
adaptor to Base station
为机座接上电源适配器

7
ACCOUNT REGISTRATION 登记账户
Follow on-screen steps to nish registration
按画面指示完成登记
Language–Select desired language
语言–选择操作系统之语言
WiFi–Join your home WiFi network with the wireless network password
无线网络–连接家居无线网络
If you are a rst time user, you need to rst create a new Carrot Cloud account. Please ll in your email address and type a new
password. Then, select “Create Account”to create a new account.
If you already have an existing Carrot Cloud account, or you are setting up additional Carrot Touch to use in the same system, please
just ll in the email address you used previously to create the account, and then enter the previous password. This time, please select
“Login” to log into the system directly. If, however, you know you had an existing account but forgot its password, please enter the
email address you used previously to create the account, then select the icon to have the password sent to your email address.
如果你是首次用户，你需要首先开设新的 Carrot 云端帐户。请填妥你的电邮地址及输入新密码。然后，选择「建立新帐户」以开设新帐户。如果你
已经有一个 Carrot 云端帐户，或你正在同一系统中使用额外的 Carrot Touch，请填妥你原有的电邮地址以开设帐户，接着输入原有的密码。这时，
请选择「登入」以直接登入系统。但如果你是现有用户，但忘记密码，请输入你开设帐户时使用的电邮地址，然后按下相关图示 以便把密码发送至
你的电邮地址。
CHARGING THE DEVICE 为你的产品充电

8
LOGGING IN 进入首页
Home Screen
This is the Home Screen where you can nd all the icons for
various control functions, but you need to rst set up the HA
system.
主萤幕
这是主萤幕，你可以找到各种遥控功能的图示，但你需要首先设定
HA系统。
After connecting to the internet, the
Carrot Touch will check if there is newer
version of rmware, please wait for the
download to complete.
连接到互联网后，Carrot Touch 将检查固件是
否有更新版本，请等候下载完成。
When you see there is a prompt to replace
application select "OK".
当你看到替换应用程式的提示讯息，请选择
「OK」。
And then select "Install" to update the
rmware.
然后选择「Install」以更新固件。
ACCOUNT REGISTRATION 登记账户

9
LOGGING IN 进入首页
Settings
Enter Settings page to set up Carrot HA system.
设定
进入系统设定页面。
Home Screen
This is the Home Screen where you can nd all the icons for
various control functions, but you need to rst set up the HA
system.
主萤幕
这是主萤幕，你可以找到各种遥控功能的图示，但你需要首先设定
HA系统。
And then select "Install" to update the
rmware.
然后选择「Install」以更新固件。
ACCOUNT REGISTRATION 登记账户

10
DOWNLOAD IR CODES FROM SERVER
从服务器下载IR代码
Carrot Touch has a built-in IR Emitter and Learner, so you can use it as a Universal IR Remote.
Before you can use it to replace your multiple remote controllers, you must give it the IR codes used
to control your IR-aware appliances. One of the easiest ways is to download the IR codes from the
Carrot Cloud.
Step 2
Select “Air-conditioning” or "Other IR
device" and input device name.
第二步
选择「空调」或「其他红外线设备」，然后输
入装置名称。
Step 3
Select “Download from server”.
第三步
选择「从服务器下载」。
Carrot Touch 有一个内置的红外线发射器及学习器，可作为通用的红外线遥控器使用。在你使用它来代替
多个遥控器之前，你必需设定IR代码以控制你的红外线电器。最简单的方法之一是从 Carrot Cloud 下载
IR代码。
Step 4
Select the Aircon Brand and model and
press OK.
Make sure you know the correct model
of the aircon. It takes a few seconds to
download the IR codes.
第四步
选择空调品牌及型号，然后按「确定」。
请确保您知道空调的型号。下载红外线代码需
要几秒钟。
Step 1
Enter this section to set up IR codes for
your appliances.
第一步
进入此部份为你的电器设定IR代码。

11
DOWNLOAD IR CODES FROM SERVER
从服务器下载IR代码
Carrot Touch has a built-in IR Emitter and Learner, so you can use it as a Universal IR Remote.
Before you can use it to replace your multiple remote controllers, you must give it the IR codes used
to control your IR-aware appliances. One of the easiest ways is to download the IR codes from the
Carrot Cloud.
Step 3
Select “Download from server”.
第三步
选择「从服务器下载」。
Carrot Touch 有一个内置的红外线发射器及学习器，可作为通用的红外线遥控器使用。在你使用它来代替
多个遥控器之前，你必需设定IR代码以控制你的红外线电器。最简单的方法之一是从 Carrot Cloud 下载
IR代码。
Step 4
Select the Aircon Brand and model and
press OK.
Make sure you know the correct model
of the aircon. It takes a few seconds to
download the IR codes.
第四步
选择空调品牌及型号，然后按「确定」。
请确保您知道空调的型号。下载红外线代码需
要几秒钟。
Step 5
You can then test the Aircon IR code you just downloaded to Carrot Touch. To test, go to
Aircon section shown above. Then, point the topside of the Carrot (where IR transmitter
is located) towards the Aircon unit and select the desired control functions.
第五步
接着，您可测试刚刚下载到 Carrot Touch 的空调红外线代码。如要进行测试，请进入如上图所示
的空调部份，然后将 Carrot Touch 的上部(即红外线发射器的位置)指向空调，并选取所需的控制
功能。

12
LEARNING IR CODES
Main Icon for Infrared devices management.
增加设备
为新添的设备进行连接。
Press“+” on the right hand side and select the device type.
增加设备
为新添的设备进行连接。
Select Room.
选择房间。
学习IR代码
Carrot Touch 有一个内置的红外线发射器及学习器，可作为通用的红外线遥控器使用。在你使用它来代替
多个遥控器之前，你必需设定IR代码以控制你的红外线电器。最简单的方法之一是从 Carrot Cloud 下载
IR代码。
Carrot Touch has a built-in IR Emitter and Learner, so you can use it as a Universal IR Remote.
Before you can use it to replace your multiple remote controllers, you must give it the IR codes used
to control your IR-aware appliances. One of the easiest ways is to download the IR codes from the
Carrot Cloud.

13
LEARNING IR CODES
Press“+” on the right hand side and select the device type.
增加设备
为新添的设备进行连接。
Select Room.
选择房间。
Select “Download from Server”.
选择「从服务器下载」。
学习IR代码
Carrot Touch 有一个内置的红外线发射器及学习器，可作为通用的红外线遥控器使用。在你使用它来代替
多个遥控器之前，你必需设定IR代码以控制你的红外线电器。最简单的方法之一是从 Carrot Cloud 下载
IR代码。
Carrot Touch has a built-in IR Emitter and Learner, so you can use it as a Universal IR Remote.
Before you can use it to replace your multiple remote controllers, you must give it the IR codes used
to control your IR-aware appliances. One of the easiest ways is to download the IR codes from the
Carrot Cloud.

14
Select the Brand and Model.
增加设备
为新添的设备进行连接。
You may add up to 6 self-dened keys at the bottom of
the panel.
增加设备
为新添的设备进行连接。
Test it immediately with your device.
选择房间
Carrot Touch 有一个内置的红外线发射器及学习器，可作为通用的红外线遥控器使用。在你使用它来代替
多个遥控器之前，你必需设定IR代码以控制你的红外线电器。最简单的方法之一是从 Carrot Cloud 下载
IR代码。
Carrot Touch has a built-in IR Emitter and Learner, so you can use it as a Universal IR Remote.
Before you can use it to replace your multiple remote controllers, you must give it the IR codes used
to control your IR-aware appliances. One of the easiest ways is to download the IR codes from the
Carrot Cloud.

15
You may add up to 6 self-dened keys at the bottom of
the panel.
增加设备
为新添的设备进行连接。
Test it immediately with your device.
选择房间
Main Icon for controlling your infrared devices..
选择房间
Carrot Touch 有一个内置的红外线发射器及学习器，可作为通用的红外线遥控器使用。在你使用它来代替
多个遥控器之前，你必需设定IR代码以控制你的红外线电器。最简单的方法之一是从 Carrot Cloud 下载
IR代码。
Carrot Touch has a built-in IR Emitter and Learner, so you can use it as a Universal IR Remote.
Before you can use it to replace your multiple remote controllers, you must give it the IR codes used
to control your IR-aware appliances. One of the easiest ways is to download the IR codes from the
Carrot Cloud.

16
IRREPEATER
红外线信号转发器
Figure 图1 (Rear view 产品背部) Figure 图2 (Bottom view 产品底部)
(IR view angle 红外线发射角)
Device must be powered by ocial adapter only. It may be damaged by incorrect adapter.
须使用原装供电适配器，错误使用适配器有机会损坏产品。
User Button
用戶按鈕
Input Power connector
电源输入接口
IR extender socket
红外线信号扩展插口
120◦
90◦
120◦
180◦
TECHNICAL INFORMATION 技术规格
Catalogue Number 目录编号 LA3-RPT1
Operating Frequency 工作频率 433.05 MHz–434.79 MHz
Output RF Power 输出射频功率 <10mW
Infrared Line-of-Sight Coverage 红外线直线覆盖 10 meters
Operating Temperature Range 工作温度范围 00–400C
Operating Humidity Range 工作湿度范围 0–95% RH non-condensing
External IR emitter 外接红外线发射线 Yes (optional accessory: Model no. ITX-002)
C-Wave® Network Repeating feature C-Wave® 网络转发功能 Yes
Compliance 合规 IEC 60950-1

17
POSITIONING 安放位置IRREPEATER
红外线信号转发器
Figure 图2 (Bottom view 产品底部)
(IR view angle 红外线发射角)
Device must be powered by ocial adapter only. It may be damaged by incorrect adapter.
须使用原装供电适配器，错误使用适配器有机会损坏产品。
User Button
用戶按鈕
TECHNICAL INFORMATION 技术规格
Catalogue Number 目录编号 LA3-RPT1
Operating Frequency 工作频率 433.05 MHz–434.79 MHz
Output RF Power 输出射频功率 <10mW
Infrared Line-of-Sight Coverage 红外线直线覆盖 10 meters
Operating Temperature Range 工作温度范围 00–400C
Operating Humidity Range 工作湿度范围 0–95% RH non-condensing
External IR emitter 外接红外线发射线 Yes (optional accessory: Model no. ITX-002)
C-Wave® Network Repeating feature C-Wave® 网络转发功能 Yes
Compliance 合规 IEC 60950-1

18
PAIRING 配对
PAIRING UP IR REPEATER
配对红外线信号转发器
Step 1
Power up the IR repeater. When connected,
you can see the LED ashes slowly on top
of the device.
第一步
给红外线信号转发器通电，当连接到电源就可
以看到设备顶端的指示灯缓慢闪烁。
Step 2
To pair up IR Repeater, go to Settings and
select Add RF Device icon as shown above.
第二步
要配对红外线信号转发器，转至设置，然后选择
添加射频设备图标，如上图所示。
You can use a paired IR Repeater to emit the IR when the appliance under control is in another room.
But you must rst follow the procedure below to pair the IR repeater to the Carrot Touch and to get
the IR codes into the Carrot Touch rst (either by direct learning or downloading from the Carrot
Cloud). Finally, please follow the later section in “Linking your Appliances”to download the IR codes
from Carrot Touch to the IR repeater.
Step 3
Select a room for the IR repeater. If you can’t
nd a name for your location you can add a
new room as shown above.
第一步
为红外线信号转发器选择房间。如果不能找到
您需要的位置名称，您可以添加一个新的房间，
如上图所示。
Step 4
Press and hold the recessed User Button
for 3 seconds until LED start ashing
rapidly.
第四步
紧按着用户按钮3秒，直到指示灯开始快速闪动。
当你需要控制的电器位于另一间房间的时候，你可以使用一个相配的红外线信号转发器(IR Repeater)以发
射红外线。但是你首先必须遵循以下的步骤，把红外线信号转发器与 Carrot Touch 配对，并把红外线代码
输入Carrot Touch 内(可通过直接取得或从家乐屋云端下载)。最后，请按照「连结你的电器」的后半部份，
从Carrot Touch 下载红外线代码到该红外线信号转发器。
