CARVIN CM68 User manual

ARCHITECT’S SPECIFICATIONS
The microphone shall be a moving coil (dynamic) type with a frequency response
of 45 to 15,000 Hz. The unit shall have a cardioid polar characteristic. The
cancellation at the sides shall be approximately 5 dB and the cancellation at the
rear shall be 15 to 20 dB. The microphone shall have a rating impedance of 300 ohms
designed for 600 ohmspreamps
The microphone connector shall be a 3-pin professional audio type designed to
mate with a XLR male connector. The microphone shall be provided with a swivel
adapter adjustable through 90° from vertical to horizontal. The adapter will mount
on a stand having a 5/8”-27 thread. The overall dimensions of the microphone
shall be 5.125” (130 mm) in length and 2.080” (53 mm) in diameter.
GUARANTEE
This Carvin product is guaranteed to be free from electrical and mechanical defects
for a period of one year from date of purchase. Microphones dropped, misused or
exposed to moisture are not covered under warranty. Please retain proof of purchase
date. This guarantee includes parts and labor.
This guarantee is in lieu of any and all other guarantees or warranties, express or
implied, and there shall be no recovery for any consequential or incidental
damages.
SHIPPING INSTRUCTIONS
Carefully repack the unit, have it insured, and return it prepaid to:
Carvin
Service Department
12340 World Trade Drive
San Diego, CA 92128
-40
-50
-60
dBV/Pa
-70
-80
-90 20 50 200 500 2k 5k 20
k
CM68 FREQUENCY RESPONSE
CARVIN ENGINEERING DATA MODEL CM68 UNIDIRECTIONAL DYNAMIC MICROPHONE INSTRUCTIONS
MODEL CM68
The Carvin CM68 is a rugged unidirectional microphone with a highly effective
built-in wind and “pop” filter.
The CM68 is Carvin’s finest hand held microphone designed for the vocalist
requiring a tight, natural sound with crisp highs and strong bass without
boominess. We recommend this microphone to performers who work close to their
mics, where high volumes can be obtained without distortion or explosive breath
“pop’s”. An excellent choice for club use, rock singers, or any vocalist requiring
the best in vocal reproductions. Designed for high end studio recording and
broadcast applications.
Microphone Features:
■ Bright, clean sound.
■ Spherical filter to control explosive breath sounds (“pop”) and wind noise in
outdoor locations.
■ Wind and “pop” filter readily removable for cleaning or replacement.
■ Effective cardioid pickup pattern to minimize background noise and undesirable
effects of studio and location acoustics. Rear and side rejection uniform to very low
frequencies and completely symmetrical about microphone axis.
■ Versatility - designed for both stage and studio use.
■ Cartridge shock-mounted for protection.
■ Includes professional 20’ XLR cable.
Polar Pattern
Cardioid — rotationally symmetrical about microphone axis, uniform with
frequency (see Figure 2)
76-CM68 0502 12340 World Trade Drive, San Diego, CA 92128
800.854.2235 carvin.com
c
UNIDIRECTIONAL
DYNAMIC
MICROPHONE
0
30
60
90
120
150
180
210
240
270
300
330
TYPICAL POLAR PATTERNS
FIGURE 2
INTERNAL CONNECTIONS
MODEL CM68 UNIDIRECTIONAL DYNAMIC MICROPHONE SPECS:
Type: Dynamic
Frequency Response: 45 to 15,000HZ
Output Level (at 1,000 Hz, 300 ohms): Open Circuit Voltage* -74 dB, (0.19 mV)
Cable: CM68: 6.0m (20 ft) three-conductor shielded broadcast type with XLR
professional audio connector*
Case: Dark grey enamel die casting and dark grey enamel steel mesh grille
Swivel Adapter: Slip-in positive-action, adjustable from 0° to 90°, with standard
5/8“-27 thread
Net Weight: (less cable) 8.5 oz.
